Single Zone Mini Splits - 15 SEER
Air Conditioning & Heat Pump
Thermal Zone Ductless Mini-Split Air Conditioning and Heat Pump systems offer the perfect solution for an easy
install with a sleek design. This new series of product offers 15 SEER inverter technology with many new features and
engineering enhancements for more efficient and quiet operation.
Features
• 15 SEER
• Inverter Technology
• Follow Me Function - Give you ability to move sensor
from indoor unit to remote with the push of a button.
• Low Ambient Control
• Compressor Heater Blanket - Allows for smoother, easier
start-up in cold weather.
• Freeze Protection - Sets heat temperature at 46°F to
prevent freezing when conditioned space is not being occupied. Perfect for vacation homes.
• Remote Control - Operable up to 33 feet from evaporator.
• Adjustable Louvers
• Diagnostic Codes
• Unique Indoor Display
• Turbo Fan Function
• Selectable Temperature Range 62°F to 86°F
• Economy/Sleep Function
• Outdoor operating Range:
Cooling: 5°F to 122°F
Heating: 5°F to 86°F - Heat Pump Models
• Auto Restart
• Timer Function
• 5 Year Compressor/ 1 Year Parts Warranty
Please note: All New 15 SEER Mini Splits are NOT compatible with the older style 13 and 14 SEER units.
Line Set Matrix
Product Code Model Number
(239-0001)
CTK141225
1/4”x1/2”x25’
(239-0002)
CTK141250
1/4”x1/2”x50’
(239-0003)
(239-0004)
(239-0005)
(239-0006)
CTK385825
CTK385850
CTK143825
CTK143850
3/8”x5/8”x25’ 3/8”x5/8”x50’ 1/4”x3/8”x25’ 1/4”x3/8”x50’
244-1201
9A45YMI
244-1202
12A45YMI
x
x
244-1204
18A45ZMI
x
x
244-1205
24A45ZMI
244-1301
9H45YMI
244-1302
12H45YMI
x
x
244-1304
18H45ZMI
x
x
244-1305
24H45ZMI
x
x
242-1306
30H46ZMI
X
X
242-1307
36H44ZMI
X
X
x
x
x
x
x
x
Note: Accessory kits AK25 (25 ft.) / AK50 (50 ft.) includes, cable (14AWG & 4C), 3” wall sleeve, drain tubing, tape and putty.
2
(239-0007)
CTK145825
1/4”x5/8”x25’
(239-0008)
CTK145850
1/4”x5/8”x50’
Single Zone Mini Splits - 15 SEER
Air Conditioning Unit Specifications
PRODUCT CODE
MODEL NUMBER
244-1201
9A45YMI
244-1202
12A45YMI
244-1204
18A45ZMI
244-1205
24A45ZMI
uF
Ml
1Ph,115V, 60Hz
15/30/19
--9000
1000
8.9
15.0
9.0
----------------2.2
DA108X1C-23EZ
ROTARY
GMCC
11021
855
4.95
------45
ESTER OIL VG74 480 ml
1Ph,115V, 60Hz
15/30/20
--12000
1330
11.8
15
9
----------------2.6
DA108X1C-23EZ
ROTARY
GMCC
11021
855
4.95
------45
ESTER OIL VG74 480 ml
1Ph,208/230V,60Hz
13/20/14
--18000
1920
8.7
15
9
--------4
DA130M1C-31FZ
ROTARY
GMCC
13443
1005
3.95
----INTERNAL
--ESTER OIL VG74/480
1Ph,208/230V,60Hz
14/25/16
--22000
2220
10.1
15
9
------------5.3
DA150S1C-20FZ
TWIN ROTARY
GMCC
15286
1150
9.7
--KSD301
EXTERNAL
35
ESTER OIL VG74/500
W
uF
RPM
CFM
dB(A)
IN
IN
LB
244-1201-E
9A45YIMI
RPG15A
Welling
46
3.0
1200/1050/800
480/420/320
39/35/28
26.77x7.01x10.04
29.33x10.04x12.99
15.43/17.64
244-1202-E
12A45YIMI
RPG15A
Welling
46
3
1200/1050/800
580/500/400
39/35/29
30.31X7.40X10.04
32.87X10.43X12.99
16.53/20.94
244-1204-E
18A45ZIMI
RPG28H
Welling
58.5
1.5
1250/1100/800
750/660/480
42/39/31
35.63X7.80X10.83
38.19X10.63X13.58
19.84/25.35
244-1205-E
24A45ZIMI
RPG45B
BROAD OCEAN
80.5
3
1200/1100/900
1250/1150/950
47/45/39
40.55X8.58X12.40
43.90X15.55X11.81
26.46/33.07
W
uF
RPM
CFM
dB(A)
IN
244-1201-C
9A45YOMI
YDK24-6AS
Welling
64/47
3.0
860/ --- /660
824
54
25.98x10.43x21.26
244-1202-C
12A45YOMI
YDK24-6AS
Welling
64/47
3
860/---/660
1400
55
25.98X10.43X21.26
244-1204-C
18A45ZOMI
YDK49-6B
Welling
119/96
2.5
860 / --- / 680
2300
59
29.92X11.22X23.23
244-1205-C
24A45ZOMI
YDK53-6FB(B)
Welling
136/130
2.5
930 / --- / 830
2700
59
33.27X12.60X27.56
Packing (W*D*H)
IN
31.10x13.98x24.41
31.10X13.98X24.41
34.92X13.98X25.39
37.99X15.55X29.72
Net/Gross weight
IN
oz.
PSIG
IN
FT
FT
FT
OZ/FT
62.83/69.45
R410A /31.8
550/340
1/4” / 3/8”
82
33
25
0.161
YES
I
62°F to 86°F
5~122°F
65.04/71.65
R410A / 31.8
550/340
1/4” / 1/2”
82
33
25
0.161
YES
I
62~86 °F
5~122 °F
76.06/81.57
R410A / 29.9
550/340
1/4” / 1/2”
98
66
25
0.161
YES
I
62~86 °F
5~122 °F
98.11/105.82
R410A / 41.6
550 / 340
3/8” / 5/8”
164
82
25
0.322
YES
I
62~86 °F
5~122 °F
Power supply
Max. current / Breaker size / Min. circuit ampacity
Starting current
Cooling Capacity
Cooling Input
Cooling Rated current
SEER
EER
Heating Capacity
Heating Input
Heating Rated current
HSPF / COP
Moisture Removal
Compressor Model
Compressor Type
Compressor Brand
Compressor Capacity
Compressor Input
Rated current(RLA)
Locked rotor Amp(LRA)
Thermal protector
Thermal protector position
Compressor Capacitor
Refrigerant oil/oil charge
INDOOR DATA
PRODUCT CODE
MODEL NUMBER
Indoor Fan Motor Model
Indoor Fan Motor Brand
Indoor Fan Motor Input
Indoor Fan Motor Capacitor
Indoor Fan Motor Speed(H/M/L)
Indoor air flow (H/M/L)
Indoor noise level (H/M/L)
Dimension(W*D*H)
Indoor unit
Packing (W*D*H)
Net/Gross weight
OUTDOOR DATA
PRODUCT CODE
MODEL NUMBER
Outdoor Fan Motor Model
Outdoor Fan Motor Brand
Outdoor Fan Motor Input
Outdoor Fan Motor Capacitor
Outdoor Fan Motor Speed
Outdoor air flow
Outdoor noise level
Dimension(W*D*H)
Outdoor unit
Refrigerant type
Design pressure
Liquid side/ Suction side
Max. refrigerant pipe length
Maximum vertical height
Design length
Extra Refrigerant charge above design length
Remote Control
Electrical Shock Protection
Indoor selection range - remote
Outdoor operating range (cool/heat) w/LoAmbientKit
PH-V-Hz
A
A
BTU/H
W
A
BTU/WH
BTU/WH
BTU/H
W
A
PNTS/H
BTU/H
W
A
A
°F
°F
3
Single Zone Mini Splits - 15 SEER
Heat Pump Unit Specifications
PRODUCT CODE
MODEL NUMBER
Power supply
Max. current / Breaker size / Min. circuit ampacity
Starting current
Cooling Capacity
Cooling Input
Cooling Rated current
SEER
EER
Heating Capacity
Heating Input
Heating Rated current
HSPF / COP
Moisture Removal
Compressor Model
Compressor Type
Compressor Brand
Compressor Capacity
Compressor Input
Rated current(RLA)
Locked rotor Amp(LRA)
Thermal protector
Thermal protector position
Capacitor
Refrigerant oil/oil charge
INDOOR DATA
PRODUCT CODE
MODEL NUMBER
Indoor Fan Motor Model
Indoor Fan Motor Brand
Indoor Fan Motor Input
Indoor Fan Motor Capacitor
Indoor Fan Motor Speed(H/M/L)
Indoor air flow (H/M/L)
Indoor noise level (H/M/L)
Dimension(W*D*H)
Indoor unit
Packing (W*D*H)
Net/Gross weight
OUTDOOR DATA
PRODUCT CODE
MODEL NUMBER
Outdoor Fan Motor Model
Outdoor Fan Motor Brand
Outdoor Fan Motor Input
Outdoor Fan Motor Capacitor
Outdoor Fan Motor Speed
Outdoor air flow
Outdoor noise level
Dimension(W*D*H)
Outdoor unit
Packing (W*D*H)
Net/Gross weight
Refrigerant type
Design pressure
Liquid side/ Suction side
Max. refrigerant pipe length
Maximum vertical height
Design length
Extra Refrigerant charge above design length
Remote Control
Electrical Shock Protection
Indoor selection range - remote
Outdoor operating range (cool/heat) w/LoAmbientKit
244-1301
9H45YMI
244-1302
12H45YMI
244-1304
18H45ZMI
uF
Ml
1Ph,115V, 60Hz
16/30/19
--9000
1000
8.9
15.0
9.0
9000
890
7.9
8.2 / 3.2
2.2
DA108X1C-23EZ
ROTARY
GMCC
11021
855
4.95
------45
ESTER OIL VG74 480 ml
1Ph,115V, 60Hz
16/30/20
--12000
1340
11.9
15
9
12000
1320
11.7
8.2 /3.2
2.6
DA108X1C-23EZ
ROTARY
GMCC
11021
855
4.95
------45
ESTER OIL VG74 480 ml
1Ph,208/230V,60Hz
13/20/14
--18000
1920
8.7
15
9
18000
1750
8
8.2/3
4
DA130M1C-31FZ
ROTARY
GMCC
13443
1005
3.95
----INTERNAL
--ESTER OIL VG74/480
W
uF
RPM
CFM
dB(A)
IN
IN
LB
244-1301-E
9H45YIMI
RPG15A
Welling
46
3.0
1200/1050/850
480/420/320
39/35/28
26.77x7.01x10.04
29.33x10.04x12.99
15.43/17.64
244-1302-E
12H45YIMI
RPG28H
Welling
46
3
1200/1050/800
580/500/400
39/35/29
30.31X7.40X10.04
32.87X10.43X12.99
16.53/20.94
244-1304-E
18H45ZIMI
RPG45B
Welling
58.5
1.5
1250/1100/800
750/660/480
42/39/31
35.63X7.80X10.83
38.19X10.63X13.58
19.84/25.35
244-1301-C
9H45YOMI
YDK24-6AS
Welling
64/47
3.0
860/ --- /660
824
56
25.98x10.43x21.26
31.10x13.98x24.41
63.93/70.55
R410A / 31.8
550/340
1/4” / 3/8”
82
33
25
0.161
YES
I
62°F to 86°F
5~122°F / 5~86°F
244-1302-C
12H45YOMI
YDK24-6AS
Welling
64/47
3
860/---/660
1400
55
25.98X10.43X21.26
31.10X13.98X24.41
66.14/70.55
R410A / 33.57
550/340
1/4” / 1/2”
82
33
25
0.161
YES
I
62~86 °F
5~122 °F /5~86 °F
244-1304-C
18H45ZOMI
YDK49-6B
Welling
119/96
2.5
860 / --- / 680
2300
59
29.92X11.22X23.23
34.92X13.98X25.39
82.67/ 88.18
R410A / 42.3
550/340
1/4” / 1/2”
98
66
25
0.161
YES
I
62~86 °F
5~122 °F /5~86 °F
PH-V-Hz
A
A
BTU/H
W
A
BTU/WH
BTU/WH
BTU/H
W
A
PNTS/H
BTU/H
W
A
A
W
uF
RPM
CFM
dB(A)
IN
IN
IN
oz.
