Estas aplicaciones y
muchas más hazlas
funcionar con:
Product
Overview
www.sdicontrol.com | 8100-9100 en Monterrey
L.D. sin costo: 01 800 -777-9100
“Simplificar procesos, brindando
soluciones integrales, a través
de un servicio con valor”.
Con una amplia gama de productos, soporte técnico y compromiso con el
cliente. Formado por profesionales en diversas áreas pero con un mismo
objetivo: brindar soluciones.
Contamos con más de 10 años de experiencia, siendo proveedores de productos en automatización industrial, divididos en 2 áreas comerciales: Control & Automation y Conveyors & Material Handling. Cada una con personal
especializado y en constante capacitación para responder cuando nuestros
clientes lo necesitan.
Por esto, y con el constante apoyo de nuestras alianzas estratégicas brindamos no sólo precios competitivos, sino un conjunto de alternativas con el objetivo de ser su principal fuente en requerimientos de control y automatización.
Nuestra amplia gama de marcas incluye líderes a nivel mundial para procesos y aplicaciones destinados a un gran ramo de
industrias como Electrónica, Automotriz, Alimentos y bebidas, Manufactura, Productos de consumo, Farmacéutica, Plásticos,
entre otras:
Nos rige una fuerte cultura basada en los valores
de Compromiso, Honestidad, Servicio y Confianza.
Alimentamos un ambiente de trabajo, pasión y
confianza bajo el cual promovemos iniciativas de
innovación y servicio enfocadas a entender y sustentar las soluciones que brindamos a nuestros
clientes.
Control &
Automation
Sdi> Control & Automation
Tenemos todo el respaldo de cada marca que representamos para darte la mejor respuesta y asegurar el
éxito de tu sistema. Preferred Vendor por AutomationDirect y Premier Partner por Advantech, somos la única
empresa en México que cuenta con estas distinciones.
Ofrecemos una gran variedad de productos para sus aplicaciones, los cuales se incorporan con gran facilidad y en su mayoría son compatibles con otras plataformas.
Algunas de nuestras categorías:
Adquisición de Datos (DAQ) y Control
Bloques de Terminales
Botones/Interruptores/Indicadores
Cableado y Conectores
Circuitos de Protección/Fusibles
Cómputo Industrial
Comunicación Industrial
Control Basado en PC
Control de Motores
Control y Medición de Procesos
Controladores Lógicos Programables (PLC)
E/S Remotas
Fuentes de Poder
Gabinetes
Interfaces de Operador (HMI)
Laptops y Tablets Industriales
Monitores Industriales
Neumática
Relevadores/Temporizadores
Switches y módulos de Seguridad
Sensores/Encoders
Servomotores y Motores a pasos
Software
Tomas y Clavijas Industriales
Torretas
Transmisiones Mecánicas y Potencia
Variadores de Frecuencia
Te ofrecemos los siguientes beneficios:
Compra en línea
Para hacer más rápidas las consultas de precios y las compras, hemos incorporado una tienda en línea especializada en control industrial: www.sdicontrol.com que opera con seguridad y en constante supervisión por nuestros
vendedores.
Respuesta rápida
Cotiza y compra con nosotros, te sorprenderán nuestros tiempos de respuesta, en menos de 24 horas recibirás
atención de alguno de nuestros vendedores dándole seguimiento a tu solicitud.
Soporte Técnico
Nuestra prioridad es dar respuesta rápida y efectiva a los obstáculos e imprevistos. Aportamos todo nuestro expertise y trabajamos en conjunto con los ingenieros de las marcas que ofrecemos para darte la mejor solución por
cualquier medio, ya sea vía email, teléfono o chat.
Envío gratuito
Si compras $450 dólares o más (sin IVA incluido) el envío de tu pedido a cualquier parte de la República Mexicana
corre por nuestra cuenta.*
Garantías directas
Lo compras con nosotros, lo tratas con nosotros. Tramitamos la garantía con el fabricante o solucionamos cualquier inconveniente, sólo tienes que comunicarte con nosotros, y nos encargaremos de todo lo demás.
30 días de prueba
Sabemos que puedes tener duda al momento de elegir un producto, es por eso que ofrecemos la oportunidad de
regresar lo que compraste en perfecto estado y restamos su valor en la siguiente compra. Pregunta a nuestros
vendedores por los productos participantes.
* Consulta términos y condiciones
Originalmente fundada como PLCDirect en 1994, la organización fue creciendo rápidamente de
una compañía con un mercado pequeño de PLC, a una con un nombre reconocido en el mercado
de la automatización.
Con más de 15,000 productos para control basado en PLC y precios bajos; los cuales son el
resultado de una administración y logística ejemplar. AutomationDirect aporta soluciones a la
medida de cada aplicación y en sus productos principales existen posibilidades de compatibilidad
con otras marcas, permitiendo la migración de un sistema a otro sin reducir o detener la productividad.
Interfaces de Operador
• Paneles táctiles de 6” a 15”
• Paneles micro gráficos de 3”-6”
• Monitores industriales de 15”-19”
Control de Movimiento
Controladores Programables y E/S Remotas
• Micro PLC a PAC para CPU
• E/S Análogas-Discretas
• Comunicaciones y redes
• Módulos de especialidad
• Software
• E/S Remotas
Drives, Neumáticos, Protección de Circuitos y Mucho más
• Sistemas Servo AC
• Control de vectores sin sensor 230/460 VAC
• Sistemas paso a paso
• Sensores / Encoders
• Motores inductivos
• Protección de circuitos/fusibles/desconectadores
• Motores AC-DC de propósito general
• Cables y módulos de conexión pre-cableada
• Gabinetes: Desconexión, metálicos y
no metálicos
• Suministros de energía DC, transformadores
de poder
• FRL de preparación de aire, válvulas solenoide,
cilindros, tubos, control de flujo y más.
Sdi> Industrial está certificado como:
AutomationDirect Preferred Vendor
Fundada en 1983, Advantech ha sido proveedor líder de productos y servicios de alta innovación
por más de 30 años.
Con una amplia cartera de productos, servicio al cliente y una red mundial; esta marca combina
información, automatización y comunicación tecnológica con un enfoque de eficiencia, conservación de energía, bajo riesgo, efectividad en costo y protección ambiental; todo para crear soluciones que permitan un planeta más inteligente.
Transportación Inteligente
• Sistemas de supervisión de trenes
• Gestión de carreteras y autopistas
• Operación interna en transporte
• Pago electrónico
• Sistema de navegación Marino ECDIS
Computadoras para el cuidado
de la Salud
• Plataformas informáticas médicas
• Sistemas inteligentes de energía
• Pantallas y computadoras médicas
Sdi> Industrial está certificado
como: Advantech Premier Partner.
Automatización de Plantas y Equipo
• Automatización de la producción
• Control de Procesos
• Prueba e inspección automática
• Automatización de empaque
Computación Móvil Industrial
• Administración de flotillas
• Logística y almacenamiento
• Aplicación de la ley
• Transportación pesada y fuera de carretera
Electricidad y Energía
• Generación y distribución de electricidad
• Energía renovable
• Automatización y administración de la
energía
Sistemas de administración de
edificios y ambiente
• Monitoreo de la calidad del aire
• Administración y tratamiento de aguas
• Monitoreo y prevención de riesgos
• Estación de telecomunicaciones y salas de
administración de control
Getac
Laptops y Tablets Industriales
Por más de 25 años, Getac ha sido proveedor de tecnología móvil robusta
ofreciendo soluciones de diseño y manufactura para los ambientes más
desafiantes. Sus productos ofrecen ventajas especialmente ingeniadas
para protección contra caídas, choques, derrames y vibración.
Getac se ha especializado en sectores de defensa, militar, servicios de
emergencia, manufactura, seguridad pública, transportación y logística.
Sólo Getac ofrece garantías de 3 o 5 años en las computadoras completamente robustas, tablets y handhelds.
Computadoras Móviles
• Los dispositivos de Getac se someten a pruebas
realizadas por laboratorios independientes e internacionales para certificar su resistencia
• Resistencia a entornos extremos, tanto de frío
como de calor
• Protección contra derrames, vibraciones intensas
y caídas
• Disipación del calor que permite que el procesador
esté refrigerado y pueda ofrecer un funcionamiento
constante a pleno rendimiento
• Lidera un diseño resistente para aumentar la
eficiencia y la productividad en el campo
• Chasis ligero fabricado en aleación de magnesio
y aluminio y reforzado con elastómero para una
protección completa
V110
Fully Rugged Convertible
• Intel Core i7 2.4 GHz Processor
• 800 NITS QuadraClear ® LED Display
• Hot-swappable battery up to 13 hours
• MIL-STD 810G and IP65 certified
• Thri-pass thru (GPS, WWAN, WLAN)
B300, X500, X500 Server
Ultra Rugged Convertible
• 1400/800 NITS QuadraClear ® LED Display
• Intel Core i7 4600 vPro 2.9 GHz Processor
• Up to 30 hours of dual batteries
• MIL-STD 810G and IP65 certified
• Night vision or Salt fog / Expansion Chassis Option for
extra PCI/ PCIE cards / Up to 5 TB of storage/RAID 0,1,5
Tablets
• Diseños delgados y ligeros
• Pantallas táctiles, LCD y tecnología Lumibond®
• Resistente a caídas de hasta 6 pies
• Tecnología revolucionaria de visión
• Conexión simultanea GPS, WWAN y antenas de
techo WLAN
• Certificación IP65
• La mejor garantía en la industria de 3 años
T800, F110, Z710
Fully Rugged Tablet
• Intel Pentium N3530 2.16 GHz Processor T800* / Intel
Core i7 2.1 GHz Processor F110* / Intel Core i7 2.7 GHz
OMAP 4430 Dual Core 1 GHz MicroProcessor Z710*
• 600/800 NITS LumiBond ® LED Display / LumiBond ®
sunlight readable touchscreen
• Certified to withstand 6 foot drop
• MIL-STD 810G and IP65 certified T800, Z710*
Handhelds
• Pantalla táctil con GPS avanzada y teclado numérico
• Resistente a vibraciones y caídas
• Protección contra agua de hasta 1 metro de profundidad
• Certificación IP68
• Resistente a temperaturas desde -30°C a 60°C
• Almacenamiento de 4GB que se puede expandir a 40GB
PS336
Rugged Handheld
•
•
•
•
•
•
6
Windows Embedded Handheld 6.5 Professional
3.5” TFT LCD VGA (480 x 640)
512MB MDDR
256MB and 8GB NAND flash
89 x 30 x 178 mm
530 g without 3G module
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Controladores Programables
Plataformas confiables a la medida de tus procesos
Contamos con un amplio rango de productos: desde PLCs con
pocas E/S hasta sistemas modulares de PLC, PC y PAC con
gran número de E/S. Los controladores basados en PC cuentan
con una interfaz de desarrollo abierto; los PACs son plataformas
simples con funcionalidades multidisciplinarias de controlador.
