6 FEB 15 CHART CHANGE NOTICES AFRHI-1 AFR HIGH ALTITUDE SUP q$i Jeppesen CHART CHANGE NOTICES highlight only significant changes affecting Jeppesen Charts, also regularly updated at www.jeppesen.com. IMPORTANT: CHECK FOR NOTAMS AND OTHER PERTINENT INFORMATION PRIOR TO FLIGHT. ENROUTE CHARTS NIGERIA GENERAL ATS ROUTES changed: UA609, IKROP (N0546.7 E00852.5) via Okitipupa NDB (OK), Lagos VORDME (LAG) to POLTO, chgd to one-way W-bound. A HI-2/3. UJ333 estbld; CRP Lagos VORDME (LAG) - CRP VOPAP at N0653.6 E00424.0, 083°, 65NM; VOPAP - CRP LIMID at N0649.5 E00456.7 - CRP INUTA at N0642.8 E00549.5, 101°, 33/53NM; INUTA - CRP LIGEK at N0633.1 E00703.9 - CRP Enugu VORDME (ENG), 100°/(280°), 75/32NM; Enugu VORDME - CRP MOKLA at N0617.8 E00834.8, 104°, 60NM; MOKLA CRP IKROP, 153°, 36NM; Lagos VORDME via Enugu VORDME to IKROP, MEA FL250, one-way SE-bound. A HI-2/3, A HI-3/7. UJ707 estbld; CRP Enugu VORDME (ENG) CRP NANUV at N0815.5 E00735.6, 003°, 106NM; NANUV - CRP Abuja VORDME (ABC), 342°/(162°), 50NM; Enugu VORDME to Abuja VORDME, MEA FL250, one-way N-bound. A HI-2/3,4. UW951 estbld; CRP DESIX (N0744.5 E00425.4) CRP TUSIB at N0833.2 E00553.0 - CRP MESES at N0852.4 E00628.0 - CRP EDEKO, 064°, 100/40/58NM, MEA FL250, one-way NE-bound. A HI-2/4. MALI GAT (General Air Traffic) IFR flights are authorized to use the following awys within the GA(P)- Area related to SERVAL operation in Mali Airspace; UA603 between GAO (N1614.0 W00001.7) and the intersection on Mali/Burkina Faso boundary at N1500.0 E00000.0; UA612, GAO (N1614.0 W00001.7) - RIPUL; UA614, IPOBA (N2228.6 W00102.9) - VOLBU; UB727, SEPAT (N1412.5 W00600.5) - TERAS; UB735, USRUT (N2339.4 W00243.3) and the Int on Mali/Mauritania boundary at N1726.8 W00542.7; UG615, Mopti VOR (MTI) - LITIL; UG855 between INAMA (N1908.0 E00410.0) and the Int on the Mali/Niger boundary at N1521.0 E00250.8; UG859 between MOKAT and the Int on the Mali/ Burkina Faso boundary at N1505.0 W00027.8; UM114 between ZAWAT (N1900.2 E00332.9) and the Int on the Mali/Niger boundary at N1522.0 E00329.0; UM608 betweenTERAS (N2044.3 E00149.5) and the Int on the Mali/Niger boundary at N1520.0 E00205.8; UM629, USRUT (N2339.4 W00243.3) - EBVAP; UM725, SBITA (N2505.6 W00500.1) - TISEN; UM974, KOSIL (N1438.4 W00700.0) - VOLBU; UQ596, UNAGA (N2024.2 W00612.9) - IPOBA; UR866, AMSEN (N2200.0 W00607.0) - VOLBU; UR981, TISEN (N2411.1 W00609.3) - DERON; UT365, DERON (N1527.1 E00037.1) - UNAGA; All Airways MEA FL320, MAA FL400. CCN 305. PROHIBITED AREA estbld within Dakar FIR/UIR and Niamey FIR/UIR. For details refer to CCN 305. A HI-1/5, A HI-2/5to7. DAKAR OCEANIC FIR-UIR CRP LIROL estbld at N0620.7 W02258.5. A HI-1/6. MALI ATS ROUTES changed: GAO VOR (GAO) decmsnd and replaced by CRP GAO at N1614.3 W00001.6. CCN 305. TESSALIT VOR (TSL) decmsnd and replaced by CRP TESSALIT [TESLT] at N2015.0 E00058.9. CCN 305. KADUNA VOR (KU) ident chgd to ’KUA’. A HI-2/4. SAUDI ARABIA ATS ROUTES changed: B412, PATOL (N2543.6 E03914.1) chgd to CRP. A HI-7/2. B544, Abha VORTAC (ABH) to NOBSU, chgd to one-way SE-bound, until 30 Aug 15. A HI-7/3,4. M449, GIBET (N2926.3 E03625.0) via Tabuk VORTAC (TBK) to Wejh VORTAC (WEJ), MEA FL160. A HI-7/1. M628, Dafinah VORDME (DFN) to AMBAG, MEA FL160. A HI-7/2,3. UL564, Batha VORDME (BAT) - SOMAL, MEA FL260; MIGMA via Sharurah VORTAC (SHA) to NADKI realigned; MIGMA to ULBON, MEA FL260, for other route details see former UT300. A HI-7/3,4. UM628, Dafinah VORDME (DFN) to AMBAG, MEA FL160. A HI-7/2,3. UT300, MIGMA (N2250.6 E05127.8) to ULBON, withdrawn. A HI-7/3,4. SEYCHELLES SEYCHELLES TMA chgd; circle with radius 50NM centered on S0440.5 E05531.3, upper limit FL105. A HI-8/2,3. MALTA NCRP INPEX estbld at N3537.5 E01514.4. A HI-3/2. q$z Please Visit Jeppesen’s Web Site: www.jeppesen.com © JEPPESEN, 2015. ALL RIGHTS RESERVED. AFRHI-2 CHART CHANGE NOTICES 6 FEB 15 AFR HIGH ALTITUDE SUP q$i SOUTH AFRICAN REP ATS ROUTES changed: UW62, Mazenod VORDME (MZV) to Mthatha VORDME (MHV), withdrawn. A HI-4/7,8, A HI-6/7. SUDAN ATS ROUTES changed: UG660, EL GENEINA [EGENA] (N1329.0 E02227.8) renamed GENEI. A HI-3/6, A HI-5/5 (to-note). TANZANIA ATS ROUTES changed: UG450, IBGEN (S0229.4 E03243.3) chgd to CRP. A HI-5/8, A HI-6/1,2. UG656, IBGEN (S0229.4 E03243.3) chgd to CRP. A HI-5/8, A HI-6/1,2. YEMEN ATS ROUTES changed: UL564, NADKI replaced by CRP ULBON at N1714.4 E04615.2; RAGNI - ULBON, 031°/211°, 47NM, MEA FL280. A HI-7/4. ZIMBABWE ATS ROUTES changed: UB540, NavData identifier [VLI07] (S1755.1 E02547.8) renamed [VLI06]; [VLI06] - Livingstone VORDME (VLI) chgd to NON-standard cruising levels, EVEN levels N-bound. A HI-4/4,5, A HI-6/4. q$z Please Visit Jeppesen’s Web Site: www.jeppesen.com © JEPPESEN, 2015. ALL RIGHTS RESERVED.
