PHOTEC
LED Catalogue 5
PHOTEC
Photec Lighting
Photec Lighting Limited is a specialist developer and supplier of
LED light fittings. Our product range is developed around high
performance branded LED chips from the world’s leading LED
manufacturers including Cree, Osram, Bridgelux, Philips, and Xicato.
Our product development teams based in the UK and Far East are
focused on ensuring our fittings meet with the high performance
requirements lighting consultants, electrical engineers and architects
demand. We strive for clarity in our published technical data and
ease of understanding from a specifier and installer point of view.
Our LED fittings have been specified and installed on projects
worldwide for clients including Hilton, Marriott, Pizza Hut, Carluccios,
Las Iguanas, Genting Casinos, Center Parcs, Whitestuff and
Lakeland.
Our catalogue and website show a selection from our extensive
range. For further information on all our products and services
please contact our UK head office on +44 (0)1420 475 429.
Contents
+44 (0)1420 475 429
Engines
1.0
Recessed downlights
2.0
Suspended/surface mounted fittings
3.0
Track mounted spotlights
4.0
Linear LED
5.0
Driver specification and wiring info
6.0
Emergency
7.0
www.photeclighting.com
TRAMSHED, SHOREDITCH:
PRO-STAR-LED-A
ARRAY-MX-LED
FLEXi-LED
BAR-LED
WHITESTUFF WILMSLOW:
MAXi-LED
ARRAY-M-LED
THE ROXY, LIVERPOOL:
PRO-STAR-LED-A
FLEXi-LED
BAR-LED
LIVERPOOL FC, HOSPITALITY SUITES:
MAXi-LED
ARRAY-MX-LED
FLEXi-LED
ROYAL OPERA HOUSE, COVENT GARDEN:
TRi-TECH-LED
ARRAY-MX-LED
GALVINS HARRODS, KNIGHTSBRIDGE:
ARRAY-MX-LED
HILTON METROPOLE, BRIGHTON:
PRO-STAR-LED-A
ARRAY-M-LED
LINi-LED
FLEXi-LED
AMBi-LED
HILTON OLYMPIA:
ACCi-LED
AMBi-LED
FLEXi-LED
LINi-LED
JITROIS, KNIGHTSBRIDGE:
PRO-STAR-LED-A
ARRAY-MX-LED
ARRAY-800-LED
THE KITCHEN STORE, BRIGHTON:
TRi-PIN-LED
ARRAY-MX-LED
LEON, KINGS CROSS STATION:
ARRAY-M-LED
PRO-STAR-LED
PRO-STAR-LED-A
TRi-PIN-LED
ORIEL, HEATHROW TERMINAL 3:
ARRAY-M-LED
MAXi-LED
FLEXi-LED
LAS IGUANAS, CARDIFF:
PRO-STAR-LED-A
ARRAY-M-LED
TRi-TECH-LED
ACCi-LED-A
FLEXi-LED
MAXi-LED
LINi-LED
PIZZA HUT, ABERDEEN:
PRO-STAR-LED-A
TRi-TECH-LED
ARRAY-M-LED
FLEXi-LED
MAXi-LED
LINi-LED
EVERYMAN CINEMAS, LEEDS:
PRO-STAR-LED-A
ARRAY-MX-LED
LINi-LED
FLEXi-LED
AMBi-LED
TRi-PIN-LED
MINT CASINO, SOUTHAMPTON:
PRO-STAR-LED-A
TRi-TECH-LED
ARRAY-M-LED
ACCi-LED-A
FLEXi-LED
MAXi-LED
LINi-LED
PHOTEC
ASTRO-LED
Description
MR16 LED engine using the latest Bridgelux BXRA
LED technology to offer comparable light output to
a standard 35W MR16 halogen lamp. ASTRO-LED
uses a single deep set LED array in combination with
an aluminium reflector to create a smooth and focused
beam of light.
ASTRO-LED is available with driver as a retro fit solution
or as part of a complete fitting package.
Technical Details
Input:
350mA
Circuit Watts:
7W
Colour Temperature:
2700K
Lamp Lamp Lumen Output:
495lm
CRI:
80+
Beam Angle:
20° / 40°
Lamp Base:
N/A
Lifetime:
50,000+ hours
Dimmable:
Mains
IP Rating:
N/A
Warranty:
2 years
PART CODE
5045
20
27
00
Beam Angle
20o / 40o
Colour Temperature
2700K
Finish
N/A
Example Part Code: 5045-20-27-00
ASTRO-LED (5045) / 20° optics (20) / 2700K
colour temperature (27) / N/A finish (00).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9052
Mains
8.75W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
1.0
PHOTEC
ASTROPLUS-LED
Description
MR16 LED engine using the latest CREE MT-G2
LED technology to offer comparable light output
to a standard 75W IRC MR16 halogen lamp.
ASTROPLUS-LED uses a single deep set LED array
in combination with an optic to create a smooth
and focused beam of light.
ASTROPLUS-LED is available with driver as a retro
fit solution or as part of a complete fitting package.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
PART CODE
5075
24
27
350mA
15.1W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
00
Beam Angle
24o / 40°
Colour Temperature
2700K
Finish
N/A
Example Part Code: 5075-24-27-00
ASTROPLUS-LED (5075) / 24° optics (24) /
2700K colour temperature (27) / N/A finish (00).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9032
Mains
15.1W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
1.1
PHOTEC
ARRAY-M-LED
Description
LED Lamp using the latest CREE® MC LED technology
to offer comparable light output to a standard 50W
AR111 halogen lamp. The lamp has the same reflector
technology creating tight beam control and very low glare.
ARRAY-M-LED is available as a retrofit lamp with driver
or as part of a complete fitting and driver package. ARRAY-M-LED can be dimmed with the 9022 mains
dimmable driver, for more information please see the
9022 driver page.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base: Lifetime:
Dimmable:
IP Rating:
Warranty:
PART CODE
5015
20
28
700mA
8.5W
2850K
300lm
80+
20o
G53 Spade only
35,000+ hours
Mains
N/A
2 years
00
Beam Angle
20o
Colour Temperature
2850K
Finish
N/A
Example Part Code: 5015-20-28-00
ARRAY-M-LED (5015) / 20o optics (20) /
2850K colour temperature (28) / N/A finish
(00).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9022
Mains
10.75W
1 lamp
230V
700mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
1.2
PHOTEC
ARRAY-MX-LED
Description
LED Lamp using the latest CREE® MT-G LED
technology to offer comparable light output to a
standard 75W AR111 halogen lamp. The lamp has the
same reflector technology creating tight beam control
and very low glare.
ARRAY-MX-LED is available as a retrofit lamp with driver
or as part of a complete fitting and driver package. ARRAY-MX-LED can be dimmed with the 9032 mains
dimmable driver. For more information please see the
9032 driver page.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base: Lifetime:
Dimmable:
IP Rating:
Warranty:
PART CODE
5035
20
28
350mA
11W
2850K
550lm
80+
20o / 45o
G53 Spade only
35,000+ hours
Mains
N/A
2 years
00
Beam Angle
20o / 45o
Colour Temperature
2850K
Finish
N/A
Example Part Code: 5035/20/28/00
ARRAY-MX-LED (5035) / 20o optics (20) /
2850K colour temperature (28) / N/A finish (00).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9032
Mains
13.75W
1 lamp
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
1.3
PHOTEC
ARRAY-800-LED
Description
LED Lamp using the latest Luxeon LED technology
to offer comparable light output to a standard 100W
AR111 halogen lamp. The lamp has the same reflector
technology creating tight beam control and very low
glare.
