30 JAN 15
CHART CHANGE NOTICES
USL-1
NORTHWEST US
q$i
Jeppesen CHART CHANGE NOTICES highlight only significant changes affecting
Jeppesen Charts, also regularly updated at www.jeppesen.com.
IMPORTANT: CHECK FOR NOTAMS AND OTHER PERTINENT
INFORMATION PRIOR TO FLIGHT.
ENROUTE CHARTS
GENERAL
NEW YORK (ARINC) CAR-B freq 21985 established.
United States National Reference System (NRS)
Waypoints: Waypoints revoked along the
US/Canadian border as follows:
KP21I
KP24A
KP24C
KP24E
KP24G
KP24Y
KS21C
KS24G
KS24I
KS24K
KU24M
KU24O
KU24Q
KU24S
KU24U
KU24W.
UNITED STATES
NAVAIDS
BRIGHAM CITY NDB (BMC) decmsnd. LO-8/2D.
PASCO VOR (PSC) freq chgd to 109.8. LO-7/6D.
Timber, Mont (BKU) mag var chgd from 8°E to 9°E.
Subtract 1° from all formation bearings. LO-7/10D.
AIRPORTS
Hill AFB Ogden, Utah (KHIF) Class D Time of
Operation 0800-0000 LT Mon-Sat, 0900-1700 LT
Sat-Sun. LO-8/2D.
MOUNTAIN HOME, Idaho, Mountain Home AFG
control tower hours of operation 0700-2400 LT
Mon-Thur, 0700-1800 LT Fri, Clsd on Sat-Sun and
holidays, O/T Class E. LO-8/1B.
Walla Walla, WA (KALW) tower hours chgd to 06001830 LT. LO-7/6D.
AIRWAYS
T302 established CUKIS - JJACE NCRP (N45
09.9 W122 03.0) 114°/294°, 17NM, MEA 7000,
MAA 17500; JJACE - JJETT (N44 56.6 W121
40.9) 114°/295°, 21NM, MEA 8000, MAA 17500.
KPDX 10-1.
V2-V298 Seattle, Wash VOR (SEA) - VAMPS MEA
8400’ E-bnd 4000’ W-bnd; VAMPS - BANDR
8400’ E-bnd 7700’ W-bnd; BANDR - BEEZR
8400’. KSEA 10-1.
V21 HOLOX NCRP established (N48 54.5 W112
26.8) Cut Bank, Mont VOR (CTB) R-332/21 DME.
Mileages:
’CTB’ - HOLOX 21 NM
HOLOX - [CDLYC] 5 NM. LO-7/8A.
V21 PERRE, UT withdrawn. Ogden, UT VOR (OGD)
- CORIN 21 NM. LO-8/2D.
V27 ZOLGI NCRP established (N47 16.4 W122
56.3) Seattle, Wash VOR (SEA) R-230/27 DME.
Mileages
CARRO - ZOLGI 3 NM
ZOLGI - WONKU 9 NM. KSEA.
V32-200 OPNUZ, UT withdrawn. Bonneville, UT VOR
(BVL) - BAGGI 10 NM. LO-8/2C.
V32-200 ZONSU, Utah established. Bonneville, Utah
VOR (BVL) R-067/8 DME. Mileages:
’BVL’ - ZOSNU 8 NM
ZOSNU - BAGGI 2 NM. LO-8/2C.
V121 Baker City, Oreg VOR (BKE) - GOYEK 20
NM, GOYEK - Donnelly, Ida VOR (DNJ) 49 NM.
LO-7/6D, LO-8/1A,B.
V142 Malad City, ID VOR (MLD) to ORNEY, MEA
10400’. ORNEY to Fort Bridger VOR (FBR), Wyo,
MEA 12200’. LO-8/2D-3C.
V165-287 JUVGA NCRP established (N47 24.7
W122 50.5) Olympia, Wash VOR (OLM) R-346/27
DME. Mileages:
CARRO - JUVGA 8 NM
JUVGA - ARPEE 25 NM. KSEA.
V187 FACTS withdrawn. Mc Chord, Wash VOR
(TCM) - COTNY 8NM. KSEA 10-1.
V187 NUPUQ renamed TUCKB. LO-7/8C.
V187 WUSVI NCRP established (N47 02.9 W120
58.1).
THICK - WUSVI - RADDY 6/22 NM. KSEA.
V204 AYAKI CNF renamed CFFMJ. LO-7/6B.
V247 ONECI RNAV NCRP established (N44 12.3
W106 30.1). Crazy Woman, Wyo VOR (CZI)
R-334/13 DME. Mileages:
’CZI’ - ONECI 13 NM
ONECI - FOURS 17 NM. LO-8/4B.
V330 NEEDS NCRP established (N43 31.9 W190
35.4) Dunoir, Wyo (DNW) R103/37 DME.
