HEAT PUMP
Nº publicación RO130078A2 27/02/2015
TABACARU DORINEL¿[RO]
Solicitantes
The invention relates to a heat pump meant to heat dwellings, office spaces and any other space. According to the invention, the
Resumen
pump consists of a compressor () wherefrom a pipe circuit (), called condenser, gets out, continued with a filter (), an expansion
valve (), with a narrowed pipe circuit (), called vaporizer, which meets the pipe circuit () in a portion (), gets into the same and it
is continued inside the pipe circuit (), on a portion (), after which it gets out of the pipe circuit () through a portion () and it is
continued until getting into the compressor ().
Method for the preparation of U-shaped geothermal energy probes
Nº publicación EP2840333A1 25/02/2015
MKM MANSFELDER KUPFER UND MESSING GMBH¿[DE]
Solicitantes
Die Erfindung bezieht sich auf ein Verfahren zur Herstellung von U-förmigen Erdwärmesonden, die direkt als Verdampfer an
Resumen
eine Wärmepumpe anschliessbar sind. Ausgehend von den Nachteilen des bekannten Standes der Technik soll ein Verfahren
geschaffen werden, das zu erheblichen Einsparungen an Material und Kosten sowie verbesserten anwendungstechnischen
Eigenschaften der Sonde führt. Hierzu wird als Lösung folgende Verfahrensweise vorgeschlagen. Ausgehend von zwei auf einer
Trommel 1 aufgewickelten kunststoffummantelten Kupferrohren 2, 3 werden deren Enden abisoliert. Entweder auf ein Ende oder
auf jedes der Enden der Kupferrohre 2, 3 wird ein Schrumpfschlauchstück 4a, 4b aufgeschoben, derart, dass die abisolierten
Endabschnitte
2a,
3a
der
Kupferrohre
frei
bleiben.
Auf diese wird ein separat hergestelltes U-förmiges Rohrstück 5 aus Kupfer geschoben, fixiert und druckdicht befestigt. Die
Schrumpfschlauchstücke 4a, 4b werden anschliessend soweit zurückgeschoben, dass das U-förmige Rohrstück 5, die vorhandene
PE-Ummantelung und die Verbindungsstellen 7 zwischen dem U-förmige Rohrstück 5 und den Enden der Kupferrohre 2, 3
vollständig überdeckt sind. Anschliessend werden die aufgezogenen Schrumpfschlauchstücke erwärmt und aufgeschrumpft.
Danach wird auf den U-förmigen Rohrsondenabschnitt eine vorgefertigte Kunststoffkappe 7 bis zur Überdeckung der
Verbindungsstellen 6 aufgeschoben und durch Erwärmung aufgeschrumpft. Der Innenraum der Kunststoffkappe 7 wird mit einer
Vergussmasse 8 ausgegossen. Nach erfolgter Aushärtung wird das restliche Ende der Kupferrohre der fertigen Erdwärmesonde
wieder auf die Trommel aufgewickelt.
CN104374119A
Nº publicación CN104374119A 25/02/2015
CN204174607U
Nº publicación CN204174607U 25/02/2015
CN104374121A
Nº publicación CN104374121A 25/02/2015
COMBINED POWER AND HEATING STATION
Nº publicación EP2839221A1 25/02/2015
VIKING HEAT ENGINES AS¿[NO]
Solicitantes
A combined heat and power plant (1) is described, in which at least
Resumen
one primary heat source (11) is thermally connected to a heat
distribution network (15) for heat energy (Q) via one or more primary
heat exchangers (111), and in which at least one secondary heat source
(12) is thermally connected to one or more energy converters (13)
arranged to, when an amount of heat energy (QH) is supplied from the
at least one secondary heat source, generate an amount of electrical
energy (PEL) for an internal electricity distribution network (19) in
the combined heat and power plant (1). A method of operating a
combined heat and power plant (1) is described as well.
