Keysight/VDI
MCK Material Characteriza.on Kit Real .me access to mm-‐wave and THz dielectric proper.es Ver. February 2015 SWISSto12 SA Innova.on Park EPFL CH-‐1015 Lausanne Switzerland www.swissto12.ch [email protected] Material Characteriza.on Kit • Fast • Calibrated • Simplified Set up • From WR15+ (47-‐77 GHz) up to WM250 (750-‐1100 GHz) • No Sample prepara.on • SoVware supplied for data Analysis E.g.: Schoc Borofloat 33 measured in the WM380 band (500-‐750 GHz) Mag eps’ 4.8 -‐8 4.6 [dB] -‐10 4.4 -‐12 4.2 -‐14 tanδ 0.05 Phase [deg] 150 50 0.04 -‐50 0.03 -‐150 500 550 600 650 700 750 frequency [GHz] In Collabora.on with Keysight 500 550 600 650 700 750 frequency [GHz]