ARRAY-800-LED is available as a retrofit lamp with driver
or as part of a complete fitting and driver package.
ARRAY-800-LED can be dimmed with the 9042 mains
dimmable driver, for more information please see the
9042 driver page.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base: Lifetime:
Dimmable:
IP Rating:
Warranty:
PART CODE
5055
20
28
450mA
15W
2800K
800lm
80+
20o / 45o
G53
35,000+ hours
Mains
N/A
2 years
00
Beam Angle
20o / 45o
Colour Temperature
2800K
Finish
N/A
Example Part Code: 5055/20/28/00
ARRAY-800-LED (5055) / 20o optics (20) /
2800K colour temperature (28) / N/A finish (00).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9062
Mains
19.5W
1 fitting
230V
450mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
1.4
PHOTEC
BASE-LED
Description
Recessed fixed MR16 LED downlight with a die-cast
aluminium body.
The BASE-LED uses the ASTROPLUS-LED engine
with the latest CREE MT-G2 LED technology in
combination with an optic which creates a clean
beam with minimal glare.
BASE-LED is also available with the lower output
ASTRO-LED engine upon request.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
04
15
350mA
15.1W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
Cutout: Ø72mm
PART CODE
5071
24
27
01
Beam Angle
24° / 40°
Colour Temperature
2700K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5071-24-27-01 BASELED (5071) / 24° optics (24) / 2700K colour
temperature (27) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9032
Mains
15.1W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.0
PHOTEC
BASE-LED-A
Description
Recessed adjustable MR16 LED downlight with a diecast aluminium body.
The BASE-LED-A uses the ASTROPLUS-LED engine
with the latest CREE MT-G2 LED technology in
combination with an optic which creates a clean
beam with minimal glare.
BASE-LED-A is also available with the lower output
ASTRO-LED engine upon request.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
04
15
350mA
15.1W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
Cutout: Ø82mm
PART CODE
5262
24
27
01
Beam Angle
24° / 40°
Colour Temperature
2700K
Finish
Example Part Code: 5071-24-27-01 BASELED-A (5262) / 24° optics (24) / 2700K colour
temperature (27) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9032
Mains
15.1W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.1
PHOTEC
MAG-LED
Description
Recessed fixed MR16 LED downlight with a die-cast
aluminium body and an integral anti-glare baffle.
The MAG-LED uses the ASTRO-LED engine with the
latest Bridgelux BXRA LED technology in combination
with a deep set reflector which creates a clean beam
with minimal glare.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty: 01
04
350mA
8.75W
2700K
495lm
80+
20° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
Cutout: Ø70mm
PART CODE
5031
20
27
04
Beam Angle
20o / 40o
Colour Temperature
2700K
Finish
White (01) / Silver (04)
Example Part Code: 5031-20-27-04
MAG-LED (5031) / 20° optics (20) / 2700K
colour temperature (27) / Silver finish (04).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9052
Mains
8.75W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.2
PHOTEC
MAG-LED-A
Description
Recessed adjustable MR16 LED downlight with a
die-cast aluminium body and an integral anti-glare baffle.
The MAG-LED-A uses the ASTRO-LED engine with the
latest Bridgelux BXRA LED technology in combination
with a deep set reflector which creates a clean beam
with minimal glare.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty: 01
04
350mA
8.75W
2700K
495lm
80+
20° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
Cutout: Ø70mm
Tilt: 25°
PART CODE
5152
20
27
04
Beam Angle
20o / 40o
Colour Temperature
2700K
Finish
White (01) / Silver (04)
Example Part Code: 5152-20-27-04
MAG-LED-A (5152) / 20° optics (20) / 2700K
colour temperature (27) / Silver finish (04).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9052
Mains
8.75W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.3
PHOTEC
PIN-LED
Description
Recessed fixed MR16 LED pinhole downlight with a
die-cast aluminium body and an integral anti-glare baffle.
The PIN-LED uses the ASTROPLUS-LED engine with
the latest CREE MT-G2 LED technology in combination
with an optic which creates a clean beam with minimal
glare.
PIN-LED is also available with the lower output
ASTRO-LED engine upon request.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty: 01
15
350mA
15.1W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
Cutout: Ø88mm
PART CODE
5162
24
27
01
Beam Angle
24o / 40°
Colour Temperature
2700K
Finish
White (01) / Black (15)
Example Part Code: 5162-24-27-01
PIN-LED (5162) / 24° optics (24) / 2700K
colour temperature (27) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9032
Mains
15.1W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.4
PHOTEC
PIN-LED-A
Description
Recessed fixed MR16 LED pinhole downlight with a
die-cast aluminium body and an integral anti-glare baffle.
The PIN-LED-A uses the ASTROPLUS-LED engine with
the latest CREE MT-G2 LED technology in combination
with an optic which creates a clean beam with minimal
glare.
PIN-LED-A is also available with the lower output
ASTRO-LED engine upon request.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty: 01
15
350mA
15.1W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
Cutout: Ø88mm
Tilt: 30°
PART CODE
5172
24
27
01
Beam Angle
24o / 40°
Colour Temperature
2700K
Finish
White (01) / Black (15)
Example Part Code: 5172-24-27-01
PIN-LED-A (5172) / 24° optics (24) / 2700K
colour temperature (27) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9032
Mains
15.1W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.5
PHOTEC
SLOT-LED-A
Description
Recessed fixed MR16 LED pinhole downlight with a
die-cast aluminium body and an integral anti-glare baffle.
The SLOT-LED-A uses the ASTROPLUS-LED engine
with the latest CREE MT-G2 LED technology in
combination with an optic which creates a clean beam
with minimal glare.
SLOT-LED-A is also available with the lower output
ASTRO-LED engine upon request.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty: 01
15
350mA
15.1W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
Cutout: Ø88mm
Tilt: 30°
PART CODE
5182
24
27
01
Beam Angle
24o / 40°
Colour Temperature
2700K
Finish
White (01) / Black (15)
Example Part Code: 5182-24-27-01
SLOT-LED-A (5182) / 24° optics (24) / 2700K
colour temperature (27) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9032
Mains
15.1W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.6
PHOTEC
PURE-LED
Description
Recessed fixed MR16 LED pinhole downlight with a
die-cast aluminium body and an integral anti-glare baffle.
The PURE-LED uses the ASTROPLUS-LED engine with
the latest CREE MT-G2 LED technology in combination
with an optic which creates a clean beam with minimal
glare.