Alertas Tecnológicas
- 1 de 7 -
ENERGÍA GEOTÉRMICA
Departamento de Patentes e Información Tecnológica
Unidad de Información Tecnológica
¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿
Nº publicación JP2015034664A 19/02/2015
(¿¿)¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿¿)¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿
Resumen
,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿,¿¿¿¿¿¿
¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿)¿2
CN204163939U
Nº publicación CN204163939U 18/02/2015
DISTRICT ENERGY SHARING SYSTEM
Nº publicación EP2837895A2 18/02/2015
DEC DESIGN MECHANICAL CONSULTANTS LTD¿[CA]
Solicitantes
A district energy sharing system (DESS) comprises a thermal energy
Resumen
circuit which circulates and stores thermal energy in water, at least
one client building thermally coupled to the circuit and which removes
some thermal energy from the circuit ("thermal sink") and/or deposits
some thermal energy into the circuit ("thermal source"), and at least
one thermal server plant that can be thermally coupled to external
thermal sources and/or sinks (e.g. a geothermal ground source) and
whose function is to maintain thermal balance within the DESS.
Alertas Tecnológicas
- 2 de 7 -
ENERGÍA GEOTÉRMICA
Departamento de Patentes e Información Tecnológica
Unidad de Información Tecnológica
Subsea heat exchanger
Nº publicación GB2517271A 18/02/2015
VETCO GRAY SCANDINAVIA AS¿[NO]
Solicitantes
A subsea heat exchanger comprising a bundle 1 of tubes having at
Resumen
least one tube winding 2 arranged to operate submerged in water and
effective for guiding a fluid F to be cooled by surrounding water in
contact with the tube. A plurality of nozzles 3 is distributed in spatial
relation to the perimeter O, wherein the nozzles are effective for
discharge of jets J of water impinging on the tubes. The nozzles are
oriented to induce in the ambient water volume a displacement R that
passes the perimeter O at a plurality of locations and directions. The
nozzles may be supported by riser pipes 4 extending from a manifold
5, the nozzle discharge is controllable through a variable speed motor
(VSD) motor 6, a seawater pump 7 and a pressure regulating device
11. The nozzles may be operable in consecutive order, and are ejectors
operating in accordance with Bernoullis principle.
CN204165280U
Nº publicación CN204165280U 18/02/2015
SYSTEME DE PRODUCTION D'ENERGIE ELECTRIQUE AU MOYEN DE DOUBLET GEOTHERMIQUE
Nº publicación FR3009613A1 13/02/2015
BRGM¿[FR]
Solicitantes
Système de production d'énergie électrique comprenant : - un géodoublet thermique comportant un premier géostock thermique et
Resumen
un second géostock thermique, les géostocks thermiques étant issus d'une technique de stockage thermique diffusif dans un
m a s s i f
r o c h e u x
des
échangeurs
thermiques
implantés
dans
chacun
des
deux
géostocks
thermiques
- un moyen permettant de faire circuler un fluide caloporteur, tel que du CO2, entre des échangeurs thermiques d'un géostock
t h e r m i q u e
à
u n
a u t r e
- un moyen de transformation de l'énergie thermique du fluide caloporteur en énergie électrique, tel qu'une turbine de type ORC.
Alertas Tecnológicas
- 3 de 7 -
ENERGÍA GEOTÉRMICA
Departamento de Patentes e Información Tecnológica
Unidad de Información Tecnológica
METHOD OF EXTRACTING ENERGY FROM A CAVITY CREATED BY MINING OPERATIONS
Nº publicación US2015033738A1 05/02/2015
UNIV MCGILL¿[CA]
Solicitantes
UNIV MCGILL¿[CA]
An energy-extracting mine ventilation system comprises: a ventilation
Resumen
unit for conditioning the intake air of a mine
a network of pipes installed in at least one cavity of the mine, the
network of pipes comprising a geothermal fluid circulating
therethrough wherein the network is in contact with a minefill material
within
the
cavity
and
a
rock
mass
wherein the minefill material transfers energy between the rock mass
of the at least one cavity and the thermal fluid
and a heat exchanger unit in fluid communication with the network of
pipes and extracting the energy from the thermal fluid The heat
exchanger unit is configured to transfer extracted energy directly or
indirectly to the ventilation unit in order to condition the intake air of
the mine, The extracted energy can be used in a variety of other
applications, such as district heating, acid leaching, and water heating.
