Configuration Table Guide

Configuration Table Guide
Version 8.2 | February 5, 2015
For the most recent version of this document, visit our documentation website.
Table of Contents
1 Configuration table overview
1.1 Accessing the configuration table
2 Configuration table values
2.1 Configuration values and UI display for Document Skip
3 dtSearch default alphabet file text
Relativity | Configuration Table Guide - 2
3
3
5
63
63
1 Configuration table overview
This guide provides a description of each entry in the configuration table, along with each entry’s
default value.
1.1 Accessing the configuration table
To access the configuration table, perform the following steps:
1. Access the primary server environment containing all databases, including EDDS.Configuration.
2. Connect to the Microsoft SQL Server Management Studio.
3. In the Object Explorer tree, expand Databases > EDDS > Tables.
4. Right-click the eddsdbo.Configuration table, and select the option Select Top 1000 Rows.
The eddsdbo.Configuration table opens. It displays the Section, Name, Value, MachineName, and
Description for all the entries in the table.
Relativity | Configuration Table Guide - 3
5. Locate the configuration value you want to change and update the Value column. Note that doing so
could have a significant effect on the performance and functionality of your Relativity environment.
Refer to Configuration table values on page 5 for a complete list of Relativity configuration values.
Relativity | Configuration Table Guide - 4
2 Configuration table values
This table provides an alphabetical list of all the configuration values related to Relativity.
Name
AboutBoxPortalLink
Account
Value
https://na3.salesforce.com/
secur/login_portal.jsp?
orgId=00D5000000072uY
&portalId=060500000004fqC
kCura.EDDS.Web
http://kcura.com/relativity/
support/technical-support
kCura.LicenseManager UNSETACCOUNT
AdvancedImagingTimeout
Relativity.Core
600
AdvancedSearchDefault
kCura.EDDS.Web
False
AgentOffHourEndTime
kCura.EDDS.Agents
5:00:00
AboutBoxSupportLink
Section
kCura.EDDS.Web
Relativity | Configuration Table Guide - 5
Description
The location to which the Relativity Icon Box redirects.
The location to which the Support link redirects.
This value populates the
Account column in the Case Statistics Rollup report.
The amount of time, in seconds,
that an advanced imaging process can actively run until it
times out (does not include waiting time).
Determines the default setting
for Advanced Search Default
when creating new users.
“False” is private, and “true” is
public.
Used in conjunction with the
AgentOffHourStartTime value to
specify a valid time range when
off hour agents should run. Currently, this only applies to the
File Deletion manager, Case Statistics Manager, and Case Man-
Name
Section
Value
Description
ager. The File Deletion manager
immediately stops deleting documents once the time of day
passes the
AgentOffHourEndTime. The
Case Statistics manager and
Case Manager continue to process until completion.
To enter a setting, use 24-hour
time notation with the format of
hh:mm:ss.
Note that if the start time is
before midnight, then you must
also set the end time before midnight. For example, a start time
of 23:00:00 might have an end
time of 23:59:00. If the start
time is midnight or later, then
you can set the end time to any
value after the start time. For
example, a start time of midnight that is between 00:00:00
and 03:00:00 can have any end
time.
Relativity | Configuration Table Guide - 6
Name
AgentOffHourStartTime
Section
kCura.EDDS.Agents
Value
00:00:00
AllowChangesToOverwriteProtection
kCura.EDDS.Web
False
AllowNativeRedactions
kCura.EDDS.Web
True
AnalyticsCategorizationBatchSize
Relativity.Core
100000
Relativity | Configuration Table Guide - 7
Description
Used in conjunction with the
AgentOffHourEndTime value to
specify a valid time range when
off hour agents should run. Currently, this applies only to the
File Deletion manager, Case Statistics Manager, and Case Manager.
To enter a setting, use 24-hour
time notation with the format of
hh:mm:ss. See the description
for the AgentOffHourEndTime
configuration value.
Determines if the Overwrite Protection drop-down menu is editable when editing or creating a
layout. If set to true, the user
can set this property to Disabled
and then save a document even
if another process has modified
the document since loading.
Determines whether users can
perform redactions within the
Native Viewer.
The size of the batch of documents submitted to the Analytics engine to be categorized.
Name
Section
AnaRelativity.Core
lyticsCategorizationCreationBatchSize
Value
1000
AnalyticsCategorizationDeadlockWait kCura.Data.RowDataGateway
30000
AnaRelativity.Core
lyticsCategorizationDeletionBatchSize
1000
AncestorCountWarningLevel
kCura.EDDS.Web
50000
APITimeout
kCura.Relativity
30
ApplicationRestrictedFileTypes
Relativity.Core
.exe;.com;.pif;.bat;.scr
Relativity | Configuration Table Guide - 8
Description
The size of the batch of CategoryResult objects created
within Relativity once the Analytics engine has categorized
them.
Time in milliseconds that
determines how long the query
should wait to retry when deadlock occurs during run of categorization set.
The size of the batch of CategoryResult objects deleted
within Relativity when the user
chooses to run a full categorization against a set that
has been previously categorized.
A warning is displayed in the
Security page when the item's
security being changed has
more than this number of
ancestors. The warning displays
because the database will be
locked for a substantial period
of time.
Sets the Relativity API token
expiration in minutes.
A semicolon(;) delimited list of
file extensions (including dots)
indicating file types that users
should be prohibited from
uploading as custom pages or
Name
Section
Value
AuditApplicationUninstallEnabled
Relativity.Core
True
AuditCountQueries
Relativity.Core
False
AuditingEnabled
kCura.Audit
True
AuditFullQueries
Relativity.Core
False
Relativity | Configuration Table Guide - 9
Description
resource files. Examples include
.exe, .com, and .bat. Also, see
RestrictedFileTypes.
Determines whether Relativity
writes an entry to the audit log
for each component edited or
deleted when you uninstall an
application. By default, auditing
is enabled.
For each list that is generated,
the system initially runs a
"count" query to get the total
number of records that fulfill the
criteria. Setting this value to
True writes the SQL query to the
History record.
Determines if auditing is
enabled throughout Relativity.
For each list page that is generated, the system initially runs
a query to get the data to fill the
rows on the current page. Setting this value to TRUE would
write the SQL query to the History record.
Name
AuditIdQueries
Section
Relativity.Core
Value
True
AuditPivotColumnRetrievalQueries
Relativity.Core
True
AuditPivotFullQueries
Relativity.Core
True
AuthenticationEmailFrom
kCura.Notification
[email protected]
AuthenticationTokenLifetimeInMinutes
Relativity.Core
5
AutoCreateRate
kCura.EDDS.Web
60
Relativity | Configuration Table Guide - 10
Description
The system will get a batch of
Artifact IDs that fulfill the criteria
and are needed to populate the
current page in the list. Setting
this value to TRUE would write
the SQL query to the History
record.
For each Pivot list and chart, a
query is run to get the unique
columns needed to display the
data. Setting this value to True
writes the SQL query to the History record.
For each Pivot list and chart, a
query runs to get the data for
the rows and columns. Setting
this value to True writes the SQL
query to the History record.
This email address appears in
the From field of email messages that contain authentication information for users.
When an application other than
Relativity is authenticated using
Relativity’s internal mechanism,
a token is received. This token is
valid for this period of time.
How often the system attempts
to create batches, in minutes.
Name
Section
AutoEmailWithCaseStatisticsManager kCura.Billing
Value
True
AutoGenPasswordLength
kCura.EDDS.Web
8
BackupDirectory
kCura.EDDS.SqlServer
During Relativity installation
BaseApplicationPath
kCura.EDDS.Procuro
During Relativity installation
BaseRelativityScriptPath
kCura.EDDS.Procuro
During Relativity installation
BasicImagingTimeout
Relativity.Core
300
Relativity | Configuration Table Guide - 11
Description
If True, the Case Statistics Manager agent generates a text file
with client billing information
which is sent to kCura automatically through the SMTP
server. Each time the agent
runs, the new text file is sent to
kCura through the SMTP server.
If false, the Case Statistics Manager agent generates a zip file
with client billing information,
which is stored in the location
specified in the EDDSFileShare
value. Each time the agent runs,
a new date-stamped file is created and stored in this folder.
Zip files stored in this location
can be manually sent to kCura.
The number of characters that
an auto-generated password
contains.
The path to the backup directory used by SQL Server. This
value should be relative to the
server where SQL Server is
installed.
The root path where the
Procuro looks for required
Relativity applications.
The root path where the
Procuro looks for its SQL scripts.