PURE-LED is also available with the lower output
ASTRO-LED engine upon request.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty: 01
350mA
15.1W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Mains
N/A
2 years
Cutout: Ø75mm
PART CODE
5192
24
27
01
Beam Angle
24o / 40°
Colour Temperature
2700K
Finish
White (01)
Example Part Code: 5192-24-27-01
PURE-LED (5192) / 24° optics (24) / 2700K
colour temperature (27) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9032
Mains
15.1W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.7
PHOTEC
JET-LED
Description
IP65 recessed fixed LED showerlight with a die-cast
aluminium body and clear cover glass.
The Jet-LED uses the ASTRO-LED engine with the
latest Bridgelux BXRA LED technology in combination
with a deep set reflector which creates a clean beam
with minimal glare.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
350mA
8.75W
2700K
495lm
80+
20° / 40°
N/A
50,000+ hours
Mains
IP65
2 years
Cutout: Ø75mm
PART CODE
5202
20
27
01
Beam Angle
20o / 40o
Colour Temperature
2700K
Finish
White (01)
Example Part Code: 5202-20-27-01
JET-LED (5202) / 20° optics (20) / 2700K
colour temperature (27) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9052
Mains
8.75W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.8
PHOTEC
MINi-LED
Description
Recessed modular gimbal downlights with powder
coated die-cast aluminium bezel and gimbal heads.
The range is available in, single, double, triple and
quadruple lamp configurations each having 30° x 30°
adjustability for full flexibility.
The MINi-LED uses the ASTRO-LED engine with the
latest Bridgelux BXRA LED technology in combination
with a deep set reflector which creates a clean beam
with minimal glare.
Part Code: 5212 – Single Gimbal
Cutout: 98mm x 98mm Tilt: 30° x 30°
Technical Details
230V
8.75W per lamp
ASTRO-LED
N/A
Mains
IP20
2 years
Input:
Circuit Watts:
Lamp Type:
Lamp Holder:
Dimmable:
IP Rating:
Warranty:
Part Code: 5222 – Double Gimbal
Cutout: 188mm x 98mm Tilt: 30° x 30°
5212
PART CODE
20
27
04
Single Gimbal
5212
Double Gimbal
5222
Triple Gimbal
5232
Quadruple Gimbal
5242
Quadruple Gimbal Square 5252
Part Code: 5232 – Triple Gimbal
Cutout: 278mm x 98mm Tilt: 30° x 30°
Beam Angle
20o / 40o
Colour Temperature
2700K
Part Code: 5242 – Quadruple Gimbal
Cutout: 370mm x 98mm Tilt: 30° x 30°
Finish
White (01) / Silver (04)
Example Part Code: 5212-20-27-04
MINi-LED (5212) / 20° optics (20) / 2700K
colour temperature (27) / Silver finish (04).
Part Code: 5252 – Quadruple Gimbal Square
Cutout: 193mm x 193mm Tilt: 30° x 30°
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9052
Mains
8.75W
1 fitting
230V
350mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.9
PHOTEC
ACCi-LED
Description
Recessed fixed LED downlight with die-cast
aluminium heatsink, high purity aluminium darklight
reflector and powder coated aluminium bezel. The
low glare reflector makes this luminaire suitable
for use in a wide range of commercial and leisure
applications.
The ACCi-LED uses the lateset Bridgelux LED
technology.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
230V
9W
2850K
600lm
82
20o
35,000+ hours
Mains
IP20
2 years
Cutout: Ø75mm
PART CODE
5001
20
28
01
Beam Angle
20o
Colour Temperature
2850K
Bezel Finish
White (01)
Example Part Code: 5001-20-28-01
ACCi-LED (5001) / 20o optics (20) / 2850K
colour temperature (28) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9072
Mains
11W
1 fitting
230V
500mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.10
PHOTEC
ACCi-LED-A
Description
Recessed adjustable LED downlight with die-cast
aluminium heatsink, high purity aluminium darklight
reflector and powder coated aluminium bezel. The low
glare reflector makes this luminaire suitable for use in a
wide range of commercial and leisure applications.
The ACCi-LED-A uses the lateset Bridgelux LED
technology.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
230V
9W
2850K
600lm
82
20o
35,000+ hours
Mains
IP20
2 years
Cutout: Ø75mm
Tilt: 25o
PART CODE
5002
20
28
01
Beam Angle
20o
Colour Temperature
2850K
Bezel Finish
White (01)
Example Part Code: 5002-20-28-01
ACCi-LED-A downlight (5002) / 20o optics
(20) / 2850K colour temperature (28) / White
finish (01) .
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9072
Mains
11W
1 fitting
230V
500mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.11
PHOTEC
PRO-STAR-LED
Description
Recessed fixed downlight with a die-cast aluminium bezel. The PRO-STAR-LED uses the ARRAY-800-LED with
the latest Luxean LED technology to offer comparable
light output to a standard 100W AR111 halogen lamp.
The lamp has the same reflector technology creating
tight beam control and very low glare.
PRO-STAR-LED can also be used with the Array-M
or Array-MX lamps, see page 1.0/1.1 for details.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
04
15
230V
19.5W
2850K
800lm
80+
20o / 45o
35,000+ hours
Mains
IP20
2 years
Cutout: Ø135mm
PART CODE
5061
20
28
04
Beam Angle
20o/ 45o
Colour Temperature
2850K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5061-20-28-04
PRO-STAR-LED downlight (5061) / 20o optics
(20) / 2850K colour temperature (28) / Silver
finish (04).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9062
Mains
19.5W
1 fitting
230V
450mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
2.12
PHOTEC
PRO-STAR-LED-A
Description
Recessed adjustable downlight with a die-cast aluminium
bezel.
The PRO-STAR-LED-A uses the Array-800-LED with the
latest Luxeon LED technology to offer comparable light
output to a standard 100W AR111 halogen lamp. The
lamp has the same reflector technology creating tight
beam control and very low glare.
PRO-STAR-LED-A can also be used with the standard
output Array-M or Array-MX lamps, see pages 1.0/1.1
for details.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
04
15
230V
19.5W
2850K
800lm
80+
20o / 45o
35,000+ hours
Mains
IP20
2 years
Cutout: Ø163mm
Tilt: 35o
PART CODE
5092
20
28
04
Beam Angle
20o/ 45o
Colour Temperature
2850K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5092-20-28-04
PRO-STAR-LED-A downlight (5092) / 20o
optics (20) / 2850K colour temperature (28) /
Silver finish (04).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9062
Mains
19.5W
1 fitting
230V
450mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
2.13
PHOTEC
MAXI-LED
Description
Recessed modular gimbal downlights with powder
coated die-cast aluminium bezel and gimbal heads.
The range is available in, single, double, triple and
quadruple lamp configurations each having 30° x 30°
adjustability for full flexibility.
The MAXi-LED uses the latest Luxeon LED technology
to offer comparable light output to a standard 50W
AR111 halogen lamp. The lamp has the same reflector
technology creating tight beam control and very low
glare.
Part Code: 5102 – Single Gimbal
Cutout: 165mm x 165mm. Tilt: 30° x 30°
MAXi-LED can also be used with the standard
output Array-M or Array-MX lamps, see pages
1.0/1.1 for details.
