Bombas de engranaje

FLUIDAL, S.L. Pº Ubarburu,79 20.115 Astigarraga (Gipuzkoa) Telf. 943 453 795 Fax. 943 454 811 - www.fluidal.com - [email protected]
28
Electrical motors
Pumps/gear flow dividers/
multigear...
Tanks, bellhousings,
couplings and filters
Bombas de engranaje
Gear pumps
Pompes à engrenage
Bomba engr.tapa eur./roscada/cónico 1:8 Gr.I
Gear pump eur.cover/threaded/conical 1:8 Gr.I
Pompe engr.couv.eur./taraudée/conique 1:8 Gr.I
GIRO DCHA.
RIGHT TURN
GIRO IZDA.
LEFT TURN
PS1007062D PS1007062S
PS1007064D PS1007064S
PS1007065D* PS1007065S*
PS1007066D PS1007066S
PS1007067D* PS1007067S*
PS1007068D PS1007068S
PS1027037D PS1027037S
ASPIRACIÓN
INLET
PRESIÓN
PRESSURE
PRESIÓN MAX. (bar)
MAX. PRESSURE (bar)
PRESIÓN PUNTA (Bar)
MAX. PEAK PRESSURE (Bar)
R.P.M.
CM³/REV
€
1/4” BSP
1/4 “BSP
1/4 “ BSP
1/4 “ BSP
1/2 “ BSP
1/2 “ BSP
1/2 “ BSP
3/8” BSP
3/8 “BSP
3/8 “ BSP
3/8 “ BSP
3/8 “ BSP
3/8” BSP
1/2 “ BSP
240
260
260
240
240
185
135
280
300
275
240
240
200
150
5000
5000
5000
5000
4000
4000
3000
1,05
1,9
2,5
3,1
3,8
4,7
6,25
140,70
144,18
149,15
149,30
152,26
154,42
160,79
Vacuum and heating
interchangers
Joysticks and directional
valves
Directional valves and
subplates
Hydraulic directional
control valves
Hydraulic Valves
*Hasta fin de existencias. / *Until end of stock. / *Jusqu`à fin du stock.
Bomba engr.tapa eur./br.Bosch/cónico 1:8 Gr.I
Gear pump eur.cover/Bosch fl./conical 1:8 Gr.I
Pompe engr.couv.eur./br.Bosch/coniq.1:8 Gr.I
GIRO DCHA.
RIGHT TURN
GIRO IZDA.
LEFT TURN
ASPIRACIÓN PRESIÓN
INLET
PRESSURE
PS1007082D
PS1007084D
PS1007085D
PS1007087D
PS1007088D
PS1007089D
PS1007090D
PS1017091D
PS1007082S
PS1007084S
PS1007085S
PS1007087S
PS1007088S
PS1007089S
PS1007090S
PS1017091S
30
30
30
30
30
30
30
30
PRESIÓN MAX. (bar)
MAX. PRESSURE (bar)
PRESIÓN PUNTA (Bar)
MAX. PEAK PRESSURE (Bar)
R.P.M.
CM³/REV
€
240
260
260
240
185
185
135
135
280
300
275
240
200
200
150
150
5000
5000
5000
4500
4000
4000
3000
3000
1,05
1,8
2,45
3,8
4,7
5,55
6,25
7,6
145,49
145,49
145,49
152,26
152,26
153,10
159,87
159,87
30
30
30
30
30
30
30
30
*Hasta fin de existencias / *Until end of stock / *Jusqu`à fin du stock
Tapa eur./eje cónico 1:8 eur./brid.eur. Gr.II
European cover-european conical shaft-european lateral way out Gr.II
Flasque europ./arbre conique 1:8 europ./brides europ. Gr.II
ARTÍCULO
PART Nº
EJE
SHAFT
ASPIRACIÓN PRESIÓN
INLET
PRESSURE
PS2007020D*
PS2007021D
PS2007022D
PS2007023D
PS2007025D
PS2007027D
PS2007028D
PS2007030D*
PS2007031D*
PS2007020S*
PS2007021S
PS2007022S
PS2007023S
PS2007025S
PS2007027S
PS2007028S
PS2007030S*
PS2007031S*
30
30
30
30
40
40
40
40
40
PRESIÓN MAX. (bar)
MAX. PRESSURE (bar)
PRESIÓN PUNTA (Bar)
MAX. PEAK PRESSURE (Bar)
R.P.M.
CM³/REV
€
250
250
250
250
240
200
170
140
130
300
300
300
300
300
240
210
180
170
3500
3500
3500
3500
2500
2200
2000
2000
2000
4,1
6,2
8,2
11,2
14
20
22,5
28
30
213,16
199,04
201,62
205,92
213,83
221,86
232,07
245,30
248,68
30
30
30
30
30
30
30
30
30
Hydraulic cylinders
*Hasta fin de existencias. / *Until end of stock. / *Jusqu`à fin du stock.
Tapa Bosch ant./eje cónico 1:5 /br.Bosch Gr.II
Former cover-conical shaft-lateral way out Bosch flange Gr.II
Flasque bosch ancienne/arbre conique 1:5/ bride Bosch Gr.II
ARTÍCULO
PART Nº
EJE
SHAFT
20C15X007 Conico Bosch
20A8.2X007 Conico Bosch
20A15X007 Conico Bosch
ASPIRACIÓN PRESIÓN DESCRIPCIÓN
CAUDAL MÁX. PRESIÓN MAX. (bar)
PRESSURE DESCRIPTION MAX. FLOW (l/min) MAX. PRESSURE (bar)
INLET
35
35
35
40
40
40
Brida Bosch
Brida Bosch
Bridas Bosch
21,6
11,32
21,6
250
250
250
*Hasta fin de existencias. / *Until end of stock. / *Jusqu`à fin du stock.
TAPA
COVER
R.P.M. CM³/REV
Bosch antigua 2500
Bosch antigua 3500
Bosch antigua 2500
15
8,2
15