PSIG
IN
FT
FT
FT
OZ/FT
°F
°F
4
Single Zone Mini Splits - 15 SEER
Heat Pump Unit Specifications
PRODUCT CODE
MODEL NUMBER
Power supply
Max. current / Breaker size / Min. circuit ampacity
Cooling Capacity
Cooling Input
Cooling Rated current
SEER
EER
Heating Capacity
Heating Input
Heating Rated current
HSPF / COP
Moisture Removal
Compressor Model
Compressor Type
Compressor Brand
Compressor Capacity
Compressor Input
Rated current(RLA)
Thermal protector
Thermal protector position
Capacitor
Refrigerant oil/oil charge
INDOOR DATA
PRODUCT CODE
MODEL NUMBER
Indoor Fan Motor Brand
Indoor Fan Motor Input
Indoor Fan Motor Capacitor
Indoor Fan Motor Speed(H/M/L)
Indoor air flow (H/M/L)
Indoor noise level (H/M/L)
Indoor unit
Dimension(W*D*H)
Packing (W*D*H)
Net/Gross weight
OUTDOOR DATA
PRODUCT CODE
MODEL NUMBER
Outdoor Fan Motor Model
Outdoor Fan Motor Brand
Outdoor Fan Motor Input
Outdoor Fan Motor Capacitor
Outdoor Fan Motor Speed
Outdoor air flow
Outdoor noise level
Outdoor unit
Dimension(W*D*H)
Packing (W*D*H)
Net/Gross weight
Refrigerant type
Design pressure
Liquid side/ Suction side
Max. refrigerant pipe length
Maximum vertical height
Design length
Extra Refrigerant charge above design length
Remote Control
Electrical Shock Protection
Indoor selection range - remote
Outdoor operating range (cool/heat) w/LoAmbientKit
uF
Ml
244-1305
24H45ZMI
1Ph,208/230V～,60Hz
14/25/16
22000
2340
10.6
15
9
22000
2150
9.7
8.2/3
5.3
DA150S1C-20FZ
TWIN ROTARY
GMCC
15286
1150
9.7
KDS301
EXTERNAL
35
ESTER OIL VG74/500
242-1306
30H46ZMI
1Ph,208/230V～,60Hz
25
30000
2800
15
16
10 C.O.P.
30000
2860
16
9.6 (Region IV -US)
6.3
DA250S2C-30MT (GMCC)
Rotary
n/a
n/a
2120
8.5
n/a
n/a
n/a
n/a
242-1307
36H44ZMI
1Ph,208/230V～,60Hz
30
36000
3000
16
14.5
9.5 C.O.P.
36000
3600
18
9 (Region IV -US)
8
TNB306FPGMC-L (GMCC)
Rotary
n/a
n/a
3080
13.5
n/a
n/a
n/a
n/a
W
uF
RPM
CFM
dB(A)
IN
IN
LB
244-1305-E
24H45ZIMI
BROAD OCEAN
80.5
3
1200/1100/900
1250/1150/950
49/45/39
40.55X8.58X12.40
43.90X15.55X11.81
26.46/33.07
242-1306-E
30H46ZIMI
n/a
n/a
3
n/a
n/a
N.A / 50 / 48 / 46
56 7/8 - 10 7/8 - 13 3/8
60 1/4 - 16 9/16 - 14 3/8
53 / 71
242-1307-E
36H44ZIMI
n/a
n/a
3
n/a
n/a
N.A / 50 / 48 / 46
56 7/8 - 10 7/8 - 13 3/8
60 1/4 - 16 9/16 - 14 3/8
53 / 71
244-1305-C
24H45ZOMI
YDK53-6FB(B)
Welling
136/130
2.5
930 / --- / 830
2700
60
33.27X12.60X27.56
37.99X15.55X29.72
103.62/111.33
R410A / 56.44
550 / 340
3/8” / 5/8”
164
82
25
0.322
YES
I
62~86 °F
5~122 °F /5~86 °F
242-1306-C
30H46ZOMI
n/a
n/a
68 / 87 / 113
3
242-1307-C
36H44ZOMI
n/a
n/a
68 / 87 / 113
3
2060
n/a
35 1/4 x 13 x 33 1/4
41 1/6 x 15 9/16 x 36
157 / 165
R410A / 5.62
550 / 340
3/8, 5/8
82
32.8
16.4
0.43
YES
2237
n/a
39 x 13 9/16 x 38
44 1/8 x 17 1/8 x 43 5/16
181 / 190
R410A / 6.06
550 / 340
3/8, 5/8
82
32.8
16.4
0.43
YES
Cooling: 5°F to 109.4°F
Heating: 19.4°F to 75.2°F
Cooling: 5°F to 109.4°F
Heating: 19.4°F to 75.2°F
PH-V-Hz
A
BTU/H
W
A
BTU/WH
BTU/WH
BTU/H
W
A
PNTS/H
BTU/H
W
A
W
uF
RPM
CFM
dB(A)
IN
IN
IN
oz.
PSIG
IN
FT
FT
FT
OZ/FT
°F
°F
5
Single Zone Mini Splits - 13 SEER
Cooling Only & Heat Pump
Thermal Zone Ductless Mini-Split Air Conditioning and Heat Pump systems offer the
perfect solution for an easy install with a sleek design. Most models are 13 Seer and
most now carry the environmentally friendly 410A refrigerant.
Quiet and efficient…these systems have never been so cool!
Features
• 13 SEER
• Low Ambient Control
• Remote Control - Operable up to 33 feet from evaporator.
• Adjustable Louvers
• Diagnostic Codes
• Turbo Fan Function
• Selectable Temperature Range 62°F to 86°F
• Economy Function
• Selectable Modes - Auto/Cool/Dry/Heat (HP models only)
• Remote lockout button
• Fan Speed Selections - Auto/Low/Medium/High
• Outdoor operating Range:
Cooling: 5°F to 122°F
Heating: 5°F to 86°F
• Auto Restart
• Timer Function
• 5 Year Compressor/ 1 Year Parts Warranty
Line Set Matrix
Product Code Model Number
242-1201
9A43YMA
242-1202
12A43YMA
242-1204
18A43ZMA
242-1205
24A43ZMA
240-1392
12H43ZGX
(239-0001)
CTK141225
1/4”x1/2”x25’
(239-0002)
CTK141250
1/4”x1/2”x50’
(239-0003)
(239-0004)
(239-0005)
(239-0006)
CTK385825
CTK385850
CTK143825
CTK143850
3/8”x5/8”x25’ 3/8”x5/8”x50’ 1/4”x3/8”x25’ 1/4”x3/8”x50’
x
x
x
x
x
x
X
x
x
X
Note: Accessory kits AK25 (25 ft.) / AK50 (50 ft.) includes, cable (14AWG & 4C), 3” wall sleeve, drain tubing, tape and putty.
6
(239-0007)
CTK145825
1/4”x5/8”x25’
(239-0008)
CTK145850
1/4”x5/8”x50’
Single Zone Mini Splits
A/C & Heat Pump Unit Specifications
Whiles Supplies Last
PRODUCT CODE
242-1201
242-1202
MODEL NUMBER
9A43YMA
12A43YMA
Cooling
Cooling
115
115
Function
Rated Voltage
Rated Frequency (Hz)
242-1204
242-1205
240-1392
18A43ZMA
24A43ZMA
12H43ZGX
Cooling
Cooling
Cooling/Heating
208-230
208-230
208/230
60
60
60
60
60
9,000
12,000
18,000
23,000
12,000/13,000
Seer
13
13
13
13
13
EER
12.1
11
1550
2000
Cooling/Heating Power Input (W)
780
1090
6.8/6.6
9.3/8.8
Cooling/Heating Rated Current (A)
7.6
10
11.3
1
2.54
3.8
5.49
2.7
YES
YES
YES
YES
YES
Cooling/Heating Capacity (BTU)
Dehumidifying Volume (pt/H)
Auto Restart
Breaker Size
Circuit Ampacity
Low Ambient Control Board
1550/1250
7.2/7.6
15
20
15
20
15
13.6
17.2
12.7
16.5
5.5
Yes
Yes
Yes
Yes
No
INDOOR DATA
242-1201-E
242-1202-E
242-1204-E
242-1205-E
240-1392-E
INDOOR UNIT PART #
9A43YIMA
12A43YIMA
18A43ZIMA
24A43ZIMA
12H43ZIGX
800/1000/1250
1000/1100/1270
1145/1235/1285
990/1100/1260
1050/1100/1250
20 output
25 output
85/81.1/72.1
86/69/58
20
5.75
4.6
N/A
2.67
0.152
Cross Flow
Cross Flow
Cross Flow
Cross Flow
Fan Motor Speed (r/min)L/M/H)
Fan Motor (W)
Fan Motor RLA(A)
Fan Type
Evaporator
Air Flow Volume (CFM)
Sound Power Level dB (A)(L/M/H)
Dimensions (W/D/H) (inches)
Air Detection
Timer (24 Hr Programmable)
Net / Gross Weight (lbs.)
Filter
Aluminum fin-copper Aluminum fin-copper
Cross Flow
Aluminum fin-copper
43/48/46
Aluminum fin-copper Aluminum fin-copper
341/271/218
471 / 412 / 371
29/36/42
40/43/46
46/49/52
325
31.1/ 7.68 / 10.43
36.22/8.86/11.50
45.52 / 8.98 / 12.99
49.21/9.06/12.80
33 / 7 / 10.6
Automatic
Automatic
Automatic
Automatic
Automatic
On/Off
On/Off
On/Off
On/Off
On/Off
16.53/19.84
28.66/33.07
33.07
39.68/55.12
24 / 33
48/49/53
Washable
Washable
Washable
Washable
Washable
OUTDOOR DATA
242-1201-C
242-1202-C
242-1204-C
242-1205-C
240-1392-C
OUTDOOR UNIT PART#
9A43YOMA
12A43YOMA
18A43ZOMA
24A43ZOMA
12H43ZOGX
Rotary
Rotary
Rotary
Rotary
Rotary/Inverter
L.R.A. (A)
40.3
47.3
32.6
34.8
33
Compressor RLA (A)
7.46
9.9
7.30/6.65
8.75/9.70
4
Compressor Power Input (W)
810
1085
1505/1510
1980/2000
628
Throttling Method
Capillary
Capillary
Capillary
Capillary
Capillary
Outdoor Operating Range (F)
5 to 109
5 to 109
5 to 109.4
5 to 109
23 to 109
Compressor Type
Condenser
Aluminum fin-copper Aluminum fin-copper Aluminum fin-copper Aluminum fin-copper Aluminum fin-copper
Fan Motor Speed (rpm)
880
880
840
760
Fan Motor (W)
77
77
128
140
830
30
Fan Motor RLA (A)
N/A
N/A
N/A
N/A
0.3
Air Flow Volume
1059
1295
1471
2060
1100 cfm
Fan Type
Axial
Axial
Axial
Axial
Axial
Sound Pressure Level dB(A)
55
56
59
57
54
Dimensions(W/D/H) (inches)
30.7 / 9.84 / 21.26
29.92/11.22/23.23
33.27 / 13.19 / 27.36
35.24/12.99/33.86
33 / 13 / 21
Net / Gross Weight (lbs.)
70.55 / 77.16
79.37/85.98
109.13
141.10/149.91
99 / 110
Refrigerant Charge (lbs.)
R410A / 2.36
R410A / 2.93
R410A / 4.41
R410A / 5.29
R410A / 2.8
CONNECTION PIPE
Design Length Ft
Design Pressure High/Low (PSIG)
Above Design Length Extra Refrigerant
Charge per Feet (oz/ft)
16.4
16.4
16.4
16.4
19
550/340
550/340
550/340
550/340
551 /174
0.322
0.699
0.32
0.32
0.21
Outer Diameter Liquid Pipe (in)
1/4
1/4
1/4
3/8
1/4
Outer Diameter Gas Pipe (in)
3/8
1/2
1/2
5/8
1/2
Max Distance Height (ft)
26.2
26.2
32.8
32.8
20
Max Distance Length (ft)
65.6
65.6
82
82
39
7
Single Zone High Efficiency Series
Mini-Split
Thermal Zone High Efficiency Mini-Split systems feature energy efficient inverter technology and
increased Seer ratings of up to 23 Seer in some models. The inverter technology maintains
temperature more accurately and matches output demand to achieve maximum efficiency.
These systems take you to the next level of cool!
Features
• 18-23 SEER
• Inverter Technology
• Low Ambient Control
• Remote Control - Operable up to 33 feet from evaporator.
• Adjustable Louvers
• Diagnostic Codes
• Turbo Fan Function
• Selectable Temperature Range 62°F to 86°F
• Economy/Sleep Function
• Outdoor operating Range:
Cooling: 5°F to 122°F
Heating: 5°F to 86°F
• Auto Restart
• Timer Function
• 5 Year Compressor/ 1 Year Parts Warranty
Line Set Matrix
Product Code Model Number
241-4001
9A423YGX
241-4004
18A420ZGX
241-4005
24A419ZGX
241-2004
18H420ZGX
(239-0001)
CTK141225
1/4”x1/2”x25’
(239-0002)
CTK141250
1/4”x1/2”x50’
x
x
x
(239-0003)
(239-0004)
(239-0005)
(239-0006)
CTK385825
CTK385850
CTK143825
CTK143850
3/8”x5/8”x25’ 3/8”x5/8”x50’ 1/4”x3/8”x25’ 1/4”x3/8”x50’
x
x
(239-0007)
CTK145825
1/4”x5/8”x25’
(239-0008)
CTK145850
1/4”x5/8”x50’
x
x
x
x
x
241-2005
24H419ZGX
* Adapter to match outdoor unit (dual and quad only) included with indoor unit.
Note: Accessory kits AK25 (25 ft.) / AK50 (50 ft.) includes, cable (14AWG & 4C), 3” wall sleeve, drain tubing, tape and putty.
