MIRA square led
h
6" square trimmed recessed downlight made of die-cast
aluminium. Suitable for installation in plasterboard ceilings
3/16“ - 1". Trim finish available in powder coated white,
gray or black
202
Opal cover for uniform illumination and high light output
of up to 89 lm/W at 3500K or enhanced glare control
through optional microprismatic shielding achieving
dynamic 3D MIRAGE effect
Use of long life, 50,000 hour high efficient medium power
e LEDs at 80% lumen maintenance (LM 80) with 11W or
15W. Optional high output performance e2 LEDs with 22W
power consumption. Superior color temperature consistency
to a 3-step McAdams ellipse, available in 3000K/CRI >84 or
3500K/CRI >83
120V | 277V as standard universal input voltage and various
dimming options available
RANGE
MOUNTING
LAMPING
ELECTRICAL
SHIELDING
N652
_ _ _ _ - 125
_ _ _ - 07
_ _ _0
_ -7
_ _ _0
_ -_
FINISH SNOOT
-_
FINISH TRIM
-_
SERIES
INSTALLATION
NUMBER OF LAMPS
VOLTAGE
COVER
COLOR
COLOR
MIRA SQUARE LED
1 _ recessed
0 _ _ _ multi
7___ 1
20 | 277V UNV
TRIM
TYPE
DIMMING
O o
pal
P microprismatic
7 white
8 black
6 gray
7 white
8 black
_ 2 _ sheet rock
_ 7 _ _ LED white
SHAPE
LAMP
_ _ 5 SQUARE LED
_ _ 3 _ e LED 11W
_ _ 4 _ e LED 15W
_ _ 5 _ e2 LED 14W
71 _ _
72 _ _
7H _ _
7D _ _
no dimming
IM 0-10V
D
Hi-lume 3D (1%) 3-wire hot dim
H
i-lume 3D (1%) digital dim
COLOR
TEMPERATURE
_ _ 5 _ 3000K CRI >84
_ _ 7 _ 3500K CRI >83
DRAWING
ACCESSORY
WITHOUT MOUNTING SET
MOUNTING SET for plaster ceilling installation
WITH MOUNTING SET (must be ordered separately)
9 15/16"
5 15/16"
TYPE CODE
Mounting set
661-04200
5 15/16"
9 15/16"
5/16" flexible
conduit by XAL
3"
SHIELDING
O opal
P microprismatic
5 1/2"
O
P
FINISH
6
7
8
6 gray
7 white
8 black