Part Code: 5112 – Double Gimbal
Cutout: 325mm x 165mm. Tilt: 30° x 30°
Technical Details
Input: Circuit Watts:
Lamp type:
Lamp holder:
Dimmable:
IP Rating:
Warranty:
Part Code: 5122 – Triple Gimbal
Cutout: 485mm x 165mm. Tilt: 30° x 30°
230V
19.5W per lamp
ARRAY-800-LED
G53
Mains
IP20
2 years
For photometric data please see ARRAY-800-LED.
5102
PART CODE
20
28
04
Single Gimbal
5102
Double Gimbal 5112
Triple Gimbal 5122
Quadruple Gimbal 5132
Quadruple Gimbal Square 5142
Part Code: 5132 – Quadruple Gimbal
Cutout: 645mm x 165mm. Tilt: 30° x 30°
Beam Angle
20o / 45o
Colour Temperature
2850K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5102-20-28-01
MAXi-LED (5102) / 20° optics (20) / 2850K
colour temperature (28) / Silver finish (04).
Part Code: 5142 – Quadruple Gimbal Square
Cutout: 325mm x 325mm. Tilt: 30° x 30°
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9062
Mains
19.5W
1 fitting
230V
450mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
2.14
PHOTEC
TURBO-LED
Description
Recessed modular gimbal downlights with powder
coated die-cast aluminium bezel and gimbal heads.
The range is available in, single, double, triple and
quadruple lamp configurations each having 30° x 30°
adjustability for full flexibility.
Part Code: 5272 – Single Gimbal
Cutout: 165mm x 165mm. Tilt: 30° x 30°
Part Code: 5282 – Double Gimbal
Cutout: 325mm x 165mm. Tilt: 30° x 30°
Part Code: 5292 – Triple Gimbal
Cutout: 485mm x 165mm. Tilt: 30° x 30°
The TURBO-LED uses the latest OSRAM LED
technology to offer comparable light output to
a standard 35W metal halide lamp.
Technical Details
Input: Circuit Watts:
Lamp Lumen Output:
Lamp type:
Lamp holder:
Dimmable:
IP Rating:
Warranty:
PART CODE
230V
26W per lamp
3000lm
OSRAM COB
N/A
N/A
IP20
2 years
5272
30 27
04
Single Gimbal
5272
Double Gimbal 5282
Triple Gimbal 5292
Quadruple Gimbal 5302
Quadruple Gimbal Square 5312
Part Code: 5302 – Quadruple Gimbal
Cutout: 645mm x 165mm. Tilt: 30° x 30°
Beam Angle
30o
Colour Temperature
2700/3000/4000K
Finish
White (01) / Silver (04) / Black (15)
Part Code: 5312 – Quadruple Gimbal Square
Cutout: 325mm x 325mm. Tilt: 30° x 30°
Example Part Code: 5272-30-27-04
TURBO-LED (5272) / 30° optics (30) / 2700K
colour temperature (27) / Silver finish (04).
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
2.15
PHOTEC
TURBO-LED-R
Description
Circular version of the TURBO-LED downlight with
diecast bezel and aluminum reflector.
TURBO-LED-R is supplied as standard with a
nondimmable LED driver, for dimming options please
contact the sales office on +44 (0) 1420 475 429.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
04
15
230V
31W
2700K/3000K/4000K
2,000/3,000lm
80+
30°
N/A
50,000+ hours
Yes
IP20
2 years
Cutout: Ø135mm
PART CODE
5214
30
30
01
Beam Angle
30°
Colour Temperature
2700K / 3000K / 4000K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5214-30-30-01
TURBO-LED-R (5214) / 30°optics
(30) / 3000K colour temperature (30) /
white bezel finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9031
No
31W
1 fitting
230V
550mA
9200
DALI
29W
1 fitting
230V
550mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.16
PHOTEC
TURBO-LED-RA
Description
Adjustable circular version of the TURBO-LED
downlight with full gimbal mechanism for maximum
flexibility.
TURBO-LED-RA is supplied as standard with a
nondimmable LED driver, for dimming options please
contact the sales office on +44 (0) 1420 475 429.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
04
15
230V
31W
2700K/3000K/4000K
2,000/3,000lm
80+
30°
N/A
50,000+ hours
Yes
IP20
2 years
Cutout: Ø175mm
Tilt: 35°
PART CODE
5332
30
30
01
Beam Angle
30°
Colour Temperature
2700K / 3000K / 4000K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5332-30-30-01
TURBO-LED-RA (5332) / 30°optics
(30) / 3000K colour temperature (30) /
white bezel finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
9031
No
31W
1 fitting
230V
550mA
9200
DALI
29W
1 fitting
230V
550mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.17
PHOTEC
AMBi-LED
Description
Recessed fixed LED downlight with die-cast
aluminium heatsink, opal polycarbonate diffuser and
powder coated aluminium bezel. The opal diffuser
provides a wide light distribution and the built in
mains dimmable driver makes it ideal for retro fit
applications.
The AMBi-LED uses the latest CREE® LED
technology
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
01
230V
16W
3000K / 4000K
700lm
75+
Diffuse
35,000+ hours
Mains
IP20
2 years
Cutout: Ø175mm
PART CODE
5021
00
30
01
Beam Angle
00
Colour Temperature
3000K / 4000K
Finish
White (01)
Example Part Code: 5021-00-30-01
AMBi-LED downlight (5021) / diffuse optics
(00) / 3000K colour temperature (30) / White
finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
Integral
Mains
16W
1 fitting
230V
N/A
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.18
PHOTEC
SHOP-LED
Description
Recessed fully adjustable downlight using the latest
Osram PrevaLED module. The SHOP-LED versatility
makes it suitable for use in retail and commercial
environments.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Weight:
Warranty:
01
04
15
230V
32.5W
3000K
2499lm
80+
24° / 36°
N/A
50,000+ hours
No
N/A
2.15kg
2 years
Cutout: Ø152mm
PART CODE
5322
20
27
01
Beam Angle
24o / 36o
Colour Temperature
3000K / 4000K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5322-24-30-01
SHOP-LED (5322) / 24° optics (24) / 3000K
colour temperature (30) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
–
No
32.5W
1 fitting
230V
1A
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
2.19
PHOTEC
PANEL-LED
Description
LED panel using the latest Epistar LED technology along
with a PMMA diffuser to produce an even diffused light.
Panel LED is supplied as standard with a non-dimmable
LED driver, for dimming options please contact the
sales office on +44 (0) 1420 475 429.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
1200mA
40W
3000K/4000K
3,400lm
80+
Diffuse
N/A
35,000+ hours
Not as standard
IP40
2 years
Accessories
Suspension Kit:
6001-SUSP
The suspension kit includes 4, silver 1m suspension
wires complete with chromed ceiling fixing points.
PART CODE
6001
00
30
04
Beam Angle
Diffuse optics
Colour Temperature
3000K / 4000K
Finish
Silver Bezel
Example Part Code: 6001-00-30-04
PANEL-LED (6001) / diffuse optics
(00) / 3000K colour temperature (30) /
silver bezel finish (04).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
Included with Panel
No
40W
1 fitting
230V
1200mA
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
2.20
PHOTEC
TRAY-LED
Description
Suspended twin gimbal with a powder coated
folded steel body. The gimbal mechanism allows full
adjustability and the long lamp life makes this luminaire
suitable for use in a wide range of commercial and
leisure applications.
