A U.S. Biorefinery Industry Is Emerging
January 28, 2015 | Jim Lane
In 2014, more than 85 million gallons of cellulosic ethanol capacity started up in the United States, along with commercial
facilities to produce advanced biofuels and chemical intermediates.
By B.A. THORP, HARRY SEAMANS and MASOOD AKHTAR
Republished by courtesy of the authors and Paper360º, where the article originally appeared.
For decades, Brazil and the United States were the major countries producing biofuels.
In Brazil, sugarcane was the raw material and ethanol producers simply fermented the extracted sugars. The spent cane (bagasse) was fed into solid fuel
boilers to produce steam and power, and the excess was sold as bedding or became waste. In the United States, corn was the raw material; the starch was
converted to sugar and fermented. Dried distillers grain was a by-product and was sold as animal feed. The cornhusks and stover were usually left in the
fields to maintain soil fertility and structure. Most U.S. corn ethanol producers used natural gas to supply process heat. Sugarcane and corn for both
processesis renewable. More important, the feedstock continues to be replanted and harvested—a key ingredient to sustainability. However, both processes have
been criticized for using land or product that displaced food-growing capacity (the food versus fuel issue).1
In addition, corn ethanol has been criticized for inefficiency and for not being sustainable. The industry is improving land use by increasing yield, gaining 30 to
50 percent yield through using spent crops. Energy required per gallon has decreased from 37,000 BTU per gallon in 1994 to 23,862 BTU per gallon in 2012.
Similar gains have been made in reducing water consumption. As industries mature, they typically become more efficient. In the United States, corn ethanol
may not have been the best gasoline replacement, but it has brought significant benefits. In particular, it became a profitable, commercial business segment
with steady employment that provided financial benefit to farmers, helped lower the price of gasoline by about a dollar per gallon, deferred the importation of
about 450 million barrels of oil in 2013, and helped the U.S. balance of trade by about $45 billion annually.
ADVANCED BIOFUELS
The Energy Independence and Security Act (EISA), enacted in 2007, included a renewable fuel standard.
Since there was already an established corn ethanol industry, the focus was on “advanced fuels,” and a target was set to produce 36 billion gallons of
renewable fuel per year in the United States by 2022. EISA authorized EPA to set up a method for monitoring and enforcing compliance. In 2009, EPA
established Renewable Fuel Standard 2 (RFS2) and enacted mandates.
To encourage the use of more diverse feedstocks, corn ethanol could only be counted to a maximum of 15 billion annual gallons of the 36 billion annual
gallons. The remaining 21 billion annual gallons would be vegetable-oil based diesel and cellulosic biofuels.3
Based on EISA and other congressional directives, the U.S. Department of Energy (DOE) and the U.S. Department of Agriculture (USDA) developed strategies
to support development of technologies and demonstration plants with initial focus on cellulosic ethanol and later a focus of additional “advanced biofuels.” DOE
and USDA’s support included research, whitepapers, models, databases, competitively bid grants and competitively selected loan guarantees. Many thought that
the milestone goals and the 36 billion annual gallon goals could be met.4
Renewable Identification Numbers were established under RFS2 to validate production and facilitate the issuance of tax credits.
Four things happened:
1. Commercialization proved difficult and fell behind targeted schedules. Some projects failed to gain financing and a couple failed to perform.
2. Federal support lacked required time consistency which created uncertainty for investors.
3. RFS2 mandates are issued late and are at a huge discount to EISA targets. Lawsuits have further reduced the certainty of mandates. RFS2 has become
problematic.5
4. Dissonance arising from the preceding points overshadowed belated, but promising, results.
ADVANCED FUEL PROGRESSES
Despite these issues, real progress was being made in the United States on the “advanced fuel” part of EISA’s goals and on a portion of the RFS2
mandates.
DOE and USDA used key learning and tightened their control to improve project execution. For example, they often required a complete pilot line with all
critical recirculation lines (integrated biorefinery pilot), and further required 1,000 continuous hours of operation. The leadership of projects not receiving funding
also incorporated key learnings.
The Bioenergy Deployment Consortium (BDC) gathered key information from the public DOE peer reviews held every two years and communicated them to all
members. Lending institutions incorporated new requirements into their criteria. Project execution slowed but improved.
Meanwhile, progress continued in other countries, some of which had more stable policies, and projects and vendors brought their developments and insights to
the United States. Real and significant progress is now emerging. In 2014, facilities in the United States provided 85 million gallons of cellulosic ethanol
capacity. The year also saw the start of commercial production of “advanced” biofuels and chemical intermediates.
Finally, there is an important recognition that bioindustry needs to have facilities that focus on high-value-added bioproducts such as chemical intermediates and
specialty chemicals to be economically viable.
CURRENT CELLULOSIC ETHANOL CAPACITY
The 85 million gallon annual cellulosic ethanol capacity is dominated by the agriculture community, which is making significant commercial progress through
working with farmers, agronomists and harvesting equipment suppliers to achieve low-cost, sustainable feedstocks.