Desde secuencias simples de máquina a procesos complejos
de control, encontrarás un controlador programable de calidad
industrial que se adapte a tu aplicación.
Controladores Lógicos Programables (PLC)
Do-More H2 Series (Micro Modular PLCs)
Powerful Micro Modular
• H2 Series CPU modules plug into a standard DL205 base
unit
• H2 Series Do-More PLCs
• Powerful performance specifications
Do-More TH1 Series (Stackable PLCs)
Space saving I/O points
• 2 CPU modules programmed using Do-more Software
• AC or DC power supply
• Base units, discrete and Analog I/O Modules for Terminator I/O
• T1H-CTRIO High-Speed Counter I/O module
DL105 (Micro Brick PLC)
Fixed - I/O with 10 inputs and 8
outputstotal
• 2K program memory
• 384 words data memory
• 91 structing programming
• RS-232 communication port
• DeviceNET slave I/O blocks
Software
Gratis
Click (Stackable Micro Brick)
Basic CPU Built-in Discrete I/O
• Discrete points 8 Input/6 Output
• DC Input/Output, DC Input/relay Output, and AC Input/
relay Output, 2 built-in RS-232 (MODBUS RTU or ASCII)
Analog CPUs - Built-in Discrete & Analog I/O
• Discrete: 4 Inputs/4 Outputs, Analog: 2 Inputs/2 Outputs
• DC Input/DC Output (sink or source), DC Input/relay Output, all with 2 analog Input and 2 analog Output channels,
2 built-in RS-232 (MODBUS RTU or ASCII) and 1 RS-485
port
DL06 (Expandable Micro Brick)
Fixed I/O 4 option for expansion from 36-100
I/O
• 14.8 KB of total memory, 229 instructions, including 8
PID loops
• 2 communication ports, including RS232/ 422/ 485
capability
• MODBUS RTU master/slave, Ethernet, DeviceNET slave,
Profibus slave, and ASCII in/out. Optional LCD display
panel for monitoring, alarms or maintenance
• Integrated high-speed inputs and pulse output
• Thermocouple and RTD temperature inputs
• Built-in real time clock/calendar
> Compra en Línea
www.sdicontrol.com
Click Modules
DC I/O
• 8-pt, 16-pt DC Input / 8-pt, 16-pt DC Output
DL05 (Micro/Brick)
8 inputs/ 6 outputs, expandable to 30 I/O total
• 0.5A, 24 VDC Output - 100-240 VAC Input
• 1.3A, 24 VDC Output - 100-240 VAC Input
• 8 combinations of AC or DC powered PLC units with AC,
DC and relay I/O, 129 instructions, including 4 PID loops
• 6 KB program and data memory, 2 communication ports
• Supports MODBUS RTU master/slave, DeviceNET slave,
Profibus slave and Ethernet networking
• Smallest I/O cards in the micro class
• Removable terminal block connectors
DL05 - DL06 Modules
Analog I/O 12, 16-bit resolution
DL205 (Micro Modular)
Lowest cost, greatest versatile solution
AC I/O & Relay Outputs
• 8-pt Input / 8-pt triac Output
• 8-pt Isolated relay Output, 8-pt relay Output
Power Supplies
• Signal ranges of 4-20 mA or 0-20 mA, and 0-5 V or 0-10 V
input and output ranges available, thermocouple and RTD
temperature inputs, 8 PID loops with auto-tune
Discrete I/O
• AC, DC sink/source and relay I/O available, 12 modules
available, panel mount and DIN-rail mounting for all PLC
units
• 6 CPUs from 2.4 K with 256 I/O to 30.4 K with a total of
16,384 possible I/O
• 4 base sizes (with built-in power supply)
• Remote I/O master and slave, Ethernet and serial-based
• Selection of 35+ I/O and communications modules
Communications and Networking
• DeviceNET, Profibus, MODBUS RTU/TCP, Ethernet
• High speed I/O, CoProcessor Module
• Motion and specialty Module
7
DL205 Modules
Discrete, Analog I/O and Communications
• Servo connectivity
• Local expansion I/O bases in all sizes
• Up to 16 PID loops with autotune
• Serial communications
• DeviceNET, Profibus, Ethernet
• High speed I/O, CoProcessor Module
• Triple-port BASIC Coprocessor
DL405 (Small Modular)
CPUs from 6.5 K with 1,152 I/O to 30.8 K with
3,584 possible I/O, with built-in power supply
• Three base sizes
• AC/DC in/out, up to 64 points
• 10 amp relay out, Thermocouple and RTD Inputs
DL305 (Small Modular)
27 years of experience
• 3 CPUs including the D3-350 CPU with PID control and
2 communication ports, 14.8 K total memory, MODBUS
Master/Slave, remote I/O and floating point math
• 5, 8 and 10-slot bases, 10/ 220 VAC or 24 VDC power
supply
• Specialty CPUs to convert a DL305 system into an RTU
for Optomux, Pamux, or to allow BASIC programming
DL305 Modules
Discrete, Analog I/O and Communications
• AC, DC I/O
• AC, DC, I/O Relays Outputs
• Eight or 12-bit analog input/output
• Specialty modules include an ASCII/ BASIC, high speed
counter, and communication interface
DL405 Modules
PID (Proportional, integral, derivate) control
• 12-bit and 16-bit analog inputs and outputs
• Thermocouple and RTD inputs
• Data communications, including serial and Ethernet
modules
• High-speed counter input and pulse output
• Serial remote I/O master and slave modules
• Ethernet remote I/O master and slave base controllers
• Slice I/O master and slave modules
Controladores Automáticos Programables (PAC)
Productivity3000
High-performance CPU
• 50Mb memory, fast scan time
• 7 communication ports and LCD display
• Hardware auto-discovery
• Easy drive integration
• Run-time editing and easy data logging on CPU
• Tag name database is friendly and flexible
• All project files (program, tag name database and all the
program documentation) in the CPU
Communication Modules
Analog I/O
• 3-8 ch Input voltage, current and temperature
• 4 ch Output voltage and current
Digital I/O
• 8-32 ch Input 24 VDC
• 6-32 ch Output 24 VDC or relay
• Communication and specific
8
Productivity2000
Micro-Modular
• CPU with 5 communication ports
• OLED message display on CPU module
• Plenty of discrete and analog I/O modules
• Status displays on all discrete I/O modules
• OLED data display on analog modules
• Easy drives integration
• FREE full-featured ProductivitySuite software
APAX-5000 Controllers
4/8 slots Distributed DAC System for RS-485
• Supports ADAM ASCII protocol or Modbus/RTU Master
• Supports Modbus/RTU protocol with user-defined
Modbus address
• Extensive software support; Windows DLL drivers, OCX
drivers, OPC server and HMI/SCADA software drivers
• Intgrated with ADAMView data acquisition software
ADAM-5000
4/8 slots PC based controller
• Serial Modbus/RTU Master, ASCII or Ethernet Modbus/
TCP (Server/Client),
• Borland C++/DOS, .NET or KW programming software
• From 10 to 30 VDC Input, 4-12 watts consumption
• Class I, DIV.2 approved
• Extensive software support; Windows DLL, OCX, OPC
server and popular HMI/SCADA software drivers
APAX-5000 Modules
Analog I/O
• 8-12 ch Input voltage, current and temperature
• 8 ch Output voltage and current
Digital I/O
• 12-24 ch Input 24 VDC
• 12-24 ch Output 24 VDC or relay
• Backplane
• Communication
• Speed counter
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Sistemas de Automatización de Edificios
Energy Data Concentrators
Powerful data concentrors
Power Meters
For sub-metering applications
Advantech BEMS
Web-based energy management system
BASPro
Programming Software package
• 2 x RS-232/485, 2 x RS-232/422/485 with automatic flow
control
• 1 x 10/100Base-T RJ-45 port and 2 x USB 2.0 ports
• Fanless design with no internal cabling
• Built-in Windows® CE with Advantech WinCE WebAccess
Energy Data Concentrator
• Supports various protocol drivers to communicate with
different devices
• Multi-thread communication, fast response time
• Browser-based energy management system
• Charts to view energy consumption from various perspectives
• Supports flexible report functions
• Various data functions to generate energy consuptions
patterns
• Advanced demand limit control
• Geographic information system for energy management
• Small size with 100mm depth
• Panel cut 92 x 46 mm
• Multi-function power measurement
• Modbus RTU protocol over RS-485
WebAccess HMI/SCADA Software
Advantech WebAccess
• Remote engineering with Cloud Architecture
• Business Intelligent Dashboard, HMI based on HTML5
• Excel Report integration & Multitouch gesture support
• Google Maps, GPS location tracking integration
• Central SCADA database server and Multilayer interoperable nodes
• Redudant SCADA, ports and devices, alarms and real time
database
• Graphical programming enviroment
• Supports remote download and maintenance by Ethernet
• Pre-defined function blocks to save development time
• Schedular and sequential control
• BA HVAC calculation
• Auto-tunning PID and RAMP/SOAK control algorithm
E/S Remotas
Más eficiente, más espacio y más ahorro
Sdi> te provee un sistema industrial con E/S, capaz de manejar
a su vez E/S remotas y distribuidas. Ofreciendo la capacidad de
monitoreo de la instalación, monitoreo de ambiente y control de
procesos industriales.
Combina puntos de E/S con sus terminales en un paquete modular para ahorrar espacio y dinero.