TRAY-LED uses the ARRAY-800-LED lamp with the latest
Luxeon LED technology to offer comparable light output
to a standard 100W AR111 halogen lamp. The reflector
technology is the same as the standard halogen AR111
lamp creating tight beam control and very low glare.
MAXi-LED can also be used with the standard
output Array-M or Array-MX lamps, see pages
1.0/1.1 for details.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
230V
2 x 19.5W
2850K
2 x 800lm
80+
20o / 45o
35,000+ hours
Mains
N/A
01
04
15
PART CODE
5072
20
28
04
Beam Angle
20o / 45o
Colour Temperature
2850K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5072-20-28-04
TRAY-LED downlight (5072) / 20o optics (20)
/ 2850K colour temperature (28) / Silver finish
(04).
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
3.0
PHOTEC
TRi-TASK-LED
Description
Track mounted adjustable spotlight using the ASTROLED engine with the latest Bridgelux BXRA LED
technology in combination with a deep set reflector
which creates a clean beam with minimal glare.
Part Code: 5114
Technical Details
Part Code: 5114/SN
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
PART CODE
Part Code: 5084/D
230V
8.75W
2700K
495lm
80+
20° / 40°
N/A
50,000+ hours
Yes
N/A
5114
20
27
15
Beam Angle
20o / 40o
Colour Temperature
2700K
Part Code:
****/BD
Part Code:
****/SN
Finishes
White (01)
Silver (04)
Black (15)
Example Part Code: 5114-20-27-15/BD
TRi-TASK-LED (5114) / 20° optics (20) / 2700K
colour temperature (27) / Black finish (15) / (BD)
Barndoors.
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
4.0
PHOTEC
STAGE-LED
Description
STAGE-LED is a compact and versatile theatrical
spotlight which can be surface, BESA base or track
mounted. It is available with a colour gel holder or
barndoor attachments.
The STAGE-LED uses the ASTROPLUS-LED engine
with the latest CREE MT-G2 LED technology in
combination with an optic which creates a clean
beam with minimal glare.
Part Code: 5124
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Weight:
Part Code: 5124/FH
Accessories / Options
Barn Doors Part Code:
Filter Holder Part Code:
Surface Mount Version:
BESA Mount Version:
Part Code: 5124/BD
PART CODE
5124
24
27
230V
8W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Yes
N/A
****/BD
****/FH
****/SM
****/BESA
15
Beam Angle
24o / 40o
Colour Temperature
2700K
Finishes
White (01)
Silver (04)
Black (15)
Example Part Code: 5124-24-27-15/BD
STAGE-LED (5124) / 24°optics (24) / 2700K
colour temperature (27) / Black finish (15) /
(BD) Barndoors.
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
4.1
PHOTEC
CAST-LED
Description
CAST-LED is a small yet powerful LED spotlight
which can accept either an honeycombe louvre
or an anti-glare snoot.
The CAST-LED uses the ASTROPLUS-LED engine
with the latest CREE MT-G2 LED technology in
combination with an optic which creates a clean
beam with minimal glare.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Weight:
Accessories/Options
Honeycombe:
Black Snoot:
White Snoot: 01
15
PART CODE
5134
24
27
230V
15.1W
2700K
950lm
80+
24° / 40°
N/A
50,000+ hours
Yes
N/A
****/HC
****/BSN
****/WSN
01
Beam Angle
24o / 40o
Colour Temperature
2700K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5134-24-27-01
CAST-LED (5134) / 24°optics (24) /
2700K colour temperature (27) / white
bezel finish (01).
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
4.2
PHOTEC
TRi-PRO-LED
Description
Adjustable track spot with integral heatsink, spun aluminium
housing and ARRAY-800-LED low glare lamp. The integral
mains dimmable driver and ARRAY-800-LED lamp make
this track spot suitable for use in schemes that require low
glare and tight beam control.
The TRi-PRO-LED uses the ARRAY-800-LED with the latest
Luxeon LED technology to offer comparable light output to
a standard 100W AR111 halogen lamp. The lamp has the
same reflector technology creating tight beam control and
very low glare.
MAXi-LED can also be used with the standard
output Array-M or Array-MX lamps, see pages
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
230V
19.5W
2850K
800lm
80+
20o / 45o
35,000+ hours
Mains
IP20
2 years
01
04
15
PART CODE
5014
20
28
15
Beam Angle
20o / 45o
Colour Temperature
2850K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5014-20-28-15
TRi-PRO-LED trackspot (5014) / 20o optics
(20) / 2850K colour temperature (28) / Black
finish (15).
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
4.3
PHOTEC
TRi-ARC-LED
Description
Adjustable track spot with integral heatsink, spun aluminium
housing and ARRAY-800-LED low glare lamp. The integral
mains dimmable driver and ARRAY-800-LED lamp make
this track spot suitable for use in schemes that require low
glare and tight beam control.
The TRi-ARC-LED uses the ARRAY-800-LED with the
latest Luxeon LED technology to offer comparable light
output to a standard 100W AR111 halogen lamp. The
lamp has the same reflector technology creating tight beam
control and very low glare.
MAXi-LED can also be used with the standard
output Array-M or Array-MX lamps, see pages
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
230V
19.5W
2850K
800lm
80+
20o / 45o
35,000+ hours
Mains
N/A
2 years
01
04
15
PART CODE
5024
20
28
15
Beam Angle
20o / 45o
Colour Temperature
2850K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5024-20-28-15
TRi-ARC-LED trackspot (5024) / 20o optics
(20) / 2850K colour temperature (28) / Black
finish (15).
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
4.4
PHOTEC
TRi-TECH-LED
Description
Adjustable track spot with integral heatsink, spun aluminium
housing and ARRAY-800-LED low glare LED lamp. The
integral mains dimmable driver and low glare LEDAR111
lamp make this track spot suitable for use in schemes that
require low glare and tight beam control.
The Tri-TECH-LED uses the ARRAY-800-LED with the latest
Luxeon LED technology to offer comparable light output to
a standard 100W AR111 halogen lamp. The lamp has the
same reflector technology creating tight beam control and
very low glare.
MAXi-LED can also be used with the standard
output Array-M or Array-MX lamps, see pages
Technical Details
Input:
230V
Circuit Watts:
19.5W
Colour Temperature:
2850K
Lamp Lumen Output:
800lm
CRI:
80+
Beam Angle:
20° / 45°
Lifetime:
35,000+ hours
Dimmable:Mains
IP Rating:
N/A
01
04
15
PART CODE
5054
20
28
04
Beam Angle
20o / 45o
Colour Temperature
2850K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5054-20-28-04
Tri-TECH-LED (5054) / 20° optics (20) /
2850K colour temperature (28) /
Silver finish (04).
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
4.5
PHOTEC
TRi-PIN-LED
Description
Adjustable trackspot with integral heatsink, spun
aluminium housing and the ARRAY-800-LED low glare
lamp. The integral mains dimmable driver and low ARRAY800-LED lamp make this track spot suitable for use in
schemes that require low glare and tight beam control.