Mileages:
’DNW - NEEDS 37 NM
NEEDS - ROWEY 26 NM. LO-8/3B.
V343 JOXIT RNAV NCRP established (N45 26.7
W111 22.3). Mileages:
QUERY - JOXIT 17 NM
JOXIT - RANEY 4 NM. LO-7/8D.
V357 TOLGA, OR NCRP - Walla Walla (ALW) VOR
MEA 6700’. LO-7/6D.
V365 WELUR NCRP established (N48 24.0 W112
18.6) Cut Bank, Mont VOR (CTB) R-155/10 DME.
Mileages:
’CTB’ - WELUR 10 NM
WELUR - PENRY 19 NM. LO-7/8A.
V430 HEKIT NCRP established (N48 33.9 W112
05.5) Cut Bank, Mont VOR (CTB) R-073/10 DME,
AGRYN NCRP established (N48 33.9 W111 51.4)
Cut Bank, Mont VOR (CTB) R-073/19 DME.
Mileages:
’CTB’ - HEKIT 10 NM
HEKIT - AGRYN 9 NM
AGRYN - WEBVO 16 NM. LO-7/8A.
V484 Hailey, Idaho NDB (HLE) - KINZE NCRP 190°/
010° 16 NM. LO-8/2A.
q$z
Please Visit Jeppesen’s Web Site: www.jeppesen.com
© JEPPESEN, 2015. ALL RIGHTS RESERVED.
USL-2
CHART CHANGE NOTICES
30 JAN 15
NORTHWEST US
AIRSPACE
IDAHO FALLS MOA established. An octagon shaped
airspace west of V257. There is a 2 mile wide
corridor with no altitude restriction exists in the
northern portion of the boundary extending from
the intersection of ID 33 and ID 22 near the point
at N43 48.3 W112 34.5 due east 12 miles to a point
approximately 1 mile south of a circular butte at at
N43 47 40 W112 34.5. Altitudes: Surface to 6000’
MSL. LO-8/2B.
RESTRICTED AREA R-6703 A-D redesignated A-J.
Lateral limits unchanged. Vertical limits:
R-6703 A/B/C/D/E/ GND - 14000’; R-6703
F/G/H/I/J GND - 5000’. KSEA 10-1.
Salt Lake City, UT Class B airspace revised. NE
corner revised of the rectangled shaped sector
approx 5 to 8 NM North of Wasatch (TCH) VOR
with the vertical limits of 6000’ - 12000’ MSL.
LO-8/2D.
V4 HUMPP - BLAKO, Wash MEA E Bnd 10000’ W
Bnd 6600’. BLAKO - Seattle, Wash VOR (SEA)
MEA E Bnd 10000’ W Bnd 4000’. KSEA 10-1.
OFF-AIRWAY INTERSECTIONS & HOLDING
PATTERNS
BANDR Int HOLDING withdrawn. KSEA.
BERNT, Wyo RNAV NCRP established at N42 54.8
W109 36.8. LO-8/3D.
BROPH, Idaho RNAV NCRP established N42 43.3
W114 52.5. LO-8/2C.
BSSMA, Idaho RNAV NCRP established N43 03.3
W115 01.3. LO-8/2C.
BUEEL, Ore RNAV NCRP established N43 52.7
W117 35.8. LO-8/1A.
BUHNR, Wash RNAV NCRP established N48 10.3
W122 53.5. KSEA 10-1.
COLLR, Ida RNAV NCRP established N44 22.9
W116 18.8. LO-8/1B.
CUDDY, Idaho RNAV NCRP established N44 29.9
W116 33.3. LO-8/1B.
DEETZ, Idaho NCRP RNAV established at N 44 12.6
W 116 04.7. LO-8/1B.
DEVLE, Oreg RNAV NCRP established N44 12.7
W117 14.9. LO-8/1A.
DRSIE, Nev RNAV NCRP established N41 03.5
W115 49.1. LO-8/1D.
ENNUM NCRP RNAV established at N 47 02.2 W 122
02.9. KSEA 10-1.
FUZII, OR RNAV NCRP established at N42 50.8
W117 11.7. LO-8/1A.
HAILEY, IDAHO NDB (HLE) established. Hold SE,
335 inbound, LEFT turns. LO-8/2A.
HAWKZ, Wash RNAV NCRP established at N46 48.9
W122 42.2. KSEA 10-1.
HYVAL, Idaho NCRP RNAV established at N 43 08.2
W 116 55.8. LO-8/1B.
LEEYO, NV RNAV NCRP established at N41 13.0
W117 19.3.
LO-8/1C.
LEIDY, WYO RNAV NCRP established at N43 41.0
W110 17.0. LO-8/3A.
LICKS, Idaho RNAV NCRP established N44 06.7
W116 42.6. LO-8/1B.