Módulos E/S
ADAM-4000
RS-485 I/O
• Robust Remote I/O Modules
• Controller Modules
• Analog I/O Modules
• Digital I/O Modules
> Compra en Línea
www.sdicontrol.com
ADAM-6000
Ethernet I/O
• Communication Controller
• Analog Input/Output Modules
• Digital Input/Ouput Modules
ADAM-6100xx, 6200xx, 2000
Ethernet IP, Profinet I/O, Wireless
• Transfer data during process control
• Analog I/O Modules
• Digital I/O Modules
• Relay Modules
9
Serial Converters and Repeaters
RS-232, RS-422/485 Transmission Data
• RS-422/485 Repeaters
• RS-232/422/485 Repeaters
• Optic Fiber to RS-232/422/485 Convertor
Terminator I/O
Ethernet, Profibus, DeviceNET, Modbus and
Koyo remote I/O
• Power Supplies / Terminal Bases / Cables
• Network Interface Modules
• Discret Input and Output Modules
• Analog I/O Modules
• Specialty Modules
Protos X
Modbus RTU (RS-485), Modbus TCP (Ethernet) Modular
• Bus Coupler
• Discrete DC I/O Terminals
• Discrete AC I/O Terminals
• Analog I/O Terminals
• Bus End Terminal/Bus Expansion Coupler Terminals
• Power Feed Terminals
Comunicación Industrial
Desempeño ejemplar, conectividad confiable
Sdi> ofrece productos de comunicación industrial de clase mundial para la automatización basada en PC.
Los switches industriales de Ethernet y los servidores seriales
cuentan no sólo con la habilidad de conectar sensores y dispositivos de E/S de campo, sino que también proveen una comunicación central de Ethernet para integrar los switches y servidores en
tiempo real.
Soluciones de Ethernet Industrial
Managed Redundant
Industrial Ethernet Switches
Unmanaged
Industrial Ethernet Switches
Media Converters
Industrial Ethernet
ProView
Industrial Ethernet Switches
EN50155
Industrial Ethernet Switches
Power Energy over Ethernet
Advanced Ethernet Solutions
• Media options: copper, fiber optic and wireless
• 10 Mbps, 100 Mbps to 1000Mbps
• EKI-7000 series X-Ring technology (<10ms)
• DIN-rail mounting and +12~48 VDC
• SCADA manageable series Switches
• Modbus/TCP communications
• SNMP communicate with NMS (Network Management
System)
10
• No setup required, they are truly plug-and-play.
• 10/100Mbps and gigabit 10/100/1000Mbps
• Media options: copper wire and fiber optic connections.
• 27 Models available
• Support vibration areas
• Vigilance systems and IP <40
• Entertainment Backup
• Compact and robust devices designed to convert and
transmit Gigabit Ethernet or Fast Ethernet networks into
Gigabit or Ethernet fiber optic networks by transparently
converting digital electric Ethernet signals to optical
signals.
• 15.4 watts power per port source IEEE802.3af (PD)
compatibles dispositive through Ethernet
• Compact metallic box IP30
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
iCOM
Serial Device Servers
Modbus & Serial Server Devices
• RS-232/422/485 connection through Ethernet
• Not additional programming
• Modbus serial devices and Modbus/TCP in Ethernet
networks
• Modbus device server (Modbus/ASCII or Modbus/RTU)
through Ethernet
Industrial Wireless
Data transmission in real time anywhere
• Wireless Mesh AP, commutation < 20 ms
• 100 Mbps, video transmition 802.11n 2x2 MIMO
• Entry level Wi-Fi AP/CPE
• WPA2/WPA/802 and 802.11n 2x2 MIMO security
authentication
Serial Communication Cards
Multiple Peripheral RS-232/422/485 Devices
• PC/104 Ethernet, RS-232 or RS422/485
• PCI-bus RS-232/422/485, PCI or ISA, or PCI-Bus Plug
and Play
• PCI Express Communication Cards
• Communication CAN Card
• ISA-bus RS-232/422/485
Interfaces de Operador (HMI)
Soluciones que marcan la diferencia entre visualizar y controlar
Con un rango completo de paneles industriales de operador, PCs
con paneles táctiles, PCs con paneles industriales y monitores industriales de pantalla plana, Sdi> ofrece un amplio rango de HMIs
para sus necesidades de automatización industrial.
Por medio de la creación de valor, soluciones estándar y configuración de productos, Sdi> provee plataformas que se ajustan a
cualquier requerimiento.
Monitores Industriales
FPM Series Monitors
LCD flat Monitors 12” – 21”, NEMA IP65
Protection
• Industrial Applications in reduced spaces, thin and light
• Stainless steel & Aluminum Chassis, wide screen
visualization
• Wide screen control panels with TCP multitouch
• Industrial Monitor for harsh environments and general
industrial application
Chassis LCD, Panel Mount
6.5”, 8.4”, 10.4”, 12.1”, 15”, 17” to 65”
• LCD Black Anti-Glare, low reflection coating
• 2W speaker x 2,
• Input Sources: 1 x VGA (15 Pin Female D-Sub), 1 x PC
Audio (Stereo Headphone Jack), 1 x DC Power Plug
• Wall Mount (VESA 75 x 75 mm)
Rack Mount
10.4”, 12.1”, 15”, 17”, 19” and 22”
• CPU 400 MHz, 1024 x 768 resolution, Flash memory 64
Mb
• System memory SDRAM 64 Mb, Ethernet 10/100 Base-T
• Power supplied through the serial communication port*
• FCC, ROHS and CE standard approval
Paneles de Operador Web (WebOP) (3.5”~4.3”, 5.6”~5.7”, 7”, 8”, 10.1”~10.4”, 12”)
WebOP-2040T
4.3” WQVGA Operator Panel
• Various LCD sizes (4.3”, 5.6”, 7”, 8”, 10.1”)
• Supports ARM9-based CPUs with 200MHz and 128MB
flash memory
• Supports RTC, battery backup RAM, and Ethernet-based
operator panels
• Front panel is IP66 compliant
> Compra en Línea
www.sdicontrol.com
WebOP-3070T
7” WVGA Cortex™
• Various LCD sizes (7”, 8”, 10.1”, 12”, 15”)
• RISC 32 bits TI ARM® Cortex™-A8 processor
• Full line LED BL TFT LCD with 50K life time
• -20°C ~ 60°C wide operating temperature range
WebOP-3120T
12” XGA Cortex™
• Various LCD sizes (7”, 10.1”, 12”)
•RISC 32 bits TI ARM® Cortex™-A8 processor
• Full line LED BL TFT LCD with 50K life time
• Bundle Panel Express HMI Runtime software
(300 tags)
11
Interfaces de Operador C-more® (6”, 8”, 10”, 12”, 15”)
E7 Series
Touchscreen 6” – 15” Interface Panel
• Support Compact flash, Color TFT Touch Panel
• Ethernet Communication
• Web Server, FTP Server, Send Email
• ECOM Ethernet Direct Logic modules
E9 Series
Touchscreen 6” – 15” Interface Panel
• All models support 64 K, up to 1024 x 768 pixel XGA
• Ethernet port 10/100MB, Serial interface RS232/422/485
• Web Server, FTP Server, Send Email
• User Library: Objects, Screen, Graphic, Sound Video
Remote HMI App for Mobile Devices
Connect, monitor, and control any C-more
panel
• C-more Panel with Ethernet port
• PC Web Browser
• iPhone / iPad / iPod touch
• Android mobile device, version 4.1 and up
Micro Paneles Gráficos de Texto y Táctiles C-more® (3”, 6”, 8”, 10”)
Marquesinas ViewMarq LED
Micro-Graphic Panels
HMI touch panels
Micro-Graphic Panels
LED Communications for Industrial Applications
• 3” – 10” monochrome or color, touch or non-touch panels
• Color Displays with Backlight, supports Portrait and
Landscape modes
• Seven user defined function keys with LED indicator
Optimate Text Panels
Perform functions of a pushbuttons, lights &
LCD Displays
• Configuration OPWINEDIT Software and Ladder logic
• Connect HMI panels & run applications inside CPU
• Single or multiple OP-1000 series panels can be connected to one CPU port
• 1, 2 & 4 line text message displays, 12 & 24 characters
• Rugged Extruded Aluminum Housing, polycarbonate
smoked lens cover
• NEMA 4, NEMA 12, 140° view angle, 100-400 ft viewing
distance
• Text messages sent by ASCII serial string or Modbus RTU
or Modbus TC
Software
Versatilidad, funcionalidad y sencillez
El software juega un papel vital en el desarrollo eficaz de sistemas de
control para la automatización.
Nuestras soluciones de software son más completas, integradas y
abiertas, proveyendo excelentes capacidades para comunicarse con
otros mecanismos, especialmente para adquisición de datos, pruebas y
medición, y control de aplicaciones.
SCADA
WebAccess
HMI/SCADA
• WebAccess Cloud, based HTML5
• Open interfaces, Excel report, GPS and Google Maps
tracking integration
• Redundant SCADA, central data bases server & Multilayer inter-operable nodes
• Open data connectivity, Alarm, Schedule & Real time
database
12
WebOP Designer/Panel Express
HMI Runtime Development Software
• Allows users to manage multiple HMI applications in one
project
• Provides index registers for modifying device addresses
at runtime
• Provides password protection of designs, macros and
upload/download operations
• Supports vertical, horizontal screen displays
ActiveX
Software Development Kit (SDK)
• ADAMView, Data Acquisition software, specially designed
for low volume ADAM projects.