8
Single Zone High Efficiency Series
Mini-Split Cooling Only
Product Code
241-4001
241-4004
241-4005
Model Number
9A423YGX
18A420ZGX
24A419ZGX
Function
Rated Voltage
Cooling Capacity (BTU) - High/Standard/Low
COOLING
COOLING
COOLING
115V AC / 1PH
208-230V AC / 1 PH
208-230V AC / 1 PH
26200/ 22000 /7800
11950 / 9000 / 4000
22000/ 18000 /6200
SEER
23
20
18
EER
4.33
3.51
3.51
COP
2.97
2.43
2.86
14°F to 118°F
14°F to 118°F
14°F to 118°F
1180 / 620 / 166
2650 / 1500 / 180
2660 / 1832 / 220
8
7.67
9.36
306/ 253 /217 /170
488/ 441/ 382/ 323
606/ 470/ 412/ 353
Dehumidifying Volume(pts/h)
2.53
4.22
5.28
Auto Restart
Yes
Yes
Yes
Breaker Size (AMPS)
25
25
25
Circuit Ampacity
15
14
14
Product Code
241-4001-E
241-4004-E
241-4005-E
Model Number
9A23YIGX
18A420ZIGX
24A419ZIGX
10
20
35
Outdoor Operating Range
Cooling Power Input (W) (high/standard/low)
Cooling Rated Current (A)
Indoor Air Circulation
(CFM) (Turbo/H/M/L)
Indoor Data
Output of Fan Motor (W)
Fan Motor Capacitor (ufd)
N/A
1.5
2.5
Fan Motor RLA ( A)
0.28
0.25
0.45
Cross Flow Fan
Cross Flow Fan
Cross Flow Fan
3.35 – 26.3
3.86 – 28.86
3.86 – 32.6
Aluminum fin - copper tube
Aluminum fin - copper tube
Aluminum fin - copper tube
Fan Type
Diameter-Length (in)
Evaporator
Pipe Diameter (in)
0.275
0.275
0.275
Row-Fin Gap (in)
2-0.059
2-0.055
2-0.059
25.9 x 11.2 x 1
29.1 x 12 x 1
32.9×15.7×1
MP28VB / 2
MP28VB / 2.5
MP35XX / 2.5
3.15
3.15
3.15
Sound Pressure Level dB(A)
42 / 38 / 30 / 28
46 / 43 / 40 / 35
51 / 43 / 40 / 35
Sound Power Level dB(A) Turbo (H/M/L)
52 / 48 / 40 / 38
56 / 53 / 50 / 45
61 / 53 / 50 / 45
34.3 / 7 / 11.1
37.8 / 7.7 / 11.8
42.9 / 8.2 / 13
36.8 / 14.8 / 10.2
40.7 / 15.4 / 11
45.7 / 16.1 / 12.2
26.5 / 33.1
28.7 / 39.7
35.3 / 46.3
Coil length(L) x height(H) x coil width (W)
Swing Motor Model / Output (w) for horizontal louver
Fuse(A)
Dimensions of Unit (W / D / H)
Dimension of Package (W / D / H)
Net / Gross Weight (lb)
Single Zone Inverter High Efficiency Line Size Information
9 A 4 23 Y I G X
B C 4 S 1 I C S
T O 1 E 1NO E
U O 0 E 5DNR
L A R VO T I
I ORE
G ROS
L
O
N
L
Y
9
Single Zone High Efficiency Series
Mini-Split Cooling Only
OUTDOOR DATA
Product Code
Model Number
241-4001-C
241-4004-C
241-4005-C
9A423YOGX
18A420ZOGX
24A419ZOGX
Compressor Model
C-6RZ110H1A
C-6RZ146H1A
C-6RZ146H1A
Compressor Type
Rotary
Rotary
Rotary
33
41
41
LRA (Amps)
Compressor RLA (Amps)
4.59
8.4
8.4
Compressor Power Input (W)
800
1640
1640
1NT11L-3979
1NT11L-3979
1NT11L-3979
Compressor overload protection
Electronic Expansion Valve
Electronic Expansion Valve
Electronic Expansion Valve
Compressor Start Method
Throttling Method
Transducer Starting
Transducer Starting
Transducer Starting
Outdoor Operating Range
14°F to 118°F
14°F to 118°F
14°F to 118°F
Aluminum fin - copper tube
Aluminum fin - copper tube
Aluminum fin - copper tube
Condenser
Pipe Diameter (in)
0.375
0.275
0.275
Row-Fin Gap (in)
2-0.055
2-0.055
2-0.055
29.41 x 20 x 1.73
32.95 x 25.98 x 1.5
38.07 x 29.45 x 1.5
830±30
690 / 500
780
Coil length(L) x height(H)
x width(L)(in)
Fan Motor Speed (rpm)
30
60
90
Fan Motor RLA (A)
Output of Fan Motor (W)
0.27
0.4
0.9
Fan Motor Capacitor (µfd)
N/A
4
4
Air Flow Volume (CFM)
1118
1883
2472
Axial fan
Axial fan
Axial fan
Fan Diameter (in)
15.75
20.47
21.73
Defrosting Method
N/A
N/A
N/A
Climate Type
T1
T1
T1
I
I
I
IP24
IP24
IP24
Fan Type
Isolation
Moisture Protection
Design Pressure High (PSI)
550
490
490
Design Pressure Low (PSI)
450
400
400
Sound Pressure Level dB(A)
52
54
56
Sound Power Level dB(A)
62
64
66
33.4 x 12.6 x 21.3
35 x 13.4 x 27.6
36.2 x 14.6 x 31.1
34.6 x 14.2 x 22.8
40.6 x 18.1 x 28.9
41.9 x 19.1 x 33.1
Net/Gross Weight (lb)
86 / 94.8
110.2 / 121.3
119 / 132.3
Refrigerant Charge (lb)
R410A / 2.98
R410A / 3.2
R410A / 3.97
Dimension of Unit
(W x D x H) (approx in)
Dimension of Package
(W x D x H)
CONNECTION PIPE
Design Length (ft)
24.9
26.2
26.2
Extra Refrigerant Charge Per feet above
design length (oz/ft)
0.16
0.22
0.32
Outer Diameter Liquid Pipe (in)
1/4”
1/4”
1/4”
Outer Diameter Gas pipe (in)
3/8”
1/2”
5/8”
Max Distance Height(ft)
32.8
49.2
49.2
Max Distance Length(ft)
65.6
98.4
98.4
10
Single Zone High Efficiency Series
Mini-Split Heat Pump
Product Code
Thermal Zone Model
241-2004
241-2005
18H420ZGX
24H419ZGX
Product Code
241-2004-C
241-2005-C
Model Of Outdoor Unit
18H420ZOGX
24H419ZOGX
Function
COOLING / HEATING
COOLING / HEATING
Compressor Model
C-6RZ146H1A
C-6RZ146H1A
Rated Voltage
208-230V AC / 1 PH
208-230V AC / 1 PH
Compressor Type
Rotary
Rotary
Cooling Capacity (BTU)-Hi/Stand/Lo
22000/ 18000 /6200
26200/ 22000 /7800
LRA (Amps)
41
41
Heating Capacity (BTU)-Hi/Stand/Lo
25000/ 25000/ 4100
28000/ 28000/ 6000
Compressor RLA (Amps)
8.4
8.4
20
19
1640
1640
1NT11L-3979
1NT11L-3979
Throttling Method
Electronic Expansion
Valve
Electronic Expansion
Valve
Compressor Start Method
Transducer Starting
Transducer Starting
SEER
HSPF
EER / C.O.P (W / W)
Outdoor Operating Range
Compressor Power Input (W)
10.2 (Region IV -US) 10.5 (Region IV -US)
8.8 (Region V-Canada) 8.8 (Region V-Canada)
3.51 / 2.71
Compressor overload protection
3.51 / 3.04
Cooling: 14°F to 118°F Cooling: 14°F to 118°F
Heating: 5°F to 75°F
Heating: 5°F to 75°F
Cooling Power Input (W) - Hi/Stand/Lo
2650 / 1500 / 180
2660 / 1832 / 220
Outdoor Operating Range
Cooling: 14°F to 118°F Cooling: 14°F to 118°F
Heating: 5°F to 75°F Heating: 5°F to 75°F
Heating Power Input (W) - Hi/Stand/Lo
Condenser
Aluminum fin - copper Aluminum fin - copper
2700 / 2700 / 260
7.67 / 13.8
9.36 / 13.81
Indoor Air Circulation (CFM)
488 / 441 /
606 / 470 /
(Turbo/H/M/L)
OUTDOOR DATA
2700 / 2700 / 240
Cooling / Heating Rated Current (A)
Pipe Diameter (in)
0.275
5/8, 1/4
Row-Fin Gap (in)
2-0.055
2-0.055
32.95 x 25.98 x 1.5
38.07 x 29.45 x 1.5
690 / 500
780
Coil length(L) x height(H) x width
(W)(in)
382 / 323
412 / 353
Dehumidifying Volume(pts/h)
4.22
5.28
Auto Restart
Yes
Yes
Breaker Size (AMPS)
25
25
Circuit Ampacity
14
14
Product Code
241-2004-E
241-2005-E
Fan Type
Model Of Indoor Unit
18H420ZIGX
24H419ZIGX
Fan Motor Speed(RPM)- Cooling
1500/1150/1050/950
1380/1000/900/750
Fan Motor Speed(RPM)- Heating
(Turbo / L / M / H)
1500/1200/1100/1000 1380/1050/ 950/850
INDOOR DATA
Output of Fan Motor (W)
Fan Motor Speed (rpm)
Output of Fan Motor (W)
60
90
Fan Motor RLA (A)
0.4
0.9
4
4
Fan Motor Capacitor (µfd)
Air Flow Volume (CFM)
20
35
1883
2472
Axial Fan
Axial Fan
Fan Diameter (in)
20.47
21.73
Defrosting Method
Auto Defrost
Auto Defrost
T1
T1
I
I
Climate Type
Isolation
Fan Motor Capacitor (ufd)
1.5
2.5
Moisture Protection
IP24
IP24
Fan Motor RLA ( A)
0.25
0.45
Design Pressure High (PSI)
490
490
Cross Flow Fan
Cross Flow Fan
Design Pressure Low (PSI)
400
400
3.86 – 28.86
3.86 – 32.6
Sound Pressure Level dB(A)
54
56
Fan Type
Diameter-Length (in)
Evaporator
Aluminum fin - copper Aluminum fin - copper
Sound Power Level dB(A)
64
66
35 x 13.4 x 27.6
36.2 x 14.6 x 31.1
40.6 x 18.1 x 28.9
41.9 x 19.1 x 33.1
Net/Gross Weight (lb)
110.2 / 121.3
119 / 132.3
Refrigerant Charge (lb)
R410A / 3.2
R410A / 3.97
Design Length (ft)
26.2
26.2
61 / 53 / 50 / 45
Extra Refrigerant Charge per
feet above design length (oz/ft)
0.22
0.32
37.8 / 7.7 / 11.8
42.9 / 8.2 / 13
Outer Diameter Liquid Pipe (in)
1/4”
1/4”
40.7 x 11 x 15.4
45.7 x 12.2 x 16.1
28.7 / 39.7
35.3 / 46.3
Pipe Diameter (in)
0.275
0.275
Row-Fin Gap (in)
2-0.055
2-0.059
Coil (L) x (H)x coil (W) (in)
29.1 x 12 x 1
32.9×15.7×1
Swing Motor Model / Output (W) (for
horizontal louver)
MP28VB / 2.5
MP35XX / 2.5
3.15
3.15
CONNECTION PIPE
Sound Pressure Level dB(A) (Turbo /
H / M / L)
46 / 43 / 40 / 35
51 / 43 / 40 / 35
Sound Power Level dB(A) (Turbo /
H/M/ L)
56 / 53 / 50 / 45
Dimensions of Unit (W x D x H) (in)
Dimension of Package (W /D/H) (in)
Fuse(A)
Net / Gross Weight (lb)
Dimension of Unit (WxDxH)
Dimension of Package (WxDxH)
in inches
11
Outer Diameter Gas pipe (in)
1/2”
5/8”
Max Distance Height(ft)
49.2
49.2
Max Distance Length(ft)
98.4
98.4
Multi Zone Mini-Split
Heat Pumps
The Sea Breeze High Efficiency Mini-Split Heat Pump system is like
having all the benefits of central air less the headache of duct work.
These freematch systems have mix and match flexibility that will allow you to control individual room
temperatures in up to five rooms. With 16 SEER, 410A, Inverter Technology, Wall Control
and Multiple Configurations, the possibilities are endless.
Now up to 5 zones on one condensing unit!
Features
• 16 SEER
• Inverter Technology
• Low Ambient Control
• Remote Control - Operable up to 33 feet from evaporator.
• Adjustable Louvers
• Diagnostic Codes
• Unique Indoor Display
• Turbo Fan Function
• Selectable Temperature Range 62°F to 86°F
• Economy/Sleep Function
• Outdoor operating Range:
Cooling: 5°F to 122°F
Heating: 5°F to 86°F
• Auto Restart
• Timer Function
• 5 Year Compressor/ 1 Year Parts Warranty
3 New Condenser Sizes - 18K, 30K, 42K
Line Set Matrix
Product Code
Model Number
243-2003-E*
243-2004-E*
243-2004E*
243-6004-E*
243-6005-E*
243-6006-E*
243-6011-E*
243-6012-E*
243-6013-E*
243-6015-E*
SHE9H4ZIGX
SHE12H4ZIGX
SHE18H4ZIGX
SMZCA12H4ZIGX
SMZCA18H4ZIGX
SMZCA24H4ZIGX
SMZD9H4ZIGX
SMZD12H4ZIGX
SMZD18H4ZIGX
SMZD24H4ZIGX
(239-0001)
CTK141225
1/4”x1/2”x25’
(239-0002)
CTK141250
1/4”x1/2”x50’
x
x
x
x
x
x
(239-0003)
CTK385825
3/8”x5/8”x25’
x
x
(239-0004)
(239-0005)
CTK385850
CTK143825
3/8”x5/8”x50’ 1/4”x3/8”x25’
(239-0006)
CTK143850
1/4”x3/8”x50’
x
x
x
x
x
x
x
x
x
x
x
x
* Adapter to match outdoor unit (dual and quad only) included with indoor unit.
12
(239-0007)
(239-0008)
CTK145825
CTK145850
1/4”x5/8”x25’ 1/4”x5/8”x50’
Multi-Zone
Heat Pump Indoor Units
Model Number
Product Code
243-2003-E
SHE9H4ZIGX
Rated Voltage & Frequency
Control
208-230 / 1PH
208-230 / 1PH
208-230 / 1PH
Remote or *Wall (Optional)
Remote or *Wall (Optional)
Setting Range
Wire Size/No of Conductors
Indoor Air Circulation (CFM) Turbo/H/M/L
Dehumidifying Volume (pt/hr)
Output (W)
Fan Motor RLA (A)
Fan Motor Capacitor (MFD/V)
Fan Type
Diameter Length (in)
61°F to 86°F
18000 (6210-22000)
9800 (2200-11000)
13000 (2400-14000)
19800 (4100-22000)
4C-14AWG
4C-14AWG
4C-14AWG
306/253/218/171
330/288/258/206
488/441/383/324
2.54
2.96
4.22
10
10
20
0.17
0.17
0.32
1
1
1
Cross flow fan
Cross flow fan
Cross flow fan
3.35-26.34
3.35-26.34
3.86-28.86
1500/1150/1050/900
1500/1150/1050/950
Speed Heating(Turbo/Hi/Med/Low) (RPM)
1450/1250/1150/1050
1450/1250/1150/1050
1500/1200/1100/1000
Aluminum, Louvered
Aluminum, Louvered
Aluminum, Louvered
Tube outside dia.(in) / Type
0.276
0.276
0.276
Row Fin Gap (in)
2-0-06
2-0.06
2-0.06
25.9x11.2x1
25.9x11.2x1
29x12x1
MP28VB / 2
MP28VB / 2
MP28VB / 2.5
3.15 A
3.15 A
3.15 A
Liquid Line
1/4”
1/4”
1/4”
Suction Line
3/8”
1/2”
1/2”
Sound Pressure Level dB(A) (T/H/M/L)
46/38/30/28
48/38/30/28
46/43/40/35
Sound Power Level dB(A) (T/H/M/L)
56/48/40/38
58/48/40/38
56/53/50/45
Design Pressure (PSI)
130.5 / 435.1
130.5 / 435.1
130.5 / 435.1
High Pressure (PSI)
550
550
500
Low Pressure (PSI)
240
240
240
Auto-restart
Dimensions &
Weight
61°F to 86°F
12000 (3100-13000)
1400/1150/1050/900
Coil Length x height x width (in)
Swing Motor Model/Output (W)
(for horizontal louver)
Fuse
Design Data
61°F to 86°F
9000 (3100 - 9600)
Speed Cooling(Turbo/Hi/Med/Low) (RPM)
Fin Type
Evaporator
243-2005-E
SHE18H4ZIGX
Remote or *Wall (Optional)
Performance & Cooling BTU (Min-Max)
Electrical
Heating BTU (Min - Max)
Fan Motor
243-2004-E
SHE12H4ZIGX
Unit Dimensions (W x D x H) (in)
Packing Dimensions (W x D x H) (in)
Net / Gross Wt (lbs)
18K CONDENSER (DUAL ZONE) 30K CONDENSER (QUAD ZONE)
● A 1/4” 3/8”
● B 1/4” 3/8”
● A 1/4” 3/8”
Yes
Yes
Yes
34.3 x 7 x 11
34.3 x 7 x 11
37.8 x 7.7 x 11.8
36.9 x 14.9 x 10.8
36.9 x 14.9 x 10.8
40.9 x 15.5 x 11.6
24.3 / 33.1
24.3 / 33.1
28.7 / 39.7
42K CONDENSER (5 PORT)
● A 1/4” 3/8”
● B 1/4” 3/8”
● B 1/4” 3/8”
● C 1/4” 3/8”
● C 1/4” 3/8”
● D 1/4” 3/8”
● D 1/4” 3/8”
● E 3/8” 5/8”
INDOOR UNIT LINE SET SIZES
*WALL
CASSETTE
DUCTED
9K - 1/4” - 3/8”
N/A
9K - 1/4” - 3/8”
12K- 1/4” - 1/2”
12K - 1/4” - 3/8”
12K - 1/4” - 3/8”
18K - 1/4” - 1/2”
18K - 1/4” - 1/2”
18K - 1/4” - 1/2”
MSWCH
243-7002
Optional Wall Control for SHE
* Includes adapters.
