FZN150 (BE31)
FZN150D (BE41)
C SOUTH AMERICA
C SOUTH AMERICA
1RBE3-200S1
(
)
FZN150/FZN150D
CATALOGO DE REPUESTOS
©2015 por Yamaha Motor Co., Ltd.
1ª edición, junio 2015
Todos los derechos reservados.
Toda reproducción o uso no autorizado
sin el consentimiento escrito de
Yamaha Motor Co., Ltd.
quedan expresamente prohibidos
Impreso en Japón.
FZN150/FZN150D
PARTS CATALOGUE
©2015 by Yamaha Motor Co., Ltd.
1st edition, June 2015
All rights reserved.
Any reprinting or unauthorized use
without the written permission of
Yamaha Motor Co., Ltd.
is expressly prohibited.
Printed in Japan.
PROLOGO
Este catálogo de repuestos corresponde a las piezas para el o los modelos que figuran en la
página de portada. Al formular el pedido de repuestos, se ruega citar este catálogo y especificar correctamente el número y el nombre de las piezas.
1. Las modificaciones y agregados que se hayan realizado después de la edición de este
Catálogo de Repuestos, serán anunciados en las Informaciones de Recambios.
Es recomendable que se hagan las correcciones necesarias en el Catálogo de Repuestos de acuerdo con las Informaciones de Recambios.
2. Abreviaciones
En este. Catálogo de Repuestos se emplean las siguientes abreviaciones.
“UR” Usar el número de partes especificado
“UN” Usar la cantidad necesaria
“AP” Piezas sustitutivas
“LM” Fabricación local (Hay que pedir los repuestos en las cercanías)
“F#” Nº de bastidor (Nº aplicable a la máquina)
“O/S” Sobredimensionado
3. La cantidad de componentes para el montaje
• Los componentes, suministrados como conjunto, se describen con un punto (.) que
precede al nombre del parte como se indica a continuación.
• La numeración que aparece a la derecha de cada descripción indica la cantidad de
partes por cada unidad de conjunto.
CODIGO Nº
DESCRIPCION
CANT. OBSERVACIONES
2F5–83310–60
ENSAMBLAJE DE LA LUZ
2
115–83311–60
.BOMBILLA (6V–18W)
1
4. Los colores de los componentes se indican como sigue en la columna de “OBSERVACIONES”.
CODIGO Nº
DESCRIPCION
CANT. OBSERVACIONES
2N4–24110–00–X5 COMP. DEL TANQUE
2
MXR
3J1–24240–10
1
PARA MXR
.GRAFICO, DEL TANQUE
5. Debe tenerse en cuenta que las ilustraciones sirven como guia para la búsqueda de los
números de partes y no deben usarse para el montaje. Durante el montaje, se recomienda usar el manual de taller correspondiente.
6. EL asterisco (*) antes del número de referencia indica los elementos modificados después de la primera edición.
FOREWORD
This Parts Catalogue is related to the parts for the model(s) on the cover page. When you are
ordering replacement parts, please refer to this Parts Catalogue and quote both part numbers
and part names correctly.
1. Modifications or additions which have been made after the issue of the Parts Catalogue
will be announced in the Parts News.
It is advisable that you make the necessary corrections to the Parts Catalogue according
to the Parts News.
2. Abbreviations
The following abbreviations are used in this Parts Catalogue.
“UR” Use specified parts number.
“UN” Use as many as needed.
“AP” Alternate Parts
“LM” Locally Made (Parts need to be ordered locally)
“F#” Frame No. (Applicable machine No.)
“O/S” Over Size
3. The number of components for assembly
• Parts, which are to be supplied in an assembly, are listed with a dot (.) in front of the
part name as shown below.
• The numeral appearing to the right of each component part indicates the quantity of
parts for each assembly unit.
PART NO.
DESCRIPTION
Q’TY REMARKS
2F5–83310–60
FRONT FLASHER LIGHT ASSY
2
115–83311–60
.BULB (6V–18W)
1
4. Applicable colours of graphics are represented in the “REMARKS” as shown below.
PART NO.
DESCRIPTION
Q’TY REMARKS
2N4–24110–00–X5 FUEL TANK COMP.
2
MXR
3J1–24240–10
1
FOR MXR
.GRAPHIC, FUEL TANK
5. Note that the illustrations for reference in finding parts numbers are not to be used for
assembling. When assembling, please use the applicable service manual.
6. The asterisk (*) before a reference number indicates modified items after the first edition.
PROLOGO
7. Números de serie
Nº de Serie del bastidor
9. Nº de serie inicial aplicable
Nº de Serie del motor
Nº de Serie del bastidor
Nº de serie
Nombre de la columna de
cantidades
Código de Modelo
Nombre de la columna de
cantidades
Código de Modelo
Nº de Serie del motor
8. Códigos de color aplicables (El símbolo (*) muestra el color de modelo.)
Abreviatura
Nombre de color
Código de color
BWC1(*)
BLUISH WHITE COCKTAIL 1
0390
CM6
CYAN METALLIC 6
1344
MBL2(*)
MAT BLACK 2
0582
S8
SILVER 8
0895
VRC1(*)
VIVID RED COCKTAIL 1
0121
YB(*)
YAMAHA BLACK
0033
YRC2
YELLOWISH RED COCKTAIL 2
1161
Nº de serie
FOREWORD
7. Applicable Serial No.
Frame Serial No.
9. Applicable Starting Serial No.
Engine Serial No.
Frame Serial No.
Serial No.
Name Of Q’ty Column
Model Code
Name Of Q’ty Column
Model Code
Engine Serial No.
8. Applicable Colour Code (The (*) mark shows Model colour.)
Serial No.
Abbreviation
Colour Name
Colour Code
BWC1(*)
BLUISH WHITE COCKTAIL 1
0390
CM6
CYAN METALLIC 6
1344
MBL2(*)
MAT BLACK 2
0582
S8
SILVER 8
0895
VRC1(*)
VIVID RED COCKTAIL 1
0121
YB(*)
YAMAHA BLACK
0033
YRC2
YELLOWISH RED COCKTAIL 2
1161
CONTENIDO
MOTOR
CILINDRO ............................................................................. 1
CIGUENAL & PISTON .......................................................... 2
VALVULA .............................................................................. 4
ARBOL DE LEVAS & CADENA ............................................ 5
BOMBA DE ACEITE ............................................................. 6
ADMISION ............................................................................. 7
DESCARGA .......................................................................... 9
CARTER ................................................................................ 10
CUBIERTA DE CARTER 1 ................................................... 11
EMBRAGUE DEL ARRANQUE ............................................ 12
EMBRAGUE .......................................................................... 13
TRANSMISION ..................................................................... 15
LEVA DE CAMBIO & HORQUILLA ....................................... 17
EJE DE CAMBIO & PEDAL .................................................. 18
SHASIS
CUADRO ............................................................................... 19
GUARDABARRO .................................................................. 20
CUBIERTA LATERAL ........................................................... 21
BRAZO TRASERO & SUSPENSION .................................... 23
DIRECCION .......................................................................... 25
HORQUILLA DELANTERA ................................................... 26
DEPOSITO DE COMBUSTIBLE ........................................... 28
DEPOSITO DE COMBUSTIBLE 2 ........................................ 30
ASIENTO ............................................................................... 32
RUEDA DELANTERA ........................................................... 33
CALIBRE FRENO DELANTERA ........................................... 34
RUEDA TRASERA ................................................................ 35
MANILLAR & CABLE ............................................................ 37
CILINDRO MAESTRO DELANTERO .................................... 38
SOPORTE & APOYAPIE ...................................................... 39
SOPORTE & APOYAPIE 2 ................................................... 41
GENERADOR ....................................................................... 42
MOTOR DE ARRANQUE ...................................................... 43
LUZ DE DESTELLADOR ...................................................... 44
MEDIDOR ............................................................................. 46
FARO DELANTERO ............................................................. 47
LUZ DE COLA ....................................................................... 49
INTERRUPTOR DE MANILLAR&PALANC ........................... 50
EQUIPO ELECTRICO 1 ........................................................ 51
EQUIPO ELECTRICO 2 ........................................................ 52
INDICE
INDICE NUMERICO ............................................................. 53
CONTENTS
ENGINE
CYLINDER ............................................................................ 1
CRANKSHAFT & PISTON .................................................... 2
VALVE ................................................................................... 4
CAMSHAFT & CHAIN ........................................................... 5
OIL PUMP ............................................................................. 6
INTAKE ................................................................................. 7
EXHAUST ............................................................................. 9
CRANKCASE ........................................................................ 10
CRANKCASE COVER 1 ....................................................... 11
STARTER CLUTCH .............................................................. 12
CLUTCH ................................................................................ 13
TRANSMISSION ................................................................... 15
SHIFT CAM & FORK ............................................................. 17
SHIFT SHAFT ....................................................................... 18
CHASSIS
FRAME .................................................................................. 19
FENDER ................................................................................ 20
SIDE COVER ........................................................................ 21
REAR ARM & SUSPENSION ............................................... 23
STEERING ............................................................................ 25
FRONT FORK ....................................................................... 26
FUEL TANK ........................................................................... 28
FUEL TANK 2 ........................................................................ 30
SEAT ..................................................................................... 32
FRONT WHEEL .................................................................... 33
FRONT BRAKE CALIPER .................................................... 34
REAR WHEEL ....................................................................... 35
STEERING HANDLE & CABLE ............................................ 37
FRONT MASTER CYLINDER ............................................... 38
STAND & FOOTREST .......................................................... 39
STAND & FOOTREST 2 ....................................................... 41
GENERATOR ........................................................................ 42
STARTING MOTOR .............................................................. 43
FLASHER LIGHT .................................................................. 44
METER .................................................................................. 46
HEADLIGHT .......................................................................... 47
TAILLIGHT ............................................................................ 49
HANDLE SWITCH & LEVER ................................................ 50
ELECTRICAL 1 ..................................................................... 51
ELECTRICAL 2 ..................................................................... 52
INDEX
NUMERICAL INDEX ............................................................. 53
REF.
Nº
CODIGO Nº
PART NO.
1 2GS–E1102–00
2 95022–06012
3 90430–06817
4 95612–08635
5 2GS–E1190–00
6 2GS–E1165–00
7 21C–E1169–10
8 90149–05807
9 2GS–E1193–00
10 95022–06025
11 2GS–E1186–00
12 21C–E2435–11
13 95022–06025
14 90430–06817
15 2GS–E1361–00
16 94703–00885
17 2GS–E1181–01
18 91810–14804
19 90110–06304
20 2GS–E1310–00
21 21C–E1351–00
22 21C–E2661–10
23 90201–05820
24 90110–06256
CYLINDER
DESCRIPCION
DESCRIPTION
CULATA DE CILINDRO COMPLETA
CYLINDER HEAD ASSY
.PERNO, DE BRIDA
.BOLT, FLANGE
.JUNTA
.GASKET
PERNO DE PUNTAL
BOLT, STUD
TAPA CULATA DE CILINDRO 1
COVER, CYLINDER HEAD 1
.PLACA RESPIRADERO
.PLATE, BREATHER
.EMAPQ CBTA.DE RESP.
.GASKET, BREATHER COVER
.TORNILLO DE REGLAJE
.SCREW
EMPAQUE
GASKET, HEAD COVER 1
PERNO, DE BRIDA
BOLT, FLANGE
CUBIERTA CULATA CIL.LAT.2
COVER, CYLINDER HEAD SIDE 2
EMPAQUE
GASKET
PERNO, DE BRIDA
BOLT, FLANGE
JUNTA
GASKET
PERNO RETEN DE CILINDRO 1
BOLT, CYLINDER HOLDING 1
BUJIA (NGK CPR8EA)
PLUG, SPARK (NGK CPR8EA)
JUNTA, DE CULATA 1
GASKET, CYLINDER HEAD 1
PASADOR DE CLAVIJA
PIN, DOWEL
TORNILLO ALLEN
BOLT, HEXAGON SOCKET HEAD
CILINDRO
CYLINDER
JUNTA, DE CILINDRO
GASKET, CYLINDER
CONDUCTO
DUCT
ARANDELA PLANA
WASHER, PLATE
TORNILLO ALLEN
BOLT, HEXAGON SOCKET HEAD
1
BE41
1 CILINDRO
BE31
FIG.
1
1
1
1
1
1
2
2
1
1
1
1
1
1
4
4
1
1
5
5
1
1
1
1
3
3
3
3
4
4
1
1
1
1
4
4
2
2
1
1
1
1
1
1
2
2
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–E1400–09
2 21C–E1681–01
3 93310–628X0
4 2GS–E1651–00
5 2GS–E1422–00
6 93306–305YC
7 90280–03017
8 2GS–E1631–00
2GS–E1636–09
2GS–E1638–09
9 21C–E1633–00
10 93450–16812
11 2GS–E1603–00
2GS–E1605–00
2GS–E1607–00
12 54B–E1536–01
13 90387–20813
14 2GS–E1454–00
15 21C–E1531–01
16 21C–E1496–20
17 90201–15022
18 90214–10006
19 54B–E1476–00
20 21C–E3362–00
21 90387–155J0
22 93306–252YG
23 93306–253Y6
CRANKSHAFT & PISTON
DESCRIPCION
DESCRIPTION
CIGUENAL COMPLETO
CRANKSHAFT ASSY
.PASADOR MANIVELA 1
.PIN, CRANK 1
.COJINETE DE RODILLOS
.BEARING
.BIELA
.ROD, CONNECTING
.MANIVELA 2
.CRANK 2
COJINETE
BEARING
CUNA WOODRUFF
KEY, WOODRUFF
PISTON (NORMA)
PISTON (STD)
PISTON (0.50MM O/S)
PISTON (0.50MM O/S)
PISTON (1.00MM O/S)
PISTON (1.00MM O/S)
PASADOR, PISTON
PIN, PISTON
SEGURO
CIRCLIP
JUEGO DE ANILLOS (NORMA)
PISTON RING SET (STD)
JUEGO DE ANILLOS (0.50MM O/S)
PISTON RING SET (0.50MM O/S)
JUEGO DE ANILLOS (1.00MM O/S)
PISTON RING SET (1.00MM O/S)
ENGRANAJE TRACCION
GEAR, DRIVE
ESPACIADOR
COLLAR
PESO 1
WEIGHT 1
ENGRANAJE CONTRAPESO
GEAR, BALANCE WEIGHT
COPA TOPE
BOSS, BUFFER
ARANDELA PLANA
WASHER, PLATE
ARANDELA DE POSICION
WASHER, CLAW
RESORTE
SPRING
RODILLO
ROLLER
ESPACIADOR
COLLAR
COJINETE
BEARING
COJINETE
BEARING
2
BE41
REF.
Nº
2 CIGUENAL & PISTON
BE31
FIG.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
4
2
2
1
1
1
1
1
1
OBSERVACIONES
REMARKS
AP
AP
AP
AP
AP
AP
AP
AP
CODIGO Nº
PART NO.
24 90282–05031
25 90215–10284
26 90170–10012
DESCRIPCION
DESCRIPTION
CHAVETA, RECTA
KEY, STRAIGHT
ARANDELA DE CIERRE
WASHER, LOCK
TUERCA
NUT
3
CRANKSHAFT & PISTON
BE41
REF.
Nº
2 CIGUENAL & PISTON
BE31
FIG.
1
1
1
1
1
1
OBSERVACIONES
REMARKS
REF.
