Technical specifications

Technical specifications
DIODE WAVELENGTH of 810 nm
Approved and certified by the international scientific community as having the best results available in
every category.
PULSE WIDTH from 5 to 400 ms
Its excellent results also include tanned skin.
FLUENCY from 10 to100 J/cm2
Has enough energy to eliminate hair without damaging the surrounding tissues.
TIP TEMPERATURE 0.5 ºC / 33 ºF ULTRACOOLING SAPPHIRE HEAD
The coldest on the market - without consumables.
Patients experience substantially less discomfort.
REPETITION RATE up to 3 Hz
Three shots per second.
POWERFUL COOLING UNIT
Greater flexibility in treatment area critical room temperature
levels, without any loss of performance in the equipment.
RELIABLE AND ROBUST TECHNOLOGY
Decreases maintenance costs and breakdowns risks.
Laser
Milesman Premium
Type
Maximum power (average pulse power)
Diode optical power
Nominal wavelength
Pulse width
Pulse repetition rate
Optical window
Fluence
Beam divergence
Recomended power supply
Voltage, frequency, current
Connection to public main
Classification
Eye risk nominal distance
Protective glasses
Optical density at 790 – 830 nm
Physical parameters
Central unit weight
Central unit size (W x D x H)
Operating radius of umbilical cord
Environmental conditions
Temperature, humidity, pressure
AlGaAs laser diode matrix
1,600 W
2,000 W
810 nm
5 – 400 ms
≤ 3 Hz
0.39 x 0.39 in - 10 x 10 mm
10 – 100 J/cm2
20ºC x 20ºC nominal
Classifications
FDA Classification
CDRH Classification
MDD Classification
Classification according EN 60825-1 norm
Operation Classification
[email protected] • www.milesman.com
FDA approved
Certified according to DIN EN ISO 9001:2000, DIN EN ISO 13485:2003
Medical Device Directive 93/42/EEC, Annex II
Hair Removal Diode Laser
100 – 240 V, 50 – 60 Hz, 12 A
Single phase grounded outlet
164 ft - 50 m
≥5
55.11 Lbs - 25 Kg / 120.64 Lbs - 45 kg
15.7x19.7x14.2 in - 40x50x36 cm
59 in - 1.5 m
60 – 80ºF, 0 - 70%, 13 – 16 psi
15 – 30ºC, 0 – 70%, 90 – 110 kPa
Class II Laser
Class IV Laser
II B
4
INTERMITTENT