LARGE CAPACITY GEOTHERMAL HEAT EXCHANGE WELL
Nº publicación WO2015016143A1 05/02/2015
NAKAGOMI HIDEKI¿[JP]
Solicitantes
[Problem] To provide a large capacity geothermal heat exchange well
Resumen
for which the capacity as a geothermal heat exchange well is increased
and that has a structure that does not require a deep well. [Solution] A
large capacity geothermal heat exchange well is characterized in that:
a porous sleeve pipe is placed in a vertical hole opened in the ground
with a fixed gap from the inner wall of a vertical hole
the gap region is made to be a permeable structure by way of filling
the gap between the pipe and the inner wall of the vertical hole with a
material, such as gravel, having good permeability
a heat exchange duct for allowing a heat exchange medium to flow is
inserted into the pipe and then is connected to an inlet and a discharge
port
of
equipment
to
be
used
the ground water in the pipe is heated and caused to flow up by way of
heat radiated by the heat exchange medium in the pipe by causing heat
exchange medium to circulate between the duct and the equipment to
b e
u s e d
in addition, a convective flow occurs around the pipe by new ground
water from the periphery flowing in the lower section of the pipe
and the radiated heat is widely dispersed to the surroundings by the
occurrence of such convective flows, thereby significantly increasing
the capacity as a geothermal heat exchange well.
Alertas Tecnológicas
- 4 de 7 -
ENERGÍA GEOTÉRMICA
Departamento de Patentes e Información Tecnológica
Unidad de Información Tecnológica
¿¿¿¿¿¿¿¿¿¿¿¿
Nº publicación JP2015025337A 05/02/2015
(¿¿)¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿¿)¿¿¿¿¿¿4¿¿,¿¿¿¿¿¿¿¿¿¿1¿¿7a¿,¿1¿¿¿a¿¿¿¿¿¿¿8¿¿¿¿¿¿¿¿3¿¿¿¿¿¿
Resumen
6¿¿¿¿¿¿¿¿¿1¿¿¿¿,¿¿¿3¿¿¿¿¿,¿¿8¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿12¿¿¿¿¿¿¿,¿¿¿¿6¿,¿¿¿¿12¿¿¿¿¿¿¿¿.(¿¿¿)¿1
¿¿¿¿¿¿¿¿¿
Nº publicación JP2015025612A 05/02/2015
(¿¿)¿¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿¿)¿¿¿¿¿1¿¿¿¿¿¿¿¿¿¿2,¿¿¿¿¿¿¿2¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿
Resumen
,¿¿¿¿¿1¿¿¿¿¿,¿¿¿¿¿¿¿1¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿)¿3
LARGE CAPACITY GEOTHERMAL HEAT EXCHANGE WELL
Nº publicación JP2015025643A 05/02/2015
[Problem] To provide a large capacity geothermal heat exchange well
Resumen
for which the capacity as a geothermal heat exchange well is increased
and that has a structure that does not require a deep well. [Solution] A
large capacity geothermal heat exchange well is characterized in that:
a porous sleeve pipe is placed in a vertical hole opened in the ground
with a fixed gap from the inner wall of a vertical hole
the gap region is made to be a permeable structure by way of filling
the gap between the pipe and the inner wall of the vertical hole with a
material, such as gravel, having good permeability
a heat exchange duct for allowing a heat exchange medium to flow is
inserted into the pipe and then is connected to an inlet and a discharge
port
of
equipment
to
be
used
the ground water in the pipe is heated and caused to flow up by way of
heat radiated by the heat exchange medium in the pipe by causing heat
exchange medium to circulate between the duct and the equipment to
b e
u s e d
in addition, a convective flow occurs around the pipe by new ground
water from the periphery flowing in the lower section of the pipe
and the radiated heat is widely dispersed to the surroundings by the
occurrence of such convective flows, thereby significantly increasing
the capacity as a geothermal heat exchange well.