Available Adapters for Outdoor Unit:
(included with 42K unit)
1/4”F to 3/8”M (06654110)
1/2”F to 3/8” M (06654111)
1/2”F to 5/8”M (06654112)
3/8”F to 1/4” M (06654113)
5/8”F to 3/8”M (06654114)
3/8”F to 1/2”M (06654120)
5/8”F to 1/2”M (06654121)
*Included in all Cassette and
Ducted Evaportaors
13
Multi Zone Mini-Split
Heat Pumps
New Cassette Evaporators - come in 12K, 18K, and 24K BTU combinations.
Features
•
•
•
Ceiling cassettes include the MSWCH wall control with
26’ of wire and a wireless remote control. The wall mount
control is not necessary if wireless remote operation is
desired.
You MUST order the corresponding cassette grille for
each ceiling cassette.
Includes a factory-installed condensate pump.
Caseette Grills
SMZCA1218GR
SMZCA24GR
Product Code
243-6016-E
for use with 12 & 18K
243-6017-E
for use with 24K
Model Of Indoor Unit
SMZCA12H4ZIGX
SMZCA18H4ZIGX
Product Code
243-6004-E
243-6005-E
243-6006-E
208-230V AC / 1 PH
Remote (standard) or
Wall (optional)
61°F to 86°F
12000
13000
4C- 14 AWG (Recommended)
208-230V AC / 1 PH
Remote (standard) or
Wall (optional)
61°F to 86°F
14400
16000
4C- 14 AWG (Recommended)
208-230V AC / 1 PH
Remote (standard) or
Wall (optional)
61°F to 86°F
22800
27400
4C- 14 AWG (Recommended)
353
353
694
2.96
3.8
5.28
845 / 700 / 530 / 600 / 515
845 / 700 / 530 / 600 / 515
620 / 570 / 520 / 280
11
1
0.23
Centrifugal
11.14 – 5.83
Aluminum fin - Inner Grooved copper
tube
11
1
0.23
Centrifugal
11.14 – 5.83
Aluminum fin - Inner Grooved copper
tube
50
3
0.43
Centrifugal
17.72 – 4.41
Aluminum fin - Inner Grooved copper tube
MP35EA
MP35EA
MP35EA
3.15
550
240
Yes
Yes
2.3
Yes
3.15
550
240
Yes
Yes
2.3
Yes
3.15
550
240
Yes
Yes
3.6
Yes
46
46
39
56
56
49
1/4”
3/8”
1/4”
1/2”
3/8”
5/8”
22.4 / 22.4 / 9.1
22.4 / 22.4 / 9.1
33.1 / 33.1 / 9.45
33.5 / 28.8 / 12.8
33.5 / 28.8 / 12.8
37.9 / 37.9 / 12.8
39.7 / 50.7
39.7 / 50.7
61.7 / 77.2
25.6 / 25.6 / 2.0
25.6 / 25.6 / 2.0
37.4 / 37.4 / 2.36
28.9 / 26.5 / 4.6
28.9 / 26.5 / 4.6
41.1 / 40.5 / 5.12
5.5 / 8.1
5.5 / 8.1
14 / 22
Rated Voltage
Control
Performance &
Electrical
FAN Motor
Evaporator
Design Data
Dimensions &
Weight
SettingRange
Cooling Capacity (BTU/H)
Heating Capacity (BTU/H)
Wire Size / No. of Conductors
Indoor Air Circulation (CFM)
(High Fan Speed)
Dehumidifying Volume(pts/h)
Fan Motor Speed (RPM)
(SH / H / M / L / SL )
Output of Fan Motor (W)
Fan Motor Capacitor (ufd)
Fan Motor RLA ( A)
Fan Type
Diameter-Height (in)
Evaporator
Swing Motor Model
(for horizontal louver)
Fuse(A)
High Pressure (PSI)
Low Pressure (PSI)
Auto Restart
Condensate Pump
Condensate Pump Lift (Ft)
Anti-Mildew Protection
Sound Pressure Level dB(A)
(High Fan Speed)
Sound Power Level dB(A)
(High Fan Speed)
Flare Liquid line
Flare Suction line
Dimensions of Unit
(W / D / H) (approx in)
Dimension of Package
(W / D / H) (approx in)
Net / Gross Weight (lb)
Dimensions of Panel
(W / D / H) (approx in)
Dimension of Panel Package
(W / D / H)(approx in)
Net / Gross Weight of Panel (lb)
14
SMZCA24H4ZIGX
Multi-Zone
Heat Pump Indoor Units
New Ducted Evaporators - come in 9K, 12K, 18K, and 24K BTU combinations.
Features
•
•
•
•
Ducted indoor units include the MSWCH wall control with 26’ of wire.
If desired, an optional wireless remote control (Part# 305100491) will
also operate these units. The MSWCH wall control is still required since
the remote control receiver is part of the MSWCH.
Includes a factory-installed condensate pump.
Ducted indoor units have low to medium static capability, therefore,
they are only designed to handle one to two supply outlets.
Model Of Indoor Unit
SMZD9H4ZIGX
SMZD12H4ZIGX
SMZD18H4ZIGX
Product Code
243-6011-E
243-6012-E
243-6013-E
243-6015-E
208-230V AC / 1 PH
Wall Control
61°F to 86°F
8500
9500
4C- 14 AWG
(Recommended)
208-230V AC / 1 PH
Wall Control
61°F to 86°F
11900
13100
4C- 14 AWG
(Recommended)
208-230V AC / 1 PH
Wall Control
61°F to 86°F
15300
18700
4C- 14 AWG
(Recommended)
208-230V AC / 1 PH
Wall Control
61°F to 86°F
23800
27400
4C- 14 AWG
(Recommended)
265
294
412
589
Performance &
Electrical
FAN Motor
Evaporator
Design Data
Dimensions &
Weight
Rated Voltage
Control
SettingRange
Cooling Capacity (BTU/H)
Heating Capacity (BTU/H)
Wire Size / No. of Conductors
Indoor Air Circulation (CFM)
(High Fan Speed)
Dehumidifying Volume(pts/h)
Fan Model
Fan Motor Speed (SH / H / M / L)
Output of Fan Motor (W)
Fan Motor Capacitor (ufd)
Fan Motor RLA ( A)
Fan Type
Fan Quantity
Diameter-Length (in)
Evaporator
Fuse(A)
High Pressure (PSI)
Low Pressure (PSI)
Auto Restart
Condensate Pump
Condensate Pump lift (ft)
Sound Power Level dB(A)
(H / L)
Flare Liquid line
Flare Suction line
Dimensions of Unit (W / D / H)
(approx in)
Net / Gross Weight (lb)
1.69
FG30A
1230 / 970 / 760 / 640
40
1.5
0.35
Centrifugal
2
5.49 – 5.30
Aluminum fin - Inner
Grooved copper tube
3.15
550
240
Yes
Yes
3.6
SMZD24H4ZIGX
2.96
3.8
5.28
FG40A
FG60A
FG20E
1130 / 960 / 830 / 700
1000 / 920 / 780 / 720
1160 / 985 / 800 / 680
49
75
22.5
3
3
3
0.35
0.43
0.54
Centrifugal
Centrifugal
Centrifugal
2
3
4
5.49 – 5.30
5.49 – 5.30
5.49 – 5.30
Aluminum fin - Inner Grooved Aluminum fin - Inner Grooved Aluminum fin - Inner Grooved
copper tube
copper tube
copper tube
3.15
3.15
3.15
550
550
550
240
240
240
Yes
Yes
Yes
Yes
Yes
Yes
3.6
3.6
3.6
47 / 41
1/4”
3/8”
49 / 42
1/4”
3/8”
51 / 43
1/4”
1/2”
52 / 44
3/8 “
5/8”
27.6 / 24.2 / 7.9
27.6 / 24.2 / 7.9
35.4 / 24.2 / 7.9
43.3 / 24.2 / 7.9
48.51 / 59.54
50.72 / 63.95
59.54 / 79.38
68.36 / 90.41
15
Multi -Zone
Heat Pump Outdoor Units
Product Code
Model Number
243-1004-C
SMZ18H46ZOGX
DUAL ZONE OUTDOOR UNIT
Rated Voltage & Frequency and Phase
Min/Max Operating Voltage
Circuit Breaker Size (A)
Working Temperature Range (cooling °F)
Working Temperature Range (heating °F)
Min Circuit Ampacity (A)
Low Ambient Cooling Function
Sound Power Level dB9 (A) (Max)
Refrigerant (R410A), (oz)
208-230 / 1PH
187/253 VA
20
14 to 118
5 to 81
15
Yes
66
47.62
Rated Capacity (BTU)
18,000
Capacity Invert Range (BTU)
7,000 - 21,000
Rated Power Input (W)
1,650
Cooling
Power Input Range (W)
680-2,800
Total Input Current (Cooling)
10.48/10.22 A
SEER
16
Rated Capacity (BTU)
19,000
Capacity Invert Range (Btu/h)
8,530-22,600
Rated Power Input (W)
1,640
Heating
Power Input Range (W)
680-2,800
Total Input Current (Heating )
10.48/10.22A
HSPF
8.2
Output (W)
60
Capacitor (UFD)
3.5
Fan Motor RLA (A)
0.54
Fan Speed (RPM) (H-M-L)
830/670/500
Fan Type
Axial Fan
Fan Blade Diameter (in)
17.52
Outdoor Fan
Air Flow Volume of Outdoor Unit (CFM)
1530/1354/942
Model
SNB130FGYMC
TYPE
Rotary Inverter
Brand
MITSUBISHI
RLA
9.56
Compressor
Input (W)
1245
Crankcase Heater Input (W)
25 +/- 7
Oil Type
PVE/FV50S
Overload Protector
1NT11L-6578
Number of Rows
2
Fin spacing (in)
0.055
Fin Type
Aluminum, Louvered
Condenser
Tube Outside Dia. (in)
0.313
Coil Length x Height x Width (in)
27.56 x 21.65 x 1.5
Defrosting Method
Auto
Number of circuits
2
Unit Dimensions (W x H x D) (in)
35.39 x 23.46 x 14.88
Dimensions & Weight
Packing Dimensions (W x Hx D) (in)
37.32 x 25.39 x 16.54
Net / Gross Weight (lb)
94.8/105.82
Flare Fitting Liquid line
1/4 “
Flare Fitting Suction line (*1)
3.8” (*1)
Service Port Fitting
1/2” - 20 UNF
High Pressure (psi)
500
Low Pressure (psi)
240
Connection
Design Length (ft)
24.6 (each indoor unit) 49.2’ total
Max Line Set Vertical Height (ft)
16.4 (each indoor unit)
Max Line Set Length (ft)
32.8 (for each indoor unit) 65.6 total
Charge over Design Length (oz. / ft)
.22 (over 49.2’)
Wiring (Indoor to Outdoor)
4C - 14 (Recommended)
Wiring (Outdoor unit to Power Disconnect)
3C- 12 AWG (Min)
*1. When the total length of liquid line is over 49.2’, the additional refrigerant charge is required.
