Table of Contents
Warnings........................................................................................................................................................................... 2
Standard Accessories................................................................................................................................................... 2
Product Layout............................................................................................................................................................... 2
Indicator Status.............................................................................................................................................................. 3
Operation.......................................................................................................................................................................... 3
Connecting the Bluetooth Speakers to a Bluetooth device.....................................................................3
Connecting to a Notebook PC via Bluetooth................................................................................................. 3
Answer/Reject incoming call............................................................................................................................... 4
Playing music via AUX-in...................................................................................................................................... 4
Enhanced mode........................................................................................................................................................ 4
NFC power on/pairing........................................................................................................................................... 4
Pairing your speaker with two playback devices.........................................................................................4
Troubleshooting............................................................................................................................................................. 5
Product Specifications................................................................................................................................................. 6
1
Thank you for purchasing the Kogan Active Bluetooth 4.0 Portable Speaker. Please take the
time to read the instructions in this instruction manual carefully. If you have any problems or
questions, please contact the Kogan.com customer support team.
Warnings
•
•
•
•
•
To reduce the risk of electric shock or fire, ensure your electrical
circuits are not overloaded.
To reduce the risk of electric shock, do not touch the plug with wet
hands.
Unplug the power cable if the speaker starts smoking or acting
abnormally. Contact the Kogan.com customer support team for
further information.
To reduce the risk of electric shock or fire, do not expose the speaker
to rain or moisture. Liquids can cause product failure and/or create a
fire hazard.
Do not place any naked flame sources such as lit candles on or near
the speaker.
Standard Accessories
Bluetooth Speaker
3.5mm Audio Cable
MicroUSB Charging Cable
Product Layout
1. Power ON/OFF
2. Micro USB port for connecting to DC 5V USB cables to charge the Bluetooth speaker.
Please take note that a power adapter is not a standard accessory to this speaker. You
can use your mobile phone adaptor to charge the speaker or connect to the USB port of
your PC or power bank to charge the speaker. The voltage is limited to 5V.
3. Hand strap attached for easier portability.
4. AUX-in jack. Connect the speaker to your PC/MP3 Player/Media Device/Tablet/Mobile or
2
5.
6.
7.
8.
9.
10.
any other playback devices with 3.5mm audio out jacks via the audio cable. Once
plugged in, the Bluetooth speaker will disconnect from any connected Bluetooth devices
automatically.
Volume Down – In Bluetooth mode and Aux in mode, hold down to decrease volume.
Volume Up – In Bluetooth mode and Aux in mode, hold down to increase volume.
Bluetooth disconnect button and Answer/Reject Call/Play/Pause button. In Bluetooth
mode, press and hold for 3 seconds to disconnect the Bluetooth. In Bluetooth mode, if
there is an incoming call, press quickly to answer the call, or hold down for 3 seconds to
reject the call. When playing music, pressing this button will pause and resume music.
LED indicator.
NFC area. Tap here to power on/pair your Bluetooth speaker.
Enhanced Mode: Press the volume up and volume down button simultaneously to enter
into enhanced mode while playing music. Press the two buttons simultaneously to
resume default mode.
Indicator Status
Indicator Colour & Action
Speaker Working Status
Blue indicator flashing
Waiting for connection
Green indicator remains on steadily
Connected to aux-in device
Blue indicator remains on steadily
Connected to a Bluetooth device
Lower power indicator flashing
Battery voltage lower than 3.3v. Red light flashing
means your speaker needs to be charged.
Red charging indicator lit
Red light on means the battery is being charged.
Once the battery is fully charged, this red indicator
light will go out.
Operation
Connecting the Bluetooth Speakers to a Bluetooth device
1. Be sure the speaker battery has enough power.
2. Turn on the speaker. It will automatically go into Bluetooth mode, ready for connecting.
The blue indicator will flash.
3. Open the Bluetooth menu on your device, then search for “U910” and connect to it. You
won't normally need to input the password for most devices, however depending on the
Bluetooth version, you may need to put in the password “0000” to connect.
4. Blue light remaining on steadily means the units are successfully paired.
5. Run the music player on your mobile device and enjoy the loud and clear sound from
your Kogan.com Bluetooth speakers.
Connecting to a Notebook PC via Bluetooth
If your notebook doesn't have native Bluetooth functionality, please buy a Bluetooth adaptor.
Install the Bluetooth adaptor and follow the instructions for your device to get the adaptor
working.
1. Start the Notebook, then search for the Bluetooth device by “Start → Setting → Control
Panel”
2. Start the Bluetooth searching function of your notebook. The blue light will flash when
searching for audio-in devices.
3. The Blue indicator will remain on once you are connected successfully.
4. You can then play the audio from your Notebook via the Bluetooth speakers.
3
Answer/Reject incoming call
1.
Quickly press the play/pause button to answer the call, then press it again to hang up
after answering.
2. Press and hold the play/pause button for 3 seconds to reject the call.
Playing music via AUX-in
The Kogan Bluetooth speaker comes with a standard 3.5mm Aux in jack for connecting with
other non-Bluetooth audio devices (e.g. mobile phones, MP3 players, tablets etc...)