The amount of time, in seconds,
Name
Section
Value
BcpShareFolderName
kCura.Chicago
BCPPath
BCryptWorkFactor
Relativity.Core
11
BrandingManagerBatchAmount
kCura.EDDS.Agents
100
BrandingRecordCreationBatchSize
Relativity.Core
1000
BufferAcquisitionTimeoutInMilliseconds
kCura.EDDS.Web.Distri 5000
buted
BufferCount
kCura.EDDS.Web.Distri 1000
buted
Relativity | Configuration Table Guide - 12
Description
that the basic imaging process
waits for a single document to
be imaged before killing the
export process and moving to
the next document.
The name of the share used for
Bulk Inserts and the Case Statistics Manager.
This is a bCrypt work factor constant that controls the strength
of the encryption used for password hashing. Any value lower
than 10 defaults to 10. Incrementing by 1 doubles the time it
takes to hash the password.
The number of files the Branding Manager brands in a single
batch.
The maximum number of
records inserted into the BrandingQueue table in a single batch.
This is used by both the Production Manager and when
attempting to resolve errors in
the web.
The amount of time the Distributed site waits to acquire a
free buffer to use for downloading before throwing an
error.
The number of buffers that the
Distributed site allocates to ser-
Name
Section
BufferSize
kCura.EDDS.Web.Distri 81920
buted
BulkLoadFileFieldDelimiter
Relativity.Data
þþKþþ
CancelRequestEnabled
Relativity.Core
True
CancelRequestInitialPollingInterval
Relativity.Core
100 msec
Relativity | Configuration Table Guide - 13
Value
Description
vicing download requests.
The maximum size, in bytes, of
the buffer used by Distributed.
Increasing this may improve file
download performance but
increases the risk of running the
Distributed server out of
memory.
The value used to separate
fields when loading bulk files
into the SQL database. Line
delimiters are this value plus a
new line.
This determines whether the
option to cancel requests is available to Relativity users. When it
is set to True, users can see an
overlay window with the option
to cancel the request and a message indicating that items are
loading. When set to False, this
functionality is not available.
This configuration setting indicates the initial time interval (in
milliseconds) used for polling
the cache on the web server during the first second of a cancel
query request. After the first
second, the time interval
increases to 450 msec.
Name
CancelRequestTimeDelay
Section
Relativity.Core
Value
3 seconds
CasesForGroupsViewID
kCura.EDDS.Web
900
CaseStatisticsBasedLockout
kCura.LicenseManager blank
CaseStatisticsNotificationIncludeEmails
kCura.LicenseManager True
CaseStatisticsNotificationList
kCura.LicenseManager empty
ChoiceLimitForUI
Relativity.Core
Relativity | Configuration Table Guide - 14
200
Description
This value controls the time
delay (in seconds) between the
initiation of a search request
and the display of an overlay
window with the option to cancel the request.
The ArtifactID of the view used
to display the workspaces at the
bottom of a group page.
Used to determine if the Case
Statistics-based lockout is active.
Expects either True or False. If
True, the email and original
email address fields in the Case
Statistics and User Rollup
reports are populated. If False,
those fields are retrieved as
empty.
Distribution list for Case Statistics reports. It expects a semicolon-delimited list of emails to
send the report to. If empty,
emails aren't sent.
For choices and single objects,
the maximum number that can
appear in a checkbox, dropdown menu, or radio button list
before switching to a pop-up
picker; we recommend setting
this value to 15. If it's not set,
lists automatically render as
Name
Section
Value
ChunkEnabledQueryChunkSize
Relativity.Data
10000
CompareWebAPIPath
kCura.EDDS.Web
During Relativity installation
ConcurrentLogin
kCura.LicenseManager per system
ContentAnalystDefaultDimensions
Relativity.Core
100
ContentAnalystDefaultMinCoherence Relativity.Core
0.95
ContentAnalystDefaultNumberOfProcessors
2
Relativity.Core
ContentAnalystFileMaxByteThreshold Relativity.Core
Relativity | Configuration Table Guide - 15
524288000
Description
pop-up pickers.
Allows the Desktop Client to pull
down a potentially large set of
artifacts (choices and folders,
specifically).
The defined Compare Web API
path.
The setting for requiring the Concurrent User Login restriction.
This value must be changed by a
tool that the dev teams owns;
defaults to disallowed.
This number of default dimensions specified for new Content
Analyst indexes.
The default minimum coherence
score to use when submitting a
similar documents job to Content Analyst.
This value indicates the number
of processors that a single Analytics index uses for a build.
Increasing the number of processors to a value greater than 2
may slow the performance of
the Analytics server. You must
adjust any setting modifications
to the requirements of your
environment.
This was deprecated in Relativity
8.1. Changing this value has no
effect on the environment.
Name
ContentAnalystMaximumBatchSize
Section
Relativity.Core
Value
1000
ContentAnalystMaxConnectorsPerIndexDefault
Relativity.Core
4
ContentAnalystMaxTotalConnectorsDefault
Relativity.Core
50
ContentAnalystShowIdentifySimilarDocuments
Relativity.Core
False
ContentAnalystShowIntegratedDtSearch
Relativity.Core
False
ContentAnalystSimilarDocsJobType
Relativity.Core
0
ContentAnalystSingleRecordMaxByteThreshold
Relativity.Core
31457280
Relativity | Configuration Table Guide - 16
Description
This is the number of documents sent to the Analytics
server by each JDBC connector
at once during index population. This value should not
be lowered from 1000, as this
would slow down populations
environment-wide.
The default maximum number
of connections allowed between
the Analytics server and SQL for
each index that uses this server.
The default maximum number
of connections allowed between
the Analytics server and SQL
across all indexes using this
server.
Determines whether Identify
Similar Documents functionality
is available for Analytics indexes
created after Relativity 8.0.
Determines whether Integrated
dtSearch functionality is available for Analytics indexes created after Relativity 8.0.
This is the default similar documents job type to submit to
Content Analyst (comprehensive).
This was deprecated in Relativity
8.1. Changing this value has no
effect on the environment.
Name
Content AnalystSmartTrain®OnByDefault
Section
Relativity.Core
Value
True
ContentAnalystTemporaryDirectory
Relativity.Core
blank
Relativity | Configuration Table Guide - 17
Description
Determines whether Analytics
indexes are enabled by default
to use the Optimize training set
functionality, which automatically excludes conceptuallyirrelevant documents from an
index’s training set.
This was deprecated in Relativity
8.1. Changing this value has no
effect on the environment.
Name
ContentAnalystTemporaryDirectory
Section
Value
Relativblank
ity.StructuredAnalytics
ContentAnalystUpdateBatchSize
Relativity.Core
50000
ContentAnalystWebServicesMaxByteThreshold
Relativity.Core
31457280
ContentAnalystWebServicesTimeout
Relativity.Core
300000
Relativity | Configuration Table Guide - 18
Description
Deprecated in Relativity
8.1.202.3. When running
structured data Analytics jobs,
the worker agents may need to
write some large extracted text
files to disk. You can use this
configuration value to enter a
UNC share path for a directory
to store these temporary files.
Use the format \\<machine
name>.<domain>\<Content
Analyst temporary directory>
(For example:
'\\mainline.kcura.corp\SASTem
pDirectory'). Be sure to use the
real machine name rather than
the localhost.
If the value is blank, Relativity
intelligently discovers the
directory. We recommend
setting this value only for singleserver environments or when
auto-discovery doesn't work.
The batch size to update the
non-similar documents in the
documents table.
This was deprecated in Relativity
8.1. Changing this value has no
effect on the environment.
The timeout value, in milliseconds, when connecting to
Analytics Web Services.
Name
CookieHttpOnly
Section
kCura.EDDS.Web
Value
True
CookieSecure
kcura.EDDS.Web
True
CopyFilesToRepository
kCura.EDDS.Winform
True
CreateCaseTimeoutValue
Relativity.Data
1800
Relativity | Configuration Table Guide - 19
Description
Prevents access to cookies by
JavaScript and other client-side
elements when set to True. This
flag is designed to attach to sensitive cookies such as the session
cookie ASP.NET_SessionId.
Forces a web browser to send
session information over HTTPS
only when set to True. This flag
is designed to attach to sensitive cookies such as the session
cookie ASP.NET_SessionId.
When set to True, users cannot
log into Relativity over HTTP.
The default value that appears
in all import and export forms
within the Relativity Desktop Client for the “copy files to repository” value.
The timeout value, in seconds,
associated with running queries
related to case creation.
Name
CreateZSRTablesForSTRs
Section
Relativity.Core
CustomPageManagerIsOffHourAgent kCura.EDDS.Agents
Relativity | Configuration Table Guide - 20
Value
True
False
Description
Controls whether ZSR tables are
created by search terms
reports. If True, search terms
reports create ZSR tables, caching the results for future use.