• DAQNavi, completed sw package to develop applications
programs using Advantech DAQ board & devices
• DiagAnywhere, help users to perform remote maintenance tasks
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
BEMS
Web-based energy management system
aiming
• Charts to view energy consumption
• Support flexible report functions
• Data Analysis functions, advanced limit control
• Geographic Information System (GIS) for energy management across multiple buildings
BASPro
For building automation application
Point of View
HMI, SCADA & OEE/Dashboard
KEPDirect OPC Server Software
OPC and DDE for PLC’s
DirectSOFT5
PLC Programming
• Built-in Panel Simulation
• Overlapping Objects (No Touch Cell Limits)
• PID and Trending
• Data Logging / eMail messaging
• Built-in PHP Server / Floating Point support
• Up to 5000 tags in development or/and runtime only
• Modbus driver and 18 Communications drivers
for PLC
• Real time PLC’s, Remote I/O devices and data acquisition
equipment
• Optional module: Alarms, events, trends, recipes, reports,
scriptable logic, scheduler’s, security system, database
interface
Software de Programación
Think & Do
PC-based control and HMI development
software
• Operator interface (HMI) as well as control
• Advanced data manipulation (even string arrays) and
advanced math functions
• Data exchange with business applications
• Large number of PID loops (up to 64)
• Open architecture for C/C++ or VisualBasic
• Auto generate tag names from DirectSOFT5
• High-performance, certified OPC-compliant via Ethernet
• Provides OPC y DDE client connections to all DirectLogic
PLCs and Productivity 3000 Ethernet dirver
• Documentation can be exported for use in other application such cross Refferences & Data Views
• More than 65 IBox instructions are available in the
following six categories: Memory, Discrete Helper, Analog
Helpers, Math, Communications and Counter I/O
• iBoxes with fill-in-the-blank-style instructions
PCs Industriales
Plataformas y Soluciones para la Integración de Aplicaciones
Sdi> ofrece una selección completa de computadoras industriales
desde chasis para montaje en rack (1U a 7U) hasta PCs embebidas sin ventilador para usos rudos en ambientes industriales
severos. Con E/S compactas y abundantes, múltiples soluciones
de expansión y diversos métodos de montaje. Estas plataformas
son apropiadas para una amplia variedad de aplicaciones en un
amplio rango de ambientes.
Computadora Industrial (IPC)
Server Chassis
Industrial Server grade IPC
• Redundant power supply, hot swap SATA/SAS hard drives
• Cooling fans 24/7 non-stop operation
• High density, Digital surveillance or SCADA Server with
high storage demand
• Rugged Chassis, server applications which high storage
demand
> Compra en Línea
www.sdicontrol.com
Industrial Motherboard
Based-Boaord MicroATX
• 244mm x 244 mm
• Intel Core i7/i5/i3 LGA 1155 MicroATX withTriple/Dual
CRT
• 10 COM, 2 USB 3.0, 8 USB 2.0 (F)/ or 10 USB 3.0 (G2)
• Dual LAN, PClex 16 (Gen 3) and DDR3 1066/1333/1600
• Applications with less than 4 slots
Single Board Computer
Passive Backplanes
• Expansion for our SBCs (Single Board Computer), Interfaces: ISA or PCI-X, or PCI or PCIe, Backplanes for SBCs Half
size: ISA, PCI, PCI/ISA, PICMG 1.3 SHB
Slot Single Board Computers
• With Silicon, CPU, Chipset, I/O, PCIM, Intel 2nd & 3rd
Generation Processor, Host Board Systems (SHB Express)
PICMG 1.3, Single Board Computer (SBC)
13
Panel PC (PPC)
Industrial Touch Monitor
(ITM) Rugged, IP54 front Panel
• Stand-alone industrial LED TFT-LCD touchscreen
• Touch Panel connecting interfaces with box PC’s
• VGA & DVI output interfaces
• Easy cleaning design 12”, 15”, 17” monitor
Multifunctional PC Panel
High Performance CPU
• Touchscreen Resistive/Capacitive/SAW
• Color TFT LCD 12.1”, 15”, 17” panel sizes, ultra slim
optional Chassis
• Processor i2/i3/i5 or Celeron, Mini-ITX AIM motherboard
• RS-232/422/485, Gigabit Ethernet, COM extended
Fanless Panel PC
Fanless Wide Screen Panel PC
• Widescreen ratio of 16:9, 40% more screen area than 4:3
displays
• Capacitive Multi-finger touchscreen, Full HD/ WXGA
screen 15.6” or 21.5”
• High Performance Intel Core i CPU
• PCI or PCIe expansion support
Paneles Industriales de Alto Rendimiento (IPPC)
Industrial Workstation
Robust design and compact size
• Rugged design, Intel Pentium III Processor
& 4 Processors
• 12.1”, 15”, 19” TFT/VGA LED Backlight LCD display
• Stainless steel Chassis, frontal Aluminum
Panel IP65
• Power Switch & DVD-ROM, two 3.5” HDDs mobile rack
drive
• Vibration protection up to 1G
Industrial Panel PC
Industrial Panel/Computer System
• Stainless steel Chassis, frontal Aluminum Panel
• High speed DDR3, Haswell platform Core i7/ i5/ i3
• Expansion PCI slots
• Up to Dual Gigabit vPro Processor
Industrial Fanless Panel PC
Frontal USB Panel PC
• Compatible with Celeron M a 1 GHz
• 1 GB Memory DDR2
• 1 CompactFlash & 2 PCI expansion slots
• SATA optional
Computadoras con Panel Táctil (TPC) (5.7”~6.5”, 10.4”, 12.1”, 15”, 17.1”, 18.5”, 21.5”)
TPC-671H
6.5” VGA LED LCD Intel® Atom™
• Intel® Atom™ Z510 1.1GHz processor
• 6.5” VGA TFT LED LCD
• Super slim and compact design with PC/ABS Resin
housing
• Fanless cooling system
• IP65 approved front panel
TPC-1581WP
15.6 WXGA TFT LED LCD Intel®
TPC-2140WP
21.5” Full HD TFT LCD
Series UNO-1100
DIN-rail PC with PC/104
Series UNO-2100
High Performance Automation Computers with
PC/104
• Industrial 15.6 HD TFT LCD with 50K Lifetime LED
Backlight
• Intel 4th Generation Core i3-4010U with 4GB DDR3L
SDRAM
• 16:9 Wide Screen with PCT Multi-Touch
• IP66 Approved Front Protection & Panel Mounting
• Built-in Intelligent Home key and i Key for Intuitive UI
• AMD dual-core T56E 1.65GHz with independent GPU,
advanced graphical performance
• 16:9 wide screen with PCT multi-touch
• Built-in function and home key button used for intuitive UI
• Anti-scratch surface: 7H hardness
• Fanless cooling system
Computadoras Embebidas
ARK-5261
Fan-less Compact Computer
• Sealed construction with fanless operation, supports
Intel® Celeron® Processor J1900 up to 2.41 GHz
• Supports 2 Giga LAN and 1 USB 3.0 + 5 USB 2.0
• Support 4 RS-232/422/485 with Auto-flow control and
COM 1 & 2 port with 5V/12V power
• Support 4 RS-422/485 Isolation module type
• Built-in 1 x PCIe, and 2 x PCI expansion slots
14
• Fanless Industrial PC
• x86 Processor, up to 70° operative temperature
• SCADA RTU, logistics, ambient vigilant applications
• System diagnosis & remote power control
• UL Hazardous resistance
• Celeron M 1GHz to 1,5 GHz Core 2 Duo
• x86 platform LAN & Dual USB interfaces, RS232 or
RS232/422/4885 or RS485
• Isolated digital I/O, 3G Expansion and compatibility with
Windows 7
• Palm, Small, Regular-sized Form, IP 40
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Series UNO-3000
Automation Equipment with PCI/PCIe Wall
mounting
• Celeron M 1GHz to 1,5 GHz Core 2 Duo / i7 Celeron 800
Series processors & QM77/QM67/HM65 PCH
• Gigabit LAN, 8 USB ports, 2 Mini PCIe sockets, 2 CFast
Sockets and up to 5 expansion slots
• 2 power inputs for redundancy and relay function
• 2 IEEE 1394b bilingual interfaces to connect machine
vision
Series UNO-4000
Electrical Substation Frame Computers
iDoor Module
Storage modules
DLT-V8310
Vehicle Mounted Computers
Accesories
For computing Mounting
• Wide powerful computing, isolated serial communication,
Ethernet ports
• Fanless Box PC: IEC 61850-3 certification, isolated PSU &
3 expansion slots I/O plug in cards
• Expansion Card: Gigabit Ethernet ports or 4 or 8
RS232/422/485, 4 smart LAN ports
• Standalone automation controller: Serial ports & other
networking interfaces, Analog I/O, Isolated Digital I/O
• PCI Express Mini Card Isolated/Non-isoolated
RS32/422/485
• Fieldbus protocol; digital & analog I/O
• Smart sensor, communication & memory
• Wi-Fi/3G/GPS/GSM/LTE wireless communication
• MRAM machine memory back up, SATA to CFast on
ThinClient terminal
Computadoras Industriales Móviles
TREK-753
All-in-one 7” Mobile data terminal
• 7” WVGA LCD with 5 programmable adjustable brightness hot key
• Windows W.E.S. & WinCE 6.0 & Ubuntu Linux
• Analog video input & CAN2.0b with J1939 protocol
supported
• Supports CDMA/HSDPA/GPRS, GPS, WLAN, BT communications
• 12V/24V option: 6~36V input range compliant to
IOS7637-2 & SAE J1113
• Color-TFT 10” or 12”
• Highly break-proven, abrasion-resistant touch screen
• Largely configurable to needs
• Extreme temperature range, cold store capable
• Fully rugged, IP66 and 5M3 for the complete system
• Mounting kits are the perfect choice for securing MDTs
(Mobile Data Terminal) to vehicles on the move
• RAM-MOUNT-01
• RAM-MOUNT-02
• RAM-MOUNT-06E
• RAM-MOUNT-07E
Seguridad
Mantén tus procesos lo más seguros posible
Ofrecemos una excelente línea de dispositivos de seguridad para
maquinaria y con precios que permiten hacer aún más para proteger lo
que es importante. Contamos con una oferta certificada de componentes
de seguridad para satisfacer las necesidades de protección, incluyendo interruptores de seguridad, cortinas de seguridad y relevadores de
seguridad.
Protege al personal y maquinaria donde los riesgos no pueden ser eliminados a través de diseño de la máquina.
Safety Switches
Interlock safety and safety limit
• Trapped Key Safety Interlock Switches
• Non-Contact Magnetic Safety Switches
• Solenoid Locking, Tongue Interlock Safety Switches
• Tongue Interlock Safety Switches
• Hinge Interlock Safety Switches
• Cable-Pull Safety Switches
> Compra en Línea
www.sdicontrol.com
Safety Light Curtains
14 mm & 30 mm resolution
• YBB-14 light curtain series with 14mm resolution for
finger protection
• YBB-30 light curtain series with 30mm resolution for
hand protection
• Used for human protection and product/machine safety
where risks cannot be eliminated by machine design and
the process might require open and frequent access
• Double PNP outputs
Safety Relay Modules
Coils & Contacts to open and close Safety
applications
• Relay modules are developed and manufactured according to IEC and EN European standards and are RoHS, CE
and UL Listed
• Single Channel Category 2 to EN954-1, PLd to EN13849-1
and SIL 2 to IEC/EN 61508
• All other units Category 4 to EN954-1, PLe to EN13849-1
and SIL 3 to IEC/EN 61508
15
Servomotores y Motores a Pasos
Sistemas de control de movimiento
Plataformas que van desde estaciones de trabajo industrial y CPUs de
grado industrial para control de movimiento, entradas de encoder y E/S
para el control general de movimiento (GMC). Una gama completa de
productos para el Control de Movimiento Industrial: Servos, Steppers,
Motores, Drives AC, Soluciones centralizadas y descentralizadas para
el Control de Movimiento y Transmisiones Mecánicas.