The TRi-PIN-LED uses the ARRAY-800-LED with
the latest Luxeon LED technology to offer comparable
light output to a standard 100W AR111 halogen lamp.
The lamp has the same reflector technology creating
tight beam control and very low glare.
MAXi-LED can also be used with the standard
output Array-M or Array-MX lamps, see pages
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
PART CODE
230V
19.5W
2850K
800lm
80+
20° / 45°
N/A
35,000+ hours
Mains
IP20
2 years
5084
20
28
15
Beam Angle
20o / 45o
Part Code:
****/BD
Part Code:
****/HC
Colour Temperature
2850K
Finishes
White (01)
Silver (04)
Black (15)
Polished Chrome (21)
Polished Copper (22)
Antique Brass (23)
Antique Bronze (24)
Example Part Code: 5084-20-28-15/BD
TRi-PIN-LED (5084) / 20° optics (20) / 2850K
colour temperature (28) / Black finish (15) / (BD)
Barndoors.
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
4.6
PHOTEC
POWER-LED
Description
Track mounted adjustable spotlight using the latest Gen2
Tridonic STARK LED module. The 180° of tilt and 355° of
makes the POWER-LED trackspot suitable for use in retail
and commercial environments.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Weight:
Warranty:
230V
65W
3000K
3850lm
80+
24° / 36°
N/A
50,000+ hours
On request
N/A
2.15kg
2 years
01
04
15
PART CODE
5094
24
30
01
Beam Angle
24o / 36o
Colour Temperature
3000K / 4000K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5094-24-30-01
POWER-LED (5094) / 24° optics (24) / 3000K
colour temperature (30) / White finish (01).
Driver Part Code
Dimming
Circuit Watts
Powers
Voltage
Output
–
No
54W
1 fitting
230V
1A
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
4.7
PHOTEC
WAVE-LED
Description
WAVE-LED is a track mounted fully adjustable spotlight
with a die-cast body and aluminium reflector.
WAVE-LED is supplied as standard with a nondimmable
LED driver, for dimming options please contact the
sales office on +44 (0) 1420 475 429.
Technical Details
Input:
Circuit Watts:
Colour Temperature:
Lamp Lumen Output:
CRI:
Beam Angle:
Lamp Base:
Lifetime:
Dimmable:
IP Rating:
Warranty:
230V
31W
2700K/3000K/4000K
2,000/3,000lm
80+
30°
N/A
50,000+ hours
Yes
IP20
2 years
01
04
15
PART CODE
5144
30
30
01
Beam Angle
30o
Colour Temperature
2700K / 3000K / 4000K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 5144-30-30-01
WAVE-LED (5144) / 30°optics (30) /
3000K colour temperature (30) / white
bezel finish (01).
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
4.8
PHOTEC
Three Circuit Track System
Description
The Photec lighting track can either be horizontally
suspended or surface mounted and used with all of
our luminaires. It is possible to mount the track vertically,
please check which luminaires can be mounted vertically
with the sales office.
A range of mounting and connection accessories are
available. Please see the options below. Each three
metre length track is supplied with a live and dead
end connector.
All components are available in black, white or silver.
Technical Details
Input: Number of circuits:
Dimensions
(cut to length on site):
IP Rating:
Weight per metre:
Warranty:
+44 (0)1420 475 429
230V
3
33 x 33 x 3000mm
N/A
1Kg/m
1 year
HT43M – 3m length of 3 circuit track
HT4-J03 – X connector
HT4-J01 – Flush track coupler
HT4-L01R – Live end feed
in right
HT4-L01L – Live end feed
in left
HT4-L02 – Track coupler
HT4-ECAP – Dead End
HT4-J05 – Flexible coupler
HT4-J09 – 3m Wire
Suspension Kit
HT4-J02R – 90° corner connector
earth inside
HT4-J02L – 90° corner connector
earth outside
HT4-J06 – 200mm-1100mm
Rigid Suspension Kit
HT4-J03R – T connector earth inside
HT4-J03L – T connector earth outside
HT4-101N – Surface
mounted mono-point
www.photeclighting.com
4.9
PHOTEC
FLEXi-LED
Description
Flexible linear LED tape with a flexible clear silicone
housing providing an IP65 rating. The flexibility and
IP rating make this product suitable for use in ceiling,
furniture and display details both in and outdoors.
Supplied in a 5m reel as standard with attached power
feed at both ends. Can be cut to length on site and
additional power feeds require a solder connection.
The FLEXi-LED uses the latest Epistar LED
technology.
Technical Details
Input: Circuit Watts:
Colour Temperature:
Lumen Output:
CRI:
Beam Angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
PART CODE
5023
12
26
Accessories
00
5023-FX
Fixing kit:
Beam Angle
120o
24V DC
14.4W/m
2200K / 2600K
900lm/m
70+
120o
35,000+ hours
1-10V
IP65
2 years
Colour Temperature
2200K / 2600K
The fixing kit includes 10 aluminium mounting clips and
5 extra end caps. Silicone Sealant is required to mount
extra end caps to retain IP rating.
Finish
N/A
Note: The LED tape can only be cut at 100mm centres
where indicated.
Example Part Code: 5023-12-27-00
FLEXi-LED tape (5023) / 120o optics (12) /
2600K colour temperature (26) / N/A finish
(00).
Once the tape has been cut additional end caps are
required to maintain an IP rating.
Driver Part Code
Dimming
Maximum Wattage
Powers
Voltage
Output
9073
see page 6.10
150W
2 reels
230V
24V
9103
see page 6.10
75W
1 reel
230V
24V
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429 www.photeclighting.com
5.0
PHOTEC
Bar-LED
Description
Modular linear LED luminaire with extruded aluminum
housing and clear resin encapsulation providing an
IP66 rating. The modules are supplied in groups
of ten as standard with 80mm of interlink cable to
allow the modules to be spaced accordingly within
any lighting detail. Custom module lengths can
be supplied on request.
40mm Pitch
160mm length: 5033
320mm length: 5043
Circuit Watts: 6.5W/m
Lumen Output: 460Lm/m
The Bar-LED uses our latest CREE LED technology.
A bus wire connection is required after every 40W
of load.
Technical Details
Input: Colour temperature:
CRI:
Beam angle:
Lifetime:
Dimmable:
IP Rating:
Warranty:
25mm Pitch
172mm length: 5053
322mm length: 5063
Circuit Watts: 10W/m
Lumen Output: 495Lm/m
5033
PART CODE
40mm pitch:
160mm length:
320mm length:
25mm pitch:
172mm length:
322mm length:
8.3mm pitch:
170mm length:
320mm length:
8.3mm Pitch
170mm length: 5073
320mm length: 5083
Circuit Watts: 21W/m
Lumen Output: 1416Lm/m
24V
2600K / 3000K / 5400K
80+
120­°
40,000+ hours
1-10V dimmable
IP66
2 years
12
26
00
5033
5043
5053
5063
5073
5083
Beam Angle
120o
Colour Temperature
2600K / 3000K / 5400K
Finish
N/A (00)
Output
Driver Part Code
Dimming
Maximum Wattage
Powers
Voltage
9033
See page 6.10
35W
4m of 40mm pitch
230V
24V
9103
See page 6.10
75W
7m of 40mm pitch
230V
24V
9033
See page 6.10
35W
3m of 25mm pitch
230V
24V
9103
See page 6.10
75W
5m of 25mm pitch
230V
24V
9033
See page 6.10
35W
1.5m of 8.3mm pitch
230V
24V
9103
See page 6.10
75W
2.5m of 8.3mm pitch
230V
24V
Please refer to LED and driver specification sheets for installation instructions
+44 (0)1420 475 429
www.photeclighting.com
5.1
PHOTEC
9001 15W 1050mA – Non Dimmable LED Driver
Technical details
Input Voltage: Output: Maximum Wattage: Dimming Protocol: Max No of Fittings: Dimensions: Weight: Lifetime: Max Dist From LED: IP Rating: Warranty:
230V
1050mA
15W
Switched
1
132 x 44 x 24mm
124g
35,000 hours
2m
IP20
2 years
Installation information
1. T
he 230V supply must be from a switched power source only & never dimmed. If a dimming system is being used please consult the
manufacturers instructions to ensure the system has been configured to switch the LED circuits.