This improves performance, but
may make rebuilding and deleting indexes take longer. If False,
building search terms reports
may take longer. Fewer tables
are left in the database, potentially resulting in faster dtSearch
index builds.
This value controls whether the
Application Manager agent
behaves as an off hour agent. If
set to True, applications containing custom components
only deploy between the hours
set in the
AgentOffHourStartTime and
AgentOffHourEndTime values. If
an application deploys when the
AgentOffHourEndTime passes,
the current deployment completes and no new deployments
occur until the next
AgentOffHourStartTime.If set to
False, the Application Manager
agent runs normally, and applications containing custom pages
are identified and deployed in
Name
Section
Value
DatabaseQuery
kCura.EDDS.Procuro
DataCenter
kCura.Billing
SELECT CAST(1 AS BIT) AS [ ],
' N/A' as ArtifactID, 'EDDS' as
[Name], @@SERVERNAME as
[Location], 'N/A' as [CaseStatus],
'' as [UpgradeStatus] UNION
SELECT CAST(1 AS BIT) AS [ ],
CAST([Case].[ArtifactID] AS
VARCHAR(20)), [Case].[Name],
[ResourceServer].[Name] as
[Location], [Code].Name as Status,
'' as [UpgradeStatus] FROM
[Case] INNER JOIN [Code] ON [Code].
ArtifactID = [Case].StatusCodeArtifactID
INNER JOIN [Artifact] ON
[Artifact].[ArtifactID] = [Case].
[ArtifactID] AND [Artifact].[DeleteFlag]
= 0 INNER JOIN [ResourceServer] ON
[Case].[ServerID] =
[ResourceServer].[ArtifactID]
blank
Relativity | Configuration Table Guide - 21
Description
the typical process.
The query used by Procuro to
determine the list of databases
available for upgrading.
Geographical location of the facility where a Relativity instance is
housed. The Case Statistics Manager agent includes this location
in the RelativityVersion.txt
metadata file that it generates.
See Case Statistics Manager on
the Agents page of the Relativity
8.2 Documentation site.
Name
DataDirectory
Section
kCura.EDDS.SqlServer
Value
During Relativity installation
DataFocusModeDefault
kCura.EDDS.Web
Off
Description
The path to the data directory
used by SQL Server. This value
should be relative to the server
where SQL Server is installed.
Default Interface Mode for
users. Types:
n
n
DefaultCaseDownloadHandlerApplicationPath
kCura.EDDS.Web
During Relativity installation
DefaultOIHiliteStyleID
kCura.Code.Data
3
DefaultNativeImagingEngineURL
Relativity.Core
Determined during native
imaging installation; manually
entered in configuration table
after native imaging installation
is completed
Relativity | Configuration Table Guide - 22
Data Focus On
Data Focus Off
The value that populates in the
“Download Handler URL” field
by default for new cases.
If you enter a full URL for this
value, the protocol must match
what is used in the browser. If
Relativity is set up to use either
HTTP or HTTPS, but not both,
you can enter a full URL. If
Relativity is set up to use both
HTTP and HTTPS, do not specify
the protocol in this value.
The default OIHiliteStyle associated with new choices. Valid
values are defined on the
OIHiliteStyle table (look within a
workspace database, not the
EDDS database).
The base URL to the web services provided by the processing server (Deprecated in
7.5).
Name
DefaultQueryTimeout
Section
kCura.AssistedReview
Value
30 (seconds)
DeobfuscateMapsFolderPath
Relativity.Core
\Relativity\EDDS\Maps folder
DeveloperMachine
kCura.EDDS.Web
False
DeveloperMode
Relativity.Core
False
DisabledUserMessage
kCura.EDDS.Web
Your Relativity Administrator
Relativity | Configuration Table Guide - 23
Description
The timeout value, in seconds,
used by default for all AssistedReview queries.
If set, the folder where the
obfuscation map files are stored
for use in the Stack Trace Deobfuscation Tool. If not set, the
Stack Trace Deobfuscation Tool
uses the …\Relativity\EDDS\Maps folder.
Determines whether the environment should be treated as a
developer machine. This should
always be set to False for production environments
Enables or disables developer
mode options within an
instance of Relativity. These
options include disabling the
cross-site request forgery (CSRF)
header requirement in the API
and returning detailed error
messages such as stack traces.
Enable this setting only in a
development environment.
The contact specified within the
message displays when a user
does not have access to Relativity.
Name
DisplayDisclaimer
Section
kCura.EDDS.Web
Value
False
DisplayHelpLink
Relativity.Core
True
DisplayLogoInTitleBar
kCura.EDDS.Web
False
DistinctBuilderMaxValue
Relativity.Data
255
DocumentSkipDefaultBehaviorDefault kCura.EDDS.Web
True
DocumentSkipEnabledDefault
Enabled
kCura.EDDS.Web
Relativity | Configuration Table Guide - 24
Description
Determines whether the disclaimer should appear when
users log into Relativity.
Determines whether the Help
link appears for all non-systemadministrators. Setting this
value to False removes the Help
link from the UI.
When set to True, the company
logo appears in the top action
bar.
The maximum number of values
allowed in a choice field before it
changes from a picker in the
item list to disabled.
Determines the default value displayed in the Skip Default Preference field on the Add User form.
The UI displays Skip when this
configuration option equals
True, and it displays Normal
when it equals False. When
DocumentSkipEnabledDefault is
set to Disabled or Force
Enabled, this configuration
option is ignored.
Determines the default value displayed in the Document Skip
field on the Add User form.
Acceptable values are Enabled,
Disabled, and Force Enabled.
Name
Section
Value
DocumentSkipLookAheadLength
kCura.EDDS.Web
1000
DocukCura.EDDS.Web
mentSkipNoMoreDocumentsMessage
Relativity | Configuration Table Guide - 25
Document Skip is enabled.
The remaining documents in
your queue no longer meet
the conditions of your view
or search. If you are done with
these records, click \"Return to
document list\".
If you would like to see the
remaining records, change your view
Description
When this option is Enabled,
the value for DocumentSkipDefaultBehaviorDefault controls
the default option displayed in
the Skip Default Preference field.
When this option is set to Disabled, or Force Enabled, the
Skip Default Preference field displays the read-only value of
Normal or Skip respectively See
Configuration values and
UI display for Document Skip on
page 63.
The progressive number of documents (starting with the current + 1) that the system
evaluates against the current
view/saved search criteria when
Document Skipping is enabled.
System default is 1000 documents, set to -1 for all documents.
Notification to user when Document Skip is enabled, and no
more documents fit the saved
search/view criteria.
Name
Section
DocumentSkipToolTip
kCura.EDDS.Web
DomainParsingSingleRecordMaxByteThreshold
Relativity.Data
dtSearchDefaultAlphabetFileText
Relativity.Core
Listed in dtSearch default alphabet file text on
page 63.
dtSearchDefaultSubIndexFragmentationThreshold
Relativity.Core
9
Relativity | Configuration Table Guide - 26
Value
from \"Skip\" to \"Normal\".
This checkbox will enable you
to bypass documents which
already meet the criteria of this
saved search/view.
1048576
Description
Document skip tooltip message
displayed in the document profile.
The Domain Parsing tool
doesn't parse records with a
value that exceeds this length
(in Bytes).
The default value of the text for
the Alphabet file when creating
a new dtSearch index.
This value is used as the default
value for the Sub-index fragmentation threshold field on
the dtSearch Index Information
screen. The value must be an
integer greater than or equal to
1. When the fragmentation level
for a sub-index equals or
exceeds the threshold level, the
system automatically compresses the sub-index during an
incremental build.
Name
dtSearchDefaultSubIndexSize
Section
Relativity.Core
Value
250000
dtSearchEnableMetricsLogging
Relativity.Data
0
dtSearchPopulationLogFilePath
Relativity.Core
blank
dtSearchQueryLogFilePath
Relativity.Core
blank
Relativity | Configuration Table Guide - 27
Description
This is used by the dtSearch
Index Manager to determine
how many sub-indexes will
make up the entire index. This
value is the maximum number
of documents to build into each
sub-index and appears by
default in the Sub-index size
field when creating a dtSearch.
A bit value to determine if
dtSearch Metrics gathering
should be enabled, for Performance testing or
Troubleshooting.
Set this to point to a file on disk
when diagnosing dtSearch problems relating to populating
indexes. This will cause dtSearch
to write debugging information
to disk. This file itself doesn’t
need to exist, but the path to it
does. Make sure that this value
is set back to nothing when the
log file is no longer needed
because it can grow in size very
quickly.