SureServo
Servo Drive
3 Standard Drives
• Optically isolated digital Inputs (8) and Outputs (5),
analog
Outputs for monitor signals (2), and line driver Output for
encoder (with scalable resolution)
• Modbus RTU
• Fully digital with up to 450 Hz velocity loop response
Servo Motor
8 Standard Motors 100W to 3kW
Accessories
Cables & ZIPLink
Drives
High performance microstepping drives and
power supplies
Power Supply & Cables
8 Standard Motors 100W to 3kW
Right-Angle
PGB Right-Angle Series
NEMA
For Small Motors
• Low inertia models: 100W, 200W, 400W, 750W and 1kW
Speeds up to 5,000 rpm.
• Medium inertia models: 1kW, 2kW and 3kW
Speeds up to 3,000 rpm.
• Optional 24 VDC spring-set holding brakes
• Integrated encoder with 2,500 (x4) pulses/revolution plus
marker pulse (once per revolution)
• Power & Feedback Cable
• ZIPLink I/O Interface
• SureServo AC servo drive, motor and cable combinations
• AC Line Filters (single and three phases)
SureStep
Motor Stepper
High-Torque Stepping Motors• Low inertia models:
100W, 200W, 400W, 750W and 1kW
• Square frame step motor style produces high torque
• 2-phase bipolar, 4-lead
• 1.8° per step, 200 Steps per Revolution
• Standard NEMA Sizes (17, 23, & 34)
• High-speed pulse input (Quadrature, cw/ccw, pulse/
direction)
• Analog velocity mode (0-5v or potentiometer)
• 120/240 VAC selectable input
• 32V, 48V, 70V DC output models available
• Low inertia models: 100W, 200W, 400W, 750W and 1kW
• Speeds up to 5,000 rpm.
Engranajes de Precisión
In-line
PGA In-Line Series
• Industry-standard mounting dimensions
• Four gear ratios available (5:1, 10:1, 15:1, 25:1)
• IP55 environmental rating
• At nominal speed, service life is 20,000 hours
16
• Industry-standard mounting dimensions
• Four gear ratios available (5:1, 10:1, 15:1, 25:1)
• IP55 environmental rating
• At nominal speed, service life is 20,000 hours
• Wide range of ratios (5, 10, 25, 50, and 100:1)
• Low backlash of 30 arc-min or less
• 20,000 hour service life
• NEMA sizes 17, 23, and 34
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Durapulse / Variadores de Frecuencia AC
GS1
120 / 230 VAC V/Hz Control
• 1/4 and 1/2 hp, 115 VAC single phase
• 1/4, 1/2 and 1 hp, 230 VAC single phase / 3-phase
• 2 hp, 230 VAC 3 phase
GS2
115 / 230 / 460 / 575 VAC V/Hz Control
• 1/4 hp to 1 hp, 115 VAC single-phase
• 1/2 hp to 7.5 hp, 230 VAC
• 1 to 10 hp, 460 VAC
• 1 to 10 hp, 575 VAC
DURAPulse
230 / 460 VAC Sensorless Vector Control
• Sensorless Vector Technology up to 100 hp
• 1 hp to 50 hp, 230 VAC 3-phase only / 1 hp to 100 hp,
460 VAC
• Standard smart keypad
Accesories
• AC Line Reactors - Input Fuse Kits & Spare
• Braking Units & Resistors - EMI / RF Filters
Controladores Automáticos AMAX
AMAX-1220,1240,1752,1754,1756
Master Card in PC
• Horizontal Frame, LED System diagnosis
• Connection to Misubishi J3, Yaskwa Sigma V & Panasonic A4/A5 models
• Digital I/O slave modules by LAN cables
AMAX-22xx/xxx, 27xx/xxx
AMONet - 485
• Increase number of axes for an AMONet-485
• Slave modules Serial Connection by CAT 5
LAN Cable
• Slave modules that extend AMONet RS485 extend Digital
I/O
PCI 12202U, PCM 32022P
PCI Interface Card AMONet-485
Supporting
• 2-port AMONet RS-485 PCI-104
• Supports two AMONet – 485 master rings
• Transfer data between host and slaves
• 2048 I/O points, 256 axes
• Combination of I/O points and axes for motion control
Motores
Posición y velocidad con precisión
Contamos con Motores de corriente alterna, directa y moto reductores
desde 0.25 hasta 300 caballos de fuerza, así como sus bases compatibles con los motores NEMA.
Los motores de acero laminado IronHorse y de fundición de hierro son
fabricados por un proveedor líder en motores con más de 20 años de
experiencia. Nuestro proveedor produce estos motores AC en un centro
de ISO9001 que pone a prueba los motores durante la producción y
después del montaje final.
AC Motors
Industrial AC Electric Motors
• Single-phase AC motors - 230V, 1800 RPM
• Horsepower ranges from 2 hp to 5 hp
• Totally Enclosed Fan Cooled (TEFC) enclosure
> Compra en Línea
www.sdicontrol.com
DC Motors
IronHorse Permanent Magnet DC (PMDC)
• IronHorse DC motors are designed for use on unfiltered
SCR (Thyristor) type and PWM (pulse width modulated)
type DC adjustable speed drives
• Heavy duty oversized ball bearings
• Service Factor: 1.0
DC Gearmotors
IronHorse® DC Gearmotors
• Available in 12, 24, and 90 VDC
• From 1/19 to 1/5 HP
• Models with parallel or right-angle gear shafts
17
Sensores / Encoders
Precisión y eficacia donde más lo necesitas
Sdi> ofrece sensores de proximidad, lineales, ultrasónicos, sensores de
flujo, corriente, voltaje, encoders, transductores, controladores de proceso
y micro interruptores necesarios para detectar la presencia de objetos en
diversas aplicaciones.
La calidad de nuestra línea de productos proviene de fabricantes con años
de experiencia en el desarrollo, manufactura y distribución de sensores
confiables para el control de procesos.
Sensores
Inductive
Proximity Sensors & Switches
Laser
Small Sizes
Photoelectric
Non-contact detection
Fiber Optic Sensors
SSF/ DFP/ DFT Series
Magnetic Proximity Sensors
IP69K prox sensors
• 18mm round amplifiers
• Rail amplifiers
• Fiber Sensors
• Multi-Port Junction Blocks
• Cuttable fiber sensors
• 2 magnetic switch models available
• 12mm or 18mm diameter magnetic sensors
• Complete overload protection
Capacitive Proximity Sensors
Sensing of metal and non-metal objects
Ultrasonic Proximity Sensors
Ultrasonic and Ultrasonic Liquid Level
Pressure Sensors
ProSense pressure switches
• 3mm / 4mm / 5mm round
• 8mm round
• 12mm round
• 18mm round
• 30mm round
• Rectangular
• 18mm round
• 30mm round
• Miniature, rectangular sensors for limited mounting
spaces
• Ultrasonic liquid level sensors
18
• Laser distance sensors - OPT series
• Diffuse DC FAL4 series
• Polarized retroreflective FALN series
• Through-beam FALH & FALD series
• Electronic pressure switches
• Mechanical pressure switches
• Compact pressure and vacuum transmitters
• Digital switches / transmitters with LCD display
• Pressure transmitters with stainless steel sensing
element
• High Performance AC/DC
• Light Screens
• DC and AC rectangular
• 5mm round - stainless
• 8mm, 12mm, 18mm round - metal
• 18mm round - IP69K
• M12 (12mm) Diameter - DC Power
• M18 (18mm) Diameter - DC Power
• M30 (30mm) Diameter - DC, AC/DC Power
• Rectangular - DC Power
• ZIPport Multi-Port Junction Blocks
• Field Wireable Connectors and T-Couplers
Temperature Sensors & Transmitters
ProSense temperature switches
• Temperature Switches
• Thermocouple Sensors/ Thermocouple Probes
• Temperature Transmitters (with Integral Sensor)
• Temperature Transmitters (Thermocouple Input)
• Temperature Transmitters (RTD Input)
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Level Sensors & Controllers
Ultrasonic & Float
Flow Sensors
FSD Series Flow Switches
• Ultrasonic Level Sensors (Non-Contact)
• Level Sensors (Contact)
• Level Controllers
• Float Level Switches
• Submersible Level Sensors
• Immune to rapid temperature changes of media
• Easy to set: turn dial to desired setpoint
• N.O. DC PNP output
• LED output status indication
• IP65/IP67
Ground Fault Sensors
Protect people, products, and processes
Pressure Transducer
Bluetooth Wireless
• Wide range of options
• Jumper-selectable setpoints of 5, 10, 30 mA
• Relay outputs with Auto or Manual reset
• Use on single- and three-phase systems
• Use up to 14 AWG copper wires
• Protect personnel, equipment and meet regulatory
requirements
• Connects to smart phones and tablets with Bluetooth®
Low Energy
• Pressure ranges from Vacuum to 10,000 psi
• Long battery life (proprietary technology) standard &
temp sensor versions
• 1% Standard accuracy with optional 0.25% Ultra high
accuracy
Current & Voltage Sensors (AC & DC)
AcuAMP family
• AC Current Transducers
• DC Current Transducers
• Single Range AC Current Switches and Indicator
• Multi-Range AC and DC Current Switches
• Voltage Transducers (AC and DC)
Pressure Switch
Transducer with Integrated
LED Display
• Totally electronic design
• High or low current, relay output
• Pressure ranges up to 10K psi
Encoders
Incremental
Position and velocity with accuracy
• TRD-S , TRD-N and TRD-GK
• Nano: Hollow Shaft
• Micro: Shaft, Hollow Shaft
• Mini: Shaft, Hollow Shaft
• Standard: Shaft, Hollow Shaft
• Wind Power Heavy Duty: Shaft, Hollow Shaft
• Heavy Duty,Oil & Gas: DrawWorks
• Solar Outdoor Encoders: Shaft
Absolute
Powerful and ready
eCode Encoders
Intelligent Encoders
Temperature / Process Controllers
Temperature Limit / PID Temperature
Timer Relays / Counters / Tachometers
Meet UL and CE conformity
• TRD-NA Series Medium Duty Standard Shaft
• Mini: Heavy Duty Design, Shatf, Shaft and Hollow
• Standard: Shaft and Hollow Shaft
• Water proof
• Measurement of Speed and Position
• High Resolution of Speed and Position
• High Update Rate of Speed, typically 10mSec
• Profibus & 485 Interface
• Rugged Design, Harsh environment
Control de Procesos
Signal Conditioners
Isolators / Transmitters / Converters
• DC Voltage or Current Input Signal Conditioners
• Universal Input Isolated Signal Conditioners
• Temperature Transmitters (Thermocouple or RTD Input)
• Programmable Temperature Transmitters (T/C or RTD
Input)
• High Speed Optical Isolators (Encoder Input)
> Compra en Línea
www.sdicontrol.com
• 100 to 240 VAC 50 / 60 Hz or 24 VDC input power
• Accepts eleven types of thermocouples
• Two types of Pt100 RTD temperature sensors, and DC
mA, mV, and Volt signals
• Four possible control outputs; Relay, Voltage Pulse,
Current, and Voltage (depending on model)
• Koyo Timer Relays - KT Series
• Fuji Timer Relays - MS Series
• Fuji Miniature Timer Relays - ST7 Series
• Multi-Function Digital Counter-Timer-Tachometer - CTT
Series
19
Control de Motores
Protección, conveniencia y rentabilidad en conjunto
Ante la continua complejidad de los sistemas de control, la necesidad
de alternativas competitivas de controladores de motor eléctrico se
hace presente.