Nº
CODIGO Nº
PART NO.
1 2GS–E2111–00
2 2GS–E2121–00
3 38B–E2119–00
4 2GS–E2126–00
5 2GS–E2113–00
6 3S0–E2118–00
7 4D9–12117–00
8 52S–E2169–10
9 1ST–E2151–00
10 2GS–12159–00
11 90170–05302
12 21C–E2156–00
13 91312–05016
VALVE
DESCRIPCION
DESCRIPTION
VALVULA DE ADMISION
VALVE, INTAKE
VALVULA DE ESCAPE
VALVE, EXHAUST
SELLO DE ACEITE VALVULA
SEAL, VALVE STEM
ASIENTO RESORTE DE VALVULA2
SEAT, VALVE SPRING 2
RESORTE VALVULA INTERNA
SPRING, VALVE INNER
SEGURO DE VALVULA
LOCK, VALVE SPRING RETAINER
RETEN RESORTE DE VALVULA
RETAINER, VALVE SPRING
DISCO DE AJUSTE
PAD, ADJUSTING
BRAZO DE BALANCIN DE VALVULA
ARM, VALVE ROCKER
TORNILLO DE AJUSTE DE VALVULA
SCREW, VALVE ADJUSTING
TUERCA
NUT
EJE DE BALANCIN
SHAFT, ROCKER 2
TORNILLO
BOLT
4
BE41
3 VALVULA
BE31
FIG.
1
1
1
1
2
2
2
2
2
2
4
4
2
2
2
2
2
2
2
2
2
2
2
2
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–E2170–00
2 93605–06800
3 93306–002YV
4 2GS–E111F–00
5 2GS–E2280–00
6 1PM–E2288–00
7 90105–08196
8 94568–G2096
9 21C–E2231–00
10 2GS–E2241–00
11 4LS–E5598–00
12 90149–06829
13 21C–E2210–02
14 2GS–E2213–00
15 90110–06393
16 21C–E2437–00
17 91312–06016
CAMSHAFT & CHAIN
DESCRIPCION
DESCRIPTION
ARBOL DE LEVAS COMPLETO 1
CAMSHAFT ASSY 1
.PASADOR DE CLAVIJA
.PIN, DOWEL
COJINETE
BEARING
PLACA
PLATE
EQUIPO DE DESCOMPRESION
DECOMPRESSION ASSY
LEVA DE DESCOMPRESION
CAM, DECOMPRESSION
TORNILLO
BOLT, FLANGE
CADENA
CHAIN
TOPE DE GUIA 1
GUIDE, STOPPER 1
TOPE DE GUIA 2
GUIDE, STOPPER 2
COLLAR
COLLAR
TORNILLO DE REGLAJE
SCREW
TENSOR CADENA DE LEVA
TENSIONER ASSY, CAM CHAIN
EMPAQUE DE CAJA TENSOR
GASKET, TENSIONER CASE
TORNILLO ALLEN
BOLT, HEXAGON SOCKET HEAD
TOPE
STOPPER
TORNILLO
BOLT
5
BE41
REF.
Nº
4 ARBOL DE LEVAS & CADENA
BE31
FIG.
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 54B–E3300–00
2 90111–05035
3 90340–12808
4 90430–12227
5 4LS–E3411–00
6 21C–E3440–00
7 21C–E3447–00
8 95022–06020
9 95022–06065
10 21C–E3449–00
OIL PUMP
DESCRIPCION
DESCRIPTION
BOMBA DE ACEITE COMPLETA
OIL PUMP ASSY
TORNILLO
BOLT,HEX. SOCKET BUTTON
TORNILLO, DE DRENAJE
PLUG, STRAIGHT SCREW
JUNTA
GASKET
FILTRO DE ACEITE
STRAINER, OIL
ELEMENTO FILTRO DE ACEITE
ELEMENT ASSY, OIL CLEANER
TAPA DEL ELEMENTO
COVER, OIL ELEMENT
PERNO, DE BRIDA
BOLT, FLANGE
PERNO, DE BRIDA
BOLT, FLANGE
JUNTA DE TAPA DE ELEMENTO
GASKET, ELEMENT COVER
6
BE41
REF.
Nº
5 BOMBA DE ACEITE
BE31
FIG.
1
1
2
2
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
OBSERVACIONES
REMARKS
REF.
Nº
CODIGO Nº
PART NO.
1 2GS–E3585–00
2 91312–06025
3 2GS–E3645–00
4 2GS–E3770–00
5 5CA–E4147–00
6 2GS–E3557–00
7 95812–06030
8 2GS–E3635–00
9 90450–43807
10 90450–48805
11 B77–E3750–00
12 2GS–E4411–00
13 2GS–E4412–00
14 2GS–E4450–00
15 2GS–E4453–00
16 2GS–E4452–00
17 2GS–E4877–00
18 90467–20050
19 20P–E443E–00
20 90467–12800
21 97602–05320
22 2GS–E4437–00
23 90387–06737
24 90387–09806
25 95822–06016
26 2GS–E1166–00
27 90467–13816
INTAKE
DESCRIPCION
DESCRIPTION
MULTIPLE
MANIFOLD
TORNILLO
BOLT
EMPAQUE
GASKET, MANIFOLD 1
INYECTOR
INJECTOR ASSY
.ANILLO O
.O-RING
EMPAQUE
GASKET
TORNILLO DE REBORDE
BOLT, FLANGE
JUNTA DE ADMISION 1
JOINT, INTAKE 1
BRIDA, MANGUERA
HOSE CLAMP ASSY
BRIDA, MANGUERA
HOSE CLAMP ASSY
CAJA DE ACELERADOR COMPL.
THROTTLE BODY ASSY
CAJA FILTRO DEL AIRE 1
CASE, AIR CLEANER 1
TAPA CAJA DEL FILTRO 1
CAP, CLEANER CASE 1
ELEMENTO COMP.FILTRO DE AIRE
ELEMENT ASSY, AIR CLEANER
UNION DEL FILTRO DEL AIRE 1
JOINT, AIR CLEANER 1
SELLO
SEAL
RESONATOR
RESONATOR
PRESILLA
CLIP
TUBO, DRENAJE
PIPE, DRAIN
PRESILLA
CLIP
TORNILLO CON RONDONA
SCREW, PAN HEAD WITH WASHER
CONDUCTO
DUCT
ESPACIADOR
COLLAR
ESPACIADOR
COLLAR
TORNILLO DE REBORDE
BOLT, FLANGE
TUBO RESPIRADERO 1
PIPE, BREATHER 1
PRESILLA
CLIP
7
BE41
6 ADMISION
BE31
FIG.
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6
6
1
1
1
1
2
2
3
3
1
1
1
1
OBSERVACIONES
REMARKS
REF.
Nº
CODIGO Nº
PART NO.
28 90467–15803
INTAKE
DESCRIPCION
DESCRIPTION
PRESILLA
CLIP
8
BE41
6 ADMISION
BE31
FIG.
1
1
OBSERVACIONES
REMARKS
REF.
Nº
CODIGO Nº
PART NO.
1 2GS–E4703–00
2 2GS–E4718–00
3 2GS–E4799–00
4 90480–12812
5 90387–06023
6 90111–06826
7 90111–06807
8 54B–E4757–00
9 21C–E4775–00
10 20P–E4747–00
11 21C–E4613–00
12 95702–08500
13 90201–08612
14 95802–08025
15 95802–08035
16 95812–08040
17 90201–087F0
EXHAUST
DESCRIPCION
DESCRIPTION
SILENCIADOR COMPL. 1
MUFFLER COMP. 1
PROTECTOR DE SILENCIADOR 1
PROTECTOR, MUFFLER 1
TAPA
CAP
TAPON
GROMMET
ESPACIADOR
COLLAR
TORNILLO
BOLT,HEX. SOCKET BUTTON
TORNILLO
BOLT,HEX. SOCKET BUTTON
AMORTIGUADOR SILENCIADOR 2
DAMPER, MUFFLER 2
TUERCA
NUT
AMORTIGUADOR DE SILENCIADOR
DAMPER, MUFFLER
JUNTA, TUBO DE ESCAPE
GASKET, EXHAUST PIPE
TUERCA DE BRIDA
NUT, FLANGE
ARANDELA PLANA
WASHER, PLATE
TORNILLO DE REBORDE
BOLT, FLANGE
TORNILLO DE REBORDE
BOLT, FLANGE
TORNILLO DE REBORDE
BOLT, FLANGE
ARANDELA PLANA
WASHER, PLATE
9
BE41
7 DESCARGA
BE31
FIG.
1
1
1
1
1
1
4
4
4
4
4
4
2
2
1
1
1
1
1
1
1
1
3
3
3
3
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
REF.
Nº
CODIGO Nº
PART NO.
1 54B–E5111–00
2 54B–E5121–01
3 21C–E5155–00
4 91830–21014
5 95802–06010
6 95022–06055
7 95022–06045
8 95022–06070
CRANKCASE
DESCRIPCION
DESCRIPTION
CARTER MANIVELA 1
CRANKCASE 1
CARTER MANIVELA 2
CRANKCASE 2
BOQUILLA 3
NOZZLE 3
PASADOR DE CLAVIJA
PIN, DOWEL
TORNILLO DE REBORDE
BOLT, FLANGE
PERNO, DE BRIDA
BOLT, FLANGE
PERNO, DE BRIDA
BOLT, FLANGE
PERNO, DE BRIDA
BOLT, FLANGE
10
BE41
8 CARTER
BE31
FIG.
1
1
1
1
1
1
2
2
1
1
3
3
4
4
5
5
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 21C–E5441–00
2 91312–06014
3 2GS–E5411–00
4 21C–E5451–10
5 45P–E5353–00
6 91830–21014
7 95022–06040
8 95022–06050
9 90340–14117
10 93210–14899
11 90340–32805
12 93210–32814
13 2GS–E5418–00
14 95802–06020
15 90387–068C9
16 90480–12812
17 21C–E5421–00
18 21C–E5461–10
19 91830–21014
20 95022–06040
21 54B–E5362–00
22 93210–19809
23 93101–10838
24 90338–30802
CRANKCASE COVER 1
DESCRIPCION
DESCRIPTION
SOSTEN DE CABLE DE EMBRAGUE
HOLDER, CLUTCH CABLE
TORNILLO
BOLT
CUBIERTA DE CARTER 1
COVER, CRANKCASE 1
EMPAQ DE CUBIERTA DE CARTER
GASKET, CRANKCASE COVER 1
JUNTA DE DRENAJE
GASKET, DRAIN
PASADOR DE CLAVIJA
PIN, DOWEL
PERNO, DE BRIDA
BOLT, FLANGE
PERNO, DE BRIDA
BOLT, FLANGE
TORNILLO, DE DRENAJE
PLUG, STRAIGHT SCREW
ANILLO O
O-RING
TORNILLO, DE DRENAJE
PLUG, STRAIGHT SCREW
ANILLO O
O-RING
CUBIERTA CAJA DE CADENA
COVER, CHAIN CASE
TORNILLO DE REBORDE
BOLT, FLANGE
ESPACIADOR
COLLAR
TAPON
GROMMET
TAPA DE CARTER DERECHA
COVER, CRANKCASE 2
JUNTA TAPA CARTER DERECHO 2
GASKET, CRANKCASE COVER 2
PASADOR DE CLAVIJA
PIN, DOWEL
PERNO, DE BRIDA
BOLT, FLANGE
TAPON DEL NIVEL DE ACEITE
PLUG, OIL LEVEL
ANILLO O
O-RING
SELLO ACEITE
OIL SEAL
TAPON
PLUG
11
BE41
REF.
Nº
9 CUBIERTA DE CARTER 1
BE31
FIG.
1
1
2
2
1
1
1
1
1
1
2
2
6
6
2
2
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
1
1
1
1
2
2
11 11
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 1PM–E5514–00
2 21C–E5521–00
3 90201–105E8
4 99009–10400
5 1PM–E5524–10
6 93310–325X3
7 90201–25290
8 2GS–E5580–00
9 91312–06020
DESCRIPCION
DESCRIPTION
ENGRANAJE 2
GEAR 2
EJE 1
SHAFT 1
ARANDELA PLANA
WASHER, PLATE
PRESILLA REDONDA
CIRCLIP
RUEDA DE ARRANQUE
WHEEL, STARTER
COJINETE DE RODILLOS
BEARING
ARANDELA PLANA
WASHER, PLATE
ENSAMBLE EXT.EMBRAGUE ARRANQUE
STARTER CLUTCH OUTER ASSY
TORNILLO
BOLT
12
BE41
REF.
Nº
STARTER CLUTCH
BE31
FIG. 10 EMBRAGUE DEL ARRANQUE
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
3
3
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 54B–E6111–10
2 54B–E7258–00
3 21C–E6193–00
4 90201–12019
5 90179–12802
6 2GS–E6150–00
7 21C–E6154–00
8 21C–E6371–00
9 54B–E6321–00
10 21C–E6331–00
11 21C–E6324–00
12 54B–E6351–00
13 21C–E6333–00
14 21C–E6337–00
15 21C–E6358–00
16 21C–E6356–01
17 54B–E6144–00
18 3C1–E6344–00
19 21C–E6135–10
20 90179–14001
21 90208–20003
22 21C–E6380–02
23 1PM–E6345–00
24 54B–E6357–00
25 93505–16844
26 93315–112Y9
27 93102–12877
DESCRIPCION
DESCRIPTION
ENGRANAJE TRACC.PRIMARIA
GEAR, PRIMARY DRIVE
COLLAR 1
COLLAR 1
CHAVETA DE AGUJA
KEY, FEATHER
ARANDELA PLANA
WASHER, PLATE
TUERCA
NUT
CAMPANA DE EMBRAGUE
PRIMARY DRIVEN GEAR COMP.
ARANDELA, DE EMPUJE 1
PLATE, THRUST 1
CUBO, DE EMBRAGUE
BOSS, CLUTCH
PLACA DE FRICCION
PLATE, FRICTION
DISCO, DE FRICCION 2
PLATE, FRICTION 2
PLACA DE EMBRAGUE
PLATE, CLUTCH 1
PLATO DE PRESION
PLATE, PRESSURE 1
RESORTE DE EMBRAGUE 1
SPRING, CLUTCH 1
TORNILLO DE RESORTE
SCREW, SPRING
PLACA DE EMPUJE
PLATE, PUSH
VARILLA DE EMPUJE 1
ROD, PUSH 1
ARANDELA
WASHER
TUERCA DE AJUSTE
NUT, ADJUSTING
ARANDELA DE CIERRE
WASHER, LOCK
TUERCA
NUT
ARANDELA DE RESORTE CONICO
WASHER, CONICAL SPRING
LEVA DE EMPUJE COMPLETA
PUSH LEVER ASSY
RESORTE DE RETORNO
SPRING, RETURN
VARILLA DE EMPUJE 2
ROD, PUSH 2
BALL
BALL
COJINETE DE RODILLOS
BEARING
SELLO ACEITE
OIL SEAL
13
BE41
REF.
Nº
CLUTCH
BE31
FIG. 11 EMBRAGUE
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
3
3
1
1
4
4
4
4
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
28 99009–20500
DESCRIPCION
DESCRIPTION
PRESILLA REDONDA
CIRCLIP
14
BE41
REF.