16
243-1006-C
SMZ30H46ZOGX
QUAD ZONE OUTDOOR UNIT
208-230 / 1PH
187/253 VA
45
14 to 118
5 to 81
26
Yes
69
77.6
29,000
7,500-34,000
3,450
650-4,500
20.74/18.57 A
16
30,400
7,500-36,000
2,850
980-3,950
20.74/18.57 A
8.2
60
3.5
0.59
690/600/500
Axial Fan
20.47
1942/1707/1413
TNB220FLHMC
Rotary Inverter
MITSUBISHI
19.62
2200
40+/- 7
PVE/FV50S
CS-7C-1595
2
0.055
Aluminum, Louvered
0.375
35.04 x 25.98 x 1.73
Auto
4
37.24 x 27.56 x 15.59
40.63 x 30.12 x 18.15
136.69 / 147.71
1/4 “
3.8” (*1)
1/2” - 20 UNF
500
240
24.6 (each indoor unit) 98’ total
32.8 (each indoor unit)
65.6 (each indoor unit) 229.7’ total
0.22 (over 98’)
4C - 14 (Recommended)
3C- 6 AWG (Min)
Multi-Zone
Heat Pump Outdoor Units
Product Code
Model Number
Rated Voltage & Frequency and Phase
Min/Max Operating Voltage
Circuit Breaker Size (A)
Working Temperature Range (cooling °F)
Working Temperature Range (heating °F)
Min Circuit Ampacity (A)
Low Ambient Cooling Function
Sound Power Level dB9 (A) (Max)
Refrigerant (R410A), (oz)
Cooling
Heating
Outdoor Fan
Compressor
Condenser
Dimensions & Weight
243-1007-C
SMZ42H46ZOGX
208-230 / 1PH
187/253 VA
50
14 to 118
5 to 81
26
Yes
68
169.3
Rated Capacity (BTU)
Capacity Invert Range (BTU)
Rated Power Input (W)
Total Input Current (Cooling)
SEER
Rated Capacity (BTU)
Capacity Invert Range (Btu/h)
Rated Power Input (W)
24.04/21.74 A
HSPF
Output (W)
Capacitor (UFD)
Fan Motor RLA (A)
Fan Speed (RPM) (H-M-L)
Fan Type
Fan Blade Diameter (in)
Air Flow Volume of Outdoor Unit (CFM)
Model
TYPE
Brand
RLA
Input (W)
Crankcase Heater Input (W)
Oil Type
Overload Protector
Number of Rows
Fin spacing (in)
Fin Type
Tube Outside Dia. (in)
Coil Length x Height x Width (in)
Defrosting Method
Number of circuits
Unit Dimensions (W x H x D) (in)
Packing Dimensions (W x Hx D) (in)
Net / Gross Weight (lb)
41,000
8,530-46,400
4,400
24.04-22.17 A
16
44,500
10,660-47,770
4,600
10.48/10.22A
8.2
140
6
1.1
860/650/550
Axial Fan
22.44
3237
TNB306FPGMC
Inverter Scroll
MITSUBISHI
19.07
3010
40
PVE/FV50S
CS01F272H01
2
0.055
Aluminum, Louvered
0.313
40.25 x 41.57 x 1.5
Auto
5
39.96 x 43.43 x 17.32
45.59 x 48.62 x 19.41
224.9 / 246.9
Four of 1.4” - 9K, 12K, 18K BTU
One of 3/8” - 21K/24K BTU (*1)
Flare Fitting Liquid line
Flare Fitting Suction line (*1)
Three of 3/8” - 9K BTU:
One of 1/2” - 12K/18K BTU (*2)
One of 5/8” - 21K/24K BTU (*3)
1/2” - 20 UNF
500
240
24.6 (each indoor unit) 123’ max total
49’ max total
Service Port Fitting
High Pressure (psi)
Low Pressure (psi)
Connection
Design Length (ft)
Max Line Set Vertical Height (ft)
Max Line Set Vertical Height (ft)
24.6 for each indoor unit
(betw indoor and indoor unit)
Max Line Set Length (ft)
82 (for each Indoor unit) 262.5 Total
Charge over Design Length (oz. / ft)
0.24 (over 123’)
Wiring (Indoor to Outdoor)
4C - 14 AWG (Recommended)
Wiring (Outdoor unit to Power
3C- 6 AWG (Min)
Disconnect)
*1. When the total length of the liquid line is over 164 ft, the additional refrigerant charge is required.
*2. When the outdoor unit is above the indoor unit, the max vertical height this indoor unit and outdoor unit is 49.2 ft.
NOTE: Outdoor unit must connect to a minimum of TWO indoor units.
17
Multi-Zone Matching Combinations
and Capacities
SMZ18H46ZOGX INDOOR OPTIONS
ONE INDOOR UNIT OPTIONS
9K
12K
TWO INDOOR UNIT OPTIONS
SMZ42H46ZOGX INDOOR OPTIONS
9K + 9K
TWO INDOOR UNIT OPTIONS
9K + 12K
9K + 9K
9K + 12K
9K + 18K
12K + 12K
12K + 18K
18K + 18K
12K + 21K
12K + 24K
18K + 24K
THREE INDOOR UNIT OPTIONS
9K + 9K + 9K
9K + 9K + 12K
9K + 12K + 12K
9K + 9K + 18K
9K + 12K + 18K
9K + 18K + 18K
12K + 12K + 12K
12K + 12K + 18K
12K + 18K + 18K
9K + 12K + 24K
12K + 12K + 21K
FOUR INDOOR UNIT OPTIONS
SMZ30H46ZOGX INDOOR OPTIONS
9K + 9K + 9K + 9K
9K + 9K + 9K + 12K
9K + 9K + 9K + 18K
9K + 9K + 12K + 12K
9K + 9K + 12K + 18K
9K + 12K + 12K + 12K
TWO INDOOR UNIT OPTIONS
FIVE INDOOR UNIT OPTIONS
9K + 9K
9K + 12K
9K + 9K + 9K + 9K + 9K
9K + 18K
12K + 12K
SMZ42H46ZOGX (con’t) - IMPORTANT
12K + 18K
18K + 18K
The system matches below are not recommended if all indoor units may require simultaneous continuous duty at full efficiency. Such an example of this is a computer room or
kitchen where heat load is constant.
THREE INDOOR UNIT OPTIONS
9K + 9K + 9K
9K + 9K + 12K
9K + 12K + 12K
9K + 9K + 18K
TWO INDOOR UNIT OPTIONS
24K + 24K
12K + 12K + 12K
FOUR INDOOR UNIT OPTIONS
9K + 9K + 9K + 9K
SMZ30H46ZOGX (con’t) - IMPORTANT
The system matches below are not recommended if all
indoor units may require simultaneous continuous duty at
full efficiency. Such an example of this is computer room
or kitchen where heat load is constant.
THREE INDOOR UNIT OPTIONS
18K + 18K + 18K
9K + 18K + 24K
12K + 18K + 24K
12K + 12K + 24K
FOUR INDOOR UNIT OPTIONS
9K + 9K + 18K + 18K
9K + 12K + 12K + 18K
9K + 9K + 9K + 24K
12K + 12K + 12K + 18K
9K + 9K+ 12K + 24K
12K + 12K + 12K + 12K
FIVE INDOOR UNIT OPTIONS
TWO INDOOR UNIT OPTIONS
9K + 9K + 9K + 9K + 18K
9K + 9K + 9K + 12K + 12K
18K + 18K
9K + 9K + 12K + 12K + 12K
9K + 9K + 9K + 9K + 12K
THREE INDOOR UNIT OPTIONS
9K + 12K + 18K
12K + 12K +18K
FOUR INDOOR UNIT OPTIONS
9K + 9K + 9K + 12K
9K + 9K + 12K + 12K
18
Installation Kits
Installation Kits
IRP Part #
239-0001
239-0002
239-0003
239-0004
239-0005
239-0006
239-0007
239-0008
URI Part
CTK141225
CTK141250
CTK385825
CTK385850
CTK143825
CTK143850
CTK145825
CTK145850
239-0009
AK25
239-0010
AK50
Description
Line sets, COPPER TUBING WITH INSULATION, 25 Feet Long of 1/2” wall insulated copper tubing with flare fitting - 1/4” OD & 1/2” OD
Line sets, COPPER TUBING WITH INSULATION, 50 Feet Long of 1/2” wall insulated copper tubing with flare fitting - 1/4” OD & 1/2” OD
Line sets, COPPER TUBING WITH INSULATION, 25 Feet Long of 1/2” wall insulated copper tubing with flare fitting - 3/8” OD & 5/8” OD
Line sets, COPPER TUBING WITH INSULATION, 50 Feet Long of 1/2” wall insulated copper tubing with flare fitting - 3/8” OD & 5/8” OD
Line sets, COPPER TUBING WITH INSULATION, 25 Feet Long of 1/2” wall insulated copper tubing with flare fitting - 1/4” OD & 3/8” OD
Line sets, COPPER TUBING WITH INSULATION, 50 Feet Long of 1/2” wall insulated copper tubing with flare fitting - 1/4” OD & 3/8” OD
Line sets, COPPER TUBING WITH INSULATION, 25 Feet Long of 1/2” wall insulated copper tubing with flare fitting - 1/4” OD & 5/8” OD
Line sets, COPPER TUBING WITH INSULATION, 50 Feet Long of 1/2” wall insulated copper tubing with flare fitting - 1/4” OD & 5/8” OD
Accessory kit, 25 feet of 4 conductor cable - 14 AWG, UL (14/4, white,red, black, green with black jacket), 25 feet of drain hose, 64 ft
of PVC tape, 3” wall sleeve, sealing putty
Accessory kit, 50 feet of 4 conductor cable - 14 AWG, UL (14/4, white,red, black, green with black jacket), , 50 feet of drain hose, 128
ft of PVC tape, 3” wall sleeve, sealing putty
CTK = copper tubing Kit
1st two numerical digits = liquid line size
2nd two numerical digits = suction line size
3rd two numerical digits = copper tubing length
AK = Accessory kit
1st two numerical digits = Length of cable, etc
*An oil trap is recommended if the indoor unit is over 17 - 23 feet in height from the outdoor unit.
Condenser Covers
IRP #
Model
Dimensions - fits units up to
Description
GC6
Generator cover, black waterproof fabric with drawstring and storage bag
33” x 25” x 26”
410-0145
CCS
Condenser cover, small size, black waterproof fabric with drawstring and storage bag
23” x 26” x 30”
410-0146
CCM
Condenser cover, medium size, black waterproof fabric with drawstring and storage bag
30” x 33” x 37”
410-0147
CCL
Condenser cover, large size, black waterproof fabric with drawstring and storage bag
34” x 37” x 48”
410-0144
Generator
G6.5KW
215-0004
Features
Engine
Rated Power
Displacement
Type
Max. Output
Volt Adjustment
Ignition
Fuel Type
Start Type
Tank Volume
Fuel consumption at rated load
with full fuel tank
Engine Oil Capacity
Engine Oil Type
Sound Level at 23 ft. (7 meters)
•
•
•
•
•
•
•
•
•
•
•
•
13HP
23.74 cu.in. (389 cc)
1 cylinder, 4-stroke, OHV, air-cooled gasoline
engine
3600 RPM
AVR (Automatic Voltage Regulation)
CDI (Capacitive Discharge Ignition)
Unleaded 89 octane or above
Recoil/ Electric Start
6.6 gal. (25L)
7.5 Hrs
1.16 qts. (1.1L)
SAE 10W-30
72 dba
Generator
Rated Watts
Surge Watts
Frequency
Voltage
Amps
Net Weight
Gross Weight
Unit Dimensions(LxWxH)
Carton Dimensions (LxWxH)
Approvals
Spark Plug
5.5 KW
6.5 KW
60 Hz
120/240 VAC
23 A
198.4 lbs (90 kg)
209.4 lbs (95 kg)
26.8” x 20.1” x 21.3”
32” x 22” x 23”
EPA and CARB
Torch F7TC, NGK BP6ES, Bosch W6D1
19
6.5 KW Peak Output
5.5 KW Continuous Output
Electric Start
Fuel level indicator
Automatic Idle
Auto Voltage Regulation
Rubber Tires
Fold Down Handles
Low Oil Shutdown
Electric Plugs included
Low Distortion (5%)
12VDC, 120 VAC, 230 VAC Outlets
PlastiDuct
PDCJ
Features
• High Quality PVC
• Quick & Easy Installation
• UV & Shock Resistant
PDC
Catalog
Number
IRP Part
Number
PD3
415-0001
CANALSPLIT 08, Code 0812 BC, 2 meter lengths (6.5 Ft), 16 meters 8pcs
per carton (52.5 Ft approx.)
5.00
PD4
415-0002
CANALSPLIT 12, Code 1212 BC, 2 meter lengths (6.5 Ft), 8 meters
per carton (26.25 Ft approx.)
