 Oracle Exadata Configura2on Assistant (OECA) for Exadata X5-­‐2 & X4-­‐8 Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | OECA for Exadata Overview X5-2 In-Memory
X5-2 EF OLTP
•  New database workloads require different compute to storage raIos •  ElasIc configuraIons allow users to incrementally expand compute and/or storage capacity as per their business needs •  Oracle Exadata ConfiguraIon Assistant (OECA) for Exadata facilitates scoping and analyzing elasIc configuraIons and reporIng environmental specificaIons 16x Database Servers
5 x HC Storage Servers
Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | 8x Database Servers
8x EF Storage Servers
New ElasIc X5-­‐2 ConfiguraIon in Detail X5-­‐2 Quarter Rack (EF or HC) •  Start with a Quarter Rack –  2 Database Servers –  3 Storage Servers •  Add DB or Storage servers (max 22 per rack) EF X5-­‐2 Database Servers –  Mix EF and HC storage servers in same rack –  No need for half rack upgrade, or full rack upgrade Extreme Flash •  Assembled with requested servers by Oracle High Capacity •  Standard Configura2ons also kept HC X5-­‐2 Storage Servers –  Or add servers incrementally at customer site –  Can add X5-­‐2 servers to older (v2 to x4) machines –  Eighth Rack, Quarter Rack, Half Rack, Full Rack –  Eighth to Quarter Upgrade (Compute, Storage, Both) Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | CreaIng Workload OpImized ConfiguraIons DB In-­‐Memory Machine 16 Database Servers + 5 High Capacity Storage Servers Extreme Flash OLTP Machine Data Warehousing Machine 8 Database Servers + 8 Extreme Flash Storage Servers 8 Database Servers + 14 High Capacity Storage Servers Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Other Database Machine Types Exadata Storage Expansion –  Specialized rack with only Exadata Storage Servers •  No database servers –  4 to 19 X5-­‐2 storage servers X4-­‐8 Database Machine –  2 to 4 8-­‐socket Xeon DB servers •  2TB to 6TB DRAM each –  3 to 14 X5-­‐2 storage servers –  For high-­‐end OLTP, large consolidaIon, in-­‐memory DB Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | Introducing OECA – Simplifying the ElasIc ConfiguraIon Planning Process •  OECA is an “Excel” Based Visual Basic applicaIon that will allow the user to rapidly plan Exadata ElasIc ConfiguraIon Scenarios •  Release Notes – Requires Microsoi Excel – Must enable Macros in Excel – Windows Only Support for Now – These training slides reflect a recent version of the tool but may appear differently than the latest version of the tool Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | CreaIng a Workload OpImized ConfiguraIon •  The following demonstraIon supports a planned Exadata X5-­‐2 Database In-­‐Memory Deployment DB In-­‐Memory Machine •  OECA for Exadata will produce a “visual” representaIon of the intended configuraIon •  The tool will also produce the Performance and Environmental CharacterisIcs for this configuraIon – Similar to what is done in the Exadata Datasheet for Full, Half, Quarter, Eighth Racks etc. 16 Database Servers + 5 High Capacity Storage Servers Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | CreaIng a Workload OpImized ConfiguraIon •  Step 1 – Launch ApplicaIon DB In-­‐Memory Machine – The Following Screen Appears 16 Database Servers + 5 High Capacity Storage Servers Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | CreaIng a Workload OpImized ConfiguraIon •  Step 2 – Select X5-­‐2 in the “SelecIon” Dropdown DB In-­‐Memory Machine Click X5-­‐2 or DB Machine and SER Click X4-­‐8 for 8 Socket Reset wipes the current Config Click 3 IB Switches to add a Spine. Min 2 Leafs required CalculaIons will appear once a legal configuraIon is selected 16 Database Servers + 5 High Capacity Storage Servers Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | CreaIng a Workload OpImized ConfiguraIon •  Step 3 – Increment the X5-­‐2 DB to 16 DB In-­‐Memory Machine DB Servers appear in the proper Uxx Rack locaIon and the proper order Note appears telling the user what to add to build a legal configuraIon 16 Database Servers + 5 High Capacity Storage Servers Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | CreaIng a Workload OpImized ConfiguraIon •  Step 4 – Increment X5-­‐2L HC to 5 DB In-­‐Memory Machine Memory, Storage and Number of Cores are calculated here Legal configuraIon achieved and calculaIons appear HC and/or EF Servers appear in the proper Uxx Rack locaIon and the proper order 16 Database Servers + 5 High Capacity Storage Servers Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | CreaIng a Workload OpImized ConfiguraIon •  Step 5 – Scroll to See the Environmental Report DB In-­‐Memory Machine 16 Database Servers + 5 High Capacity Storage Servers Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | CreaIng a Workload OpImized ConfiguraIon •  Step 6 – Scroll to See the Performance Report DB In-­‐Memory Machine 16 Database Servers + 5 High Capacity Storage Servers Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | OECA for Exadata Summary X5-2 In-Memory
X5-2 EF OLTP
•  Internal Tool to facilitate scoping and analyzing elasIc configuraIons and their environmental specs •  Supports X5-­‐2 DB Machine as well as Storage Server ElasIc ConfiguraIons •  Supports X4-­‐8 ElasIc ConfiguraIons •  Allows quick reporIng and analysis of Exadata Performance, Cores, Memory, Power, Cooling etc for a given configuraIon •  Visually demonstrates how the elasIc configuraIon will appear in the end system •  QuesIons? Contact Gurmeet Goindi at [email protected] 16x Database Servers
5 x HC Storage Servers
Copyright © 2014 Oracle and/or its affiliates. All rights reserved. | 8x Database Servers
8x EF Storage Servers