Alertas Tecnológicas
- 5 de 7 -
ENERGÍA GEOTÉRMICA
Departamento de Patentes e Información Tecnológica
Unidad de Información Tecnológica
THERMAL CONNECTION OF A GEOTHERMAL SOURCE TO A DISTRICT HEATING NETWORK
Nº publicación WO2015014648A1 05/02/2015
SIEMENS AG¿[DE]
Solicitantes
The invention relates to a method and an arrangement for providing
Resumen
heat (Qout) for a district heating supply (40): Heat (Qin) at a first
temperature level (T41, T42) is provided by means of a thermal water
conveying system (20) from a geothermal source (41). By operating a
high-temperature heat pump (43) and thermally connecting same to
the geothermal source (41), the thermal water can be conducted
through the evaporator (431) of the high-temperature heat pump (43)
and the heat (Qin) thereof can be transferred to the evaporator (431) of
the high-temperature heat pump (43). The condenser (433) of the
high-temperature heat pump (43) then supplies heat (Qout) at a
second, higher temperature level (T43, T47) to the district heating
network (40). A high-temperature compression heat pump (43) is
preferably used as the high-temperature heat pump (43). The second,
higher temperature level (T43, T47) achieved in this manner is above
100 DEG C.
THERMAL CONNECTION OF A GEOTHERMAL SOURCE TO A DISTRICT HEATING NETWORK
Nº publicación DE102013214891A1 05/02/2015
SIEMENS AG¿[DE]
Solicitantes
The invention relates to a method and an arrangement for providing
Resumen
heat (Qout) for a district heating supply (40): Heat (Qin) at a first
temperature level (T41, T42) is provided by means of a thermal water
conveying system (20) from a geothermal source (41). By operating a
high-temperature heat pump (43) and thermally connecting same to
the geothermal source (41), the thermal water can be conducted
through the evaporator (431) of the high-temperature heat pump (43)
and the heat (Qin) thereof can be transferred to the evaporator (431) of
the high-temperature heat pump (43). The condenser (433) of the
high-temperature heat pump (43) then supplies heat (Qout) at a
second, higher temperature level (T43, T47) to the district heating
network (40). A high-temperature compression heat pump (43) is
preferably used as the high-temperature heat pump (43). The second,
higher temperature level (T43, T47) achieved in this manner is above
100 DEG C.
Alertas Tecnológicas
- 6 de 7 -
ENERGÍA GEOTÉRMICA
Departamento de Patentes e Información Tecnológica
Unidad de Información Tecnológica
COMBINED POWER AND HEATING STATION
Nº publicación KR20150013132A 04/02/2015
A combined heat and power plant (1) is described, in which at least
Resumen
one primary heat source (11) is thermally connected to a heat
distribution network (15) for heat energy (Q) via one or more primary
heat exchangers (111), and in which at least one secondary heat source
(12) is thermally connected to one or more energy converters (13)
arranged to, when an amount of heat energy (QH) is supplied from the
at least one secondary heat source, generate an amount of electrical
energy (PEL) for an internal electricity distribution network (19) in
the combined heat and power plant (1). A method of operating a
combined heat and power plant (1) is described as well.
GROUND WATER CIRCULATION SYSTEM FOR GROUND-LOOP HEAT EXCHANGER
Nº publicación KR20150012823A 04/02/2015
CN204141896U
Nº publicación CN204141896U 04/02/2015
¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿
Nº publicación JP2015021714A 02/02/2015
(¿¿)
¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿¿)¿¿¿¿¿¿¿¿¿¿¿¿10¿,¿¿¿¿¿¿¿¿2¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿R¿¿¿¿¿¿¿¿¿¿¿¿¿¿11¿,¿¿¿¿¿¿¿¿2¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿
Resumen
R¿¿¿¿¿¿¿¿¿¿14¿,¿¿¿¿11¿¿¿¿¿¿¿¿¿¿R¿¿¿¿¿¿¿¿¿¿¿2¿¿¿¿¿¿¿¿¿¿¿15¿¿¿¿¿¿¿¿¿,¿¿¿11¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿20¿¿¿¿¿.¿¿¿¿20¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿11¿¿¿¿
¿¿¿¿¿¿¿¿¿¿¿¿¿.¿¿¿11¿¿¿¿¿,¿¿¿¿¿11¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿30¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿) ¿10
¿¿¿¿¿¿¿¿
Nº publicación JP2015021621A 02/02/2015
(¿¿)¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿,¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿¿)¿¿2¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿42¿¿,¿¿¿¿¿¿¿¿¿¿¿¿7¿¿¿
Resumen
¿¿¿¿¿¿¿¿¿¿¿¿43¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿¿.(¿¿¿)¿1
Alertas Tecnológicas
- 7 de 7 -
ENERGÍA GEOTÉRMICA
