Obsolete Controller Replacements.
Replacements for obsolete controllers • DESCRIPTION DSE have been manufacturing engine and generating set control modules since 1977. During this time, it is inevitable that some parts have become obsolete and are no longer available to purchase. Alongside this is the end user’s desire to update existing panels, replacing the controllers with more modern equivalents, even if the existing module is still available. This document details the most popular DSE controllers both past and present and lists the possibilities of upgrading to modules in the current range of controllers. • ‘OLD’ OR OBSOLETE PRODUCTS Legacy Part Recommended replacement Same Cutout 200 series 300 series 500 DSE705, DSE332, DSE333 501 502 503 DSE701 DSE3110, DSE4110 DSE3110, DSE4110 Notes There is no replacement for individual modules in the 200 series. This was a range of timers, voltage switch relays etc designed to combine to make an entire system. DSE do not manufacture modular systems like this, favouring a ‘combined’ approach where one module replaces a number of 200 series modules. DSE332 can be used with DSE160 self seeking supply if no DC supply is present in the ATS panel DSE333 has volts free auxiliary relays, DSE332 has DC output auxiliary relays. There is no replacement for stand alone annunciator modules. 504 annunciator 506 annunciator 507 annunciator 508 509 DSE no longer manufacture modular systems like this, favouring a ‘combined’ approach where the annunciator is either combined with the engine control module, or is part of a dedicated expansion link, driven by the host controller. DSE4420, DSE6020, DSE6120 DSE4420, DSE6020, DSE6120 DSE no longer manufacture modular systems like this, favouring a ‘combined’ approach where the annunciator is either combined with the engine control module, or is part of a dedicated expansion link, driven by the host controller. 510 annunciator 511 512 520 521 DSE3110,DSE4110, DSE4410 DSE3110, DSE4110, DSE4410 530 ATS controller DSE332, DSE333 540 / 541 expansion annunciator 550 (Basic) (no comms) 550 550 550 550 550 (Basic) (RS232) (Basic) (RS485) (Enhanced) (Autosync) (Load Share) 555 (Basic) (no comms) 555 555 555 555 555 DSE509 is still available but is a mature product, designed in 1994 There is no replacement for stand alone annunciator modules. (Basic) (RS232) (Basic) (RS485) (Enhanced) (Autosync) (Load Share) DSE7210 DSE7310 DSE332 can be used with DSE160 self seeking supply if no DC supply is present in the ATS panel DSE333 has volts free auxiliary relays, DSE332 has DC output auxiliary relays. There is no replacement for stand alone annunciator modules. DSE no longer manufacture modular systems like this, favouring a ‘combined’ approach where the annunciator is either combined with the engine control module, or is part of a dedicated expansion link, driven by the host controller. DSE7310 has more inputs/outputs than the DSE7210 DSE7310 has the possibility to add more inputs/outputs using the DSENET® expansion interface. DSE7310 DSE7310 DSE7510, DSE8610, DSE8710 DSE86xx/DSE87xx cannot operate in the same system as DSE55x, DSE55xx or DSE75xx DSE7220 DSE7320 DSE7320 has more inputs/outputs than the DSE7220 DSE7320 has the possibility to add more inputs/outputs using the DSENET® expansion interface. DSE7320 DSE7320 DSE7520 556 DSE7560, DSE8660, DSE8610 557 DSE7520 056-032 Replacement for obsolete controllers Issue 6 – A.D.Manton DSE86xx/DSE87xx cannot operate in the same system as DSE55x, DSE55xx or DSE75xx Recommended replacement Legacy Part 560 DSE4410, DSE6010, DSE6110, DSE7110, DSE7210 601D DSE4420, DSE6020, DSE6120, DSE7120, DSE7220 602D 602DS DSE4410, DSE6110, DSE7120, DSE7210, DSE7310 603 DSE7220 DSE7320 702 DSE7210 DSE7310 DSE3110 606 DSE7320 607 DSE7310 701 5103/5 12V charger 5103/5 24V charger 5110 12V charger 5110 24V charger DSE3110 DSE9130 DSE9255 DSE9140 DSE9260 604 • Same cutout? Notes DSE44x0 has DSE60x0 has DSE61x0 has DSE71x0 has DSE72x0 has no current measurement. current measurement without protection current measurement with delayed overcurrent current measurement with delayed overcurrent current measurement with full IDMT alarm DSE7310 has more inputs/outputs than the DSE7210 DSE7310 has the possibility to add more inputs/outputs using the DSENET® expansion interface. DSE7320 has more inputs/outputs than the DSE7220 DSE7320 has the possibility to add more inputs/outputs using the DSENET® expansion interface. DSE7310 has more inputs/outputs than the DSE7210 DSE7310 has the possibility to add more inputs/outputs using the DSENET® expansion interface. DSE3110 is not a keystart module, operation is by push buttons Depending upon the number of inputs and outputs being used in the 606, the new system may require more than provided on the DSE7320. In this instance, you can use the DSE2130 to provide more inputs and DSE2157 to provide more outputs. Depending upon the number of inputs and outputs being used in the 607, the new system may require more than provided on the DSE7310. In this instance, you can use the DSE2130 to provide more inputs and DSE2157 to provide more outputs. DSE3110 is not a keystart module, operation is by push buttons The new chargers are smaller and lighter, with integral mounting holes and din rail attachment. 12V 5A charger 12V 5A charger 12V 10A charger 24V 10A charger The new chargers are smaller and lighter, with integral mounting holes. CURRENT CONTROLLERS The controllers listed below are current controllers included here to give the option to update them to more recent designs of controllers, often with more functions. Legacy Part DSE710 DSE720 DSE5110 DSE5120 Recommended replacement Same cutout? DSE6010, DSE6110 DSE6020, DSE6120 DSE7110, DSE7210 DSE7120, DSE7220 DSE7210 DSE7310 DSE7310 DSE7320 DSE7510, DSE8610 DSE7520 DSE7560, DSE8760 DSE8610, DSE8710 DSE5210 DSE5310 DSE5320 DSE5510 DSE5520 DSE5560 DSE7510 • Notes Use DSE7310 if your existing system uses the RS232 / RS485 port on the DSE5210. This is not present on the DSE7210. DSE86xx/DSE87xx cannot operate in the same system as DSE55x, DSE55xx or DSE75xx DSE86xx/DSE87xx cannot operate in the same system as DSE55x, DSE55xx or DSE75xx DSE86xx/DSE87xx cannot operate in the same system as DSE55x, DSE55xx or DSE75xx RECOMMENDED DOCUMENTS The following documents are listed to aid your identification of DSE products and ease the conversion from one module to another. They are available on the DSE website www.deepseaplc.com . Click the DSE DOWNLOADS button, they are listed under DSE Guides | Training Documents DSE Part Description 056-006 056-008 056-017 056-024 056-031 Introduction to Communications DSE Part Numbering – Description of how the DSE part numbers are derived PC Configuration interfacing – Lists the different configuration possibilities of DSE controllers GSM modem – Details the possibilities when using a GSM modem with DSE products 5510 / 5520 to 7520 / 7520 conversion – Helps when converting a system from 5500 to 7500 series 056-032 Replacement for obsolete controllers Issue 6 – A.D.Manton