4pcs
5.00
PDC3
415-0003
Brackets, FAST block, Code 0803 ST (red color), 30 per pack
30
0.04
Description
QTY
Weight
(lbs)
PDC4
415-0004
Brackets, FAST block, Code 1203 ST (green color), 20 per pack
20
0.04
PDCJ3
PDCJ4
PDIC3
PDIC4
PDEC3
PDEC4
PDFC3
415-0005
415-0006
415-0007
415-0008
415-0009
415-0010
415-0011
Cover Joint, Code 0804 GC, 30 per pack
Cover Joint, Code 1204 GC, 20 per pack
Internal Corner, Code 0805 AI, 6 per pack
Internal Corner, Code 1205 AI, 4 per pack
External Corner, Code 0806 AE, 9 per pack
External Corner, Code 1206 AE, 6 per pack
Plane Curve, Code 0807 CP, 8 per pack
30
20
6
4
9
6
8
0.04
0.07
0.18
0.31
0.16
0.29
0.20
PDFC4
PDECAP3
PDWE3
PDWE4
PDWP3
PDWP4
PDT3
PDT4
PDR4
PDF18
415-0012
415-0013
415-0014
415-0015
415-0016
415-0017
415-0018
415-0019
415-0020
415-0021
Plane Curve, Code 1207 CP, 6 per pack
End Cap, Code 0808 TT, 9 per pack
Corner Wall Elbow, Code 0809 CM, 6 per pack
Corner Wall Elbow, Code 1209 CM, 4 per pack
Wall Passage, Code 0810 PM, 8 per pack
Wall Passage, Code 1210 PM, 8 per pack
“T” Shunt, Code 0813 DT, 4 per pack
“T” Shunt, Code 1213 DT, 2 per pack
Reduction, Code 1280 RI, 8 per pack
Floor Suport, Code 0450 SP, 24 per pack ,color RAL 1013, 45 cm
long (18”) Sold in Packs of 2
6
9
6
4
8
8
4
2
8
24
0.38
0.13
0.29
0.28
0.38
0.11
0.29
0.11
0.14
0.13
PDF39
415-0022
Floor Support, Code 1000 SP, 4 per pack, color RAL 1013, 1 meter
long (39”) Sold in Packs of 2
4
0.38
PDFC
415-0023
Cap for Floor Support, Code 0341 TS, Color RAL 1013, 24 per pack
24
0.07
PDAIC3
PDAEC3
415-0024
415-0025
Adjustable Corner, 80°- 105°, 6 pcs per pack
4
0.28
PDAPC3
415-0026
Adjustable External Corner, 70°- 120°, 6 pcs per pack
Adjustable Plane Curve, 65°- 130°, 6 pcs per pack
6
6
0.13
0.13
Condensate Removal Pumps
PART NUMBER
4100122
DESCRIPTION
Miniature condensate pump, 115 VAC, ETL approved, water protection
IP54, 21 dBA, N.O. Contacts
4100124
Easy Fix accessories, Leveling support, Anti-vibration pad, Pump mount
4100127
Flowatch Pump with Install Kit, 115 VAC
4100128
Flowatch Pump with Install Kit, 220/240 VAC
4100129
Miniature condensate pump, 115 VAC, ETL approved, water protection
IP54, 21 dBA, N.O./N.C. Contacts
Mounting Brackets For Mini-Split
PART NUMBER
DESCRIPTION
7100-0004 BR-440L Mounting Bracket for
mini-Split, Wall type with top bar, weight capacity not greater than 440 lbs., with mounting hardware,
Leg base 7.16
20
While
Supplies
Last
PDEC
PDECAP
PDFC
PDWP
PDT
PDWE
PDAEC
PDIC
PDAIC
PDAPC
Window Units - Remote
Cooling Only/Non-Energy Star
Electrical Requirements
FEATURES
NEMA 5-15A
115 VOLT
15 AMP
• Multiple Functions - Cooling, Dehumidifying & Fan Ventilation
•Installation Kit with Expandable Side Panels
•Retracting Louvers
NEMA 6 - 15P
230 VOLT
15 AMP
NEMA 6 - 20P
230 VOLT
20 AMP
NEMA 6 - 30P
230 VOLT
25 AMP
While Supplies
Last
Whiles Supplies
Last
Product Code
421-0055
422-0058
422-0061
422-0065
422-0068
422-0112
421-0071
422-0078
422-0114
Model Number
WA46YR
WA48YRX
WA410YRX
WA412YRX
WA418ZRX
WA418ZRB
WA424ZR
WA428ZRX
WA428ZRB
BTU Cooling
6000
8000
10000
12000
BTU Heating
N/A
N/A
N/A
N/A
N/A
N/A
EER
9.7
9.8
9.8
9.8
9.7
/
1.6
2
2.2
3.3
Airflow (CFM)
188
218/177/147
Voltage
115
115
115
115
Frequency / Cycle
60HZ
60HZ
60HZ
60HZ
60HZ
60 HZ
60HZ
60HZ
60 HZ
5.6
7.1
9.4
11
8.4/9.1
8.3 / 7.7
14.0/13.0
14.8/16.0
15.0 / 13.8
Dehumidification (pints/hour)
Amps Cooling
18500/18200 18,200/18,500 23500/24000
N/A
10.7
8.5
8.5
9
3.8
7.82
5.4
6.3
300 /262/229 265 /243 /202 441/394/353 446 / 388 / 329
230/208
28500/28000 27,500/28,000
N/A
208 / 230
482
208/230
N/A
541/500/447 523 / 485 / 445
230/208
208 / 230
Amps Heating
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Watts Cooling
620
816
1020
1225
1907/1876
1701 / 1729
2770/2830
3353/3294
3111 / 3167
N/A
N/A
Watts Heating
Plug Type / Nema #
NEMA 5-15P NEMA 5-15P
N/A
N/A
N/A
N/A
N/A
N/A
N/A
NEMA 5-15P
NEMA 5-15P
NEMA 6-15P
NEMA 6-15P
NEMA 6-20P
NEMA 6-30P
NEMA 6-30P
Power Cord Rating/ amps
13A
13A
15A
15A
15A
15A
20A
25A
30A
Power Cord Type
LCDI
LCDI
LCDI
LCDI
LCDI
LCDI
LCDI
LCDI
LCDI
Power Cord Length
Refrigerant
72”
76 3/4
78 3/4
78 3/4
78 3/4
69”
48”
78 3/4
69”
R410A
R410A
R410A
R410A
R410A
R410A
R410A
R410A
R410A
Refrigerant Charge/ Oz.
12.35
11.46
12.72
18.73
23.28
31.75
39.51
38.8
41.6
Sound (Indoor/Outdoor) dba
58/62
61/57/53
59/57/55
60/57/52
60.5/55.8/53.2
60 / 66
60/65
63/59/56
63.2 / 68.2
4 Way Air Adjustment
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
2 Way Air Swing
NO
Yes
Yes
Yes
Yes
Yes
NO
Yes
Yes
top front
top front
top front
top front
top front
top front
top front
top front
Air Discharge
Motor Type
ball bearing ball bearing/AC ball bearing/AC ball bearing/AC ball bearing/AC ball bearing/AC
top front
ball bearing
ball bearing/AC ball bearing/AC
6 μF
15 μF
15 μF
15 μF
8 μF
8μF
8 μF
8 μF
8μF
Remote
Remote
Remote
Remote
Remote
Remote
Remote
Remote
Remote
64-109 °F
64-109 °F
64-109 °F
64-109 °F
64-109 °F
64-109 °F
64-109 °F
64-109 °F
64-109 °F
Width
18 9/16”
19 1/8
19 11/16
19 11/16
23 5/8
23.6”
26 17/32”
26 1/2
26.5”
Depth
15 3/4”
15 3/4
19
20 15/16
25 1/2
25.4”
26 5/16”
25 1/2
26.5”
17.9”
18 5/8”
18 5/8
18.6”
31”-43”
31-42
Motor Capacitor / mfd
Controls
Operating Range
Cabinet Size/ inches
Height
12 3/4”
12 5/8
14 3/4
14 3/4
17 3/16
Window Opening Width (min/
max)
21”-38.1”
23-36
23-36
23-36
26 1/2-40 1/2
Thru. Wall Max. Thickness(In.)
4 23/32”
4 31/32
6 15/16
7 5/16
10
8”
7 1/4”
10
10”
Weight Gross/Net. (Lbs)
46/53
55 / 47
121.3/108
116 / 130
134/152
151/136.7
139 / 156
Approvals
cULus
cULus
cULus
cULus
cULus
cULus
cULus
cULus
cULus
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Chassis Slide In
66/56
72.7/65
21
26.5-40.5”
31 - 42”
Window Units - Remote
Cooling Only/Energy Star
Electrical Requirements
FEATURES
• Multiple Functions - Cooling, Dehumidifying & Fan Ventilation
•Installation Kit with Expandable Side Panels
•Retracting Louvers
NEMA 5-15A
115 VOLT
15 AMP
NEMA 6 - 15P
230 VOLT
15 AMP
NEMA 6 - 20P
230 VOLT
20 AMP
NEMA 6 - 30P
230 VOLT
25 AMP
While Supplies Last
While Supplies Last
Product Code
WA46YREB
WA48YREB
WA410YREB
422-0100
422-0108
422-0101
422-0109
Model Number
422-0105
422-0106
422-0107
WA412YRE
WA412YREB
WA412ZRE
WA412ZEB
BTU Cooling
6,000
8,000
10,000
12000
12,000
12000
12,000
BTU Heating
N/A
N/A
N/A
N/A
N/A
N/A
N/A
EER
11.2
11.3
11.3
11.3
11.3
11.3
11.3
Dehumidification (pints/hour)
1.5
1.9
2.3
2.5
2.5
2.5
2.5
Airflow (CFM)
251
364
485
288/244/206
490
288/244/206
490
Voltage
115
115
115
115
115
208 / 230
230 / 208
Frequency / Cycle
60HZ
60HZ
60HZ
60HZ
60 HZ
60HZ
60 HZ
Amps Cooling
5
6.2
7.8
9.5
9.4
Amps Heating
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Watts Cooling
536
708
880
1378
1060
1378
1035 / 1065
Watts Heating
Plug Type / Nema #
5.1 / 4.7
N/A
N/A
N/A
N/A
N/A
N/A
N/A
NEMA 5-15P
NEMA 5-15P
NEMA 5-15P
NEMA 5-15P
NEMA 5-15P
NEMA 6-15P
NEMA 6-15P
Power Cord Rating/ amps
15A
15A
15A
15A
15A
15A
15A
Power Cord Type
LCDI
LCDI
LCDI
LCDI
LCDI
LCDI
LCDI
69
69
69
78
69
78
69
Refrigerant
R410A
R410A
R410A
R410A
R410A
R410A
R410A
Refrigerant Charge/ Oz.
11.29
13.76
16.58
20.11
20.11
20.11
20.11
56.4 / 63.2
60.1 / 64.1
58.8 / 66.7
61/67
60 / 67
61/67
59.4 / 66.7
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Power Cord Length
Sound (Indoor/Outdoor) dba
4 Way Air Adjustment
2 Way Air Swing
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Top Front
Top Front
Top Front
Top Front
Top Front
Top Front
Top Front
Motor Type
Ball Bearing
Ball Bearing
Ball Bearing
ball bearing/AC
ball bearing/AC
ball bearing/AC
ball bearing/AC
Motor Capacitor / mfd
35μF+6μF
45μF+15μF
50μF+15μF
15μF
70μF+15μF
15μF
35μF
Remote
Remote
Remote
Remote
Remote
Remote
Remote
64 - 109 °F
64 - 109 °F
64 - 109 °F
62°F - 86°F
64 - 109 °F
62°F - 90°F
64 - 109 °F
Width
18.5”
18.5”
19”
19
19”
19
19”
Depth
15.7”
15.7”
21.5”
21.5
21.5”
21.5
21.5”
13.4”
13.4”
14.6”
14.6
14.6”
14.6
14.6”
23” - 36”
23” - 36”
23” - 36”
23”-36”
23” - 36”
23”-36”
23” - 36”
5”
5”
7.3”
8”
7.3”
8”
7.3”
44.7 / 51.5
48.6 / 55.4
62 / 67.7
Air Discharge
Controls
Operating Range
Cabinet Size/ inches
Height
Window Opening Width
(min / max)
Thru. Wall Max. Thickness
(Inches)
N.W. / G.W lbs.
Approvals
Chassis Slide Out
cULus/Energy Star cULus/Energy Star cULus/Energy Star
No
No
No
22
69/76.6
67.8 / 75.2
69.1/76.6
69.1 / 77
cULus/Energy Star
cULus/Energy Star
cULus/Energy Star
cULus/Energy Star
No
No
No
No
Window Units - Remote
Cooling Only/Energy Star
FEATURES
• Multiple Functions - Cooling, Dehumidifying & Fan Ventilation
•Installation Kit with Expandable Side Panels
•Retracting Louvers
Electrical Requirements
NEMA 5-15A
115 VOLT
15 AMP
NEMA 6 - 15P
230 VOLT
15 AMP
NEMA 6 - 20P
230 VOLT
20 AMP
NEMA 6 - 30P
230 VOLT
25 AMP
While Supplies Last
422-0102
WA415YRE
422-0110
WA415YREB
While Supplies Last
422-0103
WA418ZRE
422-0111
WA418ZREB
While Supplies Last
422-0104
WA425ZRE
422-0113
WA425ZREB
BTU Cooling
15000
15,100
18500/18100
18,200 / 18,500
25000/24700
24,700 / 25,000
BTU Heating
N/A
N/A
N/A
N/A
N/A
N/A
EER
11.2
11.2
11.2
11.2
9.8
9.8
Product Code
Model Number
Dehumidification (pints/hour)
3.2
3.17
3.8
3.8
5.7
5.7
382/359/323
382 / 360 / 323
441/382/341
446 / 388 / 329
540/500/459
523 / 485 / 445
Voltage
115
115
230/208
208 / 230
230/208
208 / 230
Frequency / Cycle
60HZ
60HZ
60HZ
60HZ
60HZ
60 HZ
12
11.7
14.2
7.8 / 7.3
11.3/12.4
12.4 / 11.3
Airflow (CFM)
Amps Cooling
Amps Heating
N/A
N/A
N/A
N/A
N/A
N/A
Watts Cooling
2147
1348
2571
1525 / 1652
2551/2520
2520 / 2551
Watts Heating
N/A
N/A
N/A
N/A
N/A
N/A
NEMA 5-15P
NEMA 5-15P
NEMA 6-15P
NEMA 6-15P
NEMA 6-20P
NEMA 6-20P
15amps
15A
15A
15A
20A
20A
LCDI
LCDI
LCDI
LCDI
LCDI
LCDI
Plug Type / Nema #
Power Cord Rating/ amps
Power Cord Type
Power Cord Length
78
69
78
69
78
69
Refrigerant
R410A
R410A
R410A
R410A
R410A
R410A
Refrigerant Charge/ Oz.
24.69
27.2
31.04
31.4
35.98
36.7
Sound (Indoor/Outdoor) dba
57/66
59 / 65
59/67
60 / 66
63/67
63.2 / 68.2
Yes
Yes
Yes
Yes
Yes
Yes
4 Way Air Adjustment
2 Way Air Swing
Air Discharge
Motor Type
Yes
Yes
Yes
Yes
Yes
Yes
Top Front
Top Front
Top Front
Top Front
Top Front
Top Front
ball bearing/AC
ball bearing/AC
ball bearing/AC
ball bearing/AC
Ball Bearing/AC
Ball Bearing/AC
Motor Capacitor / mfd
15 μF
15μF
8μF
8μF
8μF
8μF
Controls
Remote
Remote
Remote
Remote
Remote
Remote
62°F - 86°F
64-109 °F
62°F - 86°F
64-109 °F
62°F - 86°F
64-109 °F
Operating Range
Cabinet Size/ inches
Width
23.6
23.6”
23.6
23.6”
26.5
26.5”
Depth
25.4
25.4”
25.4
25.4”
26.5
26.5”
Height
Window Opening Width (min / max)
Thru. Wall Max. Thickness (Inches)
N.W. / G.W lbs.