Nº
CLUTCH
BE31
FIG. 11 EMBRAGUE
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 21C–E7411–50
2 90209–17285
3 93410–20809
4 B77–E7131–00
5 21C–E7121–10
6 B77–E7141–00
7 B77–E7151–00
8 93306–054YE
93306–054Y6
9 93306–201Y4
10 21C–E7471–00
11 98502–06012
12 21C–E7402–50
13 21C–E7221–21
14 90201–22793
15 93410–22039
16 21C–E7231–31
17 90209–18208
18 90201–178D3
19 21C–E7258–00
20 21C–E7211–20
21 B77–E7241–00
22 B77–E7251–00
23 93306–203XR
24 93306–272X4
93306–272X1
25 93102–22818
DESCRIPCION
DESCRIPTION
EJE PRIMARIO
AXLE, MAIN
ARANDELA DE SEPARACION
WASHER
SEGURO
CIRCLIP
ENGRANAJE PINON DE 3RA (22T)
GEAR, 3RD PINION (22T)
ENGRANAJE PINON DE 2DA (19T)
GEAR, 2ND PINION (19T)
ENGRANAJE PINON DE 4TA (22T)
GEAR, 4TH PINION (22T)
ENGRANAJE PINON DE 5TA (24T)
GEAR, 5TH PINION (24T)
COJINETE
BEARING
COJINETE
BEARING
COJINETE
BEARING
PLACA, DE CUBIERTA
PLATE, COVER
TORNILLO
SCREW, PAN HEAD
EJE DE TRACCION COMPLETO
DRIVE AXLE ASSY
ENGRANAJE RUEDA DE 2DA (34T)
GEAR, 2ND WHEEL (34T)
ARANDELA PLANA
WASHER, PLATE
SEGURO
CIRCLIP
ENGRANAJE RUEDA DE 3RA (29T)
GEAR, 3RD WHEEL (29T)
ARANDELA DE SEPARACION
WASHER
ARANDELA PLANA
WASHER, PLATE
COLLAR 1
COLLAR 1
ENGRANAJE RUEDA DE 1 RA (38T)
GEAR, 1ST WHEEL (38T)
ENGRANAJE DE RUEDA 4TA (23T)
GEAR, 4TH WHEEL (23T)
ENGRANAJE RUEDA DE 5TA (21T)
GEAR, 5TH WHEEL (21T)
COJINETE
BEARING
COJINETE
BEARING
COJINETE
BEARING
SELLO ACEITE
OIL SEAL
15
BE41
REF.
Nº
TRANSMISSION
BE31
FIG. 12 TRANSMISION
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
2
2
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
UR
UR
UR
UR
UR
UR
UR
UR
CODIGO Nº
PART NO.
26 93822–14800
27 4LS–E7456–00
28 95022–06010
29 21C–E5666–00
30 90201–178D3
31 99009–17400
DESCRIPCION
DESCRIPTION
CORONA (14T)
SPROCKET, DRIVE (14T)
SOPORTE DE CORONA
HOLDER, SPROCKET
PERNO, DE BRIDA
BOLT, FLANGE
SEPARADOR
SPACER
ARANDELA PLANA
WASHER, PLATE
PRESILLA REDONDA
CIRCLIP
16
BE41
REF.
Nº
TRANSMISSION
BE31
FIG. 12 TRANSMISION
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–E8540–00
2 21C–E8511–00
3 21C–E8512–00
4 21C–E8513–00
5 21C–E8531–00
6 21C–E8535–00
7 90501–06800
DESCRIPCION
DESCRIPTION
LEVA DEL CAMBIO COMPLETA
SHIFT CAM ASSY
HORQUILLA DEL CAMBIO 1
FORK, SHIFT 1
HORQUILLA DEL CAMBIO 2
FORK, SHIFT 2
HORQUILLA DEL CAMBIO 3
FORK, SHIFT 3
BARRA GUIA HORQ. CAMBIO 1
BAR, SHIFT FORK GUIDE 1
BARRA GUIA HORQ .CAMBIO 2
BAR, SHIFT FORK GUIDE 2
RESORTE DE COMPRESION
SPRING, COMPRESSION
17
BE41
REF.
Nº
BE31
FIG. 13 LEVA DE CAMBIO & HORQUILLA SHIFT CAM & FORK
1
1
1
1
1
1
1
1
1
1
1
1
4
4
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 21C–E8140–00
2 90109–06259
3 21C–E8337–00
4 21C–E8101–01
5 90508–32805
6 99001–10600
7 93608–43238
8 93102–12875
9 21C–E8110–10
10 20P–E8113–00
11 91401–20012
12 92902–06200
13 90201–06871
14 97012–06020
DESCRIPCION
DESCRIPTION
PALANCA DE TOPE COMPLETA
STOPPER LEVER ASSY
PERNO
BOLT
RESORTE
SPRING
EJE SELECTOR COMPLETO
SHIFT SHAFT ASSY
.RESORTE DE TORSION
.SPRING, TORSION
.PRESILLA REDONDA
.CIRCLIP
PASADOR DE CLAVIJA
PIN, DOWEL
SELLO ACEITE
OIL SEAL
PEDAL DE CAMBIO COMPLETO
SHIFT PEDAL ASSY
.FUNDA DEL PEDAL DEL CAMBIO
.COVER, SHIFT PEDAL
.CHAVETA
.PIN, COTTER
.ARANDELA
.WASHER
.ARANDELA PLANA
.WASHER, PLATE
PERNO
BOLT
18
BE41
REF.
Nº
SHIFT SHAFT
BE31
FIG. 14 EJE DE CAMBIO & PEDAL
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 B77–F1110–00
2 2GS–F1316–00
3 95812–10080
4 90179–10811
5 2GS–F1317–00
6 90105–08002
7 95812–08016
8 90179–08674
9 95817–10130
10 90105–10861
11 20P–E4747–00
12 90387–08822
13 21C–F1638–02
14 2GS–F1279–00
15 1PM–F4741–00
16 21C–F1717–00
DESCRIPCION
DESCRIPTION
ARMAZON COMPLETO
FRAME COMP.
SOPORTE DE MOTOR 2
STAY, ENGINE 2
TORNILLO DE REBORDE
BOLT, FLANGE
TUERCA
NUT
SOPORTE DE MOTOR 3
STAY, ENGINE 3
TORNILLO
BOLT, FLANGE
TORNILLO DE REBORDE
BOLT, FLANGE
TUERCA
NUT
TORNILLO
BOLT, FLANGE
TORNILLO
BOLT, FLANGE
AMORTIGUADOR DE SILENCIADOR
DAMPER, MUFFLER
ESPACIADOR
COLLAR
AMORTIGUADOR 1
DAMPER 1
TAPON CIEGO
PLUG, BLIND
COJIN DE ASIENTO
PAD, SEAT
AMORTIGUADOR
DAMPER
19
BE41
REF.
Nº
FRAME
BE31
FIG. 15 CUADRO
1
1
1
1
4
4
6
6
1
1
1
1
2
2
1
1
1
1
1
1
2
2
2
2
1
1
2
2
1
1
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 21C–F1511–00–33
21C–F1511–00–P2
21C–F1511–00–P3
21C–F1511–00–P4
2 90387–068C5
3 90480–08801
4 95802–06020
5 90111–06117
6 2GS–F1611–00
7 97012–06014
8 90387–06048
9 95822–06016
10 90387–08079
11 4UU–F811G–00
12 2GS–F1613–00
13 2GS–F1614–00
14 2GS–F1651–00
15 2GS–F163A–00
16 90149–06829
17 90183–06800
18 97012–06014
19 90387–06048
20 B98–F1641–00
21 95022–06016
22 95607–06100
23 90201–06078
24 21C–F8100–20
DESCRIPCION
DESCRIPTION
GUARDABARRO DELANTERO
FENDER, FRONT
GUARDABARRO DELANTERO
FENDER, FRONT
GUARDABARRO DELANTERO
FENDER, FRONT
GUARDABARRO DELANTERO
FENDER, FRONT
ESPACIADOR
COLLAR
TAPON
GROMMET
TORNILLO DE REBORDE
BOLT, FLANGE
TORNILLO
BOLT,HEX. SOCKET BUTTON
GUARDABARRO TRASERO
FENDER, REAR
PERNO
BOLT
ESPACIADOR
COLLAR
TORNILLO DE REBORDE
BOLT, FLANGE
ESPACIADOR
COLLAR
CINTA
BAND
SOPORTE DE GUARDABARRO
STAY, FENDER 1
SOPORTE DE GUARDABARRO 2
STAY, FENDER 2
TAPA DE GUARDABARRO TRAS.
COVER, REAR FENDER
CUBIERTA TRAS GUARDABARRO 1
COVER, REAR FENDER 1
TORNILLO DE REGLAJE
SCREW
TUERCA DE RESORTE
NUT, SPRING
PERNO
BOLT
ESPACIADOR
COLLAR
SOPORTE DE REFLECTOR
BRACKET, REFLECTOR
PERNO, DE BRIDA
BOLT, FLANGE
TUERCA AUTOBLOCANTE
NUT, U
ARANDELA PLANA
WASHER, PLATE
JUEGO DE HERRAMIENTAS
TOOL KIT
20
BE41
REF.
Nº
FENDER
BE31
FIG. 16 GUARDABARRO
1
1
1
1
1
4
4
4
4
2
2
2
2
1
1
2
2
2
2
4
4
4
4
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
1
1
2
2
2
2
2
2
1
1
OBSERVACIONES
REMARKS
YB(YB)
YB(YB)
VRC1(VRC1,BWC1)
VRC1(VRC1,BWC1)
CM6(YB)
CM6(YB)
YRC2(MBL2)
YRC2(MBL2)
CODIGO Nº
PART NO.
1 2GS–F1711–00
2 2GS–F172A–00–P0
2GS–WF17G–10–P1
2GS–WF17G–20–P1
2GS–WF17G–30–P1
3 2GS–F173E–10
2GS–F173E–20
2GS–F173E–30
4 90183–05807
5 97702–50012
6 2GS–F1721–00
7 2GS–F172F–00–P0
2GS–WF17H–10–P1
2GS–WF17H–20–P1
2GS–WF17H–30–P1
8 2GS–F173F–10
2GS–F173F–20
2GS–F173F–30
9 90183–05807
10 97702–50012
11 21C–F1717–00
12 2GS–F1731–00–33
2GS–F1731–00–P0
2GS–F1731–00–P1
2GS–F1731–00–P2
13 2GS–F1741–00–33
2GS–F1741–00–P0
DESCRIPCION
DESCRIPTION
CUBIERTA LATERAL 1
COVER, SIDE 1
PANEL 1
PANEL 1
PANEL 1
PANEL 1
PANEL 1
PANEL 1
PANEL 1
PANEL 1
.GRAFICO, 1
.GRAPHIC 1
.GRAFICO, 1
.GRAPHIC 1
.GRAFICO, 1
.GRAPHIC 1
TUERCA DE RESORTE
NUT, SPRING
TORNILLO ROSCA HEMBRA
SCREW, TAPPING
CUBIERTA LATERAL 2
COVER, SIDE 2
PANEL 2
PANEL 2
PANEL 2
PANEL 2
PANEL 2
PANEL 2
PANEL 2
PANEL 2
.GRAFICO 2
.GRAPHIC 2
.GRAFICO 2
.GRAPHIC 2
.GRAFICO 2
.GRAPHIC 2
TUERCA DE RESORTE
NUT, SPRING
TORNILLO ROSCA HEMBRA
SCREW, TAPPING
AMORTIGUADOR
DAMPER
TAPA LATERAL 3
COVER, SIDE 3
TAPA LATERAL 3
COVER, SIDE 3
TAPA LATERAL 3
COVER, SIDE 3
TAPA LATERAL 3
COVER, SIDE 3
TAPA LATERAL 4
COVER, SIDE 4
TAPA LATERAL 4
COVER, SIDE 4
21
BE41
REF.
Nº
SIDE COVER
BE31
FIG. 17 CUBIERTA LATERAL
1
1
1
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
S8 PARA YB,VRC1
S8 FOR YB,VRC1
UR MBL2 PARA BWC1
UR MBL2 FOR BWC1
UR MBL2 PARA YB
UR MBL2 FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR
UR FOR MBL2
S8 PARA YB,VRC1
S8 FOR YB,VRC1
UR MBL2 PARA BWC1
UR MBL2 FOR BWC1
UR MBL2 PARA YB
UR MBL2 FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
YB(YB)
YB(YB)
VRC1(VRC1,BWC1)
VRC1(VRC1,BWC1)
CM6(YB)
CM6(YB)
YRC2(MBL2)
YRC2(MBL2)
YB(YB)
YB(YB)
VRC1(VRC1,BWC1)
VRC1(VRC1,BWC1)
CODIGO Nº
PART NO.
13 2GS–F1741–00–P1
2GS–F1741–00–P2
14 90183–05807
15 97702–50012
16 90269–06814
17 2GS–XF17C–00–33
2GS–XF17C–00–P0
2GS–XF17C–00–P2
2GS–XF17C–00–P3
18 5TS–F836B–02
19 90269–06814
20 90119–06137
21 98502–06014
22 90201–06055
23 90480–01558
24 2GS–F171L–00
25 2GS–F171M–00
26 90183–05067
27 2GS–F1732–00
28 2GS–F1735–00
DESCRIPCION
DESCRIPTION
TAPA LATERAL 4
COVER, SIDE 4
TAPA LATERAL 4
COVER, SIDE 4
TUERCA DE RESORTE
NUT, SPRING
TORNILLO ROSCA HEMBRA
SCREW, TAPPING
REMACHE
RIVET
CUBIERTA LATERAL 5
COVER, SIDE 5
CUBIERTA LATERAL 5
COVER, SIDE 5
CUBIERTA LATERAL 5
COVER, SIDE 5
CUBIERTA LATERAL 5
COVER, SIDE 5
.MARCA
.TUNING FORK MARK
REMACHE
RIVET
TORNILLO CON ARANDELA
BOLT, WITH WASHER
TORNILLO
SCREW, PAN HEAD
ARANDELA PLANA
WASHER, PLATE
TAPON
GROMMET
MUELLE , CUBIERTA LATERAL 1
MOLE, SIDE COVER 1
MUELLE, CUBIERTA LATERAL 2
MOLE, SIDE COVER 2
TUERCA DE RESORTE
NUT, SPRING
SELLO 1
SEAL 1
SELLO 2
SEAL 2
22
BE41
REF.
Nº
SIDE COVER
BE31
FIG. 17 CUBIERTA LATERAL
1
1
2
2
2
2
2
2
1
1
1
1
1
1
1
2
2
4
4
2
2
2
2
2
2
1
1
1
1
2
2
1
1
1
1
OBSERVACIONES
REMARKS
CM6(YB)
CM6(YB)
YRC2(MBL2)
YRC2(MBL2)
YB(YB)
YB(YB)
VRC1(VRC1,BWC1)
VRC1(VRC1,BWC1)
CM6(YB)
CM6(YB)
YRC2(MBL2)
YRC2(MBL2)
CODIGO Nº
PART NO.
1 2GS–WF211–00
2 90387–12863
3 93317–318Y5
4 2GS–F2141–00
5 20P–F2129–00
6 95607–12200
7 90201–12028
8 2GS–F2151–00
9 90387–066J9
10 90201–060A3
11 95027–06016
12 2GS–F1650–00
13 2GS–F1644–00
14 2GS–F1645–00
15 2GS–F164F–00
16 90387–068N2
17 95027–06016
18 90183–06800
19 90119–06060
20 21C–F2147–00
21 90387–068S1
22 95027–06016
23 54C–F1668–00
24 2GS–F2210–00
25 90387–12845
26 90105–12057
27 90105–12804
DESCRIPCION
DESCRIPTION
BRAZO TRASERO COMPLETO
REAR ARM COMP.