LYONS, Idaho RNAV NCRP established at N 42 46.6
W 114 42.2. LO-8/2C.
MARYJ, S Dak NCRP established at N43 08.6 W103
30.7. LO-8/5C.
q$i
MENIN HOLDING established. Hold SE, 293
inbound, LEFT turns. LO-8/2A.
MEVLE, Idaho RNAV NCRP established N42 55.6
W114 38.6. LO-8/2C.
NATZZ, Idaho RNAV NCRP established N43 34.3
W115 18.0 LO-8/2A.
NEERO, Nev RNAV NCRP established N41 49.1
W118 01.5. LO-8/1C.
ODYSY, Idaho RNAV NCRP established N44 22.4
W116 03.5. LO-8/1B.
ORYDA, Idaho RNAV NCRP established N42 54.9
W115 09.3. LO-8/2C.
PREIS, Idaho NCRP RNAV established. LO-8/1B.
PRESN HOLDING established. Hold S, 007°
inbound, RIGHT turns. LO-8/2A.
PRNCS, Ore RNAV NCRP established N42 26.6
W117 48.9. LO-8/1C.
ROARR, Idaho RNAV NCRP established N43 15.9
W115 23.2. LO-8/2A.
RVDCT withdrawn. KSEA 10-1.
SAILL, Ore RNAV NCRP established N43 43.4 W117
06.2. LO-8/1A/B.
STILY HOLDING established. Hold W, 103° inbound
LEFT turns. KSEA.
STILY NCRP established at N48 10.0 W122 14.1.
KSEA.
TNKUS, NV RNAV NCRP established at N41 47.6
W114 52.6. LO-8/1C.
SALT LAKE CITY FIR
AIRPORTS
Hill AFB Ogden, Utah (KHIF) Class D Time of
Operation 0800-0000 LT Mon-Sat, 0900-1700 LT
Sat-Sun. LO-8/2D.
SEATTLE FIR
AIRPORTS
Walla Walla, WA (KALW) tower hours chgd to 06001830 LT. LO-7/6D.
TERMINAL CHARTS
TERMINAL
IDAHO
Idaho Falls, (Idaho Falls Regl), (12-2) RNAV (GPS)
Y RWY 20 Change AMEND1B
Mc Call, (10-9) Note removed: Rwy 16: Trees
obscuing threshold on short final.
Pocatello, (Pocatello Regl), ILS or LOC Rwy 21 Amdt
Number changed to 26D.
VOR DME Rwy 21 Amdt number changed to 10C.
MONTANA
Billings, (Billings Logan Intl), (10-9A) OBSTACLE
DEPARTURE PROCEDURE...AMEND 7
q$z
Please Visit Jeppesen’s Web Site: www.jeppesen.com
© JEPPESEN, 2015. ALL RIGHTS RESERVED.
30 JAN 15
CHART CHANGE NOTICES
USL-3
NORTHWEST US
(13-1) VOR DME Rwy 28R Amend 14 chgd to 14A,
Reference date 5 APR 2012 chgd to 31 MAY 2012.
Butte, (Mooney), RNAV (GPS) Z RWY 15 AMDT
NUMBER IS 1B.
Circle, (Circle Town Co), Rwy 12 PAPI-L (angle 3.0°)
added.
Deer Lodge, (Deer Lodge-City-Co), (Apt) Rwy 13
PAPI-L angle chgd to 3.22°. Rwy 31 PAPI-L angle
chgd to 2.72°.
Forsyth, (Tillitt), (10-9) Airport, Airport Info, Take-off
MNMS; add AMEND ORIG
Livingston, (Mission), Rwy 22 VASI-L, angle 3.00
degrees.
Roundup, (10-9; 12-1; 12-2) Unicom frequency
changed to 122.8.
OREGON
Corvallis, (Corvallis Mun), NDB Rwy17 (16-1)...
Delete D47.3 PDX at TURNO. Amdt 2A...17 OCT
2013.
Klamath Falls, (10-3) KINGSLEY 5 DEP computer
code LMT5.LMT removed.
La Grande, (La Grande/Union Co), Rwy 12 PAPI-L
(angle 3.0 degrees); Rwy 30 PAPI-L (angle 3.0
degrees).
Ontario, (Ontario Mun), RNAV (GPS) Rwy 14
(12-1)...Straight-in and circling minimums NA
at night. "Visibility reduction by helicopter NA"
changed to "Helicopter visibility reduction below 1
SM not authorized"...Amdt 0A. 17 OCT 2013.
RNAV (GPS) Rwy 32 (12-2)...Circling to Rwy 14 NA
at night. "Visibility reduction by helicopter NA"
changed to "Helicopter visibility reduction below
3/4 SM not authorized". Amdt 0A 17 OCT 2013
Portland, (Portland-Hillsboro), (23-1) VOR DME-C
AMEND O changed to AMEND OA. PARD 13 NOV
14
Portland, (Portland-Troutdale), (40-3) BLUE LAKE 3
DEP computer code BLUE3.BTG removed.