Set this to point to a file on disk
when diagnosing dtSearch problems relating to performing
searches. This will cause
dtSearch to write debugging
information to disk. This file
Name
Section
Value
dtSearchStreamBufferSize
Relativity.Data
1048576 (1 MB)
dtSearchStreamThresholdInBytes
Relativity.Data
1048576
dtSearchWorkerProgressThreshold
Relativity.Data
1000
EDDSFileShare
Relativity.Data
During Relativity installation
Relativity | Configuration Table Guide - 28
Description
itself doesn’t need to exist, but
the path to it does. Make sure
that this value is set back to
nothing when the log file is no
longer needed because it can
grow in size very quickly.
Controls the size, in bytes, of
the buffer used within the
dtSearchStream object. This buffer is allocated into memory as
soon as the agent starts. Relativity checks to see if the value has
changed between jobs and reallocates the buffer if a change is
detected.
This is used by the dtSearch
Index Manager when populating an index. If the size of all
the text associated with a document is larger than this value,
the text is streamed directly into
dtSearch. Otherwise, the text is
converted to bytes and the
bytes are sent to dtSearch.
Controls the number of documents a worker agent sends to
the dtSearch engine before
reporting progress back to the
database. Changing this value
may have an impact on performance.
The location used for the mas-
Name
Section
Value
EmailFrom
kCura.Notification
blank
EmailLinkURLOverride
kCura.EDDS.Web
https://relativity.kcura.com
Description
ter-level file share. If you change
the location, make sure that the
new directory is shared.
The email address populated in
the “from” field when sending
email notifications. The email
address must be valid. Email aliases can be entered in this
format: Alias Name [email protected]
You need to set this item only
when the URL used to access
Relativity by end users is not the
actual URL of the Relativity web
server. This can happen under
certain conditions:
n
n
Relativity | Configuration Table Guide - 29
Your Relativity IIS server
is part of a server farm
and/or behind a load balancer. In this case, the
URL used to access
Relativity is the URL of
the load balancer or the
farm, not the URL of a
specific server.
You have a security certificate installed on a load
balancer or firewall, and
the device is doing URL
rewriting when passing
requests on to the Relativity server. In this case,
Name
Section
Value
EmailTo
kCura.Notification
blank
EnableNativeRedactions
kCura.EDDS.Web
True
EnableTransactionalImports
Relativity.Core
True
EncryptedSMTPPassword
kCura.Notification
blank
EnvironmentData
kCura.LicenseManager xxxx
EnvironmentName
kCura.Notification
Relativity | Configuration Table Guide - 30
DefaultRelativityEnvironmentName
Description
you use HTTPS to access
Relativity, but the actual
Relativity server doesn't
use HTTPS.
The email address populated in
the “to” field when sending
email notifications. The email
address must be valid. Separate
multiple email addresses with a
semicolon.
To enable native highlighting,
redactions, links, and tagging,
this must be manually added
and set to True.
You can set this value to False to
turn off the SQL transactions
that occur on import. This could
speed up performance in the
database. However, it's dangerous because it can cause
invalid records in the database.
The password for the username
associated with the credentials
of the SMTP server. This password validates against the
SMTP authentication.
Encrypted data about your
environment. Changing this will
shut down Relativity.
The name of the environment.
This value is used when sending
Name
Section
EnvironmentPubToken
kCura.LicenseManager xxxx
ExportBatchSize
Relativ1000
ity.StructuredAnalytics
ExportSubdirectoryDigitPadding
kCura.EDDS.Winform
3
ExportVolumeDigitPadding
kCura.EDDS.Winform
2
FavoritesEnabled
Relativity.Core
TRUE
FileDeleteChunkSizeOnDocumentDelete
Relativity.Data
1000
FileDeletionManagerBatchAmount
kCura.EDDS.Agents
100
ForceWebClientManagerUpgrade
kCura.EDDS.Web
False
Relativity | Configuration Table Guide - 31
Value
Description
notifications. You should
update the default value to a setting appropriate for use in your
environment.
kCura’s public key. Do not
change.
The batch size used by Structured Analytics agents when
pulling document information
out of Relativity and pushing it
to Content Analyst staging web
service. Changing this value will
impact performance.
The default value that appears
in the Relativity Desktop Client
export form for the “volume subdirectory digit padding” value.
The default value that appears
in the Relativity Desktop Client
export form for the ”export
volume digit padding” value.
Determines if Favorites appear
in the UI.
Determines the number of
records deleted at once from
associated tables when documents are deleted in mass.
The number of documents that
the File Deletion Manager
deletes in a single batch.
When set to True, Internet
Name
Section
ForgotPasswordRequestBody
kCura.EDDS.Web
ForkCura.EDDS.Web
gotPasswordRequestCompletedBody
Relativity | Configuration Table Guide - 32
Value
Description
Explorer checks to make sure
the user's web client manager
version matches the version of
Relativity exactly. If it doesn't, it
automatically prompts the user
to install a new web client manager.
<HTML><BODY> <P>We received a request to The text in the body of the forreset the password associated with this email gotten password request email
address. Click the link below to reset your pass- message.
word. This link will expire after 15
minutes.<BR/><BR/> {RESETLINK}<BR/><BR/>
We recommend opening this link in Internet
Explorer.<BR/><BR/> You can also copy and
paste the following text into your address
bar:<BR/><BR/> {RESETTEXT}<BR/><BR/> If you
did not request this change, contact your system admin.<BR/><BR/> Please do not reply to
this email.<BR/><BR/></P></BODY></HTML>
<HTML><BODY> <P>The password associated The text in the body of the forwith this email address has been successfully
gotten password request email
reset. Click the link below to login.<BR/><BR/> message when the request has
{LOGINLINK}<BR/><BR/> We recommend open- been completed.
ing this link in Internet Explorer.<BR/><BR/>
You can also copy and paste the following text
into your address bar:<BR/><BR/> {LOGINTEXT}
<BR/><BR/> If you did not request this change,
contact your system admin.<BR/><BR/> Please
do not reply to this
email.<BR/><BR/></P></BODY></HTML>
Name
ForgotPasswordRequestEmailFrom
Section
kCura.Notification
Value
[email protected]
ForgotPasswordRequestInvalidBody
kCura.EDDS.Web
ForgotPasswordRequestSubject
kCura.EDDS.Web
<HTML><BODY> <P>We received a request to
reset the password associated with this email
address. <BR/><BR/> Your password can't be
reset due to a problem with your account.
Contact your system admin for assistance.<BR/><BR/> If you did not request this
change, contact your system
admin.<BR/><BR/> Please do not reply to this
email.<BR/><BR/></P></BODY></HTML>
Password reset request
FTDirectory
kCura.EDDS.SqlServer
During Relativity installation
Relativity | Configuration Table Guide - 33
Description
The value in the From field for
the forgotten password request
email message.
The text in the body of the forgotten password request email
message if the user is locked
out.
The value in the Subject field for
the forgotten password request
email message.
The path to the full-text directory used by the SQL Server.
This value should be relative to
the server where SQL Server is
installed.
Name
GlobalWorkspaceUpgradeLimit
Section
Relativity.Data
HeaderLogo
kCura.EDDS.Web
HeaderLogoLarge
kCura.EDDS.Web
HelpLinkURL
kCura.EEDS.Web
Relativity | Configuration Table Guide - 34
Value
4
Description
The global limit on the maximum number of Workspace
Upgrade Worker agents that
can access any of the SQL servers in your Relativity environment. Each SQL server can
have a different number of
these agents accessing it, but
the maximum number accessing
a single server can’t exceed the
global limit set in this configuration value. To set the number of agents on a specific
server, see Servers on the Documentation site.
The name of the image file used
for the header. This file must be
located within the Images
folder.
The name of the large image file
used for the header. This file
must be located within the
Images folder.
http://kcura.com/relativity/
The URL for the help link in the
Portals/0/Documents/<RELEASE NUMBER>%20- user drop-down menu.