.ESPACIADOR
.COLLAR
.COJINETE
.BEARING
EJE DEL BARCULANTE
SHAFT, PIVOT
TAPA DE EMPUJE 2
COVER, THRUST 2
TUERCA DE AUTO-CIERRE
NUT, SELF-LOCKING
ARANDELA PLANA
WASHER, PLATE
SELLO DE GUARDA
SEAL, GUARD
ESPACIADOR
COLLAR
ARANDELA PLANA
WASHER, PLATE
PERNO, DE BRIDA
BOLT, FLANGE
GUARDABARRO TRANSERO COMP.
REAR FENDER COMP.
APOYO TRASERO
STAY, REAR
ASIDERO SILLIN
STAY, REAR
APOYO 1
STAY 1
ESPACIADOR
COLLAR
PERNO, DE BRIDA
BOLT, FLANGE
TUERCA DE RESORTE
NUT, SPRING
TORNILLO CON ARANDELA
BOLT, WITH WASHER
PROTECTOR DE CADENA
PROTECTOR, CHAIN
ESPACIADOR
COLLAR
PERNO, DE BRIDA
BOLT, FLANGE
ETIQUETA DE FRANJA
LABEL, TIRE
AMORTIGUADOR TRASERO COMPLETO
SHOCK ABSORBER ASSY, REAR
ESPACIADOR
COLLAR
TORNILLO
BOLT, FLANGE
TORNILLO
BOLT, FLANGE
23
BE41
REF.
Nº
BE31
FIG. 18 BRAZO TRASERO & SUSPENSION REAR ARM & SUSPENSION
1
1
1
1
2
2
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
8
8
8
8
2
2
2
2
1
1
2
2
2
2
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
28 95612–12100
29 90201–122H1
DESCRIPCION
DESCRIPTION
TUERCA U
NUT, U
ARANDELA PLANA
WASHER, PLATE
24
BE41
REF.
Nº
BE31
FIG. 18 BRAZO TRASERO & SUSPENSION REAR ARM & SUSPENSION
2
2
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 21C–F3412–00
2 21C–F3413–00
3 21C–F3414–00
4 4LS–F341E–10
5 4LS–F341E–00
6 5YY–F3416–00
7 90179–25615
8 20P–F3418–00
9 90202–26142
10 21C–F3435–00
11 95022–08040
12 90201–22018
13 90176–22081
14 21C–F3441–00
15 95022–08035
16 2GS–F317E–00
17 2GS–F317F–00
18 21C–F317J–00
19 95822–06016
20 90387–07819
21 95812–06012
DESCRIPCION
DESCRIPTION
PISTA DE BOLAS 2
RACE, BALL 2
BASE DE BOLA 3
RACE, BALL 3
BASE DE BOLA 4
RACE, BALL 4
RETEN DE COJINETE
RETAINER, BALL BEARING
RETEN DE COJINETE
RETAINER, BALL BEARING
CUBIERTA DE BASE DE BOLA 2
COVER, BALL RACE 2
TUERCA
NUT
ARANDELA ESPECIAL
WASHER, SPECIAL
ARANDELA DE PLANA
WASHER, PLATE
PLATINA SUPERIOR
CROWN, HANDLE
PERNO, DE BRIDA
BOLT, FLANGE
ARANDELA PLANA
WASHER, PLATE
TUERCA CORONA
NUT, CROWN
SOPORTE DE MANUBRIO
HOLDER, HANDLE UPPER
PERNO, DE BRIDA
BOLT, FLANGE
SOPORTE 1
STAY 1
SOPORTE 2
STAY 2
AMORTIGUADOR 1
DAMPER 1
TORNILLO DE REBORDE
BOLT, FLANGE
ESPACIADOR
COLLAR
TORNILLO DE REBORDE
BOLT, FLANGE
25
BE41
REF.
Nº
STEERING
BE31
FIG. 19 DIRECCION
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
2
2
1
1
1
1
2
2
4
4
1
1
1
1
2
2
2
2
4
4
3
3
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–F3100–00
2 2GS–F3102–00
3 21C–F3126–11
4 21C–F3114–00
5 21C–F3111–00
6 21C–F3118–00
7 21C–F3149–00
8 21C–F3141–00
9 21C–F3181–00
10 21C–F3158–00
11 21C–F3173–00
12 2GS–F3144–00
13 21C–F3156–00
14 2GS–F3145–00
15 21C–F3146–00
16 4FM–23125–40
17 2GS–F3170–00
18 21C–F3110–00
19 2GS–F3171–00
20 2GS–F3103–00
21 21C–F3136–11
22 21C–F3114–00
23 21C–F3111–00
24 21C–F3118–00
25 21C–F3149–00
26 21C–F3141–00
27 21C–F3181–00
DESCRIPCION
DESCRIPTION
HORQUILLA DELANTERA COMPLETA
FRONT FORK ASSY
.HORQUILLA DELANTERA COMPL.(MI)
.FRONT FORK ASSY (L.H)
..TUBO EXTERIOR (IZQUIERDO)
..TUBE, OUTER (L.H)
..EMPAQUE
..GASKET
..PERNO DE TAPA
..BOLT, CAP
..SEPARADOR
..SPACER
..ARANDELA DE RESORTE SUPERIOR
..WASHER, SPRING UPPER
..RESORTE HORQUILLA DELANT.
..SPRING, FRONT FORK
..TORNILLO CABEZAHEXAGONAL
..BOLT, HEXAGON SOCKET HEAD
..EMPAQUE
..GASKET
..VASTAGO AHUSADO
..SPINDLE, TAPER
..GUARDAPOLVO
..SEAL, DUST
..ANILLO DE ENGANCHE
..RING, SNAP
..RETEN DE ACEITE
..OIL SEAL
..ARANDELA DE SELLO DE ACEITE
..WASHER, OIL SEAL
..METAL CORREDIZO 1
..METAL, SLIDE 1
..CILINDRO COMPL DE HORQ DELANT
..CYLINDER COMP., FRONT FORK
..TUBO INTERIOR COMPLETO 1
..INNER TUBE COMP.1
..PISTON HORQUILLA DELANT.
..BUSH, INNER TUBE
.HORQUILLA DELANTERA COMPL.(MD)
.FRONT FORK ASSY (R.H)
..TUBO EXTERIOR 2
..TUBE, OUTER
..EMPAQUE
..GASKET
..PERNO DE TAPA
..BOLT, CAP
..SEPARADOR
..SPACER
..ARANDELA DE RESORTE SUPERIOR
..WASHER, SPRING UPPER
..RESORTE HORQUILLA DELANT.
..SPRING, FRONT FORK
..TORNILLO CABEZAHEXAGONAL
..BOLT, HEXAGON SOCKET HEAD
26
BE41
REF.
Nº
FRONT FORK
BE31
FIG. 20 HORQUILLA DELANTERA
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
28 21C–F3158–00
29 21C–F3173–00
30 2GS–F3144–00
31 21C–F3156–00
32 2GS–F3145–00
33 21C–F3146–00
34 4FM–23125–40
35 2GS–F3170–00
36 21C–F3110–00
37 2GS–F3171–00
38 21C–F3340–02
39 5YY–F3462–00
40 21C–F3411–00
41 21C–F3346–00
DESCRIPCION
DESCRIPTION
..EMPAQUE
..GASKET
..VASTAGO AHUSADO
..SPINDLE, TAPER
..GUARDAPOLVO
..SEAL, DUST
..ANILLO DE ENGANCHE
..RING, SNAP
..RETEN DE ACEITE
..OIL SEAL
..ARANDELA DE SELLO DE ACEITE
..WASHER, OIL SEAL
..METAL CORREDIZO 1
..METAL, SLIDE 1
..CILINDRO COMPL DE HORQ DELANT
..CYLINDER COMP., FRONT FORK
..TUBO INTERIOR COMPLETO 1
..INNER TUBE COMP.1
..PISTON HORQUILLA DELANT.
..BUSH, INNER TUBE
.PLATINA INFERIOR COMPLETA
.UNDER BRACKET COMP.
..SELLO PARA POLVO
..SEAL, DUST
..PISTA DE BOLAS 1
..RACE, BALL 1
.PERNO 1
.BOLT 1
27
BE41
REF.
Nº
FRONT FORK
BE31
FIG. 20 HORQUILLA DELANTERA
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 B77–F4110–00
2 21C–F4181–00
3 90480–15363
4 21C–F4183–00
5 90464–80802
6 90387–068B2
7 90387–107H6
8 2GS–F4191–00
9 90201–060A3
10 90201–06380
11 97012–06014
12 90105–06169
13 95822–06030
14 21C–F4188–10
15 2GS–XF17D–00–33
2GS–XF17D–00–P0
2GS–XF17D–00–P2
2GS–XF17D–00–P3
16 2GS–F4549–00
17 2GS–F414A–00
18 90445–14808
19 21C–F4614–00–P0
20 90159–05065
21 90179–05804
22 21C–WF461–11
23 2GS–E3971–00
24 90464–16006
DESCRIPCION
DESCRIPTION
DEPOSITO DE COMBUSTIBLE COMP.
FUEL TANK COMP.
AMORTIGUADOR DE MONTAJE 1
DAMPER, LOCATING 1
TAPON
GROMMET
AMORTIGUADOR DE MONTAJE 3
DAMPER, LOCATING 3
BRIDA
CLAMP
ESPACIADOR
COLLAR
ESPACIADOR
COLLAR
SOPORTE DEPOSITO DE COMBUST.1
BRACKET, FUEL TANK 1
ARANDELA PLANA
WASHER, PLATE
ARANDELA PLANA
WASHER PLAIN
PERNO
BOLT
TORNILLO
BOLT, FLANGE
TORNILLO DE REBORDE
BOLT, FLANGE
MOLDURA DEPOSITO COMBUST.
MOLD, FUEL TANK
CUBIERTA, TECHO
COVER, TOP
CUBIERTA, TECHO
COVER, TOP
CUBIERTA, TECHO
COVER, TOP
CUBIERTA, TECHO
COVER, TOP
.EMBLEMA
.EMBLEM
CUBIERTA DE LLENADOR
COVER, FILLER
TUBO
HOSE
PLACA DE TAPA
PLATE, CAP
TORNILLO CON VALONA
SCREW, WITH WASHER
TUERCA
NUT
TAPA DE DEPOSITO COMPLETO
CAP ASSY WITH LOCK
ANILLO DE ESPACIADOR
PIPE, FUEL 1
BRIDA
CLAMP
28
BE41
REF.
Nº
FUEL TANK
BE31
FIG. 21 DEPOSITO DE COMBUSTIBLE
1
1
2
2
2
2
1
1
1
1
2
2
2
2
1
1
2
2
2
2
2
2
2
2
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
3
3
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
YB(YB)
YB(YB)
VRC1(VRC1,BWC1)
VRC1(VRC1,BWC1)
CM6(YB)
CM6(YB)
YRC2(MBL2)
YRC2(MBL2)
S8
S8
CODIGO Nº
PART NO.
25 2GS–F4364–00
26 97702–50012
27 2GS–E3907–00
28 2GS–F4491–00
29 2GS–F414G–00
30 91312–05010
DESCRIPCION
DESCRIPTION
SOPORTE
STAY
TORNILLO ROSCA HEMBRA
SCREW, TAPPING
BOMBA DE COMBUSTIBLE COMPLETA
FUEL PUMP COMP.
SOPORTE BOMBA COMBUSTIBLE
BRACKET, FUEL PUMP
SELLO
SEAL
TORNILLO
BOLT
29
BE41
REF.
Nº
FUEL TANK
BE31
FIG. 21 DEPOSITO DE COMBUSTIBLE
1
1
1
1
1
1
1
1
1
1
4
4
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–XF412–00–33
2GS–XF412–10–P0
2GS–XF412–30–P1
2GS–XF412–40–33
2GS–XF412–50–P2
2 2GS–F4245–00
2GS–F4245–10
2GS–F4245–30
2GS–F4245–40
2GS–F4245–50
3 2GS–F4257–20
2GS–F4257–30
2GS–F4257–10
4 2GS–XF413–00–33
2GS–XF413–10–P0
2GS–XF413–30–P1
2GS–XF413–40–33
2GS–XF413–50–P2
5 2GS–F4246–00
2GS–F4246–10
2GS–F4246–30
2GS–F4246–40
2GS–F4246–50
6 2GS–F4258–20
2GS–F4258–30
2GS–F4258–10
7 90480–13398
DESCRIPCION
DESCRIPTION
CUBIERTA LATERAL 1
TANK SIDE COVER 1
CUBIERTA LATERAL 1
TANK SIDE COVER 1
CUBIERTA LATERAL 1
TANK SIDE COVER 1
CUBIERTA LATERAL 1
TANK SIDE COVER 1
CUBIERTA LATERAL 1
TANK SIDE COVER 1
.CALCOMANIA DEPOSITO COMBUST.2
.GRAPHIC, FUEL TANK 2
.CALCOMANIA DEPOSITO COMBUST.2
.GRAPHIC, FUEL TANK 2
.CALCOMANIA DEPOSITO COMBUST.2
.GRAPHIC, FUEL TANK 2
.CALCOMANIA DEPOSITO COMBUST.2
.GRAPHIC, FUEL TANK 2
.CALCOMANIA DEPOSITO COMBUST.2
.GRAPHIC, FUEL TANK 2
.CALCOMANIA DEP. COMBUSTIBLE10
.GRAPHIC, FUEL TANK 10
.CALCOMANIA DEP. COMBUSTIBLE10
.GRAPHIC, FUEL TANK 10
.CALCOMANIA DEP. COMBUSTIBLE10
.GRAPHIC, FUEL TANK 10
CUBIERTA LATERAL 2
TANK SIDE COVER 2
CUBIERTA LATERAL 2
TANK SIDE COVER 2
CUBIERTA LATERAL 2
TANK SIDE COVER 2
CUBIERTA LATERAL 2
TANK SIDE COVER 2
CUBIERTA LATERAL 2
TANK SIDE COVER 2
.CALCOMANIA 3
.GRAPHIC 3
.CALCOMANIA 3
.GRAPHIC 3
.CALCOMANIA 3
.GRAPHIC 3
.CALCOMANIA 3
.GRAPHIC 3
.CALCOMANIA 3
.GRAPHIC 3
.CALCOMANIA DEP. COMBUSTIBLE11
.GRAPHIC, FUEL TANK 11
.CALCOMANIA DEP. COMBUSTIBLE11
.GRAPHIC, FUEL TANK 11
.CALCOMANIA DEP. COMBUSTIBLE11
.GRAPHIC, FUEL TANK 11
TAPON
GROMMET
30
BE41
REF.
Nº
FUEL TANK 2
BE31
FIG. 22 DEPOSITO DE COMBUSTIBLE 2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
OBSERVACIONES
REMARKS
UR PARA YB
UR FOR YB
UR PARA VRC1
UR FOR VRC1
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA YB
UR FOR YB
UR PARA VRC1
UR FOR VRC1
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA VRC1
UR FOR VRC1
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA YB
UR FOR YB
UR PARA VRC1
UR FOR VRC1
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA BWC1
UR FOR BWC1
CODIGO Nº
PART NO.