A variety of technical approaches have been developed, and more are emerging to improve the economics of operations:
POET-DSM Advanced Biofuels, which held a grand opening in September 2014 in Emmetsburg, Iowa, will produce 20 million annual gallons (growing to 25
million) of cellulosic ethanol from corn stover. The plant is located adjacent to a POET 55 million annual gallon corn ethanol plant. The stover feedstock is
gathered after corn harvest. Seventy-five percent of the corn crop residue is left in the field, which studies have shown is sufficient to maintain soil fertility. The
smaller size for the cellulosic ethanol plant was selected in part to be able to gather biomass from a nominal 45-mile radius. The process for the corn stover
after harvest involves pretreatment, enzymatic hydrolysis to sugars, fermentation to ethanol and, finally, distillation. The effluent stream from the cellulosic plant is
sent to an anaerobic digester to produce biogas that is used in both plants. The solid stream of lignin is burned in a solid fuel boiler to produce steam for
both plants.
In Hugoton, Kansas, Abengoa will produce 25 million annual gallons of cellulosic ethanol and 18 megawatts (MW) of power from wheat straw and agricultural
waste. The process is similar to that of POET-DSM. Residuals are sent to a solid fuel boiler to produce process heat and power. At the time of writing,
DuPont was slated to start up a 29 million annual gallon cellulosic ethanol plant from corn stover in Nevada, Iowa, in late 2014. The process will be similar
to the two described above.
INEOS Bio, based in Vero Beach, Fla., has eliminated forest waste as a feedstock and is supplementing citrus waste with sorted municipal solid waste
(SMSW); they will continue to make 8 million annual gallons of cellulosic ethanol and generate 6 MW of power. The process includes pretreatment, gasification,
syngas cleanup, anaerobic fermentation to ethanol and distillation. Steam recovered from the gasification/cleanup stage is passed through a turbine to generate
power, and the extracted steam from the turbine is used for process heat.
Quad County Corn Processors is producing 2 million gallons of cellulosic ethanol per year using corn kernel cellulose (a corn fiber waste product) as
feedstock. The corn kernel cellulose is a byproduct of the firm’s 35 million gallon per year corn ethanol plant. Quad County invented and patented Cellerate
technology and recently granted Syngenta an exclusive license to market the process to other ethanol plants in the United States and Canada. Cellerate
technology has the ability to generate 1 billion gallons of additional ethanol by adding the bolt-on technology to the existing dry grind ethanol plants without
using any more corn.
In Alpena, Mich., American Process, Inc. (API) is producing about 1 million annual gallons of cellulosic ethanol per year from the hemicellulose in the effluent
obtained from an adjacent hardboard mill. The mill washes its fiber to remove some hemicellulose to prevent the hardboard sticking to the plates during hot
pressing. Previously, these hemicellulose materials wound up in the mill’s effluent stream. BDC maintains metrics on these and other plants and can estimate
capital cost, operating cost, time to construct, federal and state incentives and details about technology and commercial potential.
There are a number of organizations that track and report developments. However, BDC may be the only one that validates and develops metrics for projects
across all industries. BDC has created a critical success model that can be used to judge commercial potential.6 These and other metrics are available to all
BDC members.
UNIQUE CAPACITY
Documented progress is also occurring outside the United States as well as in emerging facilities within the U.S.:
Beta Renewables established a 12 million annual gallon cellulosic ethanol facility in Italy, licensed a second plant in Brazil (Gran Bio) and is licensing its third
and fourth plants in North Carolina and the Slovak Republic.
GranBio in Brazil is producing 21.6 million annual gallons of cellulosic ethanol from bagasse using the Beta Renewables technology.
Enerkem, in Alberta, Canada, is producing 10 million annual gallons of bio-methanol from SMSW.
Fiberight, in Iowa, is restarting 6 million annual gallons of cellulosic ethanol from SMSW and paper mill sludge.
Dong Energy in Denmark has a demonstration plant with a capacity of 0.8 tons of cellulosic ethanol and 1.5 tons of bio-pellets per hour. If the plant were to
run full time this would amount to 1.8 million gallons of cellulosic ethanol and 13,000 tonnes of biopellets per year.
Husky Energy in Alberta, Canada, is very interesting because it captures and sells or uses 250 tons of CO2 from its corn ethanol fermenters.
CHEMICAL INTERMEDIATE OR SPECIALIST CHEMICAL CAPACITY
Comparative BDC metrics indicate that due to a relatively low selling price, extremely low-cost feedstock and a capital expenditure (CapEx) of about $7 per
annual gallon are needed to make commercially viable transportation fuels in the United States.7
Others studying or struggling with project economics have come to a similar position.8 Some will achieve these metrics or will find business synergies that
make transportation fuel biorefineries economical. However, these facilities will not utilize all of the existing sources of low cost biomass. A group of companies
has focused on producing higher value chemicals or chemical intermediates for the chemical and food industries, in order to achieve feedstock flexibility and an
acceptable return on investment.