2. The LED power supply cannot be located further than 2m from the LED luminaire.
3. The LEDs must not be hot wired as this can cause instant failure of all LED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.2
PHOTEC
9002 18W 1050mA – Mains Dimmable LED Driver
Technical details
Input Voltage: Output: Maximum Wattage: Dimming Protocol: Max No of Fittings: Dimensions: Weight: Lifetime: Max Dist From LED: IP Rating: Warranty: 230V
1050mA
18W
Leading and trailing edge.
1
113 x 44 x 28mm
108g
35,000 hours
2m
IP20
2 years
Installation information
1. The 230V mains supply can be dimmed with a number of architectural control systems. Please contact the sales office for more information.
2. The LED power supply cannot be located further than 2m from the LED luminaire.
3. The LEDs must not be hot wired as this can cause instant failure of all LED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.3
PHOTEC
9022 18W 700mA – Mains Dimmable LED Driver
Technical details
Input Voltage:
Output:
Maximum Wattage:
Dimming Protocol:
Max No of Fittings:
Dimensions:
Weight:
Lifetime:
Max Dist From LED:
IP Rating:
Warranty:
230V
700mA
18W
Leading and trailing edge
1
113 x 44 x 28mm
108g
35,000 hours
2m
IP20
2 years
Installation information
1. The 230V mains supply can be dimmed with a number of architectural control systems. Please contact the sales office for more information.
2. The LED power supply cannot be located further than 2m from the LED luminaire.
3. The LEDs must not be hot wired as this can cause instant failure of all lLED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.4
PHOTEC
9032 18W 350mA – Mains Dimmable LED Driver
Technical details
Input Voltage:
Output:
Maximum Wattage:
Dimming Protocol:
Max No of Fittings:
Dimensions:
Weight:
Lifetime:
Max Dist From LED:
IP Rating:
Warranty:
230V
350mA
18W
Leading and trailing edge
1
113 x 44 x 28mm
108g
35,000 hours
2m
IP20
2 years
Installation information
1. The 230V mains supply can be dimmed with a number of architectural control systems. Please contact the sales office for more information.
2. The LED power supply cannot be located further than 2m from the LED luminaire.
3. The LEDs must not be hot wired as this can cause instant failure of all lLED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.5
PHOTEC
9052 9W 350mA – Mains Dimmable LED Driver
Technical details
Input Voltage:
Output:
Maximum Wattage:
Dimming Protocol:
Max No of Fittings:
Dimensions:
Weight:
Lifetime:
Max Dist From LED:
IP Rating:
Warranty:
230V
350mA
9W
Leading and trailing edge
1
113 x 44 x 28mm
108g
35,000 hours
2m
IP20
2 years
Installation information
1. The 230V mains supply can be dimmed with a number of architectural control systems. Please contact the sales office for more information.
2. The LED power supply cannot be located further than 2m from the LED luminaire.
3. The LEDs must not be hot wired as this can cause instant failure of all lLED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.6
PHOTEC
9062 18W 450mA – Mains Dimmable LED Driver
Technical details
Input Voltage:
Output:
Maximum Wattage:
Dimming Protocol:
Max No of Fittings:
Dimensions:
Weight:
Lifetime:
Max Dist From LED:
IP Rating:
Warranty:
230V
450mA
18W
Leading and trailing edge
1
113 x 44 x 28mm
108g
35,000 hours
2m
IP20
2 years
Installation information
1. The 230V mains supply can be dimmed with a number of architectural control systems. Please contact the sales office for more information.
2. The LED power supply cannot be located further than 2m from the LED luminaire.
3. The LEDs must not be hot wired as this can cause instant failure of all lLED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.7
PHOTEC
9072 18W 500mA – Mains Dimmable LED Driver
Technical details
Input Voltage:
Output:
Maximum Wattage:
Dimming Protocol:
Max No of Fittings:
Dimensions:
Weight:
Lifetime:
Max Dist From LED:
IP Rating:
Warranty:
230V
500mA
18W
Leading and trailing edge
1
113 x 44 x 28mm
108g
35,000 hours
2m
IP20
2 years
Installation information
1. The 230V mains supply can be dimmed with a number of architectural control systems. Please contact the sales office for more information.
2. The LED power supply cannot be located further than 2m from the LED luminaire.
3. The LEDs must not be hot wired as this can cause instant failure of all lLED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.8
PHOTEC
9033 35W 24V – LED Driver
Technical details
Input Voltage:
Output:
Maximum Wattage:
Dimensions:
Lifetime:
Max Dist From LED:
IP Rating:
Warranty:
230V
24V
35W
148 x 40 x 30mm
40,000 hours
7m
IP20
2 years
Installation information
1. A maximum of 11 LINi-LED modules can be run from a 35W driver.
2. A maximum of 15 BAR-LED modules can be run from a 35W driver.
3. This driver can be used in conjunction with the Osram OT-DIM unit, please see page 6.8 for loading and wiring details.
4. T
he 230V supply must be from a switched power source only & never dimmed. if a dimming system is being used please consult the
manufacturers instructions to ensure the system has been configured to switch the LED circuits, the LEDs are dimmed by the 1-10V OT-DIM
unit if specified. If the 240V input voltage is dimmed then the LED modules and driver could be irreparably damaged.
5. The LED power supply cannot be located further than 7m from the first LED modules.
6. The LEDs must not be hot wired as this can cause intsant failure of all LED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429.
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.9
PHOTEC
9103 75W 24V – LED Driver
Technical details
Input Voltage:
Output:
Maximum Wattage:
Dimensions:
Lifetime:
Max Dist From LED:
IP Rating:
Warranty:
230V
24V
75W
180 x 60 x 35mm
40,000 hours
7m
IP20
2 years
Installation information
1. A maximum of 1, 5m length of FLEXi-LED can be run from a 75W driver.
2. A maximum of 20 LINi-LED modules can be run from a 75W driver.
3. A maximum of 25, 40mm pitch BAR-LED modules can be run from a 75W driver.
4. This driver can be used in conjunction with the Osram OT-DIM unit, please see page 6.10 for loading and wiring details.