1. Plug one end of the audio cable into the AUX in jack of the speaker, then plug the other
end into the audio source AUX jack. The green indicator will then remain on steadily.
2. Your speaker will disconnect the Bluetooth connection and will automatically switch to
external source play.
Enhanced mode
Enhanced mode is designed for a premium level of sound intensity and bass.
1. Make sure the speaker is on and working properly.
2. Press the volume up and volume down buttons simultaneously to enter into enhanced
mode. The blue indicator will flash to indicate successful operation.
3. Press the two buttons simultaneously to resume default mode.
NFC power on/pairing
Make sure your mobile phone has NFC functionality.
1. Start the NFC from the settings of your phone.
2. Tap your mobile phone on the NFC area of the speaker. The speaker will power on
automatically and the indicator will flash.
3. Five seconds later, tap your mobile phone to the NFC area again to activate NFC pairing.
When your mobile phone asks “Pairing with Bluetooth?”, select 'Yes'.
4. Your mobile phone will now be connected and you can play wireless music.
5. Tap your mobile phone to the NFC area again to disconnect the Bluetooth.
Pairing your speaker with two playback devices
Your speaker can support two playback devices at the same time.
1. Follow step one of how to pair your Bluetooth device (to be known as playback device 1)
to the speaker.
2. Press and hold the play/pause button for two seconds to disconnect the Bluetooth
connection. The speaker will memorize the mac address playback device 1.
3. Follow step one of how to pair your Bluetooth device (to be known as playback device 2)
to your speaker.
4. Then pair playback device 1 again. You can now play music via two playback devices.
Please note: only one device can play audio at a time. You cannot send music from both devices
to the speaker at once. You will need to pause one player if you want to play music from the
other.
Notes
Your speaker will power off automatically within 15 minutes if you do not pair any devices with it
to save power. You will need to power the speaker on again to use it.
If your speaker has paired with over 8 devices, there will be 2 or more seconds delay for
scanning and pairing with new playback devices. This is due to your speaker needing to scan the
previously paired devices first to repair with them automatically.
Simply hold the previous track and next track buttons down together for 3 seconds to clean all
of the devices stored in memory and resume default settings.
4
Troubleshooting
Problem
Solution
Speaker will not turn on.
•
Make sure the battery has sufficient power.
Paired Bluetooth device will not connect
•
If your device requires a passcode, make sure to
input '0000'
Turn the Bluetooth speaker off and on again.
Remove the speaker from the pairing list on your
Bluetooth device, then pair the device and the
speaker again.
•
•
Speaker indicates a connection but will not play music
•
•
Cannot pair the Bluetooth speakers with my Bluetooth
enabled device
•
•
•
•
No audio from a Bluetooth device
•
•
•
•
Poor sound quality from a Bluetooth device
•
•
•
•
•
No audio from AUX source
•
•
•
•
Poor sound quality from AUX source
•
•
•
5
Turn off or disable Bluetooth on all other paired
devices nearby, then reconnect the device you
want to play from.
Turn the Bluetooth speaker off and on again.
Make sure your Bluetooth speakers are
discoverable.
Your Bluetooth device may be out of range. Try
to move it closer to your Bluetooth speakers.
Make sure your Bluetooth device supports the
transfer of audio.
Reset your Bluetooth speaker.
Make sure your Bluetooth speakers are not muted
and the volume is up.
Make sure your Bluetooth device is playing music
and has the volume up.
Your Bluetooth device might be out of range.
Turn the Bluetooth speakers off and on again.
Your Bluetooth device might be out of range.
Move the Bluetooth speakers and device away
from any devices that generate electromagnetic
interference such as another Bluetooth device,
cordless phone, microwave oven or a wireless
router.
Try turning off Wi-Fi to improve audio quality.
Make sure the music file itself isn't poor quality.
Turn the Bluetooth speaker off and on again.
Make sure your connected device is on and
playing.
Make sure your speaker is in AUX-in mode.
Make sure the audio cable is correctly inserted.
Increase the volume level on the device and
speaker.
Reduce the volume level on the AUX source.
Make sure the 3.5mm audio cable is fully inserted
into both the speaker and the device.
Make sure your audio source and music file is not
of poor quality.
Product Specifications
Product
Channel
2.0 Channel Stereo
Amplifier
Digital Amplifier
Driver
Full range 40mm 4ohm x 5W x 2
Size
151 x 65 x 66mm
Weight
480g
Technical Parameters
Bluetooth Chipset
CSR
Bluetooth Version
V4.0
Supported Protocol & Profile
A2DP, AVRCP, HFE, HFP
Battery
1400mAh PLB
Charging Voltage Limitation
5V
AAC (Advanced Audio Coding)
Supported
Playback Time
Approx 6 hours
Frequency Response
90Hz ~ 20KHz
Working Temperature
-10C ~ 50C
AUX-in Jack
3.5mm
Please contact the Kogan.com customer support team if you have any further questions
regarding the use of this product.
