Sr Particulars Qty 1 11 kv H.T 3CX95 Sqmm XLPE cable 25

Sr
Particulars
1 11 kv H.T 3CX95 Sqmm XLPE cable
2 11 kv H.T cable joint (Indoor Type)
3
4
6
7
8
9
Transformer 11kv/433V, 1000kva outdoor ( Transformer
already avaiaible. Only erection rate to be quoted )
type with O.L.T.C &complete accessories(supplied by
company)
LT Panel with 2000Amp ACB includes Aluminum
Busbar with all fault relay & tripping mechanism,
metering size of pannel 2670x2500x1300, relays to be
provied as per existing panel
L.T Distribution Panel (shop)
Incomer -1600Amp (A.C.B)-1 nos (E.D.O)
Foroutgoing
1) 400Amp (M.C.C.B)- 1 Nos
2) 200Amp (M.C.C.B)- 3 Nos
3) 630Amp (M.C.C.B)- 1 Nos
4) 315Amp (M.C.C.B)- 1 Nos
5) 125Amp (M.C.C.B)- 2 Nos
6) 63Amp (M.C.C.B)- 3 Nos. With metring to incoming
& all outgoing switchgear&ACB with tripping mechanism
Trench
1) trench preparing by removing pavor block
0.7 Mtr deep,600mm width Refilling by reti
& sand refixing of pavor block
2)trench preparing by removing concreting road
0.7 Mtr deep,600mm width Refilling by reti
& sand refixing of concreting road
3) R.C.C Pipe 300mm die
Earthing
Earthing by pit digging with 600x600x6mm
G.I Plate ,salt,coal.G.I. Pipe,C.I Chamber
cover .complete with all respect
Earthing material G.I. Strip
G.I. Strip 50x3
Qty
25 Mtr
2 Nos
1 Nos
1 Nos
01 Nos
30 Mtr
70 Mtr
30 Mtr
30 Nos
50 M
10
11
12
13
14
15
16
17
18
19
20
21
22
G.I. Strip 25x3
150 m
8Guage G.I wire
75 Mtr
12 Guage Copper wire
75 Mtr
Foundation for transformer 2mtr x 1.5 mtr x
1 Nos
1.4 mtr (height) including 6 inches p.c.c on top
L.T Cable
L.T Cable -3.5cx 400 mm2 alluminum
570 M
1) 3.5c x185sqmm AL armad cable
150 M
2)3.5c x120sqmm AL armad cable
150 M
3)3.5c x70sqmm AL armad cable
40 Mtr
4)4c x16sqmm AL armad cable
80 Mtr
5)4c x06sqmm AL armad cable
170 M
5)4c x04sqmm AL armad cable
100 M
6)4c x2.5sqmmCopper cable
70 Mtr
Termination
3.5cx400mm2 cable termination
16 Nos
1) 3.5c x185sqmm Tremination
08 Nos
2)3.5c x120sqmmTremination
06 Nos
3)3.5c x70sqmm Tremination
04 Nos
4)4c x16sqmm Tremination
04 Nos
5)4c x06sqmm Tremination
16 Nos
5)4c x04sqmm Tremination
08 Nos
6)4c x2.5sqmmTremination
18 Nos
T.P.N (M.C.B) 8 Way Distribution box 63 amp
1 Nos
T.P.N (M.C.B) 8 Way Distribution box 16 amp
3 Nos
A.P.F.C Panel with 315 kvar capacity with 12 stage
1 Nos
relay&capacitor of different capacitywith Harmonic supressor
Switchgear
1)125 amp switch fuse unit with encloser
4 Nos
2 63Amp T.P.N M.C.B in ms box
2 Nos
3) 16Amp T.P M.C.B in ms box
09 Nos
4)100Amp T.P.N M.C.B in ms box
02 Nos
light point for light /fan/bell 20mm Hms pvc conduit with 112 Nos
point wiring as above for plug pts on switch board as above10 Nos
same as above for independent plug on seprate board
10 Nos
light point for light /fan/bell 20mm Hms pvc conduit with 124 Nos
point wiring as above for plug pts on switch board as above16 Nos
same as above for independent plug on seprate board
08 Nos
Supply of 8 Mtr swaged Pole for street light duly painted 10 Nos
street light pole bracket 1.2 mtr long suitable for pole moun10 Nos
street light pole FRP pole box of size 200x150x100
10 Nos
concreting of street light pole
10 Nos
G.I Pipe for cable encloser of proper size
20 Nos
(height 1.5 mtr)
23 trench for street light cable 0.7 mtr deep ,refilling with sand120 Mtr
Supply,assembly,testing of 250W philips make metal
24 halide fittings including lamp& control gear in the main
UR
plant shed
Supply ,asswmbly,testing of 73W LED fittings including
25
12 NOS
lamp & control gear for main plant shed
Supply ,asswmbly,testing of 250W Metal hilid fittings
26
UR
including lamp & control gear for main plant shed
Supply,assembly,testing of 28W Tube light fittings with
27
24 Nos
electronic choke &complete tube etc.
Supply ,asswmbly,testing of 250W mercury vapour
28 fittings including lamp & control gear for outdoor yard
UR
lighting on poles
Supply ,asswmbly,testing of 73W LED fittings including
29
10 NOS
lamp & control gear for outdoor yard lighting on poles
Supply ,asswmbly,testing of 250W Metal hilid fittings
30 including lamp & control gear for outdoor yard lighting
UR
on poles
15 watt solar light 15 feet pole (GI),60wp PV 40 AH
31 battery12 V lead acid tubular battery 12hrs backup,Dsut
UR
to dawn operation
Supply ,assembly ,testing of fans 1200mm sweep
33
10 Nos
complete with regulator& accessaries etc.
34 With Electrical Inspector for getting drawing
1 Job
approved & Installation approved and
charging permission
Materials
Total Rs.
Above all rates are inclusive all taxes
