parallel flow standard condensers condensadores

PARALLEL FLOW STANDARD CONDENSERS
CONDENSADORES ESTÁNDAR DE FLUJO PARALELO
MODEL
PART NO.
PASSES
HEIGHT
LENGTH
WIDTH
CONNECTION TYPE
Modelo
Referencia
Pasos
Alto
Largo
Ancho
Tipo de conexión
Tripac
Tripac
Tripac
Tripac
T11003
T11005
T11006
T11054
3
2
2
2
358
309
309
360
608
508
608
608
16
16
16
16
Flange
Flange
Flange
Flange
MODEL
PART NO.
PASSES
HEIGHT
LENGTH
WIDTH
INLET CONNECTION
OUTLET CONNECTION
Modelo
Referencia
Pasos
Alto
Largo
Ancho
Conexión entrada
Conexión salida
Harrison
Harrison
Sanden
Sanden
Sanden
Sanden
Sanden
Sanden
Sanden
T11052
T11057
T11001
T11002
T11050
T11051
T11053
T11056
T11058
3
2
4
4
4
4
4
4
4
358
281
361
361
361
361
312
405
360
608
508
623
703
680
460
540
500
580
16
16
16
16
16
16
25
16
16
1/2"
1/2"
3/8"
1/2"
1/2"
1/2"
1/2"
1/2"
1/2"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
3/8"
PARALLEL FLOW STANDARD CONDENSERS
CONDENSADORES ESTÁNDAR DE FLUJO PARALELO
TRIPAC
Climetal Part No. T11003
Dimensions
358x608x16
Connection
Flange
Passes
3
Climetal Part No. T11005
Dimensions
309x508x16
Connection
Flange
Passes
2
Climetal Part No. T11006
Dimensions
309x608x16
Connection
Flange
Passes
2
Climetal Part No. T11054
Dimensions
360x608x16
Connection
Flange
Passes
2
PARALLEL FLOW STANDARD CONDENSERS
CONDENSADORES ESTÁNDAR DE FLUJO PARALELO
HARRISON
Climetal Part No. T11052
Dimensions
358x608x16
Passes
3
Inlet Connection
1/2"
Outlet Connection 3/8"
Climetal P/N
Core dimensions
Pass arrangement
T11057
281X508X16
2
Inlet connection
Outlet connection
1/2"
3/8"
SANDEN
Climetal Part No. T11001
Dimensions
361x623x16
Passes
4
Inlet Connection
3/8"
Outlet Connection 3/8"
Climetal Part No. T11002
Dimensions
361x703x16
Passes
4
Inlet Connection
1/2"
Outlet Connection 3/8"
Climetal Part No. T11050
Dimensions
361x680x16
Passes
4
Inlet Connection
1/2"
Outlet Connection 3/8"
Climetal Part No. T11051
Dimensions
361x460x16
Passes
4
Inlet Connection
1/2"
Outlet Connection 3/8"
PARALLEL FLOW STANDARD CONDENSERS
CONDENSADORES ESTÁNDAR DE FLUJO PARALELO
SANDEN
Climetal Part No. T11053
Dimensions
312x540x25
Passes
4
Climetal P/N
Core dimensions
Pass arrangement
T11058
360X580X16
4
Inlet Connection
1/2"
Outlet Connection 3/8"
Inlet connection
Outlet connection
1/2"
3/8"
Climetal Part No. T11056
Dimensions
405x500x16
Passes
4
Inlet Connection
1/2"
Outlet Connection 3/8"