Redmond, (Roberts), (11-1 ILS or LOC DME Rwy
22, 12-20 RNAV (RNP) Z Rwy 4, 12-21 RNAV
(RNP) Z Rwy 22, 12-3 RNAV (GPS) Y Rwy 22,
13-1 VOR DME Rwy 22, 13-2 VOR-A) Obstacle
3801’ at Rwy 22 end should be 3081’.
Scappoose, (Scappoose Industrial), VOR DME-A,
AMEND 3A. Chart note: Circling to Rwy 15 not
authorized at night. Helicopter visibility reduction
note changed to: Helicopter visibility reduction
below 1 SM not authorized.
q$i
Rwy 30 PAPI-R chgd to PAPI-L.
Olympia, (Olympia Regl), (10-3) YELM 2 DEP
computer code YELM2.YELM removed.
Renton, (Renton Mun), (10-3) BELLEVUE 2 DEP
computer code BELVU2.BELVU removed.
(10-3A) RENTN 2 DEP computer code RENTN2.
RENTN removed.
Seattle, (Boeing Field/King Co Intl), (10-9) Airport
Mag Var 20 degrees.
Seattle, (Seattle-Tacoma Intl), (20-2A) EPHRATA SIX
ARRIVAL- Flaak holding pattern leg length 10 NM.
(20-3F) SEATTLE 4 DEP computer code SEATL4.
SEATL removed.
(20-9) - Taxiway F has a hold line it is not a
non-controllable stop bar.
20-9, 20-9E, 20-9F Taxiway F at hot spot number 3 is
a hold line.
Spokane, (Spokane Intl), (12-2, 12-21) Rwy 7 chart
note: VGSI and RNAV glidepath not coincident.
Tacoma, (Tacoma Narrows), (10-3) Narrows 1 Dep
computer code (NAROS1.NAROS) added.
Whidbey I NAS, (Oak Harbor), (32-1) RNAV (GPS)
Rwy 14 lighting changed to ALSF-2.
Yakima, (Yakima/Mcallister), (10-9) Rwy 22 PAPI-L
(angle 3.0°).
WYOMING
Casper, (Casper-Natrona Co Intl), Airport name
changed to Casper/Natrona Co Intl.
Ft Bridger, 12-1 Apt RWY 04/22 PLOWED WINTER
MONTHS; RWY 07/25 CLSD WINTER MONTHS
EXCEPT FOR SKI EQUIP ACFT; DIRT/TURF
RWYS NOT MAINTAINED; RWY 06/24 IS NOW
RWY 07/25.
Rawlins, (Rawlins Mun), OBSTACLE DEPARTURE
PROCEDURE CHANGE TO READ: RWY 4,
TURN RIGHT, THENCE... RWY 22,
TURN LEFT, THENCE... ...CLIMB TO 10000 ON
RWL R-200 AND CKW R-080 TO
CKW VOR/DME THEN ON ASSIGNED ROUTE.
AIRCRAFT DEPARTING
EASTBOUND V4 OR V6 CLIMB ON RWL R-200
TO ASSIGNED ROUTE THEN
CLIMB ON COURSE. Amend # 3A.
Sheridan, (Sheridan Co), (10-9A) RWY 5 PAPI-L
angle chgd to 4.0°.
WASHINGTON
Ellensburg, (Bowers), (10-9) Airport Amendment
number 2A.
Ephrata, (Ephrata Mun), Rwy 3/21 PAPI-R chgd to
PAPI-L.
Everett, (Snohomish Co), (10-9) Apt, Seattle Center
call sign changed to Seattle Departure, (11-1) ILS
or LOC DME Z Rwy 16R, (11-1A) ILS Z Rwy 16R
SA CAT II, (11-2) ILS or LOC DME Y Rwy 16R
, (12-1) RNAV (GPS) Z Rwy 16R, (12-2) RNAV
(GPS) Y Rwy 16R, (12-3) RNAV (GPS) Rwy 34L,
(13-1) VOR DME Rwy 16R, (13-2) VOR Rwy
16R Seattle Center call sign changed to Seattle
Approach.
Kelso, (Southwest Washington Regl), (12-1/APT)
Rwy 12 PAPI changed from left to right side.
q$z
Please Visit Jeppesen’s Web Site: www.jeppesen.com
© JEPPESEN, 2015. ALL RIGHTS RESERVED.
USL-4
CHART CHANGE NOTICES
30 JAN 15
NORTHWEST US
q$i
INTENTIONALLY LEFT BLANK
q$z
Please Visit Jeppesen’s Web Site: www.jeppesen.com
© JEPPESEN, 2015. ALL RIGHTS RESERVED.