Documentation%
20Help%20Site/index.htm
#Relativity Online Help/Documentation
Site/Welcome.htm
Name
HTMLEditorToolbar
ImageExportThreshold
Section
Value
kCur[[ 'fontname', 'space','fontsize',
a.Web.UI.WebControls 'space','formatblock',
'space','bold', 'italic', 'underline',
'separator','strikethrough',
'subscript', 'superscript',
'separator','copy', 'cut', 'paste',
'space', 'undo', 'redo' ],
[ 'justifyleft', 'justifycenter',
'justifyright', 'justifyfull',
'separator', 'orderedlist',
'unorderedlist', 'outdent', 'indent',
'separator','forecolor',
'hilitecolor', 'textindicator',
'separator','inserthorizontalrule',
'createlink', 'insertimage',
'inserttable']]
Relativity.Core
300
ImageOnTheFlyJobPriorityDefault
Relativity.Core
1
ImageQCOnByDefault
kCura.ImagingSetEventHandlers
False
Relativity | Configuration Table Guide - 35
Description
Sets the Relativity API token
expiration in minutes.
The amount of time, in seconds,
that the TIFNative manager
waits for a single document to
be imaged before killing the imaging process and moving to the
next document.
The default priority for all
Image-on-the-fly jobs.
The checkbox that prompts to
Hide Images for QC Review
when imaging documents in an
Imaging Set defaults to checked
if this value is set to True.
Name
ImageViewerBufferSize
Section
kCura.EDDS.Web
Value
10485760
ImagingJobPriorityDefault
Relativity.Core
100
ImportBatchSize
Relativ2000
ity.StructuredAnalytics
InitialNumberOfViewableDocuments
Relativity.Core
Relativity | Configuration Table Guide - 36
1000
Description
The maximum number of bytes
that the ImageViewer preloads
into memory.
The default priority for all Imaging jobs, excluding Image-onthe-fly jobs.
The batch size used by Structured Analytics agents when
pulling document information
from the Analytics staging web
service and pushing it into
Relativity. Changing this value
impacts performance.
The initial number of viewable
items on list pages. This is the
value in the “First xxx” dropdown menu on the bottom of
list pages.
Name
Instance
Section
Value
kCura.LicenseManager UNSETINSTANCE
KeyboardShortcutsDefault
kCura.EDDS.Web
LargeExtractedTextMaximumSize
Relativ157286400
ity.StructuredAnalytics
LazyLoadHighlightSets
kCura.EDDS.Web
Relativity | Configuration Table Guide - 37
True
True
Description
In the Case User Rollup report,
this value is used as a prefix for
the Case User ID and Usage ID
columns. In the Case Statistics
Rollup report, this value is used
as a prefix in the Usage ID, Case
ID, and name columns. It's used
to populate the Instance
column in the Case Statistics Rollup report.
Modifying the instance name by
updating this value immediately
invalidates your Relativity and
Processing licenses.
For new users, this value
determines the default value for
Enabling Keyboard Shortcuts.
The maximum acceptable size,
in bytes, of extracted text sent
to Relativity Analytics. If
extracted text exceeds this size,
the job fails to run and an error
message appears. You must
remove the flagged document
(s) from your saved search
before running the job.
This value defaults to 157286400
bytes because Analytics doesn't
reliably handle extracted text
larger than this size.
To enable selective loading of
Name
Section
Value
LDFDirectory
kCura.EDDS.SqlServer
C:\Logs\
LegacyAuditCutoff
kCura.EDDS.Web
7/23/2008 3:16:57 PM
LockoutNotificationList
kCura.LicenseManager [email protected];
[email protected]
LogOutLogo
kCura.EDDS.Web
LongRunningQueryTimeout
kCura.AssistedReview
3600 (seconds)
LongRunningQueryTimeout
kCura.Data.RowDataGateway
6000
LongRunningQueryTimeout
Relativ120
ity.StructuredAnalytics
Relativity | Configuration Table Guide - 38
Description
persistent highlight sets, this
must be manually added and
set to True.
The path to the log file directory
used by SQL Server. This value
should be relative to the server
where SQL Server is installed.
The date that the environment
was upgraded to 4.20. It's used
within messages explaining to
the user that audit framework
changed.
Distribution list for emails warning of a Case Statistics-based or
license-based lockout
The name of the image file used
for the LogOut Page. This must
be located within the Images
folder.
The timeout value, in seconds,
used by the long-running Assisted Review queries.
This is used in various places in
the system to time out queries
that run for a significant length
of time, and potentially lock an
associated table.
The timeout value, in seconds,
associated with running queries
related to structured data analytics.
Name
MassActionUpgradeBatchAmount
Section
kCura.EDDS.Web
Value
1000
MassCleanseBatchAmount
kCura.EDDS.Web
1000
MassCopyBatchAmount
kCura.EDDS.Web
100
MassCreateBatchSize
kCura.Relativity
500
MassCreateWordIndexBatchAmount kCura.EDDS.Web
1000
MassCustomBatchAmount
kCura.EDDS.Web
1000
MassDeleteBatchAmount
kCura.EDDS.Web
100
Relativity | Configuration Table Guide - 39
Description
The number of workspaces per
batch when you run an Edit Priority, Retry Upgrade, or Cancel
Upgrade mass operation on the
Workspace Upgrade queue.
The number of documents per
batch for the mass cleanse process.
Defaults to the currently configured value for MassDeleteBatchAmount, controls the
batch amount when copying
Dynamic Objects.
The number of artifacts per
batch for the mass create process of the Services API.
The number of documents per
batch for the mass create word
index process.
The number of items per batch
for custom mass operations.
This value controls the batch
sizes for all custom mass operations.
The number of documents per
batch for the mass delete process.
Name
MassDeleteBatchAmount
Section
kCura.Relativity
Value
100
MassEditBatchAmount
kCura.EDDS.Web
1000
MassExportBatchAmount
kCura.EDDS.Web
10000
MassImageBatchAmount
kCura.EDDS.Web
1000
MassImportSqlTimeout
Relativity.Data
60
MassMoveBatchAmount
kCura.EDDS.Web
1000
Relativity | Configuration Table Guide - 40
Description
The number of documents per
batch for the mass delete
process.
Note: The RelativityServices API
(RSAPI) does not currently
support the mass delete
operation. This means that the
RSAPI always performs a
deletion one artifact at a time,
regardless of the value for the
MassDeleteBatchAmount
configuration in the
kCura.Relativity section of the
table.
The number of documents per
batch for the mass edit process.
In processing, this is the number of errors that will be marked
as ignored or will be put into
retry tables at a time.
The number of documents per
batch for the mass export process.
The number of documents per
batch for the mass image process.
The timeout value, in seconds,
associated with long running
queries run by any form of mass
import - this includes image and
native.
The number of documents per
Name
Section
Value
MassProcessTranscriptBatchAmount kCura.EDDS.Web
1000
MassProduceBatchAmount
kCura.EDDS.Web
1000
MassRedactPopupDelay
Relativity.Core
3
MaxAnalyticsIndexIdleDays
kCura.EDDS.Agents
30
MaxArtifactBatchSizeForExecuteBatch kCura.Relativity
2000
MaxColumnsForMinWidth
20
kCura.EDDS.Web
Relativity | Configuration Table Guide - 41
Description
batch for the mass move process.
The number of documents per
batch for the mass transcript
process.
The number of documents per
batch for the mass produce process.
Determines the length of time
(in seconds) before the creating
redactions popup appears.
The number of days that an Analytics Index can remain idle
before the case manager agent
automatically disables it.
Maximum number of artifacts
that can be submitted to
ExecuteBatch in one batch.
Views with a column count
greater than this number are
assumed to be wider than the
display. This allows the system
to make optimizations that
drastically reduce lag time when
working with large views.
However, this may result in a
suboptimal user experience on
views with fewer columns.
Reduce this number if users
complain that their views are
freezing Internet Explorer.
Name
MaxErrorListItems
Section
Relativity.Data
Value
50000
MaximumActionsAllowedForRelativityScript
kCura.EDDS.Web
10
MaximumColumnsAllowedForRelativityScriptReport
kCura.EDDS.Web
7
MaximumDisplayCountForMultiPicker kCura.EDDS.Web
10
MaximumListPageTextLength
kCura.EDDS.Web
500
MaximumLongTextSizeForExportInCell
kCura.EDDS.WebAPI
1048576
Relativity | Configuration Table Guide - 42
Description
The maximum number of errors
that appear on the Error page.
For Relativity scripts, the maximum number of actions that
can be included in the script
body; 10 is the recommended
value.
For Relativity scripts, the maximum number of columns that
can be rendered when the script
runs as a report; 7 is the recommended value.
The maximum number of items
to display while editing multiobject and multi-choice fields.
The maximum number of characters that the item list display
for a text field.
During export, if the length of a
long-text cell (in characters)
exceeds this value, Relativity
pulls down a token instead of
the text for that cell. When the
Desktop Client comes across
that cell, it knows to make a separate call to pull down the text
for that cell.
