LED-T8 1200mm-22W

T8 1200mm LED Tube
22 W
FICHA TÉCNICA (1/5)
High brightness is one of the obvious features for the tubes.
High efficiency energy saving, energy saving 80% than
incandescent lamp, energy saving 70% than fluorescent
light.
Solid light source, strong vibration resistance, easy to transport and install, high safety.
Life span up to 35,000hours, the LED efficiently protected
by constant current power.
Fast response, no flicker, glare small,lit instantly reach full
luminous flux output.
Environmental protection, no ultraviolet rays, no infrared or
mercury and hazardous substance.
Novelty and fashion, close to the customers' needs and
feelings, into more technology elements and personalized
design, and leading the LED tube in the market.
Widely used for hotel, bar, corridor, commerce place,
museum, storeroom, the bathroom, restaurant, Exhibition
hall, Jewelry lighting and home lighting, etc
It stands for the trend of development of LED tube, and is
much popular around the world since it come out.
SPECIFICATION
Electric Parameter
Item Number
Power Consumption
Input Voltage
Input AC Current
Power Factor
Drive Mode
Start Time
Maximum Duty Cycle
Short Circuit Protection
Open Circuit Protection
Reverse Polarity Protection (RPP)
PC Cover
Safety Grade
www.expoled.com.mx
www.expomex.com
SJ-T8-22W-E120-DW
SJ-T8-22W-E120-NW
22W±1W
AC85-277V 50-60HZ
0.05A @ AC220V \50HZ
≥0.95
Constant current driver
≤2000ms
0.45
Yes
Yes
Yes
Clear/Milky/Strip Cover
Class II
GRUPO EXPOMEX - PRODUCTIVIDAD INTEGRAL, S.A. DE C.V.
Matriz – Monterrey, N.L. Isaac Garza 2423 Ote / Col. Obrera CP 64010 T: (81) 81-505-777 y 788
Sucursal – México, D.F. Río Álamo No 25 / Col. Argentina / Del. Miguel Hidalgo CP 11270 T: (55) 5527-9800 y 03
T8 1200mm LED Tube
22 W
FICHA TÉCNICA (2/5)
Optics Parameter
LED
LAMP
TAIWAN
Origin
22-24LM/led for White @ 50MA
21-23LM/led for White @ 50MA
LED Bright
4000-4500 K
5800-6500 K
LED Color Temperature
≥75%
≥75%
CRI
SMD3328 LEDs / 120pcs
LED Packing Type
50±2mA
Current / Whole Lamp
2400M±5%
2350LM±5%
Initial Brightness
115lm\W±5% Clear 100lm/W±5%-Milky 112lm\W±5% Clear 98lm/W±5%-Milky
Initial Light Efficiency
120°
Beam Angle
35000 Hours
LM70
Structure Parameters
Lamp Base
Lamp Body Type
Sheel Structure Material
Net Weight / Lamp
Isolation Grade
Packing Information
G13
Aluminium
Aluminium Body and PC
350 g/Tube
Isolation Level I
1pc/gift box
12pcs/carton
NW: 7.5kgs/ctn
GW: 8.0kgs
Carton Size: 1260*155*122mm
Three Years
Warranty
Reliability
Bump Test
Oscillate test
OK
OK
Environment Parameters
Working Temperature
Storage Temperature
Theoretical Lifespan at 25°C
-20°C - 40°C
-20°C - 60°C
35000H = 24years (≈4H/day)
* The lifespan will change according to the working temperature and working hours per day.
* Expoled reserves the right to improve the design details and materials as necessary.
www.expoled.com.mx
www.expomex.com
GRUPO EXPOMEX - PRODUCTIVIDAD INTEGRAL, S.A. DE C.V.
Matriz – Monterrey, N.L. Isaac Garza 2423 Ote / Col. Obrera CP 64010 T: (81) 81-505-777 y 788
Sucursal – México, D.F. Río Álamo No 25 / Col. Argentina / Del. Miguel Hidalgo CP 11270 T: (55) 5527-9800 y 03
T8 1200mm LED Tube
22 W
FICHA TÉCNICA (3/5)
THREE KINDS OF PC COVER
Clear Cover
Milky Cover
Strip Cover
Normal Labels
Energy Efficiency and Standard
PRINTING LABELS
Laser Printing
PACKING TUBES
1pc/gift box
12pcs/carton
NW: 7.5kgsGW: 8.0kgs
Carton Size: 1260*155*122mm
DIMENSION DIAGRAM
www.expoled.com.mx
www.expomex.com
GRUPO EXPOMEX - PRODUCTIVIDAD INTEGRAL, S.A. DE C.V.
Matriz – Monterrey, N.L. Isaac Garza 2423 Ote / Col. Obrera CP 64010 T: (81) 81-505-777 y 788
Sucursal – México, D.F. Río Álamo No 25 / Col. Argentina / Del. Miguel Hidalgo CP 11270 T: (55) 5527-9800 y 03
T8 1200mm LED Tube
22 W
FICHA TÉCNICA (4/5)
TEST REPORT (with Milky Cover)
APPLICATION
www.expoled.com.mx
www.expomex.com
GRUPO EXPOMEX - PRODUCTIVIDAD INTEGRAL, S.A. DE C.V.
Matriz – Monterrey, N.L. Isaac Garza 2423 Ote / Col. Obrera CP 64010 T: (81) 81-505-777 y 788
Sucursal – México, D.F. Río Álamo No 25 / Col. Argentina / Del. Miguel Hidalgo CP 11270 T: (55) 5527-9800 y 03
T8 1200mm LED Tube
22 W
FICHA TÉCNICA (5/5)
CONNECTING DIAGRAM
ATTENTION
According to the packing of the rated voltage in use,not too high or too low voltage in the
state of use.
Can't be installed in the combustible objects in use,no matter what the situation,lamps can
not covered by insulating matting or similar material.
LED lamp should not be used as a dimmer lighting places.
Make sure the light is powered off ,when you install or replace this lamps.
LED can't use optical instruments directly to watch, and level of 1M.
Banned in the outdoor and the rain into place using.
When found the Lamps work abnormal (from interest,Flash),please check the lamp holder
and lamp contact performance and the power supply voltage is normal or not,if normal,fault
is still not ruled out,need to replace the new lamps.
The shelf lift of products: 3years (from the date of sale).
WARNING
It is strictly prohibited to install LED tubes before take the starter,otherwise you will instantly
start high voltage let the LED tubes to burn out.
Please install the lamp at the suitable place.
Make sure the light is powered off when you install or clean this lamps.
For cleaning only use a dry, soft cloth; never use chemicals or water.
Do not touch the LED light when it is switched on.
Do not store or use this product in places with high temperature or high humidity.
Do not open the lamp, please ask the specific operation to repair if need.
No guarantee claims for the unit and no liability for any resulting personal damage or material damage will be accepted if the unit is used for other purposes than originally intended, if
it is not correctly connected or operated, if it is over-loaded or not repaired in an expert way