Cumpliendo con estrictas normas de seguridad (IEC), nuestra línea
de contactores y arrancadores ofrece eficiencia en costo con un solo
proveedor.
Control de Motores Eléctricos
AC Motor Soft Starters
STELLAR™ SR22, SR33 and SR44 Series
Electric Miniature Contactors
3-Pole & 4-pole
Motor Monitoring Relays
ProSense
Fuji Contactors / Overload
Contactors
Fuji Manual Motor Starters
DUO series
Eaton Cutler-Hammer Contactors
Electromechanical motor control solutions
Manual Motor Controllers
GH SeriesElectric motor controls
AC Drives
Variable Frequency Drives
• Compact 3-Phase Soft Starters - 2-phase control
• 5A to 370A rated current versions @ 208–460V
• Internal bypass contacts for run (SR22 – SR33)
• External bypass capability for run (SR44)
• 1/2 to 100 hp and 60 to 300 hp / IEC-947, UL, CSA, CE
• Fuji SUPERMAGNET™ for greater reliability
Overload
• Phase loss protection / Trip indicator
• Isolated N.O. and N.C. contacts
• Ambient temperature compensation
Contactors / Starters / Overloads
GH Series
• 45mm and 60mm Contactors / Overloads
• Manual Starters / Protectors
• Up to 20 - 300 horsepower at 480 volts
20
• IEC current ratings from 7 Amp to 22 Amp
•Dimensions of the 7A to 16A contactors are the same for
both AC or DC coil voltages
•Heavy-duty oper ation
•Rated up to 15hp @ 460V
• Short Circuit Protection
• Thermal Overload Relay Functions
• A wide motor capacity range up to 30 kW (40 Hp at 480
VAC)
• Maximum breaking capacity of 100 kA at 240 VAC and 50
kA at 460 VAC per IEC 60947-2
• Optional accesories: Auxiliary and Alarm Contact Blocks
• Motor controller switch sizes in 30 Amps, 40 Amps and
60 Amps up to 600 VAC
• 2-pole and 3-pole motor control switch
configurations
• Available NEMA 1, 3/3R and 4X motor controller enclosures
• Thermoset body provides high resistance to
electrical arc tracking
• Phase Monitoring Relays for phase loss protection
• Alternating Relays for motor load protection in applications where load used is requuired by equalizing the ru
ntime of 2 loads
• Pump Seal Failure Relays for seal failure detection
• IEC Sizes A through F, 120 V or 240 V coil
• EN60947-4-1 IEC 947-4-1 compliance
• 45 mm frame rated maximum 20 Hp at 460 V
• 2,000,000 electrical and 20,000,000 mechanical operations
• Maximum horsepower ratings through 20 Hp at 460 V
• Holding circuit contact(s) supplied standard
• CENELEC EN50011 in contactor and terminal markings
• GS1 Series Mini AC Drives
• GS2 Series Micro AC Drives
• DURApulse AC Drives - GS3 Series
• GS Series AC Drives Configuration Software & Communications
• AC Drive (VFD) Spare Parts & Accessories
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Gabinetes Industriales
Protección industrial para equipo y cableado en ambientes críticos
Sdi> pone a su disposición la línea de gabinetes más grande de
América del Norte; Hubbell/Wiegmann, quien ha sido fabricante
de gabinetes industriales por más de 70 años.
Esta línea ofrece gabinetes NEMA en todas sus categorías así
como gabinetes eléctricos a un gran precio. Es por esto que la
marca es parte de nuestra oferta.
Desconexión
NEMA 4
For occasional washdown
• Gasketed and the door is clamped for maximum sealing.
They have continuous hinges, mounting feet, and padlock
hasps.
• Applications where a pressurized stream of water will be
used or machine tool cutter coolant.
• Designed to house: Allen-Bradley, ABB Controls, CutlerHammer/Westinghouse, General Electric, I-T-E Max-Flex™,
Square D
NEMA 4/12
Attractive, clean line industrial cabinet
• Concealed hinges, interchangeable and easily removable
doors, door latching system installed on door with a slotted insert defeater mechanism, and rear mounting holes
• Designed to house: Allen-Bradley, ABB Controls, CutlerHammer/Westinghouse, General Electric, I-T-E Max-Flex™,
Square D
Metálicos
NEMA 4X
Harsher environments
• Applications include food, such as meat/ poultry processing facilities, where total washdown with disinfectants
occur repeatedly and petro-chemical facilities, including
offshore petroleum sites
• Hubbell Wiegmann metal NEMA 4X enclosures are made
of 304 stainless steel
• Designed to house: Allen-Bradley, ABB Controls, CutlerHammer/Westinghouse, General Electric, I-T-E Max-Flex™,
Square D
NEMA 12
From small wall mounts to multi-door freestanding
NEMA 1
Protecting controls and terminations
• Designed to house: Allen-Bradley, ABB Controls, CutlerHammer/Westinghouse, General Electric, I-T-E Max-Flex™,
Square D
• Gasketed doors seal the enclosure’s contents from airborne contaminants and non-pressurized water and oil.
• Single Door Wall Mount
• Small Continuous Hinge Wall Mount
• Large Continuous Hinge Wall Mount
• Screw Cover Wall Mount - painted with/without Knockouts
• Screw Cover Wall Mount - galvanized with/without
Knockouts
NEMA 3R
For outdoor use
NEMA 4
For occasional washdown
NEMA 4/12
Powerful and Attractive
NEMA 4X
Stainless steel enclosures
• Gasketed and the door is clamped for maximum sealing.
They have continuous hinges, mounting feet, and padlock
hasps.
• Applications where a pressurized stream of water will be
used or machine tool cutter coolant.
• JIC Lift-Off Cover Wall Mount, Single-Door Wall Mount,
JIC Continuous-Hinge Wall Mount, Two-Door Floor Mount,
> Compra en Línea
www.sdicontrol.com
• Reversible doors for left or right opening
• Semi-flush 1/4-turn latches for easy opening / positive
sealing
• Available in wall mount models with sizes up to 60” x 36”.
• Optional mounting feet are available for conventional wall
mounting
• Single Door Wall Mount (Stainless Steel optional) and
Sub-panels
• Provide a degree of protection against falling rain or
sleet; and to be undamaged by the formation of ice on the
enclosure.
• Can be used as a wiring box, junction box or pull box in
commercial and general industrial.
• Screw Cover Wall Mount, Hinge Cover Wall Mount, Wiring
Trough and Sub-panels
• For a harsher environments than standard NEMA 4
units, applications where corrosive materials and caustic
cleaners are used
• Applications include food, such as meat/poultry processing facilities, where total washdown with disinfectants
occur repeatedly and petro-chemical facilities, including
offshore petroleum sites.
21
NEMA 12
Indoor applications
• Gasketed doors seal the enclosure’s contents from airborne contaminants and non-pressurized water and oil. These
NEMA enclosures are available in sizes from small wall
mounts to multi-door freestanding models.
• Recommended for: packaging, material handling, noncorrosive process control, and manufacturing applications
NEMA 12 Pushbutton
Less time, more productivity
• PBGX Series 22.5 mm, NPB Series 30.5 mm, PBXD (extra
deep) Series 30.5 mm, PSL (slimline) Series 30.5 mm,
PBYX (extra size) Series 30.5 mm and PBSS (stainless
steel) Series 30.5 mm Pushbutton NEMA 12 Wall Mount
• WPBA (sloping) Series 30.5 mm Pushbutton NEMA 12
Operator Console
• Hole Plugs & Seals
NEMA 12 Operator Consoles & Consolets
Industrial Electrical Enclosures
• W1C NEMA 12 Operator Consoles - Single-Door Freestanding
• WC9 NEMA 12 Operator Consoles - Single-Door Consolets
• WC10 NEMA 12 Operator Consoles - Single-Door
• WC12 NEMA 12 Operator Consoles - Two-Door
• WC14 NEMA 12 Operator Consoles - Single-Door
• Column and Base Series Pedestal
• Optional Console Top and Sub-panel and Sloping Cover
No metálicos
NEMA Sub-Panels
Must be purchased separately
• N1P - for NEMA 1 and NEMA 12 Enclosures
• P - for NEMA 4, 4X, and 12 Continuous
• NP - for NEMA 1, 4, 4X, 4/12 and 12 Wall Mount
• NPDD - for NEMA 1, 4, 4X, 4/12 and 12 Two-Door Floor
Mount
• WA Series - Sub-panels, center panel supports, swingout panels and side-mount panels for NEMA Freestanding
Enclosures.