Approvals
Chassis Slide Out
17.9
17.9”
17.9
17.9”
18.6
18.6”
26 1/2-40 1/2
26.5-40.5”
26 1/2-40 1/2
26.5-40.5”
31”-42”
31-42”
10”
8”
10”
8”
10”
10”
101.6/117
103.6 / 118
113.5/128.7
114 / 128.7
130.9/146.5
129.8 / 145.4
cULus/Energy Star
cULus/Energy Star
cULus/Energy Star
cULus/Energy Star
cULus/Energy Star
cULus/Energy Star
Yes
Yes
Yes
Yes
Yes
Yes
23
Window Units - Remote
with Electric Heat
Electrical Requirements
FEATURES
• Multiple Functions - Cooling, Dehumidifying & Fan Ventilation
•Installation Kit with Expandable Side Panels
•Retracting Louvers
NEMA 5-15A
115 VOLT
15 AMP
NEMA 6 - 15P
230 VOLT
15 AMP
NEMA 6 - 20P
230 VOLT
20 AMP
NEMA 6 - 30P
230 VOLT
25 AMP
Product Code
Model Number
422-0115
WH48YRB
422-0116
WH412ZRB
422-0117
WH418ZRB
422-0118
WH425ZRB
BTU Cooling
8,000
11,600 / 12,000
18,200 / 18,500
24,700 / 25,000
BTU Heating
N/A
N/A
N/A
N/A
Electric Heat Capacity
3,500
8,500/11,000
13,000/16,000
13,000/16,300
EER
10.9
10.9
10.7
9.4
Dehumidification (pints/hour)
1.6
2.5
3.8
5.7
593 / 520 / 441
696 / 633 / 553
446 / 388 / 329
523 / 485 / 445
208 / 230
Airflow (CFM)
Voltage
115
208 / 230
208 / 230
60 HZ
60 HZ
60 HZ
60 HZ
Amps Cooling
6.3
5.2 / 5.0
8.3 / 7.7
12.4 / 11.3
Amps Heating
N/A
N/A
N/A
N/A
Watts Cooling
734
1064 / 1100
1701 / 1729
2628 / 2660
Watts Heating
N/A
N/A
N/A
N/A
5-15P
6-20P
6-30P
6-30P
Frequency / Cycle
Plug Type / Nema #
Power Cord Rating/ amps
Power Cord Type
Power Cord Length
Refrigerant
Refrigerant Charge/ Oz.
15
20
30
30
LCDI
LCDI
LCDI
LCDI
76
69
69
69
R410A
R410A
R410A
R410A
13.4
22.22
31.75
36.7
57.5 / 64.5
60.9 / 67.2
60 / 66
63.2 / 68.2
4 Way Air Adjustment
Yes
Yes
YES
YES
2 Way Air Swing
Yes
Yes
YES
YES
Top Front
Top Front
Top Front
Top Front
Ball bearing
Ball bearing
Ball Bearing
Ball Bearing
Sound (Indoor/Outdoor) dba
Air Discharge
Motor Type
50+15μF(Dual Type)
4μF
8μF
8μF
Remote
Remote
Remote
Remote
64 - 109 °F
64 - 109 °F
64 - 109 °F
64 - 109 °F
Width
22.6”
22.6”
23.6”
26.5”
Depth
23”
23”
25.4”
26.5”
Height
16.1
16.1”
17.9”
18.6”
26.8” - 36”
26.8” - 36”
26.5 - 40.5”
31 - 42”
Motor Capacitor / mfd
Controls
Operating Range
Cabinet Size/ inches
Window Opening Width (min / max)
Thru. Wall Max. Thickness (Inches)
N.W. / G.W lbs.
Approvals
Chassis Slide Out
6.1”
6.1”
8”
10”
70.6 / 82
83.8 / 94.8
116.8 / 131
130.9 / 146.5
cULus
cULus
cULus
cULus
Yes
Yes
Yes
Yes
24
Window Units
Heat Pump with Remote
Electrical Requirements
FEATURES
NEMA 5-15A
115 VOLT
15 AMP
• Multiple Functions - Cooling, Dehumidifying
& Fan Ventilation
•Installation Kit with Expandable Side Panels
•Retracting Louvers
NEMA 6 - 15P
230 VOLT
15 AMP
NEMA 6 - 20P
230 VOLT
20 AMP
NEMA 6 - 30P
230 VOLT
25 AMP
While Supplies Last
Model Number
Product Code
Rated Voltage (VAC)
Cooling Capacity
Heating Capacity
Electric Heat Capacity
EER Rating
COP Rating
Dehumidification (pints/hr)
Air Flow Max (CFM)
Operating Voltage Range (VAC)
Frequency/Cycle
Cooling Amps
Cooling Watts
Heating Amps
Heating Watts
Electric Heat Amps
Electric Heat Watts
Plug Type - LCDI
Power Cord Rating (amps)
Power Cord Length (Inches)
Minimum Circuit Breaker Size (amps)
Minimum Circuit Capacity (amps)
Refrigerant Charge - R410a (oz.)
Max dbA Level (Indoor/Outdoor)
4 Way Air Adjustment
2 Way Air Swing
Air Discharge
Motor Type
Fan Motor Capacitor (MFD)
Controls
Ambient Operating Temperature
Unit Size (Inches)
Width
Depth
Height
Window Width Opening (Inches)
Thru. Wall Max. Thickness (Inches)
Weight Gross/Net. (Lbs)
Certification
Chassis Slide Out
WHP412ZR
WHP412ZRB
422-0119
421-0079
208-230
11200 / 11600
10000 / 10300
8500 / 10700
9.5
8.9
4.54
282
198 to 253
60
5.9 / 5.5
1180 / 1220
5.6 / 5.1
1130/1160
14.6/16
2765 / 3575
NEMA 6-20P
18A
59”
20A
20A
28.22
62 / 66
Yes
N/A
top front
ball bearing
4 μF
WHP418ZR
421-0080
208 / 230
208-230
10,600 / 11,000
17000 / 17300
9,600 / 10,000
15700 / 16000
8,500 / 11,000
9000 / 11000
9.8
9
9.2
8.9
2.5
7.45
696 / 633 / 553
570
198 - 253
198 to 253
60
60
5.2 / 5.0
9.0 / 8.5
1082 / 1122
1880 / 1920
5.0 / 4.8
8.8 / 8.3
1043 / 1087
1770 / 1800
14.5 / 16
15.6/16
2821 / 3450
3030 / 3680
6-20P
NEMA 6-20P
20
20A
69”
59”
20A
20A
20A
20A
29.63
35.27
60.9 / 67.2
62 / 66
Yes
N/A
Yes
Yes
Top Front
side
Ball bearing
ball bearing
4μF
7 μF
<109 °F
Remote
Remote
64 - 109 °F
<109 °F
22 19/32”
22.6”
26
Remote
23 5/8”
15 5/16”
27” to 39”
5 1/2
95.9 / 114.6
cULus
Yes
25
23”
27 3/4
16.1”
16 9/10
26.8” - 36”
30” to 38.1”
6.1”
9
90 / 97
160.9 / 143.3
cULus
cULus
Yes
Yes
Through The Wall Units
Sea Breeze Through the Wall units are designed with
a universal fit for easy replacement and fits most major brand sleeves.
Optional Wall Sleeves Available See bottom of page for part #
Electrical Requirements
NEMA 5-15A
115 VOLT
15 AMP
NEMA 6 - 15P
230 VOLT
15 AMP
Model Number
Product Code
Power Source Rated Voltage (VAC)
Rated Frequency (HZ)
Phase
Cooling Capacity (BTU/H)
Heating Capacity (BTU/H)
Set Point Min./Max. (Cool and Heat)
Cooling Power Input (W)
Heating Power Input (W) (HP)
NEMA 6 - 20P
230 VOLT
20 AMP
STW48AYX
423-0040
STW410AYX
423-0041
STW410AZE
423-0100
115
60
1
8000
115
60
1
10000
208/230
60
1
9800/10000
62°F / 86°F
850
62°F / 86°F
1064
62°F / 86°F
1020/1000
8
9.6
4.6/5
1467
1467
283/247/216
45.7
9.4
14.6
282/245/211
55.8
9.4
14.6
288/265/244
55.8
9.8
520
300
24 3/16” x 14 1/2” x 20 1/4”
58.3
68.2
R410A
0.79
400-450
520
300
24 3/16” x 14 1/2” x 20 1/4”
60.5
68.2
R410A
0.93
400-450
520
300
24 3/16” x 14 1/2” x 20 1/4”
68.2
77.9
R410A
1.06
Centrifugal
Centrifugal
1290 / 1130 / 995
Centrifugal
1330/1230/1130
Aluminum Fin
57/53/49
Aluminum Fin
57/53/51
Aluminum Fin-copper tube
61/58/56
GMCC
RECHI
Electric Heater (W)
Cooling Power Current (A)
Heating Power Current (A)
Rated Input (W) (Cool / Heat) (Max Power Input)
Rated Current (A) (Cool / Heat) (Max Power Input)
Air Flow Volume (CFM) (H/M/L)
Dehumidifying Volume (PINTS/DAY)
EER (BTU/WH)
COP
Application Area (FT2)
Permissible Excessive Operating Pressure for the Liquid Side
Permissible Excessive Operating pressure for the Suction Side
Dimension (INCHES) (WXHXD)
Net Weight (LBS) Net Weight
Gross Weight (LBS) Gross Weight
Refrigerant
Refrigerant Charge (LBS)
INDOOR SIDE
Fan Type
Fan Motor Speed (H/M/L)
Output of Fan Motor (W)
Evaporator Form
Sound Pressure Level
OUTDOOR SIDE
NEMA 6 - 30P
230 VOLT
25 AMP
Compressor Manufacturer/
L.R.A. (A)
37
21
Compressor RLA (A)
6.6
3.9
730
Capillary
62ºF~90ºF (17ºC-32ºC)
64ºF~109ºF(18ºC-43ºC)
860
Capillary
62ºF~90ºF (17ºC-32ºC)
64ºF~109ºF(18ºC-43ºC)
Axial-flow
66/60/56
Aluminum Fin Copper Tube
1290 / 1130 / 995
Axial-flow
63/59/56
Aluminum Fin Copper Tube
1330 / 1230 / 1130
Axial-fan
65 Max
15 AMPS
423-0050
15 AMPS
423-0050
15 AMPS
423-0050
Compressor Pwr Input (W)
Throttling Method
Indoor Operation Temp
Ambient Temp (Cooling)
Ambient Temp (Heating)
Condenser Form
Fan Motor Speed (RPM)
Fan Type
Sound Pressure Level
Defrosting Method
Breaker Size
Wall Sleeve 26” (optional)
Capillary
62ºF~90ºF (17ºC-32ºC)
64ºF~109ºF(18ºC-43ºC)
Aluminum Fin Copper Tube
26
Through The Wall Units
Wall Sleeve Dimensions
423-0050 - 25 1/2” W x 17 1/2” D x 15 1/4” H
423-0020 - 26” W x 16 3/4” D x 16 3/4” H
Model Number
STW412AYX
STW412AZE
STW412AEZX
423-0042
423-0101
423-0044
STW412AZ
423-0013
STW412HPZRB
Product Code
Power Source Rated Voltage (VAC)
115
208/230
208/230
208/230
208 / 230
Rated Frequency (HZ)
60
60
60
60
60 Hz
Phase
1
1
1
1
1
12000
12000/11700
11700/12000
11400/11800
11700 / 11500
62°F / 86°F
62°F / 86°F
62°F / 86°F
61°F / 86°F
64 - 109 °F
1270
1224/1194
1300/1330
1200/1160
1200 /1 220
Cooling Capacity (BTU/H)
8600/10600 (Electric heater)
Heating Capacity (BTU/H)
Set Point Min./Max. (Cool and Heat)
Cooling Power Input (W)
1140 / 1160
2800/3450 (Electric heater)
Electric Heater (W)
Cooling Power Current (A)
11400 / 11200
2800/3450 (Electric heater)
Heating Power Input (W) (HP)
11.5
5.5/5.9
Heating Power Current (A)
1713
Rated Input (W) (Cool / Heat) (Max Power Input)
6.6/6.0
423-0103
2900 / 3500
5.6/6.0
6.1 / 5.6
15/13.5 (Electric heater current)
N/A
5.9 / 5.4
1780
1500
1500
7.7
7.9
8.1
8
306/274/241
288/265/244
286/262/241
283/259/235
288 / 265 / 244
Dehumidifying Volume (PINTS/DAY)
60.9
60.9
60.9
81
84
EER (BTU/WH)
9.4
9.8
9
9.8
9.6
Rated Current (A) (Cool / Heat) (Max Power Input)
Air Flow Volume (CFM) (H/M/L)
9.9
COP
450-550
450-550
450-550
450-550
172 - 258
Permissible Excessive Operating Pressure for the
Liquid Side
Application Area (FT2)
520
520
520
551 PSIG
551 PSIG
Permissible Excessive Operating pressure for the
Suction Side
300
300
300
174 PSIG
174 PSIG
24 3/16” x 14 1/2” x
20 1/4”
24 3/16” x 14 1/2” x
20 1/4”
24 3/16” x 14 1/2” x 20 1/4”
26”X15.6”X21.7”
26” X 15 3/4” X 16
3/4”
68
71.5
66
86
86
Dimension (INCHES) (WXHXD)
Net Weight (LBS) Net Weight
Gross Weight (LBS) Gross Weight
Refrigerant
Refrigerant Charge (LBS)
77.9
81.6
78.1
103.6
99
R410A
R410A
R410A
R410A
R410A
1.24
1.323
1.06
1.39
29.98 oz
Centrifugal
Centrifugal
Centrifugal
Centrifugal
Centrifugal
1480/1380/1265
1480/1380/1265
1070/1000/920
1070 / 1000 / 920
30
30
INDOOR SIDE
Fan Type
Fan Motor Speed (H/M/L)
Output of Fan Motor (W)
Evaporator Form
Sound Pressure Level dB (A) [H / M / L]
Aluminum Fin-copper Aluminum Fin-copper
60/58/56
Aluminum Fin-copper
Aluminum Fin-copper Aluminum Fin-copper
61/58/56
60/58/55
58/56/54
59 / 57 / 55
GMCC
RECHI
Rechi
Highly (Rotary)
27
29.5
29.5
30
4/3.65
5
5
5.1
OUTDOOR SIDE
Compressor Manufacturer/
L.R.A. (A)
Compressor RLA (A)
850/865
1125
1125
1090
Capillary
Capillary
Capillary
Capillary
Capillary
Indoor Operation Temp
62ºF~90ºF (17ºC32ºC)
62ºF~90ºF (17ºC32ºC)
23ºF~109ºF
64ºF~86ºF (18ºC30ºC)
64ºF~86ºF (16ºC30ºC)
Ambient Temp (Cooling)
64ºF~109ºF(18ºC43ºC)
64ºF~109ºF(18ºC43ºC)
64ºF~109ºF(18ºC-43ºC)
64ºF~109ºF(18ºC43ºC)
64ºF~86ºF (18ºC30ºC)
Compressor Pwr Input (W)
Throttling Method
≤75.2ºF (24ºC)
Ambient Temp (Heating)
Condenser Form
Aluminum Fin Copper Aluminum Fin Copper
Fan Motor Speed (RPM)
Fan Type
Axial-fan
Aluminum Fin Copper
19ºF~86ºF
Aluminum Fin Copper Aluminum Fin Copper
1480/1380/1265
1420 / 1320 / 1220
1600
1600
Axial-fan
Axial-fan
Axial-fan
Axial-fan
Sound Power Level dB (A) [H / M / L]
71/69/67
65
60/58/55
66/64/62
69 / 67 / 65
Breaker Size
15 AMPS
15 AMPS
20 AMPS
15 AMPS
20 AMPS
Wall Sleeve 26” (optional)
423-0050
423-0050
423-0050
423-0020
423-0020
27
PTAC
Package Terminal Air Conditioning Units
Seabreeze PTAC units are an excellent option for the hospitality industry. They have a universal size
to fit other PTAC sleeves for easy replacement and can change to 2KW, 3KW, or 5KW electric heater
with a quick connect plug. Flexi Plug helps reduce inventory requirements.
