InVerto Pendant - Warm White
Inverto Pendant WW Eb Black
3090109
Caracterisiticas de la gama
16W (high efficiency) or 21W (high output) pendant luminaire only applies on integral driver version
Adjustable pendant cable (1.7m as supplied)
Integral or remote driver options
Can be used without glass for higher light output and different
optical appearance (Indoor use only)
4 standard colours: gloss black, matt white, satin silver and matt
rust
Freedom of installation - only applies on integral driver version:
350mA or 450mA LED driver, resulting in 16W and 21W
respectively 2 settings: High efficiency: 16W providing 955lm at
60lm/W High output: 21W providing 1,130lm at 54lm/W
Optional colour braided cables for contemporary aesthetic look
(IP21 rating)
Comes with a 40° beam as standard. Narrow beam kit available
as separate accessory
DESCRIPCIÓN DEL PRODUCTO
Tecnología
LED
Número de orden
3090109
Código EAN
8711971901099
Montaje
Ceiling pendant
Ángulo de haz (°)
40°
Temperatura de color (K)
3000
Tensión (V)
230-240
Lámparas
LED16W 914Lm / 21W 1113Lm Warm White
Color
Gloss Black
Lámpara incluida
Integrated LED
Clasificación IP
65
© Havells Sylvania
|
Date Printed: 29 Dec 2014
|
Data Last Updated: 10 Dec 2014
Page 1 of 5
InVerto Pendant - Warm White
Inverto Pendant WW Eb Black
3090109
TABLA DE DATOS
Datos generales
Tecnología
LED
Número de orden
3090109
Código EAN
8711971901099
SE del número electrónico
7500239
FI del número electrónico
4578936
Montaje
Ceiling pendant
Notas
Can be used without glass for higher light output and different optical
appearance (Indoor use only)
Descripción larga
16W (high efficiency) or 21W (high output) pendant luminaire - only applies on
integral driver version. Adjustable pendant cable (1.7m as supplied). Integral
or remote driver options. Can be used without glass for higher light output and
different optical appearance (Indoor use only). 4 standard colours: gloss
black, matt white, satin silver and matt rust. Freedom of installation - only
applies on integral driver version: 350mA or 450mA LED driver, resulting in
16W and 21W respectively 2 settings: High efficiency: 16W providing 955lm at
60lm/W High output: 21W providing 1,130lm at 54lm/W. Optional colour braided
cables for contemporary aesthetic look (IP21 rating). Comes with a 40° beam
as standard. Narrow beam kit available as separate accessory
Nombre del producto
Inverto Pendant WW Eb Black
Entorno
Exterior
Cantidad del paquete a la venta
1
Datos ópticos
Ángulo de haz (°)
40°
Temperatura de color (K)
3000
Tipo de distribución
Direct - Symmetric
Datos eléctricos
Tensión (V)
230-240
Corriente de transmisión (mA)
350mA/450mA
Lámparas
LED16W 914Lm / 21W 1113Lm Warm White
Número de cabezales
1
Disponibilidad del transformador
Included
Montaje del transformador
Integral
Número total de lámparas
1
© Havells Sylvania
|
Date Printed: 29 Dec 2014
|
Data Last Updated: 10 Dec 2014
Page 2 of 5
InVerto Pendant - Warm White
Inverto Pendant WW Eb Black
3090109
Datos físicos
Peso (kg)
1.43
Color
Gloss Black
Lámpara incluida
Yes
Lámpara incluida
Integrated LED
Clasificación IP
65
Emergencia
Without
Suspensión
1.7m pendant cable
Single package dimensions (L x W x H) (cm)
18.50 x 29.60 x 11.50
Outer package dimensions (L x W x H) (cm)
18.50 x 29.60 x 11.50
© Havells Sylvania
|
Date Printed: 29 Dec 2014
|
Data Last Updated: 10 Dec 2014
Page 3 of 5
InVerto Pendant - Warm White
Inverto Pendant WW Eb Black
3090109
FOTOMETRÍA
DIBUJOS TÉCNICOS
ETIQUETADO ENERGÉTICO
© Havells Sylvania
|
Date Printed: 29 Dec 2014
|
Data Last Updated: 10 Dec 2014
Page 4 of 5
InVerto Pendant - Warm White
Inverto Pendant WW Eb Black
3090109
© Havells Sylvania
|
Date Printed: 29 Dec 2014
|
Data Last Updated: 10 Dec 2014
Page 5 of 5