8 90480–01559
9 90160–05812
10 90202–05180
11 90183–05807
12 45S–F411G–00
13 45S–F411H–00
14 90480–14828
15 95802–06012
16 2GS–F4124–00
17 90387–06048
18 95827–06012
19 2GS–XF13F–00–33
2GS–XF13F–00–P0
2GS–XF13F–00–P1
2GS–XF13F–00–P2
20 5YY–F413B–00
21 2GS–XF13J–00–33
2GS–XF13J–00–P0
2GS–XF13J–00–P1
2GS–XF13J–00–P2
22 5YY–F413B–00
23 97702–50012
24 90183–05807
DESCRIPCION
DESCRIPTION
TAPON
GROMMET
TORNILLO REDONDO ROSCA HEMBRA
SCREW, ROUND TAPPING
ARANDELA DE PLANA
WASHER, PLATE
TUERCA DE RESORTE
NUT, SPRING
CUBIERTA COMPL. 1, GUIA DE AIR
HOOK, SIDE COVER 1
CUBIERTA COMPL. 2, GUIA DE AIR
HOOK, SIDE COVER 2
TAPON
GROMMET
TORNILLO DE REBORDE
BOLT, FLANGE
ARO RESF DE AIRE
AIR SHROUD
ESPACIADOR
COLLAR
TORNILLO
BOLT, FLANGE
GUIA DE AIRE 1
GUIDE, AIR 1
GUIA DE AIRE 1
GUIDE, AIR 1
GUIA DE AIRE 1
GUIDE, AIR 1
GUIA DE AIRE 1
GUIDE, AIR 1
.EMBLEMA
.EMBLEM
GUIA DE AIRE 2
GUIDE, AIR 2
GUIA DE AIRE 2
GUIDE, AIR 2
GUIA DE AIRE 2
GUIDE, AIR 2
GUIA DE AIRE 2
GUIDE, AIR 2
.EMBLEMA
.EMBLEM
TORNILLO ROSCA HEMBRA
SCREW, TAPPING
TUERCA DE RESORTE
NUT, SPRING
31
BE41
REF.
Nº
FUEL TANK 2
BE31
FIG. 22 DEPOSITO DE COMBUSTIBLE 2
2
2
8
8
8
8
8
8
1
1
1
1
2
2
2
2
1
1
2
2
2
2
1
1
1
1
1
1
YB(YB)
YB(YB)
VRC1(VRC1,BWC1)
VRC1(VRC1,BWC1)
CM6(YB)
CM6(YB)
YRC2(MBL2)
YRC2(MBL2)
1
1
1
OBSERVACIONES
REMARKS
1
1
1
1
1
6
6
6
6
YB(YB)
YB(YB)
VRC1(VRC1,BWC1)
VRC1(VRC1,BWC1)
CM6(YB)
CM6(YB)
YRC2(MBL2)
YRC2(MBL2)
CODIGO Nº
PART NO.
1 2GS–F4710–00
2 1PM–F4741–00
3 95022–08012
4 2GS–F4750–00
5 2GS–F4741–00
6 4LS–F4741–00
7 21C–F4780–01
8 95022–06010
9 2GS–F478E–00
10 21C–WF479–00
11 2GS–F117K–00
12 90159–06054
13 2GS–F474A–00
14 2GS–F474W–00
15 95812–08025
16 92902–08200
DESCRIPCION
DESCRIPTION
ASIENTO SIMPLE COMPLETO
SINGLE SEAT ASSY
.COJIN DE ASIENTO
.PAD, SEAT
PERNO, DE BRIDA
BOLT, FLANGE
ASIENTO TANDEM COMPLETO
TANDEM SEAT ASSY
.COJIN DE ASIENTO
.PAD, SEAT
.COJIN DE ASIENTO
.PAD, SEAT
CERRADURA SILLIN COMPLETO
SEAT LOCK ASSY
PERNO, DE BRIDA
BOLT, FLANGE
CABLE
CABLE, SEAT LOCK
CUBIERTA, DE COLA
ROTOR SUB ASSY WITH KEY
SOPORTE DE CERRADURA
STAY, LOCK
TORNILLO CON VALONA
SCREW, WITH WASHER
FIADOR DE EMPUNADURA
ASSIST, GRIP
FIADOR DE EMPUNADURA 2
ASSIST,GRIP 2
TORNILLO DE REBORDE
BOLT, FLANGE
ARANDELA
WASHER
32
BE41
REF.
Nº
SEAT
BE31
FIG. 23 ASIENTO
1
1
4
4
2
2
1
1
2
2
2
2
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
4
4
4
4
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 21C–F5168–20–33
2 21C–F510C–10
3 93106–22808
4 93306–252XG
93306–252YH
5 94110–17818
6 93900–00824
7 21C–F5183–01
8 2GS–F5181–00
9 90171–14800
10 90252–55800
11 92902–14200
12 2GS–F531B–10
2GS–F531B–20
2GS–F531B–30
DESCRIPCION
DESCRIPTION
RUEDA FUNDIDA DELANTERA
CAST WHEEL, FRONT
COLLAR
COLLAR ASSY.
SELLO ACEITE
OIL SEAL
COJINETE
BEARING
COJINETE
BEARING
NEUMATICO(100/80-17 MC 52P)
TIRE (100/80-17 MC 52P)
VALVULA
VALVE, RIM
COLLAR DE RUEDA
COLLAR, WHEEL
EJE DE LA RUEDA
AXLE, WHEEL
TUERCA ENTALLADA
NUT, CASTLE
PASADOR DE CHAVETA
PIN, COTTER
ARANDELA
WASHER
EMBLEMA DE RUEDA
EMBLEM, WHEEL
EMBLEMA DE RUEDA
EMBLEM, WHEEL
EMBLEMA DE RUEDA
EMBLEM, WHEEL
33
BE41
REF.
Nº
FRONT WHEEL
BE31
FIG. 24 RUEDA DELANTERA
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
OBSERVACIONES
REMARKS
YB
YB
UR
UR
UR
UR
MRF
MRF
UR PARA BWC1
UR PARA BWC1
UR PARA YB
UR PARA YB
UR PARA MBL2
UR PARA MBL2
CODIGO Nº
PART NO.
1 21C–F582U–00
2 90111–08029
3 2GS–F580U–00
4 54B–W0057–00
5 54B–W0047–00
6 54B–F5919–00
7 54B–W0048–00
8 2GS–W0045–00
9 54B–F5924–00
10 54B–F5916–00
11 54B–F5925–00
12 54B–F5937–00
13 54B–F5917–00
14 54B–F5926–00
15 90105–10319
DESCRIPCION
DESCRIPTION
DISCO DE FRENO (DERECHO)
DISK, BRAKE (RIGHT)
TORNILLO
BOLT,HEX. SOCKET BUTTON
CALIBRE COMPLETO (DERECHO)
CALIPER ASSY (RIGHT)
.PISTON COMPLETO PINZA
.PISTON ASSY, CALIPER
..JUEGO DE RETENES DE PINZA
..CALIPER SEAL KIT
.SOPORTE DE PASTILLAS
.SUPPORT, PAD
.CJTO TORNILLO DE PURGA
.BLEED SCREW KIT
.JUEGO DE COJIN DE FRENO
.BRAKE PAD KIT
.PASADOR
.PIN, PAD
.TAPON
.PLUG
.PRESILLA
.CLIP
.FUNDA
.BOOT 2
.FUNDA DE CALIBRE
.BOOT, CALIPER
.PERNO
.BOLT
TORNILLO
BOLT, FLANGE
34
BE41
REF.
Nº
FRONT BRAKE CALIPER
BE31
FIG. 25 CALIBRE FRENO DELANTERA
1
1
5
5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 21C–F5338–20–33
2 21C–F530S–10
3 93306–252XG
93306–252YH
4 93106–22808
5 21C–F5364–00
6 5US–F5321–10
7 5YY–WF533–00
8 90506–12001
9 90506–15001
10 5YY–F5351–00
11 21C–F5355–01
12 90101–06814
90101–06046
13 95307–06600
14 36L–F533A–00
15 20P–F5366–00–33
16 93306–054YA
93306–054Y5
17 20P–F5377–00
18 93106–26801
19 2GS–F5441–00
20 90116–08826
21 95602–08200
22 94114–17801
23 93900–00824
24 21C–F5371–00
DESCRIPCION
DESCRIPTION
RUEDA FUNDIDA TRASERA
CAST WHEEL, REAR
ASAMBLEA DE COLLAR
COLLAR ASSY
COJINETE
BEARING
COJINETE
BEARING
SELLO ACEITE
OIL SEAL
AMORTIGUADOR
DAMPER
PLACA DE ZAPATA DE FRENO
PLATE, BRAKE SHOE
JUEGO DE ZAPATA DE FRENO
BRAKE SHOE KIT
RESORTE DE TENSION
SPRING, TENSION
RESORTE DE TENSION
SPRING, TENSION
ARBOL DE LEVAS
CAMSHAFT
PALANCA DE ARBOL DE LEVAS
LEVER, CAMSHAFT
TORNILLO
BOLT
TORNILLO
BOLT
TUERCA
NUT
PLACA INDICADOR
PLATE, INDICATOR
EMBRAGUE DE MASA
CLUTCH, HUB
COJINETE
BEARING
COJINETE
BEARING
COLLAR DE RUEDA
COLLAR, WHEEL
SELLO ACEITE
OIL SEAL
CORONA (41T)
SPROCKET, DRIVEN (41T)
ESPARRAGO
BOLT, STUD
TUERCA DE AUTO-CIERRE
NUT, SELF-LOCKING
NEUMATICO(140/60 R17 MC 63P)
TIRE (140/60 R17 MC 63P)
VALVULA
VALVE, RIM
BARRA TENSORA
BAR, TENSION
35
BE41
REF.
Nº
REAR WHEEL
BE31
FIG. 26 RUEDA TRASERA
1
1
1
1
2
2
2
2
1
1
4
4
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
YB
YB
UR
UR
UR
UR
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6
6
6
6
1
1
1
1
1
1
YB
YB
UR
UR
UR
UR
MRF
MRF
CODIGO Nº
PART NO.
25 90109–08063
26 95302–08700
27 90201–08326
28 91401–20012
29 90109–08831
30 95302–08600
31 92902–08200
32 2GS–F5381–00
33 21C–F5377–01
34 21C–F5383–10
35 90171–14800
36 90252–55800
37 90201–15814
38 94568–B5128
39 21C–F5388–11
40 21C–F2174–00
41 92902–08600
42 95302–08600
43 2GS–F531B–10
2GS–F531B–20
2GS–F531B–30
DESCRIPCION
DESCRIPTION
PERNO
BOLT
TUERCA
NUT, HEXAGON
ARANDELA PLANA
WASHER, PLATE
CHAVETA
PIN, COTTER
PERNO
BOLT
TUERCA
NUT, HEXAGON
ARANDELA
WASHER
EJE DE RUEDA
AXLE, WHEEL
COLLAR DE RUEDA
COLLAR, WHEEL
COLLAR DE RUEDA
COLLAR, WHEEL
TUERCA ENTALLADA
NUT, CASTLE
PASADOR DE CHAVETA
PIN, COTTER
ARANDELA PLANA
WASHER, PLATE
CADENA (R428HBSX-128-2)
CHAIN (R428HBSX-128-2)
TIRADOR DE CADENA 1
PULLER, CHAIN 1
EXTREMO 1
END 1
ARANDELA
WASHER, PLATE
TUERCA
NUT, HEXAGON
EMBLEMA DE RUEDA
EMBLEM, WHEEL
EMBLEMA DE RUEDA
EMBLEM, WHEEL
EMBLEMA DE RUEDA
EMBLEM, WHEEL
36
BE41
REF.
Nº
REAR WHEEL
BE31
FIG. 26 RUEDA TRASERA
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
2
2
2
2
2
2
4
4
2
2
2
OBSERVACIONES
REMARKS
UR PARA BWC1
UR PARA BWC1
UR PARA YB
UR PARA YB
UR PARA MBL2
UR PARA MBL2
CODIGO Nº
PART NO.
1 21C–F6111–01
2 2GS–F6311–00
3 2GS–F6312–00
4 98507–05012
5 21C–F6335–01
6 4TL–F6372–00
7 90123–08046
8 90179–08148
9 21C–F6241–00
10 21C–F6240–10
11 21C–F620B–21
DESCRIPCION
DESCRIPTION
MANUBRIO
HANDLEBAR
CABLE DE ACELERADOR 1
CABLE, THROTTLE 1
CABLE DE ACELERADOR 2
CABLE, THROTTLE 2
TORNILLO DE CABEZA PLANA
SCREW, PAN HEAD
CABLE DE EMBRAGUE
CABLE, CLUTCH
CUBIERTA DE PALANCA DE MANUB 1
COVER, HANDLE LEVER 1
PERNO
BOLT
TUERCA
NUT
EMPUNADURA
GRIP
EMPUNADURA COMPLETA
GRIP ASSY
EXTREMO DE EMPUNADURA
END GRIP ASSY
37
BE41
REF.
Nº
STEERING HANDLE & CABLE
BE31
FIG. 27 MANILLAR & CABLE
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 21C–F5872–00
2 90401–10818
3 90201–10815
4 54B–WF587–00
5 54B–W0041–00
6 54B–F5854–00
7 54B–F5852–00
8 54B–F589H–00
9 5YY–F5867–00
10 90105–06859
11 54B–F5855–00
12 54B–H3980–01
13 54B–H3922–00
14 90109–06859
15 54B–F6338–00
16 21C–F5875–00
17 21C–F5876–00
18 21C–F3317–00
DESCRIPCION
DESCRIPTION
MANGUERA DE FRENO 1
HOSE, BRAKE 1
PERNO DE UNION
BOLT, UNION
ARANDELA PLANA
WASHER, PLATE
CILINDRO MAESTRO SUB COMPLET
MASTER CYLINDER SUB ASSY
.JUEGO DE CILINDRO MAESTRO
.CYLINDER KIT, MASTER
.EMPAQUE,DIAFRAGMA
.DIAPHRAGM, RESERVOIR
.TAPA DE TANQUE DE RESERVA
.CAP, RESERVOIR
.TORNILLO
.SCREW
.SOPORTE DE CILINDRO MAESTRO
.BRACKET, MASTER CYLINDER
.TORNILLO
.BOLT, FLANGE
.BUJE DE DIAFRAGMA
.BUSH,DIAPHRAGM
INTERRUP. DE PARADA DELANTERO
FRONT STOP SWITCH ASSY
PALANCA 2
LEVER 2
PERNO
BOLT
TUERCA DE AJUSTE
NUT, ADJUSTING
SOPORTE DE MANGUERA FRENO 1
HOLDER, BRAKE HOSE 1
SOPORTE DE MANGUERA FRENO 2
HOLDER, BRAKE HOSE 2
SOSTEN DE CABLE
HOLDER, CABLE
38
BE41
REF.