Enclosure Parts & Accesories
The Hubbell-Wiegmann line
NEMA 4X & 3R
Hubbell Wiegmann Fiberglass
Enclosure Fans and Exhaust Grilles
Fan Kits
Vortex Coolers
W7 Series
• Lighting
• Exhaust Grille and Filter
• Vortex Coolers
• Hole Plugs / Casters / Panel Supports
• Swing Out Panel, Floor Stand and Filter Fan kits
• Electrical Interlocks & Defeaters
• Locks and Latches
• Premier Series (6 in. X 6 in. to 16 in. X 14 in.)
• JIC Series (6 in. X 4 in. to 20 in. X 16 in.)
• Slimline Junction (3 - 17 in. X 3 in. to 9 in. X 6 in.)
• Pushbutton Enclosures for 22mm & 30mm (1 PB to 25
PB)
• Control NEMA 3R and 4X (30 in. X 20 in. to 60 in. X 36 in.)
• Sub-Panels, Spare Parts & Accessories
Control térmico
Air Conditioners
NEMA / UL Type 4, 4X, 12
• Digital Temperature Controller
• Active Condensate Evaporation System
• CFC-Free refrigerant
• Pre-wired for external alarm monitoring connections
• Anti short-cycle compressor protection
• Range from 1,000 to 8,000 BTUs
• 115V with an expected service life of 30,000 hours
• Polycarbonate fire retardant plastic grilles, UL94-VO
• “Click and Fit” system installation without screws
Exhaust Grilles and Exhaust Filters
• Durable, reusable filter mat included
• NEMA 1 (NEMA 12 with optional WPFG Series gasket)
• IP43 (IP54 with optional WPFG Series gasket)
• Suitable for harsh environments
• Small physical size
• Creates cool air without refrigerants (no CFCs, HCFCs)
• Exceptionally reliable - no moving parts and virtually no
maintenance
• UL Listed
• NEMA 12, NEMA 4 or NEMA 4X
Communication Ports
Single Outlet
Communication Ports
Duplex Outlet / GFCI Duplex Outlet
Conectores de Paneles
Communication Ports
No Outlet
• All D-Sub connectors are FEMALE EXTERIOR and MALE
INTERIOR referenced to the cabinet
• 9-pin D-Sub pin configuration is available as a break out
configuration in some unit
• NEMA / UL Type 12, 4, & 4x, IP 65, UL file number
E329932, RoHS compliant
22
• Aluminum housing with gasket
• Interface connections are straight through, pin 1 to pin
1, etc.
• Reset 3 Amp circuit breaker to limit the power output of
the unit
• NEMA / UL Type 12, 4, & 4x, IP 65, UL file number
E329932, RoHS compliant
• Aluminum housing with gasket
• Interface connections are straight through, pin 1 to pin
1, etc.
• Reset 3 Amp circuit breaker to limit the power output of
the unit
• NEMA / UL Type 12, 4, & 4x, IP 65, UL file number
E329932, RoHS compliant
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Armado del Gabinete
Terminal Blocks
Standard DIN-Rail
• Single-level, Double-level and Triple-level DINnectors
• Ground DINnectors
• Mini DINnectors
• Disconnect and Plug-in DINnectors
• Thermocouple and Circuit Protection DINnectors
• Direct Mount Terminal Blocks
Cables
Electrical Hook-Up / Building Wire
• Insulation Type MTW Sizes - 10, 12, 14, 16, 18 AWG
• Insulation Type TFFN Sizes - 16, 18 AWG
• Insulation Type THHN Sizes - 4, 6, 8, 10, 12, 14 AWG
• Wire Marking Tags
Wire Duct
Wire Management
• Dinosaur Flexible
• Replacement Wire Duct Covers
• Duct separators, Wire retainers, Identification tags and
more
• Solid Wall Wire Duct - TSH Series
• Thin Finger Wire Duct - T1E Series
• Wire Duct - T1 Series
DIN Rail
Brackets for DINnector Terminal Blocks and
other
• Slotted zinc-dichromated steel
• 1 meter (39 inch) lengths
• 35mm or 15mm widths
• 7.5mm or 15mm heights
ZIPLink
Five-second Device Wiring System
• Productivity3000 PAC
• DL05/06, DL205, DL305, 405 and CLICK PLC
• GS/DuraPulse Drives
• SureServo Drives
• Available for other PLC brands
Partes y Accesorios
For NEMA enclosures
• Floor & Stand Kits
• Mounting Feet
• Casters, Drip Shield Kits, Windows Kits
• Adapter Plates for Disconnect Enclosures
• Hole Seals & Plugs, Folding Shelves, Grounding
• Locks & Latches, Electrical Interlocks & Defeaters
• Internal Mounting
Botones, Interruptores e Indicadores
Variedad y calidad en indicadores y botones industriales
Las mejores opciones del mercado en lo que respecta a botones
pulsadores, interruptores de operador, paros de emergencia, luces
piloto (leds), torretas y un sinfín de alternativas de alta calidad ya
sea en metal o no metal.
22mm
Metal
Pilot Devices
• Chrome-plated corrosion resistant
• Switch support base mounts into panels up to 6mm thick
• Pressure terminals: eVasy, secure wiring, up to 14 AWG
wire
• Mount up to six contact blocks in any combination
• Switch contacts rated at 10 amps thermal current
• IP65 Rating (after installation), RoHS compliant
> Compra en Línea
www.sdicontrol.com
Non metal
Momentary Switches / Panel Indicator Lights
• Robust Remote I/O Modules
• Controller Modules
• Analog I/O Modules
• Digital I/O Modules
Eaton e22
from Eaton Cutler-Hammer
• (IP65, IP66 ratings to IEC 529) UL Listed (NEMA) Types 1,
2, 3, 3R, 4, 4X, 12, and 13 when installed
• Complete assembled devices
• RoHS Compliant
• Transformer, full voltage, resistor, or LED light units.
23
30mm
Eaton HT800 Series
from Eaton Cutler-Hammer
• NEMA 1, 2, 3, 3R, 4, 4X, 12, and 13 protection - Use them
indoors or out. Color-coded contact blocks are NEMA rated
to A600/ P600 and IEC rated AC15/ DC13
• Anodized aluminum mounting ring
• Grounding kits included with each device
• Extended lamps and LEDs
Interruptores de Pie
Fuji Electric
AR30B0R Series
• Large 65mm mushroom heads with 30mm
metal mounting
• Non-illuminated
• Extended lamps and LEDs
Interruptores sencillos y dobles
Free movement / Locked in neutral position
Stacklights
Stack Lights Modules/ Industrial Emergency
Lights
Hazardous Location Control Stations
Killark control stations
• Dimensions: 11.02” x 5.5”x 5.7” (280 x 140 x 145mm)
• Materials: base, cover and pedal of shock-resistant ABS
• Colors: Single unit:gray base, yellow cover, or, gray base,
half-red cover Double unit: one gray base with gray cover,
and one gray base with yellow cover
Dispositivos de Señalización
Visual-Audible
Warning Alarms/ Annunciators / Sound
Buzzers
• 22.5mm panel-mount electrical
• With LED indicators for industrial control panel applications
• WERMA 150 Series LED Indicator/ Buzzers
• WERMA 450 Series LED Indicator / Buzzers
• WERMA modular stacklights / Stack light tower systems
• WERMA pre-assembled stacklight units
• WERMA FlatSIGN LED signal column (wall mount)
• Eaton pre-assembled stacklight units and components
• Designed to contain and extinguish explosions
• Pushbutton, selector switches and pilot light bodies are
copper-free aluminum
• Operating shaft in both pushbuttons and selector switches are stainless steel
• Miniature and standard size pushbuttons (miniature 3/4”
overall diameter, standard 1-3/8” overall diameter)
Productos de Control Eléctrico
Protección personalizada para tu conexión
Ya sea que busques fusibles, interruptores, o cualquier otro tipo
de protección en circuitos, en Sdi> disponemos de una completa
selección de dispositivos de protección industrial para diversas
aplicaciones y requerimientos para tu control eléctrico.
Circuitos de Protección / Fusibles / Desconectadores de Energía
Miniature Circuit Breakers
UL 489 DIN rail mounted
• Complete family rated for 10 kAIC @ 277/480 VAC
• Single pole, two-pole and three-pole
• Thermal magnetic overcurrent protection: C and D curves
• Fulfills UL 489, CSA C22.2 No.5 and also IEC 60947-2
Standard
• Module width of only 17.7 mm (per pole)
24
MCCB
15-800 and 15-600 Amp Breakers
• Suitable for feeder and branch circuit protection
• Advanced arc extinguishing technology
• 9 Frame sizes from Fuji and Eaton Corp.
• Visual handle position indicators
• UL 489 rated
Supplementary Circuit Protectors / Breakers
UL1077 Rated
• WMZ Series Single, Double and Triple Pole
• EURO series mini single-pole 0.25A to 10A circuit
breakers
• DN-DIS-BLADE - circuit disconnect
• 35 mm DIN-rail mountable, Protector Breakers
• CE marked in accordance with Low Voltage Directive
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Fuses, Fuse Holders and Fuse Blocks
Current ratings up to 600 amps
• Current Limiting: Class CC, Class J, Class RK
• General Purpose: Class M Midget and Small Dimension
• General Purpose Electronic Ceramic
• GS Drives Fuse Kits & Spare Fuses
• Small Dimension Electronic Glass
•v PLC Spare Fuses
Disconnect Switches
UL 508 & UL 98 Rated
• Used Disconnect and Non-Fused Switch Disconnects
• The SC Series, FB Series and the new Gladiator CFS
Series switch disconnects meet UL98 standards
• UL, CSA, CE and IEC rated
• Double break contacts
• The SD series of modular load disconnect switches meet
UL 508 standards
Manual Motor Controllers
AC motor controllers/ motor disconnects
• Motor controller switch sizes in 30 Amps, 40 Amps and
60 Amps up to 600 VAC
• Quick make, slow break design
• Thermoset body provides high resistance to electrical arc
tracking
• Silver alloy contacts for excellent conductivity and
extended life
Productos de Poder
Respaldo y confianza para tu sistema
Contamos con transformadores y fuentes de poder, incluyendo transformadores encapsulados, fuentes de poder para montaje en riel, entre otras
diversas alternativas.