Name
Section
MaximumNativeSizeForViewerInBytes kCura.EDDS.Web
Value
10485760
MaximumNumberOfImagesForExportChunk
MaximumPasswordAgeDefault
kCura.EDDS.WebAPI
10000
kCura.EDDS.Web
0
MaximumPasswordLength
kCura.EDDS.Web
50
MaximumTextVolumeForExportChunk
MaxInvalidLoginAttempts
kCura.EDDS.WebAPI
1048576
Relativity.Core
10
MaxListItems
Relativity.Data
1000
MaxNumberOfArtfactsToMassCreate kCura.Relativity
Relativity | Configuration Table Guide - 43
1000000
Description
The maximum size, in bytes, of a
native file that the Native Viewer
attempts to display. If a native
document exceeds this size, the
user will instead see a page
explaining that the document is
too large to be displayed.
The maximum number of
images, in total bytes, that
export in a single set.
When creating users, the
default value for the maximum
password age.
Controls the maximum user
password length allowance. This
value cannot be set to a value
greater than 50.
The maximum text, in total
bytes, that export in a single set.
The maximum number of login
attempts a user can make with a
given username before Relativity locks out that username.
The maximum number of items
that appear on the dtSearch/CA
error popups, the
batch/linked/search/relational
panes in the viewer, and the
error list at Home.
The maximum number of artifacts that can be submitted to
the MassCreate API function at
Name
Section
Value
MaxNumberOfArtfactsToMassEdit
kCura.Relativity
1000000
MaxPasswordHistory
Relativity.Core
5
MaxPDVQueryLength
Relativity.Core
60
MaxQueryConditionCharacterLength Relativity.Core
100000
MaxTreeviewChildNodes
Relativity.Core
1000
MinimumExcerptTextLength
kCura.AssistedReview
120
Relativity | Configuration Table Guide - 44
Description
a time.
The maximum number of artifacts that can be submitted to
the MassEdit API function at a
time.
Controls how many password
changes that Relativity checks
for duplicate passwords. Setting
this to a large value could prevent a user from ever using the
same password twice.
The timeout value, in seconds,
associated with running queries
related to displaying document
lists.
The maximum length of a criterion in the view criteria picker.
The maximum number of nodes
under a single parent node that
appear in the tree view. If the
number of child nodes is
exceeded, an error message
appears. This improves user
experience and avoids memory
issues within the browser.
The minimum number of characters required for a text excerpt
for designation and issues.
Name
MinimumPasswordLength
Section
kCura.EDDS.Web
Value
8
MinimumSeedInfluence
kCura.AssistedReview
25
MinimumSupportedIeVersion
kCura.EDDS.Web
8
MissedServerCheckInsBeforeAlert
Relativity.Core
3
Relativity | Configuration Table Guide - 45
Description
Controls the minimum user
password length requirement.
This value cannot be set to a
value less than 8.
The minimum number of documents required to be categorized by each example
document returned in an Assisted Review stratified sample.
This is only available if you add it
locally.
Lists the minimum version of IE
that is allowed to view Relativity. Relativity is designed for IE 8
or higher, and lowering this
value may result in a poor user
experience for users with IE7 or
below. Note: This value is not
meant for client modification
and dictates only which versions
of IE are supported. Changing
this value doesn't attempt
improve the user experience for
users with versions of IE lower
than 8.
Number of times that a server
can fail to check in with Relativity before the application generates an alert indicating that
the server is nonresponsive. The
ServerCheckInInterval configuration value specifies the
Name
Section
Value
OCRCompilationBatchSize
kCura.EDDS.Agents
100
OCRProcessingBatchSize
kCura.EDDS.Agents
1000
OCRWorkerBatchAmount
kCura.EDDS.Agents
100
OCRWorkerInsertBatchSize
kCura.EDDS.Agents
500
PasswordNotificationRelativityURL
kCura.Relativity
blank
PasswordResetMessageBody
kCura.EDDS.Web
Hello - The following Relativity
login information has
been set: - URL = {URL} UN = {EMAIL} - PW = {PASSWORD}
You should now be able to log in.
Remember, the password is
case sensitive. Thanks!
Relativity | Configuration Table Guide - 46
Description
time interval indicating how frequently the server must check
in with Relativity. See ServerCheckInInterval.See ServerCheckInInterval.
The number of updates to the
document table, with the
OCRed text, that the OCR Manager makes in a single transaction.
The number of items transferred from OCR_POP tables
into OCR_TEXT in a single batch.
The number of images a single
OCR worker agent pulls and
OCRs at a time.
The number of inserts to the
OCR Worker table that the OCR
Manager agent batches into a
single transaction.
The URL for Relativity used in a
password notification email
(used only by the API).
The password Reset Email message Text.
Name
PasswordReset
MessageSubject
PasswordResetRequestLimit
Section
kCura.EDDS.Web
Value
Relativity Login Information - {EMAIL}
Relativity.Data
10
PivotMaximumNumberOfColumns
Relativity.Data
100
PivotMaximumNumberOfRows
Relativity.Data
20000
PivotNumberOfRowsPerPage
kCura.EDDS.Web
15
PivotQueryTimeout
Relativity.Data
180
PrintImageWarningThreshold
kCura.EDDS.Web
500
ProcessingDiscoverJobPriorityDefault Relativity.Core
Relativity | Configuration Table Guide - 47
100
Description
The password Reset Email Subject Text.
Indicates the number (from 1050) of password reset requests
that an individual email address
can generate. After reaching this
number, the email address can't
receive any additional Reset
Password emails unless the user
clicks the link provided in the
email. After the Case Manager
agent runs again, the Reset Password emails resume. Until the
Case Manager agent runs, no
auditing is logged for the user.
The maximum number of
columns that appear in the
pivot.
This is the maximum number of
rows that appear in the pivot.
The default number of rows per
page in the pivot.
This is the timeout period, in
seconds, on the pivot query.
If a user attempts to mass print
and the number of images to be
printed exceeds this threshold,
a warning appears to let the
user know that they're attempting to print a large number of
documents.
The default priority for all Pro-
Name
Section
Value
ProcessingErrorRetrievalInitialBatchSize
Relativity.Core
1000
ProcessingErrorUpdateBatchSize
Relativity.Core
1000
ProcessingExportBatchSize
Relativity.Core
1000
ProcessingExportMaxThreads
Relativity.Core
4
ProcessingInventoryJobPriorityDefault
ProcessingPublishJobPriorityDefault
Relativity.Core
100
Relativity.Core
90
ProcessingRetryCount
Relativity.Core
3
Relativity | Configuration Table Guide - 48
Description
cessing Discover jobs.
The initial number of errors to
pull back from the processing
server in one call. If this fails, the
number is halved until it either
succeeds or fails in pulling back
one error.
The batch size used when
updating processing errors.
If this is set to a value higher
than 1,000 and you attempt to
republish a processing set that
contains 1,000 or more errors,
you will receive an agent error.
Retrying errors manually on the
Errors tab isn’t affected by this
issue.
The number of documents per
batch when importing documents during processing.
The number of threads used by
the Invariant worker to run publishing jobs. This value must be
1 or greater.
The default priority for all Processing Inventory jobs.
The default priority for all Processing Publish jobs.
The number of times to retry a
processing job before flagging
the job as Paused.
Name
ProcessingRetryTimerDuration
Section
Relativity.Core
Value
600
ProcessingSetStatusUpdateInterval
Relativity.Core
5000 (milliseconds)
ProcessingWebAPIPath
Relativity.Core
<blank>
Relativity | Configuration Table Guide - 49
Description
The amount of time, in seconds,
to wait until automatically retrying paused jobs.
The interval at which the processing set console updates the
status of the processing set.
The URL that directs to the Windows Authenticated Relativity
Web API endpoint used by processing. This URL is required for
processing and must be entered
by the Relativity Administrator.
Name
QueryCacheMode
Section
Relativity.Core
Value
SQLDependency
Description
QueryCacheMode controls the
type of SQL caching Relativity
uses.
Configuration value options:
SQLDependency – Uses
SQL Service Broker
n TimeBased – Caches data
in the SQL cache for 30
seconds
The preferred configuration
value is SQLDependency, as this
option notifies the web server in
the event SQL data is updated.
Since the TimeBased option
caches SQL data for 30 seconds,
data used by the web server
may be briefly outdated. You
can also enter a value of None,
but doing so results in no SQL
caching and denies those performance increases allowed by
either of the above values.
Because of this, we recommend
that you don't enter None.
Determines if the quick nav
search box displays.
Determines the maximum number of results displayed in quick
nav. The value must be a number between 2 and 50.