Heater Options
2KWPC - 2KW, 20 Amp, LCDI plug (425-0021) NEMA 6-20P
used to convert to 2KW
3KWPC - 3KW, 20 Amp, LCDI plug (425-0022) NEMA 6-20P
included with ALL Units
5KWPC - 5KW, 30 Amp, LCDI plug (425-0023) NEMA 6-30P
used to convert to 5K
Not for use with 425-0009 and 425-0010
FEATURES
• Auto Restart
• 410A
• Wall Sleeve Dimensions - 425-0019 - 42” W x 13 3/4” D x 16” H
Product Code
Model Number
Voltage Rating (V/Ph/Hz)
Cooling Capacity (Btu/Hr)
Heating Capacity (Btu/Hr)
Electric Heating (Watts)
Dehumidification (Pts/Hr)
EER (Btu/W)
COP (Btu/W)
Compressor Type
Air Flow (H/M/L/) CFM
Power Input (Watts)
(cool/heat mode)
Rated Current (Amps) (compressor and fan in cool/heat
mode).
Full Load Current (Amps)
[3KW electric heat and fan.]
Breaker Min. Size (Amps)
Plug Type (LCDI)
Noise Level Max. (dBa)
Indoor/Outdoor
Coil Type
Unit Dimensions
(W x H x D)Inches
425-0009
PTAC49CH3ZX
208-230/1/60
9,000
N/A
3,000
1.71
11.3
N/A
MITSUBISHI
312/294/277
425-0039
PTAC49HP3ZB
208-230/1/60
9,000
8,100
3,000
1.82
11.3
3.3
SAMSUNG
312/294/277
425-0011
PTAC412CH3ZX
208-230/1/60
12,000
N/A
3,000
3.49
10.7
N/A
SAMSUNG
341/324/306
425-0012
PTAC412HP3ZX
208-230/1/60
12,000
10,700
3,000
3.49
10.7
3.1
SAMSUNG
341/324/306
425-0013
PTAC415CH3ZX
208-230/1/60
15,000
N/A
3,000
4.65
9.8
N/A
PANASONIC
341/324/306
425-0015
PTAC415HP3ZB
208-230/1/60
15,000
13,800
3,000
4.65
9.8
2.9
PANASONIC
341/324/306
800 / N/A
800 / 720
1120 / N/A
1120 / 1010
1530 / N/A
1530 / 1390
5 / N/A
208VAC - 14.7A
230VAC - 13.7A
20A (3KW)
NEMA 6-20P
5.6 / 4.9
208VAC - 14.7A
230VAC - 13.7A
20A (3KW)
NEMA 6-20P
8.1 / N/A
208VAC - 14.7A
230VAC - 13.7A
20A (3KW)
NEMA 6-20P
8.1 / 6.9
208VAC - 14.7A
230VAC - 13.7A
20A (3KW)
NEMA 6-20P
10.5 / N/A
208VAC - 14.7A
230VAC - 13.7A
20A (3KW)
NEMA 6-20P
10.5 / 11
208VAC - 14.7A
230VAC - 13.7A
20A (3KW)
NEMA 6-20P
51/62
51/62
53/65
53/65
53/65
53/65
Aluminum Fin
Copper Tube
Aluminum Fin
Copper Tube
Aluminum Fin
Copper Tube
Aluminum Fin
Copper Tube
Aluminum Fin
Copper Tube
Aluminum Fin
Copper Tube
42.1 X 16 X 21.5
42.1 X 16 X 21.5
42.1 X 16 X 21.5
42.1 X 16 X 21.5
42.1 X 16 X 21.5
42.1 X 16 X 21.5
Pkg Dimensions
(W x H x D) Inches
44.9 X 25.3 X 18.1
Weight (Net/Shipping) Lbs
111/131
Refrigerant Type/Charge
R410A / 2.09 lbs
Certifications
UL & CSA
Warranty (Compressor/Parts) 5 YEARS / 1 YEAR
44.9 X 25.3 X 18.1
114/133
R410A / 2.09 lbs
UL & CSA
5 YEARS / 1 YEAR
45.28 X 23.82 X 18.9 45.28 X 23.82 X 18.9 45.28 X 23.82 X 18.9
116/136
118/138
119/139
R410A / 2.2 lbs
R410A / 2.2 lbs
R410A / 2.38 lbs
UL & CSA
UL & CSA
UL & CSA
5 YEARS / 1 YEAR
5 YEARS / 1 YEAR
5 YEARS / 1 YEAR
28
45.28 X 23.82 X 18.9
121/141
R410A / 2.38 lbs
UL & CSA
5 YEARS / 1 YEAR
PTAC & PTAC Accessories
265/277 Volt Heat Pump PTACs
425-0040
PTAC49HP3VB
265-2771/60
9,000
8,100
3,000
2.11
11.3
3.3
RECHI
312/294/277
While Supplies Last
425-0033
PTAC412HP3VX
265-277/1/60
12,000
10,700
3,000
3.49
10.7
3.1
SAMSUNG
341/324/306
Will Replace PTAC412HP3VX
425-0041
PTAC412HP3VB
265-277/1/60
12,000
10,700
3,000
2.75
10.7
3.1
RECHI
341/324/306
425-0035
PTAC415HP3VX
265-2771/60
15,000
13,800
3,000
4.65
9.8
2.9
PANASONIC
341/324/306
800 / 715
1120 / 1010
1120 / 1010
1530 / 1390
3.4 / 2.9
4.8
4.8 / 4.5
5.8
11.6
11.6
20A (3KW)
208VAC - 4.5A
230VAC - 13.5A
20A (3KW)
11.6
11.6
20A (3KW)
208VAC - 5.3A
230VAC - 13.5A
20A (3KW)
NEMA 7-20P
NEMA 6-20P
NEMA 7-20P
NEMA 6-20P
Noise Level Max. (dBa) Indoor
52/51/50
52/50/48
54/53/52
56/55/54
Noise Level Max. (dBa) Outdoor
66/65/64
63/61/59
66/65/64
66/65/64
Aluminum Fin Copper Tube
Aluminum Fin Copper Tube
Aluminum Fin Copper Tube
Aluminum Fin Copper Tube
Unit Dimensions (W x H x D)Inches
42.1 X 16 X 21.5
42.1 X 16 X 21.5
42.1 X 16 X 21.5
42.1 X 16 X 21.5
Pkg Dimensions (W x H x D) Inches
45 X 18.5 X 25.4
45.28 X 23.82 X 18.9
45 X 18.5 X 25.4
45.28 X 23.82 X 18.9
Weight (Net/Shipping) Lbs
Refrigerant Type/Charge
Certifications
Warranty (Compressor/Parts)
108/128
R410A / 24.34
UL, CSA, AHRI
5 YEARS / 1 YEAR
118/138
R410A / 2.2 lbs
UL & CSA
5 YEARS / 1 YEAR
112/132
R410A/26.8
UL, CSA, AHRI
5 YEARS / 1 YEAR
121/141
R410A / 2.38 lbs
UL & CSA
5 YEARS / 1 YEAR
Product Code
Model Number
Voltage Rating (V/Ph/Hz)
Cooling Capacity (Btu/Hr)
Heating Capacity (Btu/Hr)
Electric Heating (Watts)
Dehumidification (Pts/Hr)
EER (Btu/W)
COP (Btu/W)
Compressor Type
Air Flow (H/M/L/) CFM
Power Input (Watts) (cool/heat mode)
Rated Current (Amps) (compressor and fan
in cool/heat mode).
Full Load Current (Amps)
(3KW electric heat and fan.)
Breaker Min. Size (Amps)
Plug Type (LCDI)
Coil Type
Parts Sold Separately
PART NUMBER
425-0019
425-0021
425-0022
425-0023
425-0036
425-0037
425-0038
425-0024
425-0025
425-0027
425-0028
425-0029
DESCRIPTION
Wall Sleeve (W/D/H)(42” x 13 3/4” x 16”)
2KWPC Power Cord for 208V PTAC
3KWPC Power Cord for 208V PTAC
5KWPC Power Cord for 208V PTAC
2KWPC265 Power Cord for 265V PTAC
3KWPC265 Power Cord for 265V PTAC
5KWPC265 Power Cord for 265V PTAC
Outdoor Louvered Grill
Clear Anodized Grill
Outdoor Soft Dove Powder Coated
PTAC Drain Kit
PTAC Leveling Legs
425-0024
Outdoor Louvered Grill
425-0019
PTAC Wall Sleeve
425-0025
Clear Anodized Grill
Thermostat Options
PART NUMBER
435-0014
435-0005
435-0006
435-0007
435-0008
435-0009
435-0010
435-0012
435-0013
DESCRIPTION
Wireless Thermostat and Receiver
TSN11X Room Thermostat
TSP12X Room Thermostat
THN13X Room Thermostat
THP14X Room Thermostat
STS11 Touch Screen Thermostat
STS32 Touch Screen Thermostat
Outdoor Sensor For Thermostats
Indoor Sensor For Thermostats
435-0014
Wireless Thermostat
& Reciever
29
435-0009
STS11Touch Screen Thermostat
Portable Air Conditioning Units
The Sea Breeze Portable Air Conditioning unit is a
quick and easy solution for cooling
a hard to reach spot without a permanent installation.
FEATURES
• 10+ Gallons Dehumidification Capacity a day
•Includes Flexible Vent Hose and Window Adapter
• Digital Display
• 24 Hour ON/OFF
Product Code
Model Number
Description
Cooling Capacity
Heating Capacity
Rated Voltage
Rated Frequency
Rated Cooling Current
Rated Cooling Power
Heating Rated Current
Rated Heating Power
EER
Cycling Airflow (H/M/L)
Refrigerant
Noise (class)
Weight (net wt)
Weight (gross wt)
Unit Dimensions (W/H/D)
Dehumidifying Volume
Breaker Size
LCDI Plug
Power Cord Length
Vent Hose Max Length
Vent Hose Diameter
Clock & 24 hr Timer
Filter
• Caster Wheels
• Auto Defrost HP Only
• Full Tank Alarm
• Tank or Continuous Drain
250-0021
PAS412M
Single Pipe
12000 BTU/h
N/A
115 VAC
60 HZ
11.8 A
1355 W
N/A
N/A
8.9
292/265/238
R410A
55/52/49 db(A)
70.4 LBS
78.1 LBS
18.4" x 15.6" x 30.1"
7.6 gallon/day
20 A
NEMA5-15P
7.54'
56"
5 1/4"
Timer Only
Washable
250-0022
PAS412DM
Dual Pipe
12000 BTU/h
N/A
115 VAC
60 HZ
11.8 A
1355 W
N/A
N/A
8.9
282/253/233
R410A
55/53/52 db(A)
71.5 LBS
80.2 LBS
18.4" x 18.8" x 30.1"
7.6 gallon/day
20 A
NEMA5-15P
7.54'
56"
5 1/4"
Timer Only
Washable
250-0023
PAS412HPM
Single Pipe
12000 BTU/h
11000 BTU/h
115 VAC
60 HZ
11.8 A
1355 W
10.8 A
1240 W
8.9
292/265/238
R410A
55/52/49 db(A)
71.5 LBS
79.2 LBS
18.4" x 15.6" x 30.1"
7.6 gallon/day
20 A
NEMA5-15P
7.54'
56"
5 1/4"
Timer Only
Washable
250-0024
PAS414M
Single Pipe
14000 BTU/h
N/A
115 VAC
60 HZ
11.9 A
1580 W
N/A
N/A
8.9
292/265/238
R410A
55/52/49 db(A)
72.6 LBS
81.4 LBS
18.4" x 15.6" x 30.1"
8.9 gallon/day
20 A
NEMA5-15P
7.54'
56"
5 1/4"
Timer Only
Washable
Dehumidifier Specifications
Product Code
270-0018
270-0019
Model Number
DH450SM
DH470SM
Rated Voltage
115 VAC
115 VAC
Rated Frequency
60 Hz
60 Hz
Rated Current
4.7 A
6.9 A
Rated Imput
520 W
720 W
Refrigerant
R410A
R410A
Weight (net wt)
36.3 lbs
39.6 lbs
Weight (gross wt)
38.5 lbs
41.8 lbs
Unit Dimensions (W/H/D) 15.4" x 10.8" x 23.2" 15.4" x 10.8" x 23.2"
Dehumidifying Volume
50 pts/day
70 pts/day
HP.PSIG
540 psi
540 psi
LP.PSIG
300 psi
300 psi
Filter
Tank Size
Washable
1.585 gal
Washable
1.585 gal
270-0020
DH470SMP
115 VAC
60 Hz
6.9 A
720 W
R410A
40.7 lbs
42.9 lbs
15.4" x 10.8" x 23.2"
70 pts/day
540 psi
300 psi
Washable
1.585 gal
30
FEATURES
• Auto Shut Off
• Drain Hose Connection
• Adjustable Air Guide
• Low Power Consumption
• Digital Display
• Caster Wheels
• Filter Alert
• Timer-Auto Stop
• Full Tank Alarm
• DH470SMP includes
condensate pump with
6.3 ft of lift
Corporate Headquarters
International Refrigeration Products
1035 Wheeler Way
Langhorne, PA 19047
Phone: 215-750-9876
Fax: 215-750-1169
Technical Support: 704-504-8590
www.irproducts.biz
ESCB-12015