Nº
BE31
FIG. 28 CILINDRO MAESTRO DELANTERO FRONT MASTER CYLINDER
1
1
2
2
4
4
1
1
1
1
1
1
1
1
2
2
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 35B–F7451–00
2 2GS–F7452–00
3 90508–183B9
4 91701–08040
5 91401–25015
6 21C–F7413–01
7 98502–05014
8 90109–08202
9 21C–F7261–00
10 90201–10841
11 2GS–F7414–00
12 95812–08025
13 35B–F7461–00
14 2GS–F7462–00
15 90508–183B9
16 91701–08040
17 91401–25015
18 21C–F7413–01
19 98502–05014
20 90109–08202
21 2GS–F144G–00
22 95802–06010
23 21C–F7211–10
24 90506–26807
25 21C–F7261–00
26 90201–10841
27 2GS–F7424–00
DESCRIPCION
DESCRIPTION
APOYAPIE
FOOTREST
SOPORTE, DE APOYAPIE 1
BRACKET, FOOTREST 1
RESORTE DE TORSION
SPRING, TORSION
PASADOR DE ABRAZADERA
PIN
CHAVETA
PIN, COTTER
CUBIERTA DE APOYAPIE
COVER, FOOTREST
TORNILLO
SCREW, PAN HEAD
PERNO
BOLT
EJE
SHAFT
ARANDELA PLANA
WASHER, PLATE
AMORTIGUADOR DE APOYAPIE
DAMPER, FOOTREST
TORNILLO DE REBORDE
BOLT, FLANGE
APOYAPIE
FOOTREST
SOPORTE, DE APOYAPIE 2
BRACKET, FOOTREST 2
RESORTE DE TORSION
SPRING, TORSION
PASADOR DE ABRAZADERA
PIN
CHAVETA
PIN, COTTER
CUBIERTA DE APOYAPIE
COVER, FOOTREST
TORNILLO
SCREW, PAN HEAD
PERNO
BOLT
SOPORTE DE INTERRUPTOR
STAY, STOP SWITCH
TORNILLO DE REBORDE
BOLT, FLANGE
PEDAL DE FRENO
PEDAL, BRAKE
RESORTE DE TENSION
SPRING, TENSION
EJE
SHAFT
ARANDELA PLANA
WASHER, PLATE
AMORTIGUADOR DE APOYAPIE 2
DAMPER, FOOTREST 2
39
BE41
REF.
Nº
STAND & FOOTREST
BE31
FIG. 29 SOPORTE & APOYAPIE
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
28 95812–08025
DESCRIPCION
DESCRIPTION
TORNILLO DE REBORDE
BOLT, FLANGE
40
BE41
REF.
Nº
STAND & FOOTREST
BE31
FIG. 29 SOPORTE & APOYAPIE
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 45S–F7111–00
2 90387–10822
3 90506–35816
4 21C–F7114–00
5 95602–10200
6 95812–10035
7 21C–F7231–00
8 91401–20012
9 92902–06200
10 90240–06804
11 92902–06200
12 90501–10815
13 90249–12008
14 90179–06835
15 21C–F7311–00
16 90506–23807
17 90445–13806
18 90101–10812
19 90387–10003
20 90201–10841
21 90185–10811
22 20P–F7431–00
23 20P–F7441–00
24 91701–08035
25 91401–25015
26 90501–12743
27 93501–04805
DESCRIPCION
DESCRIPTION
PUNTAL PRINCIPAL
STAND, MAIN
ESPACIADOR
COLLAR
RESORTE DE TENSION
SPRING, TENSION
TOPE DE PUNTAL PRINCIPAL
STOPPER, MAIN STAND
TUERCA DE AUTO-CIERRE
NUT, U FLANGE
TORNILLO DE REBORDE
BOLT, FLANGE
VARILLA DE FRENO
ROD, BRAKE
CHAVETA
PIN, COTTER
ARANDELA
WASHER
PASADOR CON HOYO
PIN, CLEVIS
ARANDELA
WASHER
RESORTE DE COMPRESION
SPRING, COMPRESSION
PASADOR
PIN
TUERCA
NUT
PUNTAL LATERAL
STAND, SIDE
RESORTE DE TENSION
SPRING, TENSION
TUBO
HOSE
TORNILLO
BOLT
ESPACIADOR
COLLAR
ARANDELA PLANA
WASHER, PLATE
TUERCA AUTOBLOCANTE
NUT, SELF-LOCKING
APOYAPIE POSTERIOR 1
FOOTREST, REAR 1
APOYAPIE POSTERIOR 2
FOOTREST, REAR 2
PASADOR DE ABRAZADERA
PIN
CHAVETA
PIN, COTTER
RESORTE DE COMPRESION
SPRING, COMPRESSION
BOLA
BALL
41
BE41
REF.
Nº
STAND & FOOTREST 2
BE31
FIG. 30 SOPORTE & APOYAPIE 2
1
1
2
2
1
1
1
1
2
2
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
2
2
2
2
2
2
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–H1450–00
2 2GS–H1410–00
3 91312–06030
4 91312–06016
5 95707–12500
6 90201–12019
DESCRIPCION
DESCRIPTION
ROTOR COMPLETO
ROTOR ASSY
ESTATOR COMPLETO
STATOR ASSY
TORNILLO
BOLT
TORNILLO
BOLT
TUERCA DE BRIDA
NUT, FLANGE
ARANDELA PLANA
WASHER, PLATE
42
BE41
REF.
Nº
GENERATOR
BE31
FIG. 31 GENERADOR
1
1
1
1
3
3
2
2
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–H1800–00
2 5D9–H1828–00
3 5D9–H1861–00
4 2GS–H183G–00
5 5TP–H1801–00
6 91312–06020
7 93210–29807
DESCRIPCION
DESCRIPTION
MOTOR DE ARRANQUE COMPLETO
STARTING MOTOR ASSY
.TORNILLO DE EMPUJE 2
.SCREW 2
.EMPAQUETADURA
.GASKET
.CABLE DEL MOTOR COMPL.
.CORD COMP.
.JUEGO DE ESCOBILLA
.BRUSH SET
TORNILLO
BOLT
ANILLO O
O-RING
43
BE41
REF.
Nº
STARTING MOTOR
BE31
FIG. 32 MOTOR DE ARRANQUE
1
1
2
2
1
1
1
1
1
1
2
2
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–H3310–00
2 54B–H331A–00
3 1GC–H3311–00
4 20P–H3318–00
5 2GS–H331E–10
6 20P–H3618–00
7 20P–H213A–00
8 20P–H3333–00
9 20P–H2133–00
10 2GS–H3320–00
11 54B–H332A–00
12 1GC–H3311–00
13 20P–H3318–00
14 54B–H332E–10
15 20P–H3618–00
16 20P–H213A–00
17 20P–H3333–00
18 20P–H2133–00
19 2GS–H3330–00
20 54B–H333A–00
21 1GC–H3311–00
22 20P–H3318–10
23 2GS–H333E–00
24 20P–H3618–00
25 20P–H213A–00
26 20P–H3333–00
27 20P–H2133–00
DESCRIPCION
DESCRIPTION
DESTELLADOR DE LUZ DELANT.
FRONT FLASHER LIGHT ASSY 1
.LENTES COMPLETO 1
.LENS COMP 1
.AMPOLLETA (12V-10W)
.BULB (12V-10W)
.SOPORTE DE DESTELLADOR 1
.STAY, FLASHER 1
.CORDON COMPLETO
.CORD ASSY
.PLACA
.PLATE
.TORNILLO ACCESORIO
.SCREW, FITTING
.TORNILLO ACCESORIO DE LENTE
.SCREW, LENS FITTING
.TORNILLO ACCESORIO
.SCREW, FITTING
DESTELLADOR DE LUZ DELANT.
FRONT FLASHER LIGHT ASSY 2
.LENTES COMPLETO 2
.LENS COMP 2
.AMPOLLETA (12V-10W)
.BULB (12V-10W)
.SOPORTE DE DESTELLADOR 1
.STAY, FLASHER 1
.CABLE COMPL.
.CORD ASSY
.PLACA
.PLATE
.TORNILLO ACCESORIO
.SCREW, FITTING
.TORNILLO ACCESORIO DE LENTE
.SCREW, LENS FITTING
.TORNILLO ACCESORIO
.SCREW, FITTING
DESTELLADOR DE LUZ TRAS.COMPL.
REAR FLASHER LIGHT ASSY 1
.LENTES COMPLETO 1
.LENS COMP 1
.AMPOLLETA (12V-10W)
.BULB (12V-10W)
.SOPORTE DE DESTELLADOR 1
.STAY, FLASHER 1
.CABLE COMPLETA
.CORD ASSY
.PLACA
.PLATE
.TORNILLO ACCESORIO
.SCREW, FITTING
.TORNILLO ACCESORIO DE LENTE
.SCREW, LENS FITTING
.TORNILLO ACCESORIO
.SCREW, FITTING
44
BE41
REF.
Nº
FLASHER LIGHT
BE31
FIG. 33 LUZ DE DESTELLADOR
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
28 2GS–H3340–00
29 54B–H334A–00
30 1GC–H3311–00
31 20P–H3318–10
32 2GS–H334E–00
33 20P–H3618–00
34 20P–H213A–00
35 20P–H3333–00
36 20P–H2133–00
37 5YY–H3318–10
DESCRIPCION
DESCRIPTION
DESTELLADOR DE LUZ TRAS.COMPL.
REAR FLASHER LIGHT ASSY 2
.LENTES COMPLETO 2
.LENS COMP 2
.AMPOLLETA (12V-10W)
.BULB (12V-10W)
.SOPORTE DE DESTELLADOR 1
.STAY, FLASHER 1
.CABLE COMPLETA
.CORD ASSY
.PLACA
.PLATE
.TORNILLO ACCESORIO
.SCREW, FITTING
.TORNILLO ACCESORIO DE LENTE
.SCREW, LENS FITTING
.TORNILLO ACCESORIO
.SCREW, FITTING
SOPORTE DE DESTELLADOR 1
STAY, FLASHER 1
45
BE41
REF.
Nº
FLASHER LIGHT
BE31
FIG. 33 LUZ DE DESTELLADOR
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
4
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–H3500–00
2 90480–14818
3 97702–50014
4 90201–05036
5 2GS–H3615–00
6 90338–10800
7 90179–05804
8 98902–05020
9 2GS–F8380–00
10 20P–F836B–00
11 21C–H3756–03
12 90464–14803
DESCRIPCION
DESCRIPTION
METRO COMPLETO
METER ASSY
TAPON
GROMMET
TORNILLO ROSCA HEMBRA
SCREW, TAPPING
ARANDELA PLANA
WASHER, PLATE
PANTALLA, MEDIDOR
BLIND, METER
TAPON
PLUG
TUERCA
NUT
TORNILLO DE LIGAR
SCREW, BIND
VISERA COMPLETO
WINDSCREEN ASSY
.MARCA
.TUNING FORK MARK
SENSOR, UNIDAD
SENSOR, UNIT
BRIDA
CLAMP
46
BE41
REF.
Nº
METER
BE31
FIG. 34 MEDIDOR
1
1
3
3
3
3
3
3
1
1
4
4
4
1
1
1
1
3
3
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–H4300–00
2 20P–H4314–00
3 21C–H4347–00
4 2GS–H430A–00
5 21C–H4502–00
6 21C–H4312–00
7 90480–14101
8 90387–068D4
9 95802–06025
10 95812–06012
11 90183–06800
12 2GS–F3121–00
13 90269–06814
14 2GS–F3122–00–33
2GS–F3122–00–P0
2GS–XF312–10–P1
2GS–XF312–20–33
2GS–XF312–30–P2
15 2GS–F8391–10
2GS–F8391–20
2GS–F8391–30
16 2GS–F3132–00–33
2GS–F3132–00–P0
2GS–XF313–10–P1
2GS–XF313–20–33
2GS–XF313–30–P2
17 2GS–F8392–10
DESCRIPCION
DESCRIPTION
FARO DELANTERO COMPLETO
HEADLIGHT ASSY
.AMPOLLETA (12V-35/35W)
.BULB (12V-35/35W)
.AMPOLLETA (12V-5W)
.BULB (12V-5W)
.UNIDAD DE FARO DELANTERO COMPL
.HEADLIGHT UNIT ASSY
.CUBIERTA COMPLETO
.COVER COMP.
.CABLE COMPLETA
.CORD ASSY
TAPON
GROMMET
ESPACIADOR
COLLAR
TORNILLO DE REBORDE
BOLT, FLANGE
TORNILLO DE REBORDE
BOLT, FLANGE
TUERCA DE RESORTE
NUT, SPRING
CUBIERTA SUPERIOR 1
COVER, UPPER 1
REMACHE
RIVET
CUBIERTA EXTERIOR 1
COVER, OUTER 1
CUBIERTA EXTERIOR 1
COVER, OUTER 1
CUBIERTA EXTERIOR 1
COVER, OUTER 1
CUBIERTA EXTERIOR 1
COVER, OUTER 1
CUBIERTA EXTERIOR 1
COVER, OUTER 1
.CALCOMANIA 1
.GRAPHIC 1
.CALCOMANIA 1
.GRAPHIC 1
.CALCOMANIA 1
.GRAPHIC 1
CUBIERTA EXTERIOR 2
COVER, OUTER 2
CUBIERTA EXTERIOR 2
COVER, OUTER 2
CUBIERTA EXTERIOR 2
COVER, OUTER 2
CUBIERTA EXTERIOR 2
COVER, OUTER 2
CUBIERTA EXTERIOR 2
COVER, OUTER 2
.CALCOMANIA 2
.GRAPHIC 2
47
BE41
REF.
Nº
HEADLIGHT
BE31
FIG. 35 FARO DELANTERO
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
1
1
3
3
1
1
3
3
1
1
1
1
1
1
1
1
1
1
1
1
1
1
OBSERVACIONES
REMARKS
UR PARA YB
UR FOR YB
UR PARA VRC1
UR FOR VRC1
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA YB
UR FOR YB
UR PARA VRC1
UR FOR VRC1
UR PARA BWC1
UR FOR BWC1
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
UR PARA BWC1
UR FOR BWC1
CODIGO Nº
PART NO.
17 2GS–F8392–20
2GS–F8392–30
18 90160–05812
19 2GS–F3123–00–P0
20 90269–06814
21 97702–50012
22 90183–05807
DESCRIPCION
DESCRIPTION
.CALCOMANIA 2
.GRAPHIC 2
.CALCOMANIA 2
.GRAPHIC 2
TORNILLO REDONDO ROSCA HEMBRA
SCREW, ROUND TAPPING
CUBIERTA INFERIOR
COVER, UNDER 1
REMACHE
RIVET
TORNILLO ROSCA HEMBRA
SCREW, TAPPING
TUERCA DE RESORTE
NUT, SPRING
48
BE41
REF.
Nº
HEADLIGHT
BE31
FIG. 35 FARO DELANTERO
1
1
2
2
1
1
4
4
1
1
3
3
OBSERVACIONES
REMARKS
UR PARA YB
UR FOR YB
UR PARA MBL2
UR FOR MBL2
MBL2
MBL2
CODIGO Nº
PART NO.
1 2GS–H4710–00
2 2GS–H4721–00
3 2GS–H4720–00
4 2GS–H4723–00
5 54B–H4714–00
6 97702–40512
7 97702–50016
8 90201–05036
9 90480–14819
10 90480–01558
DESCRIPCION
DESCRIPTION
UNIDAD FARO TRASERO COMPL.