Determines if recent history
items appear.
n
QuickNavEnabled
Relativity.Core
True
QuickNavMaxResults
Relativity.Core
20
RecentHistoryEnabled
Relativity.Core
TRUE
Relativity | Configuration Table Guide - 50
Name
RecentHistoryNumberOfItemsDisplayed
Section
Relativity.Core
Value
10
Description
The number of recent history
items stored and displayed by
the favorites control if Recent
History is enabled.
RelativityInstanceURL
Relativity.Core
Blank string ("")
The URL identifying the protocol
and host name used for your
Relativity instance. For example,
you might use
https://kcura.com/ as the
instance URL for your
environment. The URL in this
configuration value can be used
by any Relativity applications
deployed in your environment,
which need to provide external
links to users. For example, this
value could be used by an
application that adds a link to a
Relativity application in an email
message.
RelativityScriptPickerViewID
kCura.EDDS.Web
902
RelativityServicesPath
Relativity.Core
Set during Relativity installation
Relativity | Configuration Table Guide - 51
Note: Don't use localhost as the
host name in this configuration
value.
The View ArtifactID of the Relativity Script Picker.
Indicates the URL for the Services API. This path is referenced
by event handlers and custom
pages. Procuro automatically
sets this value on installation.
Name
ReplaceCaseNameWithArtifactID
Section
kCura.Billing
Value
False
ReplaceUserNameWithHashValue
kCura.Billing
False
RepositoryVolumeMax
Relativity.Core
1000
RestrictedFileTypes
Relativity.Core
.exe;.html;.htm;.js
Relativity | Configuration Table Guide - 52
Description
If True, the Case Name in the
billing statistics report (generated either by manual run of
the Billing Statistics - User script
or by automatic run of the Case
Statistics Manager agent) is
replaced with the Case ArtifactID. By default, this is False,
and the Case Name appears.
Determines whether the user
name portions of user email
addresses are replaced with
hash values in billing information sent manually or sent
automatically through the
SMTP server. If True, all text preceding the @ symbol in each
user email address is replaced
with a unique hash value.
Domains remain unencrypted.
By default, this value is set to
False, and entire user email
addresses appear. If you manually run the billing script, the
value you select in the interface
overrides this configuration
value.
The maximum number of files
allowed in a repository case subdirectory.
A semicolon-delimited list of file
extensions, including dots, that
Name
Section
Value
RestrictedNativeFileTypes
Relativity.Core
HTML;HTM;EXE
Retries
kCura.AssistedReview
3
Retries
Relativ3
ity.StructuredAnalytics
RetryWaitTime
kCura.AssistedReview
Relativity | Configuration Table Guide - 53
30
Description
users are prohibited from
uploading to file fields (excluding
Custom Pages). For example: .exe;.html
See also ApplicationRestrictedFileTypes.
A semicolon-delimited list of file
types users are prohibited from
uploading to file fields (excluding
Custom Pages). These values
are regular expression enabled,
so custom validation behavior is
also supported.
Number of times agents retry
upon failure of a given operation. After retries are
exhausted, the project has an
error status; retries occur every
30 seconds by default.
Number of times agents retry
upon failure of a given Structured Analytics operation. After
retries are exhausted, the project has an error status; retries
occur every 30 seconds by
default.
The number of seconds
between Relativity's attempt to
retry errors.
Name
RSAConfigFilePath
Section
Relativity.Core
Value
%RelativityWebInstallDir%\RSA
RUMEnable
kCura.EDDS.Web
True
RUMEndpoint
kCura.EDDS.Web
https://rum-cloud.kcura.com:443/
RUMIdentifier
kCura.EDDS.Web
A000C182-52A6-417D-A279-BC24F365B20D
SamplingStatisticalPopulationResultsLimit
kCura.EDDS.Web
300
SearchAgentServicePort
Relativity.Core
6870
SearchCacheTableCreationTimeout
Relativity.Core
60
SearchIndexerLongRunningQueryTimeout
Relativity.Data
1200
Relativity | Configuration Table Guide - 54
Description
The location of the sdconf.rec
file and optional sdopts.rec file.
These files initialize the RSA library when RSA authentication is
configured.
Relativity User Metrics collects
click data if this value is set to
True.
The URL for data submission for
Relativity User Metrics.
Stores the GUID to identify an
instance for Relativity User Metrics.
The minimum number of items
in a data set required for statistical sampling to be valid.
Fewer items than the default
value constitutes an insufficient
population for reliable statistical
sampling and throws an error if
the user attempts to sample.
The default port which used by
the dtSearchAgent to service
search requests.
The timeout value, in seconds,
for the creation of a Search
Cache table.
The timeout value, in seconds,
associated with long running
queries run by dtSearch, CA,
and Domain Parsing.
Name
SearchIndexerMaxPopulationErrors
Section
Relativity.Data
Value
5000
SearchIndexerTextFromSQLChunkSizeInBytes
Relativity.Data
1048576
SendNotificationOnImportCompletion Relativity.Core
False
SendNotificationOnImportCompletionByDefault
ServerCheckInInterval
kCura.EDDS.Winform
False
Relativity.Core
60000 msec
ServerManagerRetries
kCura.EDDS.Agents
3
Relativity | Configuration Table Guide - 55
Description
The maximum number of errors
allowed for a single population
process in dtSearch or CA before
the job is terminated. If this
limit is reached, the respective
agent throws an exception saying that the failure limit has
been reached.
The size of the text chunks
streamed from SQL to either the
dtSearch or CA agents when
they are writing large files to
disk. Increasing this value may
improve performance when populating large files. The larger this
value becomes, the greater the
chance that either the dtSearch
or CA agent will run out of
memory.
Determines whether an email is
sent to the user running the
import upon completion.
The default value for sending a
notification to the user uploading data.
Time interval (in milliseconds)
used to indicate how frequently
a server must check in with
Relativity.
Number of attempts made by
the Server Manager agent to
connect to a server before it
Name
Section
Value
ServicesAPIBaseUriOnAgentServers
kCura.Relativity
net.pipe://localhost/
SerkCura.Relativity
vicesAPIHostingOnAgentServersMode
SelfHosting
ServicesAPIHostingOnAgentServersPredefinedURL
kCura.Relativity
http://localhost:9997/
Relativity.Services/
ServicesAPIMetadataPortOnAgentServers
SessionTimeoutDelay
kCura.Relativity
6867
kCura.EDDS.Web
90000
ShowDeobfuscateTool
kCura.EDDS.Web
False
Relativity | Configuration Table Guide - 56
Description
sets the server inactive.
Base URI for the self-hosted Services API on agent servers. Use
the following format:
net.pipe://localhost/.
Determines how agents access
the Services API in a Relativity
environment. Available Values
include SelfHosting and PredefinedURL.
The URL that agents use to
access the Services API server
when ServicesAPIHostingOnAgentServersMode is set
to PredefinedURL.
TCP port used by the metadata
endpoint of the self-hosted Services API on agent servers.
Relativity issues a warning
before a user’s session expires.
This value is the amount of
time, in milliseconds, that the
user receives the warning before
the session expires.
If False, the deobfuscate tool
won't appear.
Name
ShowForgotPasswordLink
Section
kCura.EDDS.Web
Value
False
ShowStackTraceOnError
kCura.EDDS.Web
True
SMTPPort
kCura.Notification
25
SMTPServer
kCura.Notification
blank
SMTPUserName
kCura.Notification
blank
SqlServerLDFDirectory
Relativity.Data
During Relativity installation
Relativity | Configuration Table Guide - 57
Description
If True, displays the "Forgot
your password?" link on the
Relativity login screen, allowing
users to reset their own passwords.
If True, full stack traces display
to users when an error occurs.
The port used for SMTP transactions. The default value can
be changed to another port
based on the setup of the SMTP
server in your environment. It
must be an integer value.
The SMTP server used to send
notifications. The default value
should be updated with a setting appropriate for your environment.
The username associated with
the credentials of the SMTP
server. It's validated against the
SMTP authentication. The
SMTPUserName must be associated with the same account as
defined in EmailFrom.
The path to the log file directory
used by SQL Server. This value
should be relative to the server
where SQL Server is installed.
Name
SQLTimeout
Section
kCura.EDDS.Procuro
Value
7200
StatisticsOutputFileSizeLimit
Relativity.Core
512
SupportedVersions
X.X
SupportLinkHref
SyncExcludes
kCura.EDDS.TemplateManager
kCura.EDDS.Web
Relativity.Core
SystemArtifactCacheExpiration
Relativity.Core
blank
kCura.Sync.dll;
kCura.Sync.Utility.dll;
NullableTypes.dll;
itextsharp.dll
240 (minutes)
Description
The SQL timeout value used
when executing Procuro scripts.