5. T
he 230V supply must be from a switched power source only & never dimmed. if a dimming system is being used please consult the
manufacturers instructions to ensure the system has been configured to switch the LED circuits, the LEDs are dimmed by the 1-10V OT-DIM
unit if specified.
If the 230V input voltage is dimmed then the LED modules and driver could be irreparably damaged.
6. The LED power supply cannot be located further than 7m from the first LED modules.
7. The LEDs must not be hot wired as this can cause intsant failure of all LED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.10
PHOTEC
9073 125W 24V – LED Driver
Technical Details
Input Voltage:
Output:
Maximum Wattage:
Dimensions:
Lifetime:
Max Dist From LED:
IP Rating:
Warranty:
230V
24V
125W
220 x 70 x 40mm
40,000 hours
7m
IP20
2 years
Installation information:
1. A maximum of 1, 5m lengths of FLEXi-LED can be run from a 125W driver.
2. A maximum of 40 LINi-LED modules can be run from a 125W driver.
3. A maximum of 50, 40mm pitch BAR-LED modules can be run from a 125W driver.
4. This driver can be used in conjunction with the Osram OT-DIM unit, please see page 6.10 for loading and wiring details.
5. T
he 230V supply must be from a switched power source only & never dimmed. if a dimming system is being used please consult the
manufacturers instructions to ensure the system has been configured to switch the LED circuits, the LEDs are dimmed by the 1-10V OT-DIM
unit if specified.
If the 240V input voltage is dimmed then the LED modules and driver could be irreparably damaged.
6. The LED power supply cannot be located further than 7m from the first LED modules.
7. The LEDs must not be hot wired as this can cause intsant failure of all LED modules connected to the driver.
If in doubt please contact our helpline on 01420 475 429
Wiring Diagram
+44 (0)1420 475 429
www.photeclighting.com
6.11
PHOTEC
9083 1-10V Dimmable OT-DIM
Technical details
Input Voltage:
Output:
Maximum Wattage:
Dimming Protocol:
Max no of fittings:
OT-DIM Dimensions:
Weight:
Lifetime:
Max Dist From LED:
IP Rating:
24V
24V
120W
1-10V
See relevant product page
172 x 42 x 20mm
75g
40,000 hours
7m
IP20
Installation information
1. The OT-DIM unit can run a maximum load of 120W.
2. T
he 230V supply must be from a switched power source only & never dimmed. if a dimming system is being used please consult the
manufacturers instructions to ensure the system has been configured to switch the led circuits, the LEDs are dimmed by the 1-10V OT-DIM
unit. If the 230V input voltage is dimmed then the led modules and driver could be irreparably damaged.
3. The LED power supply cannot be located further than 7m from the first led modules.
4. The LEDs must not be hot wired as this can cause instant failure of all led modules connected to the driver.
If in doubt please contact our helpline on 01420 473 889.
Wiring diagram
+44 (0)1420 475 429
www.photeclighting.com
6.12
PHOTEC
LED Drivers
The table below shows the electrical details for each Photec LED driver. LED drivers have a high in-rush current
relative to their Circuit Watts and this means that the number of drivers per circuit is normally dictated by the in-rush
current and not the total load. If you are unsure about anything please contact technical on 01420 475 429 or via
email: [email protected].
Quantity per 6A MCB*
Quantity per 10A MCB*
Minimum
Maximum
Minimum
Maximum
0.02ms
4
24
4
30
1.12A
5.1ms
4
25
4
30
15-52V
1.02A
4.5ms
4
24
4
30
9W
6-26V
1.02A
4.5ms
1
4
1
4
450mA
18W
8-32V
1.2A
4.5ms
1
4
1
4
–
500mA
18W
9-36V
1.12A
5.1ms
4
25
4
30
9033
Linear LED
24V
35W
–
18A
0.4ms
1
4
1
4
9103
Linear LED
24V
75W
–
15A
0.02ms
1
4
1
4
Part number
Runs
Output
Maximum
wattage (w)
Forward
voltage (Vf)
In-rush
current (A)
Period
9002
ACCi-LED
1050mA
18W
3-18V
1.2A
9022
ARRAY-M-LED
700mA
18W
6-26V
9032
ARRAY-MX-LED
350mA
18W
9052
ASTRO-LED
350mA
9062
ARRAY-800-LED
9072
*These quantities are indicative only, please check the in-rush current and duration with the MCB / dimming control system supplier.
+44 (0)1420 475 429
www.photeclighting.com
6.13
PHOTEC
EM-LED
Description
EM-LED is a recessed emergency downlight suitable
for switchable maintained or non-maintained operation.
EM-LED is available with self-test mode, please add
the relevant suffix shown below to the part number
for self-test.
Technical Details
01
15
Input:
230V
Circuit Watts: 3W
Colour Temperature: 6000K
Lamp Lumen Output: 110lm
CRI:
N/A
Beam Angle: 110°
Lamp Base:
N/A
Lifetime:
50,000+ hours
Dimmable:
Yes
IP Rating: IP20
Weight:
600g
Emergency Duration: 3 hours
Operating Mode:Switchable Maintained/NonMaintained
Recharge Time: 24 hours
Ballast Lumen Output: 100%
Cutout: Ø40mm
PART CODE
7001
110
60
01
Beam Angle
110o
Accessories/Options
Self-Test Operation: ****/ST
Colour Temperature
6000K
Finish
White (01) / Black (15)
Example Part Code: 7001-120-60-01
EM-LED (7001) / 110° optics (120) / 6000K
colour temperature (60) / white bezel finish
(01).
+44 (0)1420 475 429
www.photeclighting.com
7.0
PHOTEC
EM-TRACK-LED
Description
EM-TRACK-LED is a track mounted non-maintained
emergency luminaire with an integral 3 hour battery
pack and inverter.
Technical Details
Input:
230V
Circuit Watts: 3W
Colour Temperature: 6000K
Lamp Lumen Output: 110lm
CRI:
N/A
Beam Angle: 110°
Lamp Base:
N/A
Lifetime:
50,000+ hours
Dimmable:
Yes
IP Rating: IP20
Weight:
600g
Emergency Duration: 3 hours
Operating Mode:Switchable Maintained/NonMaintained
Recharge Time: 24 hours
Ballast Lumen Output: 100%
01
15
PART CODE
7002
110
60
01
Beam Angle
110o
Colour Temperature
6000K
Finish
White (01) / Silver (04) / Black (15)
Example Part Code: 7002-120-60-01
EM-TRACK-LED (7002) / 110° optics (120) /
6000K colour temperature (60) / white bezel
finish (01).
+44 (0)1420 475 429
www.photeclighting.com
7.1
Copyright © 2011 Photec Lighting Ltd
Whilst every effort has been made to ensure this catalogue accurately reflects the products shown we are not responsible for printing errors, wrong dimensions, descriptions or
technical data. The company reserve the right to amend all products herein detailed, any time and without prior notice. Unauthorised reproductions and copies are prohibited.
PHOTEC
Photec Lighting Limited
Unit 45
Woolmer Way Industrial Estate
Bordon
Hampshire
GU35 9QE +44 (0)1420 475 429
[email protected]
www.photeclighting.com
