1. Ingeniería

Mediseal Sealed Fitting - 600x600 - IP54/20
600x600 4x14W T5
4065451
Caracterisiticas de la gama
IP65 or IP54 to the lit space
IP54 or IP20 to the void area
No visible fixings unique concealed frame retention clips no screws
providing contamination traps
Aluminium frames fully welded and linished corner joints completely
sealed and robust
Non particulate shedding gasketry suitable for high specification clean
room applications
Suitable for prepared aperture and 15mm T bar ceiling systems
Designed around T5 lamp technology shallow depth to suit compacted
ceiling voids
Fully integral emergency facility
Optional LG3 compliant louvre
HF gear as standard with optional dimming
600mm x 600mm 4 x 24W T5 available on request
DESCRIPCIÓN DEL PRODUCTO
Núm ero de orden
4065451
Código EAN
5026524654517
Certificaciones
F-mark
Montaje
Ceiling recessed
Carcasa
Aluminium
LOR (%)
52
Tensión (V)
230
Lám paras
4 x 14W T16 G5
Color
White
Clasificación IP
20 54
© Havells Sylvania
|
Date Printed: 26 Jan 2015
|
Data Last Updated: 01 Dec 2014
Page 1 of 5
Mediseal Sealed Fitting - 600x600 - IP54/20
600x600 4x14W T5
4065451
TABLA DE DATOS
Datos generales
Núm ero de orden
4065451
Código EAN
5026524654517
FI del núm ero electrónico
4327100
Certificaciones
F-mark
Montaje
Ceiling recessed
Descripción larga
IP65 or IP54 to the lit space. IP54 or IP20 to the void area. No visible fixings
unique concealed frame retention clips no screw s providing contamination
traps. Aluminium frames fully w elded and linished corner joints completely
sealed and robust. Non particulate shedding gasketry suitable for high
specification clean room applications. Suitable for prepared aperture and
15mm T bar ceiling systems. Designed around T5 lamp technology shallow
depth to suit compacted ceiling voids. Fully integral emergency facility. Optional
LG3 compliant louvre. HF gear as standard w ith optional dimming. 600mm x
600mm 4 x 24W T5 available on request
Nom bre del producto
600x600 4x14W T5
Disponibilidad de sistem a de control
Included
Montaje del sistem a de control
Integral
Tipo de sistem a de control
Electronic
Entorno
Interior
Aplicación general
Health care
Carcasa
Aluminium
Aplicación específica
Bathrooms, Cooking, Corridors, Entrance halls, Examination / Treatment,
Hospitals, Reception Areas, Show rooms, Stairw ell, Waiting room, Washrooms
Cantidad del paquete a la venta
1
Datos ópticos
LOR (%)
52
Tipo de distribución
Symmetric
Control de deslum bram iento
LG3
Datos eléctricos
Tensión (V)
230
Protección eléctrica
Class I
Lám paras
4 x 14W T16 G5
Núm ero de cabezales
1
Núm ero total de lám paras
4
© Havells Sylvania
|
Date Printed: 26 Jan 2015
|
Data Last Updated: 01 Dec 2014
Page 2 of 5
Mediseal Sealed Fitting - 600x600 - IP54/20
600x600 4x14W T5
4065451
Datos físicos
Peso (kg)
7.80
Color
White
Lám para incluida
No
Anchura (m m )
600
Longitud (m m )
600
Clasificación IP
20 54
Tipo de techo
Module 600x600
Longitud del recorte (m m )
572
Form a del recorte
Square
Profundidad de em potrado (m m )
70
Acabado del difusor
Clear prismatic
Material difusor
Acrylic
Em ergencia
Without
Single package dim ensions (L x W x H) (cm )
60.00 x 60.00 x 7.00
Outer package dim ensions (L x W x H) (cm )
60.00 x 60.00 x 7.00
© Havells Sylvania
|
Date Printed: 26 Jan 2015
|
Data Last Updated: 01 Dec 2014
Page 3 of 5
Mediseal Sealed Fitting - 600x600 - IP54/20
600x600 4x14W T5
4065451
FOTOMETRÍA
DIBUJOS TÉCNICOS
ETIQUETADO ENERGÉTICO
© Havells Sylvania
|
Date Printed: 26 Jan 2015
|
Data Last Updated: 01 Dec 2014
Page 4 of 5
Mediseal Sealed Fitting - 600x600 - IP54/20
600x600 4x14W T5
4065451
© Havells Sylvania
|
Date Printed: 26 Jan 2015
|
Data Last Updated: 01 Dec 2014
Page 5 of 5