This value is set in seconds.
The maximum size in of kilobytes (KB) for a file aggregated
by a Statistics event handler.
This file size is per event handler
in a given workspace. For
example, the Case Statistics
Manager collects data added to
this type of file.
The Relativity versions supported by the template manager.
The URL for the support link.
A list of system DLLs that exist in
the sync directory that should
not be recognized as syncs.
The number of minutes before
the system artifact cache for any
given workspace expires and
refreshes the next time it's
accessed.
If you're restoring archived databases into newly created workspaces, we recommend that
you reduce this value to 15 or 30
minutes.
Relativity | Configuration Table Guide - 58
Name
TallyBatchAmount
Section
kCura.EDDS.Web
Value
1000
TermsLinkHref
kCura.EDDS.Web
blank
TextExtractionTemporaryDirectory
Relativity.Core
blank
TitleText
kCura.EDDS.Web
Relativity
TrustedIPsForTokenLogin
kCura.EDDS.Web
empty
UserCanChangePasswordDefault
kCura.EDDS.Web
True
UserCanChangeSettingsDefault
kCura.EDDS.Web
True
UsePermissionsCaching
Relativity.Data
True
Relativity | Configuration Table Guide - 59
Description
The number of documents per
batch for the tally process.
The URL for the terms link. If this
isn't blank, every user must
agree to the disclaimer at least
once before logging into Relativity.
The temporary directory used
by the Text Extraction Manager.
If left blank, the default document directory for the case is
used.
The text of the header title
within Relativity.
The comma-delimited list of trusted IP addresses for logging into
Relativity with an authentication
token.
When creating a user, the
default value for the User Can
Change Password option.
When creating a user, the
default value for the User Can
Change Settings option.
Determines the mechanism for
checking user permissions. If set
to true, Relativity uses a permissions caching mechanism to
improve performance by minimizing calls to the SQL database. If set to false, Relativity
makes a database call when per-
Name
Section
Value
UsePermissionsCachingSeconds
Relativity.Data
30
ViewableDocumentsIncrementCount Relativity.Core
5000
ViewQueryOptimization
Relativity.Core
True
ValidateAssemblyVersion
kCura.EDDS.WebAPI
x.x.*.*
Relativity | Configuration Table Guide - 60
Description
missions need to be checked.
The number of seconds
between the previous and next
cache refresh. If a change
occurred during this interval,
the refresh updates the access
rights that a user has to a
Relativity object.
The number of items that can
be added to the viewable set on
various list pages. It's the value
in the “Add next xxx” drop-down
menu on the bottom of various
lists. This has a functional maximum value of 10,000. This
means that even if the value in
the configuration table exceeds
10,000, the user will see Add
next 10,000 in the drop down
menu.
If set to True, this populates the
total documents in an Item List
view using one SQL query to generate the IDs of all items in the
list. This eliminates the need for
a second SQL query to get the
total count of documents.
Determines which parts of the
Relativity version number validate between the Desktop Client and the Relativity |
Configuration Table - 17 WebAPI
Name
Section
Value
Description
version. For example, given the
WebAPI version is 4.20.1.1 and
the Desktop Client is 4.20.1.2
*.*.*.* match
x.x.*.* match
n x.x.x.x do not match (the
last node between the
two is different)
n x.x.x.* match
n *.*.*.x do not match
The Web API path that the
DBMT uses.
n
n
WebAPIPath
kCura.EDDS.DBMT
http://localhost/RelativityWebAPI/
WebAPIPath
kCura.EDDS.Web
During Relativity installation
WebClientBatchSize
Relativity.Core
1000
WebClientTimeout
kCura.EDDS.Web
3000
Relativity | Configuration Table Guide - 61
The WebAPI path for Relativity.
If you enter a full URL for this
value, the protocol must match
what is used in the browser. If
Relativity is set up to use either
HTTP or HTTPS, but not both,
you can enter a full URL. If
Relativity is set up to use both
HTTP and HTTPS, do not specify
the protocol in this value.
Determines the batch size for
mass creating and mass deleting
redactions within the web client
The value, in milliseconds, that
the web client components will
wait for a response when making a WebAPI call before assuming the request has timed out.
Name
WebClientMaximumRetries
Section
kCura.EDDS.Web
Value
2
WebClikCura.EDDS.Web
entNativeViewerCacheAheadMaxSizeInBytes
52428800
WebClientPerformanceLatencyTests
kCura.EDDS.Web
5
WebClientPerformanceLoggingInterval
kCura.EDDS.Web
300000
WebClientPopupDelay
kCura.EDDS.Web
3000
WebClientRedaction
Warning
kCura.EDDS.Web
False
WebClientLongTimeout
kCura.EDDS.Web
3000
WebClientValidateAssemblyVersion
kCura.EDDS.Web
x.x.x.x
Relativity | Configuration Table Guide - 62
Description
The maximum number of times
the web client attempts to make
a WebAPI call before throwing
an error.
The maximum size, in bytes, a
file can be to allow the Relativity
Web Client Native Viewer Cache
Ahead technology to cache it.
The number of latency tests performed by the Relativity web client when logging performance.
The amount of time, in milliseconds, between performance logging audits from
the Relativity web client.
Determines the length of time
(in milliseconds) before popups
appear when performing a long
running operation.
When set to True, a warning
appears if there is a 25x25 redaction on the page.
The value, in milliseconds, that
the web client components
waits for a response when making a potentially long running
WebAPI call before assuming
the request has timed out.
This value affects how the web
client manager determines
whether it needs to download
Name
Section
Value
Description
and install a new version of the
web client. For example, given
that Relativity is version 4.20.1.1
and the web client is 4.20.1.2:
n
n
n
n
n
*.*.*.* will not cause a
download/install
x.x.*.* will not cause a
download/install
x.x.x.x will cause a download/install (the last node
between the two is different)
x.x.x.* will not cause a
download/install
*.*.*.x will cause a download/install
2.1 Configuration values and UI display for Document Skip
The following rules apply to the DocumentSkipDefaultBehaviorDefault configuration value and UI display:
DocumentSkipDefaultBehaviorDefault (configuration value and UI
display for document skip field)
Enabled
Enabled
Disabled
Force Enabled
DocumentSkipDefaultBehaviorDefault
(configuration value)
True
False
Setting Ignored
Setting Ignored
Skip Default Preference
Field (UI display)
Skip
Normal
Normal (Read-only)
Skip (Read-only)
3 dtSearch default alphabet file text
Some of the characters in the alphabet file are not printable, so screenshots were used instead of the actual text.
Relativity | Configuration Table Guide - 63
[Letters] // Original letter, lower case, upper case, unaccented
0000
1111
2222
3333
4444
5555
6666
7777
8888
9999
AaAA
BbBB
CcCC
DdDD
EeEE
FfFF
GgGG
HhHH
IiII
JjJJ
KkKK
LlLL
MmMM
NnNN
Relativity | Configuration Table Guide - 64
OoOO
PpPP
QqQQ
RrRR
SsSS
TtTT
UuUU
VvVV
WwWW
XxXX
YyYY
ZzZZ
____
aaAa
bbBb
ccCc
ddDd
eeEe
ffFf
ggGg
hh H h
iiIi
jjJj
kkKk
llLl
Relativity | Configuration Table Guide - 65
mmMm
nnNn
ooOo
ppPp
qqQq
rrRr
ssSs
ttTt
uuUu
vvVv
wwWw
xxXx
yyYy
zzZz
[Hyphens]
[Spaces]
Ignore
[End]
CJKRanges = 2e80-ac00 ac00-d7af f900-faff fe30-fe4f
Relativity | Configuration Table Guide - 66
Proprietary Rights
This documentation (“Documentation”) and the software to which it relates (“Software”) belongs
to kCura Corporation and/or kCura’s third party software vendors. kCura grants written license
agreements which contain restrictions. All parties accessing the Documentation or Software must:
respect proprietary rights of kCura and third parties; comply with your organization’s license
agreement, including but not limited to license restrictions on use, copying, modifications, reverse
engineering, and derivative products; and refrain from any misuse or misappropriation of this
Documentation or Software in whole or in part. The Software and Documentation is protected by
the Copyright Act of 1976, as amended, and the Software code is protected by the Illinois Trade
Secrets Act. Violations can involve substantial civil liabilities, exemplary damages, and criminal
penalties, including fines and possible imprisonment.
©2015. kCura Corporation. All rights reserved. Relativity® and kCura® are registered trademarks
of kCura Corporation.
Relativity | Configuration Table Guide - 67