The list below provides a few examples that are in production or are close to startup:
•
Amyris is making 2 million annual gallons of farnesene in Brazil.
•
BioAmber is making 17,000 annual tons of succinic acid in France and has announced a 30,000 ton per year plant in Sarnia, Ontario, Canada. Myriant
is making 30 million pounds of succinic acid in Lake Providence, La.
•
Solazyme currently has three renewable oil and bioproducts facilities in operation, including a large-scale commercial demonstration foods facility in
Peoria, Ill., a 20,000 metric tpy facility in Clinton, Iowa, and a 100,000 metric tpy facility in Brazil.
•
Go has converted one-third of the capacity of a corn ethanol plant in Minnesota to make isobutanol and will convert the remainder later.
•
Green Biologics will conduct a demonstration scale conversion of corn into n-butanol in a plant in Iowa, then quickly follow that by converting a corn
ethanol plant in Minnesota to a commercial scale plant producing n-butanol.
•
Segetis has a pilot plant in Minnesota making levulinic acid and has converted this into a plasticizer; the firm has a comprehensive economic
development package to construct a 21.1 million pound per year facility in Hoyt Lakes, Minn.
•
Virent received an additional investment from Coca-Cola to expand its pilot plant to a demonstration scale facility to produce paraxylene from purchased
sugars. Plant based para-xylene is expected to pave the way for 100 percent bio PET bottles.
PROMISING APPROACHES FOR WOODY BIOMASS
Progress has been slower and more difficult for developers who selected wood as the feedstock. The high lignin content and the tightly bound structure of
wood, as well as the higher cost of feedstock, present greater techno-economic challenges than do crops, spent crops or SMSW, which can be an exceedingly
low cost feedstock under many circumstances.9 While there has been significant pain with the closure of Choren in Germany, along with Range Fuels and
KiOR, there has also been significant learning.
Most of those who chose to use woody biomass as a feedstock have abandoned the hydrolysis approach. Low-cost thermal or thermochemical approaches have
been developed. Several projects that are moving forward have been able to keep CapEx under $7 per annual gallon. Those moving forward with higher
CapEx have moved to very-low-cost feedstock.
There are currently several promising approaches demonstrated at the laboratory or pilot scale: Cool Planet is constructing a $56 million facility in Louisiana that
will use unique pyrolysis techniques to produce 5 million annual gallons of high-octane gasoline and a bio-char that enhances plant growth.
Licella (Ignite Energy Resources) has won a grant to build a commercial-scale module with a capacity of 2 million annual gallons in Australia. The module will
use a catalytic hydrothermal upgrading approach to liquefy wet wood into bio-crude, which can be coblended with fossil crude for petroleum refinery feedstock
to produce drop-in fuels. This high-temperature and high-pressure facility will have dual feedstock capability (lignite and woody biomass). This dual feedstock
facility has a higher CapEx, but facilities with one feedstock can have CapEx of under $7 per annual gallon.
Proton Power has a pilot/demonstration facility that can transform available switchgrass directly into a blendable biodiesel. The unique thermal process avoids
Fischer- Tropsch gas-to-liquid conversion. Funding of $35 million has been obtained to build a 5 million annual gallon facility adjacent to the pilot/demonstration
plant.
Borregaard developed the BALI process to economically produce commercial grade lignin and cellulosic ethanol. The firm built a demonstration plant to prove
that this lignin would satisfy growing customer demand. As a “by-product” of the current operation, the firm produces 5.3 million annual gallons of cellulosic
ethanol. It is estimated that a possible first-of-its-kind BALI plant in the United States will produce about 27 million annual gallons of cellulosic ethanol.
Clearly, the high lignin content and dense growth of woody biomass have presented a greater challenge than anticipated, but unique approaches to overcome
these challenges have emerged. Announcements for other emerging technologies and commercial facilities are expected in the near term.
CONCLUSIONS
It is clear that despite regulatory uncertainty, a biorefinery industry for “advanced biofuels and bioproducts” is emerging in the United States. However, it is
difficult to track its progress because of its newness, the confidentiality inherent in any new technology, confusing bioenergy/biorefinery announcements and the
lack of organizations that can perform objective analyses across all technologies and industries.
Eighty-five million annual gallons of cellulosic ethanol and a similar amount of chemical intermediates can be easily dismissed as unique or trivial when the
2022 EISA goal is 21 billion annual gallons of “advanced” renewable biofuels. However, the techno-economic development that produced the current quantities
cannot be dismissed. Biorefineries have begun to arrive. Social, political and economic trends will only add to the driving forces. It is clear that those who are
interested in or who will be impacted by biorefineries need to be allocating more resources to assembling an objective analysis of opportunities, to learn what
they can about the bio-industry progress and pending announcements.
To paraphrase what Edward Deming said at his conferences on statistical process control: “It is not necessary to do any of this; failure to remain competitive
is always an option.”
Ben Thorp, Harry Seamans and Masood Akhtar are cofounders of the Bioenergy Deployment Consortium (BDC), which has its website here.