TAILLIGHT UNIT ASSY
.LENTE DE FARO TRASERO
.LENS, TAILLIGHT
.BASE DE LUZ TRASERA
.BASE ASSY
.EMPAQUE LENTE FARO TRASERO
.GASKET, TAIL LENS
.AMPOLLETA (12V-21/5W)
.BULB (12V-21/5W)
.TORNILLO ROSCA HEMBRA
.SCREW, TAPPING
TORNILLO ROSCA HEMBRA
SCREW, TAPPING
ARANDELA PLANA
WASHER, PLATE
TAPON
GROMMET
TAPON
GROMMET
49
BE41
REF.
Nº
TAILLIGHT
BE31
FIG. 36 LUZ DE COLA
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
1
1
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–F6280–00
2 2GS–F6290–00
3 2GS–H3972–00
4 B77–H3975–00
5 5YY–H2911–00
6 21C–H3912–00
7 36L–H3945–10
8 95707–06300
9 9750M–06425
10 90201–08834
11 36L–H3936–00
DESCRIPCION
DESCRIPTION
ESPEJO COMPLETO (IZQUIERDO)
REAR VIEW MIRROR ASSY (LEFT)
ESPEJO COMPLETO (DERECHO)
REAR VIEW MIRROR ASSY (RIGHT)
INTERRUPTOR DE MANIJA 4
SWITCH, HANDLE 4
INTERRUPTOR DE MANIJA 2
SWITCH, HANDLE 2
SOPORTE DE LEVA 1
HOLDER, LEVER 1
PALANCA 1
LEVER 1
PERNO DE PALANCA
BOLT, LEVER
TUERCA DE BRIDA
NUT, NYLON
PERNO CON ARANDELA
BOLT, WITH WASHER
ARANDELA PLANA
WASHER, PLATE
BANDA DE CABLE DE INTERRUPTOR
BAND, SWITCH CORD
50
BE41
REF.
Nº
BE31
FIG. 37 INTERRUPTOR DE MANILLAR&PALANC HANDLE SWITCH & LEVER
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
OBSERVACIONES
REMARKS
CODIGO Nº
PART NO.
1 2GS–H2310–00
2 97502–05520
3 20P–H2370–02
4 B77–H591A–00
5 2GS–H5546–00
6 1C6–H2100–10
7 2GS–H2115–00
8 2GS–H2116–00
9 5YY–H2131–10
10 2GS–H1960–00
11 95802–06025
12 21C–H2530–00
13 2GS–H2590–00
2GS–H2590–10
14 90464–16061
15 90464–50800
16 2GS–F177G–00
17 90119–06137
DESCRIPCION
DESCRIPTION
BOBINA DE ENCENDIDO COMPLETA
IGNITION COIL ASSY
PERNO CON ARANDELA
BOLT, WITH WASHER
TAPON DE BUJIA COMPLT
PLUG CAP ASSY
UNIDAD CONTROL
ENGINE CONTROL UNIT ASSY
BANDA
BAND
BATERIA COMPLETA(YTX5L-BS 12V
BATTERY (YTX5L-BS 12V 4AH)
CABLE CONDUCTOR POSITIVO
WIRE, PLUS LEAD
CABLE CONDUCTOR NEGATIVO
WIRE, MINUS LEAD
TIRANTE DE BATERIA
BAND, BATTERY
RECTIFICADOR Y REGULADOR
RECTIFIER & REGULATOR ASSY
TORNILLO DE REBORDE
BOLT, FLANGE
INTERRUPTOR DE PARADA COMPLETO
STOP SWITCH ASSY
CONJUNTO DE CABLES
WIRE HARNESS ASSY
CONJUNTO DE CABLES
WIRE HARNESS ASSY
BRIDA
CLAMP
BRIDA
CLAMP
CAJA DE BATERIA
BOX, BATTERY
TORNILLO CON ARANDELA
BOLT, WITH WASHER
51
BE41
REF.
Nº
ELECTRICAL 1
BE31
FIG. 38 EQUIPO ELECTRICO 1
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
4
4
1
1
1
1
2
2
OBSERVACIONES
REMARKS
UR
UR
UR
UR
CODIGO Nº
PART NO.
1 21C–H2540–00
2 90430–10148
3 52B–H3591–00
4 90201–10128
5 2GS–H592A–00
6 5YY–H1950–10
7 54B–H1940–01
8 91312–05008
9 2GS–H2501–00
10 90149–06118
11 21C–H2917–01
12 1PA–H2576–00
13 2GS–XH250–10
14 21C–H3350–00
15 2GS–H3371–00
16 95827–06012
17 5US–H5110–00
18 95702–05500
19 2GS–F418E–00
20 95807–06014
21 90387–068S1
DESCRIPCION
DESCRIPTION
INTERRUPTOR NEUTRAL COMPL
NEUTRAL SWITCH ASSY
JUNTA
GASKET
UNIDAD TERMOSTATO
THERMO UNIT
ARANDELA PLANA
WASHER, PLATE
SENSOR
SENSOR, OXYGEN
RELE COMPLETO
RELAY ASSY
CONJUNTO ARRANCADOR RELEVO
STARTER RELAY ASSY
TORNILLO
BOLT
LLAVE DE IGNICION COMPLT
MAIN SWITCH STEERING LOCK
TORNILLO DE REGLAJE
SCREW
INTERRUPTOR
SWITCH
SENSOR ANGULO DE INCLINATION
SENSOR, LEAN ANGLE
LLAVE DE IGNICION COMPLT
MAIN SW. STRG. LOCK SUB ASSY
RELE DE DESTELLADOR COMPL.
FLASHER RELAY ASSY
BOCINA
HORN
TORNILLO
BOLT, FLANGE
REFLECTOR COMPLETO
REFLECTOR ASSY
TUERCA DE BRIDA
NUT, FLANGE
CAJA 1
BOX 1
TORNILLO
BOLT, FLANGE
ESPACIADOR
COLLAR
52
BE41
REF.
Nº
ELECTRICAL 2
BE31
FIG. 39 EQUIPO ELECTRICO 2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
1
2
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
OBSERVACIONES
REMARKS
AP
AP
INDICE NUMERICO
NUMERICAL INDEX
CODIGO Nº
PART NO.
4D9–12117–00
2GS–12159–00
4FM–23125–40
2GS–E1102–00
2GS–E111F–00
2GS–E1165–00
2GS–E1166–00
21C–E1169–10
2GS–E1181–01
2GS–E1186–00
2GS–E1190–00
2GS–E1193–00
2GS–E1310–00
21C–E1351–00
2GS–E1361–00
2GS–E1400–09
2GS–E1422–00
2GS–E1454–00
54B–E1476–00
21C–E1496–20
21C–E1531–01
54B–E1536–01
2GS–E1603–00
2GS–E1605–00
2GS–E1607–00
2GS–E1631–00
21C–E1633–00
2GS–E1636–09
2GS–E1638–09
2GS–E1651–00
21C–E1681–01
2GS–E2111–00
2GS–E2113–00
3S0–E2118–00
38B–E2119–00
2GS–E2121–00
2GS–E2126–00
1ST–E2151–00
21C–E2156–00
52S–E2169–10
2GS–E2170–00
21C–E2210–02
2GS–E2213–00
21C–E2231–00
2GS–E2241–00
2GS–E2280–00
1PM–E2288–00
REF.
Nº
3
3
20
20
1
4
1
6
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
3
4
4
4
4
4
4
4
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
7
10
16
34
1
4
6
26
7
17
11
5
9
20
21
15
1
5
14
19
16
15
12
11
11
11
8
9
8
8
4
2
1
5
6
3
2
4
9
12
8
1
13
14
9
10
5
6
CODIGO Nº
PART NO.
21C–E2435–11
21C–E2437–00
21C–E2661–10
54B–E3300–00
21C–E3362–00
4LS–E3411–00
21C–E3440–00
21C–E3447–00
21C–E3449–00
2GS–E3557–00
2GS–E3585–00
2GS–E3635–00
2GS–E3645–00
B77–E3750–00
2GS–E3770–00
2GS–E3907–00
2GS–E3971–00
5CA–E4147–00
2GS–E4411–00
2GS–E4412–00
2GS–E4437–00
20P–E443E–00
2GS–E4450–00
2GS–E4452–00
2GS–E4453–00
21C–E4613–00
2GS–E4703–00
2GS–E4718–00
20P–E4747–00
54B–E4757–00
21C–E4775–00
2GS–E4799–00
2GS–E4877–00
54B–E5111–00
54B–E5121–01
21C–E5155–00
45P–E5353–00
54B–E5362–00
2GS–E5411–00
2GS–E5418–00
21C–E5421–00
21C–E5441–00
21C–E5451–10
21C–E5461–10
1PM–E5514–00
21C–E5521–00
1PM–E5524–10
REF.
Nº
1
4
1
5
2
5
5
5
5
6
6
6
6
6
6
21
21
6
6
6
6
6
6
6
6
7
7
7
7
15
7
7
7
6
8
8
8
9
9
9
9
9
9
9
9
10
10
10
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
12
16
22
1
20
5
6
7
10
6
1
8
3
11
4
27
23
5
12
13
22
19
14
16
15
11
1
2
10
11
8
9
3
17
1
2
3
5
21
3
13
17
1
4
18
1
2
5
CODIGO Nº
PART NO.
2GS–E5580–00
4LS–E5598–00
21C–E5666–00
54B–E6111–10
21C–E6135–10
54B–E6144–00
2GS–E6150–00
21C–E6154–00
21C–E6193–00
54B–E6321–00
21C–E6324–00
21C–E6331–00
21C–E6333–00
21C–E6337–00
3C1–E6344–00
1PM–E6345–00
54B–E6351–00
21C–E6356–01
54B–E6357–00
21C–E6358–00
21C–E6371–00
21C–E6380–02
21C–E7121–10
B77–E7131–00
B77–E7141–00
B77–E7151–00
21C–E7211–20
21C–E7221–21
21C–E7231–31
B77–E7241–00
B77–E7251–00
21C–E7258–00
54B–E7258–00
21C–E7402–50
21C–E7411–50
4LS–E7456–00
21C–E7471–00
21C–E8101–01
21C–E8110–10
20P–E8113–00
21C–E8140–00
21C–E8337–00
21C–E8511–00
21C–E8512–00
21C–E8513–00
21C–E8531–00
21C–E8535–00
2GS–E8540–00
REF.
Nº
10
4
12
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
11
12
12
12
12
12
12
12
12
12
12
11
12
12
12
12
14
14
14
14
14
13
13
13
13
13
13
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
8
11
29
1
19
17
6
7
3
9
11
10
13
14
18
23
12
16
24
15
8
22
5
4
6
7
20
13
16
21
22
19
2
12
1
27
10
4
9
10
1
3
2
3
4
5
6
1
CODIGO Nº
PART NO.
B77–F1110–00
2GS–F117K–00
2GS–F1279–00
2GS–F1316–00
2GS–F1317–00
2GS–F144G–00
21C–F1511–00–33
21C–F1511–00–P2
21C–F1511–00–P3
21C–F1511–00–P4
2GS–F1611–00
2GS–F1613–00
2GS–F1614–00
21C–F1638–02
2GS–F163A–00
B98–F1641–00
2GS–F1644–00
2GS–F1645–00
2GS–F164F–00
2GS–F1650–00
2GS–F1651–00
54C–F1668–00
2GS–F1711–00
21C–F1717–00
2GS–F171L–00
2GS–F171M–00
2GS–F1721–00
2GS–F172A–00–P0
2GS–F172F–00–P0
2GS–F1731–00–33
2GS–F1731–00–P0
2GS–F1731–00–P1
2GS–F1731–00–P2
2GS–F1732–00
2GS–F1735–00
2GS–F173E–10
2GS–F173E–20
2GS–F173E–30
2GS–F173F–10
2GS–F173F–20
2GS–F173F–30
2GS–F1741–00–33
2GS–F1741–00–P0
2GS–F1741–00–P1
2GS–F1741–00–P2
2GS–F177G–00
20P–F2129–00
REF.
Nº
15
23
15
15
15
29
16
16
16
16
16
16
16
15
16
16
18
18
18
18
16
18
17
15
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
17
38
18
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
CODIGO Nº
PART NO.
1
11
14
2
5
21
1
1
1
1
6
12
13
13
15
20
13
14
15
12
14
23
1
16
11
24
25
6
2
7
12
12
12
12
27
28
3
3
3
8
8
8
13
13
13
13
16
5
53
2GS–F2141–00
21C–F2147–00
2GS–F2151–00
21C–F2174–00
2GS–F2210–00
2GS–F3100–00
2GS–F3102–00
2GS–F3103–00
21C–F3110–00
21C–F3111–00
21C–F3114–00
21C–F3118–00
2GS–F3121–00
2GS–F3122–00–33
2GS–F3122–00–P0
2GS–F3123–00–P0
21C–F3126–11
2GS–F3132–00–33
2GS–F3132–00–P0
21C–F3136–11
21C–F3141–00
2GS–F3144–00
2GS–F3145–00
21C–F3146–00
21C–F3149–00
21C–F3156–00
21C–F3158–00
2GS–F3170–00
2GS–F3171–00
21C–F3173–00
2GS–F317E–00
2GS–F317F–00
21C–F317J–00
21C–F3181–00
REF.
Nº
18
18
18
26
18
20
20
20
20
20
20
20
20
20
20
20
35
35
35
35
20
35
35
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
19
19
19
20
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
4
20
8
40
24
1
2
20
18
36
5
23
4
22
6
24
12
14
14
19
3
16
16
21
8
26
12
30
14
32
15
33
7
25
13
31
10
28
17
35
19
37
11
29
16
17
18
9
CODIGO Nº
PART NO.
21C–F3181–00
21C–F3317–00
21C–F3340–02
21C–F3346–00
21C–F3411–00
21C–F3412–00
21C–F3413–00
21C–F3414–00
5YY–F3416–00
20P–F3418–00
4LS–F341E–00
4LS–F341E–10
21C–F3435–00
21C–F3441–00
5YY–F3462–00
B77–F4110–00
45S–F411G–00
45S–F411H–00
2GS–F4124–00
5YY–F413B–00
2GS–F414A–00
2GS–F414G–00
21C–F4181–00
21C–F4183–00
21C–F4188–10
2GS–F418E–00
2GS–F4191–00
2GS–F4245–00
2GS–F4245–10
2GS–F4245–30
2GS–F4245–40
2GS–F4245–50
2GS–F4246–00
2GS–F4246–10
2GS–F4246–30
2GS–F4246–40
2GS–F4246–50
2GS–F4257–10
2GS–F4257–20
2GS–F4257–30
2GS–F4258–10
2GS–F4258–20
2GS–F4258–30
2GS–F4364–00
2GS–F4491–00
2GS–F4549–00
21C–F4614–00–P0
REF.
Nº
20
28
20
20
20
19
19
19
19
19
19
19
19
19
20
21
22
22
22
22
22
21
21
21
21
21
39
21
22
22
22
22
22
22
22
22
22
22
22
22
22
22
22
22
21
21
21
21
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
27
18
38
41
40
1
2
3
6
8
5
4
10
14
39
1
12
13
16
20
22
17
29
2
4
14
19
8
2
2
2
2
2
5
5
5
5
5
3
3
3
6
6
6
25
28
16
19
INDICE NUMERICO
NUMERICAL INDEX
CODIGO Nº
PART NO.