Los transformadores de control están especialmente diseñados para
aplicaciones que requieren estabilidad confiable en voltaje de salida y
altamente regulado; estos convertidores proporcionan una fuente de poder
confiable para cargas sensibles en procesos de control industrial.
Fuentes de Poder DC
RHINO PSM Series
Slim-line, metal case 12 VDC and 24
RHINO PSP Series
Slim-line, plastic case of 5, 12 and 24VDC
RHINO PS Series
Low profile, metal case 12 VDC and 24 VDC
RHINO PSC Series
Plastic case 5 VDC, 12 VDC and 24 VDC
RHINO PSS Series
Panel mount 24 VDC or 12 VDC
RHINO PSB Series
DIN-Rail mount basic DC voltage
• 12 VDC, 78 to 156 watts - 24 VDC, 90 to 600 watt
• Industrial grade metal case
• DIN rail mounting/optional wall mount
• Specialty modules for redundancy, power backup and
UPS
• NEC Class 2 Compliant, low-profile and adjustable output
• 12W to 90W - Universal 85 to 264 VAC input voltage and
output current limitation
• UL508 listed, UL1310 recognized for NEC Class 2 compliance, CE marked - DIN-rail mount
> Compra en Línea
www.sdicontrol.com
• 5 VDC, 20 W, 4 A output
• 12 VDC, 24 to 120 watts - 24 VDC, 24 to 120 watts
• Universal input 85 to 264 VDC/VAC
• DIN rail mount, compact plastic housing
• 35 to 100 Watts
• Universal input voltage, 85-264 VAC / 100-375 VDC
• Rugged aluminum housing
• Overload, overvoltage and thermal protection
• 12VDC, 50 to 75 watt - 24 VDC, 50 to 600 watt
• Selectable input voltage: 93-132 VAC or 187-264 VAC
• Durable metal case
• DIN rail mount
• 24 VDC or 12 VDC outputs, 15 to 480 Watts
• Universal input voltage, 85-264 VAC / 120-375 VDC single
phase or 320-575 VAC 3-phase input
• Overload, overvoltage and thermal protection
25
RHINO PSE Series
Single and dual output encapsulated
• 5V, 12V, 15V and 24V DC outputs available (including
some negative voltage models)
• Single output or 4 different dual output models
• Universal input 85-264 VAC, 47-440 Hz (60 Watt, 47-63
Hz)
• AC-DC mini power supply models
• Chassis mount, panel mount, or 35mm DIN rail mount
with optional adapter kit
24 VDC Open Frame
Panel or DIN rail mounted
• 24 VDC output, 1.2A (30W) and 3.7A (90W) versions
• Selectable input voltage (95-130 VAC or 190-264 VAC)
• Compact footprint saves panel space
• Overload and short circuit protection
Convertidores DC a DC
Converters
Plastic Slim-Line Case
• Ultra-wide input voltage range
• 5, 12 and 24 VDC adjustable output ranges
• Overload and short circuit protection
• Low ripple and noise
• I/O-isolation 1500 VDC
• Reliable snap-on mount on 35mm DIN rail
• Wall-mount bracket included
Stepper Power Supplies
STP Series
• 120/240 VAC selectable input
• 32V, 48V, 70V DC output power supply models available
• All models have additional 5VDC, 500 mA regulated logic
supply
• The additional 5V supply has electronic overload protection
• Fusing is included for both incoming AC and outgoing DC
power
Salidas de Poder
Isolated Multiple Outputs
FA-DCDC-1
DIN Rail convenience outlet
3 Receptable
Encapsulated Transformers
Commercial quality
Buck-Boost Transformers
NEMA Rated
Open-Style UL Listed
UL 1953 Listed
Open-Style UL Recognized
UL 1059 Recognized
• Four Outputs: +/-10VDC and +/-5VDC
• Each output is rated at 125mA
• I/O-isolation 1500 VDC
• Input voltage range is 12-24V DC ±15% at approx. 6.7
Watts
• 30mm round AT / VT1 / PTW Series
• Wall-mount bracket built-in
• 125 VAC input, 15A max
• 35 mm DIN Rail
• 14 to 12 AWG wire capacity
• UL 508 listed
Transformadores de Energía
Compact Control Transformers
High inrush applications
• MQMJ Series – 480x240 VAC to 240x120 VAC
• MGJ Series – 380x277x208 VAC to 240x120 VAC
• PG Series – 240x120 VAC to 24x12 VAC
• MLI Series – 480x240 VAC to 120x25 VAC
• C1F****LE Series – 480x240 VAC to 240x120 VAC
• C1F****WE Series – 277x¿/240/208/120 VAC to 240x120
VAC
• C1F****XE Series – 240x120 VAC to 24x12 VAC
• MLI Series – 220/208/200/190x440/416/400/380 to
240x120 VAC
• Encapsulated with electrical grade resin
• Cores of high-quality electrical steel
• 60 Hz operation
• NEMA 3R-rated enclosures
• 240x120 to 24x12 VAC
• 240x120 to 32x16 VAC
Bloques de Distribución de Energía
Finger-Safe
UL 1953 Listed
• Fully enclosed block, IP 20
• DIN Rail
• Tin plated Aluminum Connectors suitable for copper
conductors
26
• Up to 310 Amps
• 600 VAC/DC
• Tin plated Aluminum Connectors suitable for copper
conductors
• Panel Mounting
• Up to 760 Amps
• Aluminum box connectors, copper wire
• Tin plated Aluminum Connectors suitable for copper
conductors
• For branch circuit applications
Larga distancia sin costo > 01 800 777-9100
en Monterrey > 8100-9100
Filtros
Power Line filters / Surge Protectors
ADPV Series Power Line Filters
• Standard filter series
• AC voltages: 120 VAC, 240 VAC
• Current range: 1A, 3A, 5A
• Status indicator: LED
• Alarm contacts: No
Conectores con Interfaz de Panel
Power Line filters / Surge Protectors
ADPH Series Power Line Filters
• AC voltages: 120 VAC, 240 VAC
• Current range: 10A, 15A
• Status indicator: LED
• Alarm contacts: Yes (form C),
• @ 250VAC / 30VDC contact rating
ZIP port Panel Interface Connectors (PICs)
Pass through Connections
• No outlet / Communication Ports
• Single Outlet / Communication Ports
• Duplex Outlet / Communication Ports
• GFCI Duplex Outlet / Communication Ports
Neumática
Presentamos NITRA, tu mejor opción en precio y calidad
Incluye series de productos que ayudan a satisfacer una amplia
gama de aplicaciones de suministro de aire, regulación de la presión
y filtración, entre otros. Cada serie está diseñada para funcionar en
aplicaciones autónomas, su diseño modular permite el montaje de
campo para la combinación de componentes adicionales.
Las series de NITRA son: AF Series, NITRA AR Series, AFR
Series, AL Series, NITRA ARV, AVP series, AVS-3 series y AVS-5.
Componentes Nitra
Air preparation
Filtration, regulation and compressed lubrication
Solenoid Control Valves
Pneumatic Directional Control
Cilinders and position switches
Interfacing Pneumatic and Electrical Systems
Pneumatic Air Cylinders
NITRA series
Push to Connect Fittings
Quick connect and release
Valves and Speed Controlers
Accurate air flow regulation
• Air Filters
• Air Lubricators
• Combination Air Line Filter and Regulators
• Manual Shut-off Air Pressure Relief Valves
• Pneumatic Air Preparation and Accessories
• High working pressure and temperature/chemical
resistance
• 100 foot and 500 foot package sizes
• Shore A 98 hardness
• Strong, flexible and kink resistant
> Compra en Línea
www.sdicontrol.com
• General Purpose Solenoid Valves
• Modular / Manifold Solenoid Valves
• Process / Pipeline Solenoid Valves
• Accessories - Pneumatic Control Air Valve Solenoids
• Push-to-Connect Fittings (Thermoplastic & Stainless
Steel)
• Threaded Brass Fittings
• Bulkhead unions
• Unions: straight, reducers, Teeelbow, Y, cross and triple
branch
• Working pressure: -29.5” Hg to 800 psi
• Working Temperature 32 to 390°F (0 to 200°C)
• Electronic switch output, PNP or NPN, normally open and
normally closed
• Solid state reliability, no moving parts for longer life
• AMR technology with small hysteresis for precise sensing
• Compact and easy to mount on round body and T-slot
pneumatic cylinders
• LED switch status indication
• Elbow Meter-in, meter-out and in-line flow configurations
• NPT and BSPT (R) threads available
• Air control valve bodies can be rotated after installation
• Release rings are color coded to differentiate between
meter-in and meter-out
• Working pressure: -29.5” Hg to 150 psi.
• Working Temperature 32 to 140°F (0 to 60°C)
27
Somos una empresa mexicana comprometida con las
exigencias de la industria. Proveedores de diversos
productos y soluciones de alto desempeño, divididos
en 2 áreas especializadas, dedicando lo mejor de
cada una para nuestros clientes.
La manera más sencilla de adquirir equipos y productos para
automatización industrial. Con el constante apoyo de nuestras
alianzas estratégicas ofrecemos precios competitivos, en
conjunto de una logística efectiva, eficiente y en capacitación
continua.
Prolongamos nuestra visión de simplificar procesos, con nuestra tienda en
línea que ofrece una manera segura, sencilla y práctica de comprar;
también encontraras una gran variedad de publicaciones, noticias, seminarios e información técnica de nuestros productos.
Tienda en línea: www.sdicontrol.com
Ingeniería y equipos aplicados para optimizar su producción
al máximo. Formada por un grupo de ingenieros enfocados
a diseñar y brindar soluciones efectivas y al mejor costo en
manejo de materiales.
Trabajando en cercanía de nuestros clientes al implementar equipos eficientes y ergonómicos que faciliten la operación de los trabajadores. Contamos
con diseño in house y colaboradores que hacen las modificaciones requeridas para equipos personalizados, permitiendo una instalación y automatización con empresas especializadas para cada solución.
Conoce todos los productos en: www.sdicmh.com
Soporte Dinámico Industrial S.A. de C.V.
Zona #510 Col. Chapultepec, San Nicolás de los Garza, N.L. 66450
Tel.: (81) 8100-9100, L.D. sin costo 01-800-777-9100
[email protected] | www.sdindustrial.com.mx