2GS–F4710–00
1PM–F4741–00
2GS–F4741–00
4LS–F4741–00
2GS–F474A–00
2GS–F474W–00
2GS–F4750–00
21C–F4780–01
2GS–F478E–00
21C–F510C–10
21C–F5168–20–33
2GS–F5181–00
21C–F5183–01
21C–F530S–10
2GS–F531B–10
2GS–F531B–20
2GS–F531B–30
5US–F5321–10
21C–F5338–20–33
36L–F533A–00
5YY–F5351–00
21C–F5355–01
21C–F5364–00
20P–F5366–00–33
21C–F5371–00
20P–F5377–00
21C–F5377–01
2GS–F5381–00
21C–F5383–10
21C–F5388–11
2GS–F5441–00
2GS–F580U–00
21C–F582U–00
54B–F5852–00
54B–F5854–00
54B–F5855–00
5YY–F5867–00
21C–F5872–00
21C–F5875–00
21C–F5876–00
54B–F589H–00
54B–F5916–00
54B–F5917–00
54B–F5919–00
REF.
Nº
23
15
23
23
23
23
23
23
23
23
24
24
24
24
26
24
26
24
26
24
26
26
26
26
26
26
26
26
26
26
26
26
26
26
26
25
25
28
28
28
28
28
28
28
28
25
25
25
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
1
15
2
5
6
13
14
4
7
9
2
1
8
7
2
12
43
12
43
12
43
6
1
14
10
11
5
15
24
17
33
32
34
39
19
3
1
7
6
11
9
1
16
17
8
10
13
6
CODIGO Nº
PART NO.
54B–F5924–00
54B–F5925–00
54B–F5926–00
54B–F5937–00
21C–F6111–01
21C–F620B–21
21C–F6240–10
21C–F6241–00
2GS–F6280–00
2GS–F6290–00
2GS–F6311–00
2GS–F6312–00
21C–F6335–01
54B–F6338–00
4TL–F6372–00
45S–F7111–00
21C–F7114–00
21C–F7211–10
21C–F7231–00
21C–F7261–00
21C–F7311–00
21C–F7413–01
2GS–F7414–00
2GS–F7424–00
20P–F7431–00
20P–F7441–00
35B–F7451–00
2GS–F7452–00
35B–F7461–00
2GS–F7462–00
21C–F8100–20
4UU–F811G–00
20P–F836B–00
5TS–F836B–02
2GS–F8380–00
2GS–F8391–10
2GS–F8391–20
2GS–F8391–30
2GS–F8392–10
2GS–F8392–20
2GS–F8392–30
2GS–H1410–00
2GS–H1450–00
2GS–H1800–00
5TP–H1801–00
5D9–H1828–00
REF.
Nº
25
25
25
25
27
27
27
27
37
37
27
27
27
28
27
30
30
29
30
29
29
30
29
29
29
29
30
30
29
29
29
29
16
16
34
17
34
35
35
35
35
35
35
31
31
32
32
32
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
9
11
14
12
1
11
10
9
1
2
2
3
5
15
6
1
4
23
7
9
25
15
6
18
11
27
22
23
1
2
13
14
24
11
10
18
9
15
15
15
17
17
17
2
1
1
5
2
CODIGO Nº
PART NO.
2GS–H183G–00
5D9–H1861–00
54B–H1940–01
5YY–H1950–10
2GS–H1960–00
1C6–H2100–10
2GS–H2115–00
2GS–H2116–00
5YY–H2131–10
20P–H2133–00
20P–H213A–00
2GS–H2310–00
20P–H2370–02
2GS–H2501–00
21C–H2530–00
21C–H2540–00
1PA–H2576–00
2GS–H2590–00
2GS–H2590–10
5YY–H2911–00
21C–H2917–01
2GS–H3310–00
1GC–H3311–00
20P–H3318–00
20P–H3318–10
5YY–H3318–10
54B–H331A–00
2GS–H331E–10
2GS–H3320–00
54B–H332A–00
54B–H332E–10
2GS–H3330–00
20P–H3333–00
54B–H333A–00
REF.
Nº
32
32
39
39
38
38
38
38
38
33
33
33
33
33
33
33
33
38
38
39
38
39
39
38
38
37
39
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
33
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
4
3
7
6
10
6
7
8
9
9
18
27
36
7
16
25
34
1
3
9
12
1
12
13
13
5
11
1
3
12
21
30
4
13
22
31
37
2
5
10
11
14
19
8
17
26
35
20
CODIGO Nº
PART NO.
2GS–H333E–00
2GS–H3340–00
54B–H334A–00
2GS–H334E–00
21C–H3350–00
2GS–H3371–00
2GS–H3500–00
52B–H3591–00
2GS–H3615–00
20P–H3618–00
21C–H3756–03
21C–H3912–00
54B–H3922–00
36L–H3936–00
36L–H3945–10
2GS–H3972–00
B77–H3975–00
54B–H3980–01
2GS–H4300–00
2GS–H430A–00
21C–H4312–00
20P–H4314–00
21C–H4347–00
21C–H4502–00
2GS–H4710–00
54B–H4714–00
2GS–H4720–00
2GS–H4721–00
2GS–H4723–00
5US–H5110–00
2GS–H5546–00
B77–H591A–00
2GS–H592A–00
54B–W0041–00
2GS–W0045–00
54B–W0047–00
54B–W0048–00
54B–W0057–00
2GS–WF17G–10–P1
2GS–WF17G–20–P1
2GS–WF17G–30–P1
2GS–WF17H–10–P1
2GS–WF17H–20–P1
2GS–WF17H–30–P1
2GS–WF211–00
REF.
Nº
33
33
33
33
39
39
34
39
34
33
33
33
33
34
37
28
37
37
37
37
28
35
35
35
35
35
35
36
36
36
36
36
39
38
38
39
28
25
25
25
25
17
17
17
17
17
17
18
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
CODIGO Nº
PART NO.
23
28
29
32
14
15
1
3
5
6
15
24
33
11
6
13
11
7
3
4
12
1
4
6
2
3
5
1
5
3
2
4
17
5
4
5
5
8
5
7
4
2
2
2
7
7
7
1
54
21C–WF461–11
21C–WF479–00
5YY–WF533–00
54B–WF587–00
2GS–XF13F–00–33
2GS–XF13F–00–P0
2GS–XF13F–00–P1
2GS–XF13F–00–P2
2GS–XF13J–00–33
2GS–XF13J–00–P0
2GS–XF13J–00–P1
2GS–XF13J–00–P2
2GS–XF17C–00–33
2GS–XF17C–00–P0
2GS–XF17C–00–P2
2GS–XF17C–00–P3
2GS–XF17D–00–33
2GS–XF17D–00–P0
2GS–XF17D–00–P2
2GS–XF17D–00–P3
2GS–XF312–10–P1
2GS–XF312–20–33
2GS–XF312–30–P2
2GS–XF313–10–P1
2GS–XF313–20–33
2GS–XF313–30–P2
2GS–XF412–00–33
2GS–XF412–10–P0
2GS–XF412–30–P1
2GS–XF412–40–33
2GS–XF412–50–P2
2GS–XF413–00–33
2GS–XF413–10–P0
2GS–XF413–30–P1
2GS–XF413–40–33
2GS–XF413–50–P2
2GS–XH250–10
90101–06046
90101–06814
90101–10812
90105–06169
90105–06859
90105–08002
90105–08196
90105–10319
90105–10861
90105–12057
90105–12804
REF.
Nº
21
23
26
28
22
22
22
22
22
22
22
22
17
17
17
17
21
21
21
21
35
35
35
35
35
35
22
22
22
22
22
22
22
22
22
22
39
26
26
30
21
28
15
4
25
15
18
18
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
22
10
7
4
19
19
19
19
21
21
21
21
17
17
17
17
15
15
15
15
14
14
14
16
16
16
1
1
1
1
1
4
4
4
4
4
13
12
12
18
12
10
6
7
15
10
26
27
CODIGO Nº
PART NO.
90109–06259
90109–06859
90109–08063
90109–08202
90109–08831
90110–06256
90110–06304
90110–06393
90111–05035
90111–06117
90111–06807
90111–06826
90111–08029
90116–08826
90119–06060
90119–06137
90123–08046
90149–05807
90149–06118
90149–06829
90159–05065
90159–06054
90160–05812
90170–05302
90170–10012
90171–14800
90176–22081
90179–05804
90179–06835
90179–08148
90179–08674
90179–10811
90179–12802
90179–14001
90179–25615
90183–05067
90183–05807
REF.
Nº
14
28
26
29
29
26
1
1
4
5
16
7
7
25
26
18
17
38
27
1
39
4
16
21
23
22
35
3
2
24
26
19
21
34
30
27
15
15
11
11
19
17
17
17
17
22
22
35
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
2
14
25
8
20
29
24
19
15
2
5
7
6
2
20
19
20
17
7
8
10
12
16
20
12
9
18
11
26
9
35
13
21
7
14
8
8
4
5
20
7
26
4
9
14
11
24
22
INDICE NUMERICO
NUMERICAL INDEX
CODIGO Nº
PART NO.
90183–06800
90185–10811
90201–05036
90201–05820
90201–06055
90201–06078
90201–060A3
90201–06380
90201–06871
90201–08326
90201–08612
90201–087F0
90201–08834
90201–10128
90201–105E8
90201–10815
90201–10841
90201–12019
90201–12028
90201–122H1
90201–15022
90201–15814
90201–178D3
90201–22018
90201–22793
90201–25290
90202–05180
90202–26142
90208–20003
90209–17285
90209–18208
90214–10006
90215–10284
90240–06804
90249–12008
90252–55800
90269–06814
REF.
Nº
16
18
35
30
34
36
1
17
16
18
21
21
14
26
7
7
37
39
10
28
29
29
30
11
31
18
18
2
26
12
12
19
12
10
22
19
11
12
12
2
2
30
30
24
26
17
17
35
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
17
18
11
21
4
8
23
22
23
10
9
10
13
27
13
17
10
4
3
3
10
26
20
4
6
7
29
17
37
18
30
12
14
7
10
9
21
2
17
18
25
10
13
10
36
16
19
13
CODIGO Nº
PART NO.
90269–06814
90280–03017
90282–05031
90338–10800
90338–30802
90340–12808
90340–14117
90340–32805
90387–06023
90387–06048
90387–066J9
90387–06737
90387–068B2
90387–068C5
90387–068C9
90387–068D4
90387–068N2
90387–068S1
90387–07819
90387–08079
90387–08822
90387–09806
90387–10003
90387–107H6
90387–10822
90387–12845
90387–12863
90387–155J0
90387–20813
90401–10818
90430–06817
90430–10148
90430–12227
90445–13806
90445–14808
90450–43807
90450–48805
90464–14803
90464–16006
90464–16061
90464–50800
90464–80802
90467–12800
90467–13816
REF.
Nº
35
2
2
34
9
5
9
9
7
16
16
22
18
6
21
16
9
35
18
18
39
19
16
15
6
30
21
30
18
18
2
2
28
1
1
39
5
30
21
6
6
34
21
38
38
21
6
6
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
20
7
24
6
24
3
9
11
5
8
19
17
9
23
6
2
15
8
16
21
21
20
10
12
24
19
7
2
25
2
21
13
2
3
14
2
4
17
18
9
10
12
24
14
15
5
20
27
CODIGO Nº
PART NO.
90467–15803
90467–20050
90480–01558
90480–01559
90480–08801
90480–12812
90480–13398
90480–14101
90480–14818
90480–14819
90480–14828
90480–15363
90501–06800
90501–10815
90501–12743
90506–12001
90506–15001
90506–23807
90506–26807
90506–35816
90508–183B9
90508–32805
91312–05008
91312–05010
91312–05016
91312–06014
91312–06016
91312–06020
91312–06025
91312–06030
91401–20012
91401–25015
91701–08035
91701–08040
91810–14804
91830–21014
REF.
Nº
6
6
17
36
22
16
7
9
22
35
34
36
22
21
13
30
30
26
26
30
29
30
29
29
14
39
21
3
9
4
31
10
32
6
31
14
26
30
29
29
30
30
29
29
1
8
9
9
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
28
18
23
10
8
3
4
16
7
7
2
9
14
3
7
12
26
8
9
16
24
3
3
15
5
8
30
13
2
17
4
9
6
2
3
11
28
8
5
17
25
24
4
16
18
4
6
19
CODIGO Nº
PART NO.
92902–06200
92902–08200
92902–08600
92902–14200
93101–10838
93102–12875
93102–12877
93102–22818
93106–22808
93106–26801
93210–14899
93210–19809
93210–29807
93210–32814
93306–002YV
93306–054Y5
93306–054Y6
93306–054YA
93306–054YE
93306–201Y4
93306–203XR
93306–252XG
93306–252YG
93306–252YH
93306–253Y6
93306–272X1
93306–272X4
93306–305YC
93310–325X3
93310–628X0
93315–112Y9
93317–318Y5
93410–20809
93410–22039
93450–16812
93501–04805
93505–16844
93605–06800
93608–43238
93822–14800
93900–00824
CODIGO Nº
PART NO.
REF.
Nº
14
30
30
23
26
26
24
9
14
11
12
24
26
26
9
9
32
9
4
26
12
26
12
12
12
24
26
2
24
26
2
12
12
2
10
2
11
18
12
12
2
30
11
4
14
12
24
26
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
12
9
11
16
31
41
11
23
8
27
25
3
4
18
10
22
7
12
3
16
8
16
8
9
23
4
3
22
4
3
23
24
24
6
6
3
26
3
3
15
10
27
25
2
7
26
6
23
55
94110–17818
94114–17801
94568–B5128
94568–G2096
94703–00885
95022–06010
95022–06012
95022–06016
95022–06020
95022–06025
95022–06040
95022–06045
95022–06050
95022–06055
95022–06065
95022–06070
95022–08012
95022–08035
95022–08040
95027–06016
95302–08600
95302–08700
95307–06600
95602–08200
95602–10200
95607–06100
95607–12200
95612–08635
95612–12100
95702–05500
95702–08500
95707–06300
95707–12500
95802–06010
95802–06012
95802–06020
95802–06025
95802–08025
95802–08035
REF.
Nº
24
26
26
4
1
12
23
1
16
5
1
1
9
9
8
9
8
5
8
23
19
19
18
18
18
26
26
26
26
26
30
16
18
1
18
39
7
37
31
8
29
22
9
16
35
38
7
7
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
5
22
38
8
16
28
8
2
21
8
10
13
7
20
7
8
6
9
8
3
15
11
11
17
22
30
42
26
13
21
5
22
6
4
28
18
12
8
5
5
22
15
14
4
9
11
14
15
CODIGO Nº
PART NO.
95807–06014
95812–06012
95812–06030
95812–08016
95812–08025
95812–08040
95812–10035
95812–10080
95817–10130
95822–06016
95822–06030
95827–06012
97012–06014
97012–06020
97502–05520
9750M–06425
97602–05320
97702–40512
97702–50012
97702–50014
97702–50016
98502–05014
98502–06012
98502–06014
98507–05012
98902–05020
99001–10600
99009–10400
99009–17400
99009–20500
REF.
Nº
39
19
35
6
15
23
29
29
7
30
15
15
6
16
19
21
22
39
16
16
21
14
38
37
6
36
17
17
17
21
22
35
34
36
29
29
12
17
27
34
14
10
12
11
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
20
21
10
7
7
15
12
28
16
6
3
9
25
9
19
13
18
16
7
18
11
14
2
9
21
6
5
10
15
26
23
21
3
7
7
19
11
21
4
8
6
4
31
28
